2. New MSP Concealed Ceiling Unit (FBQ-D & FXSQ-A)
New Concealed Floor Standing Unit (FNQ-A & FXNQ)
New Siesta SkyAir Cassette
New Mini VRVs
VRV IV S-Series Mini VRV Compact
VRV IV S-Series Standard Mini VRV
Extended control possibilities of AHU applications

3. 01
New MSP Duct Unit
FBQ-D & FXSQ-A
Title - Internal use only

4. The new MSP Duct Unit
FBQ-D / FXSQ-A
Optimum comfort guaranteed no matter the length of ductwork or type of grills!
Improved efficiency
Improved dimensions
Improved sound level
Improved external static pressure
Automatic air flow adjustment function measures the air volume
and static pressure and adjusts it towards the nominal air flow,
whatever the length of duct, making installation easier and
guaranteeing comfort. Moreover, the ESP can be changed via the
wired remote control to optimize the supply air volume
Main features and benefits
Height reduction 300mm -> 245mm
Reduced height resulting in one of the slimmest Medium Static Pressure units within the market
Inverter driven fan giving a great flexibility to set the required ESP curve or to automatically select the correct fan curve, assuring comfort at all times.
Increased external static pressure up to 150 Pa
Top efficiency, highest Energy label ranking in the market (SkyAir)
Additional 15 class model dedicated for small surface areas which require extended ESP (VRV).
Title - Internal use only

5. The new MSP Duct Unit Launch: April 2015 FBQ-D / FXSQ-A
Capacity class 15 20 25 35 50 60 71
100
125
140
200
250
FBQ-D
Cooling capacity [kW]
1.7
2.2
2.8
3.5
5.0
5.7
7.1
9.5
12.0
13.4
20.0
25.0
Heating capacity [kW]
1.9
2.5
3.2
4.0
5.5
7.0
7.5
10.8
13.5
15.5
23.0
28.0
Capacity class 15 20 25 32 40 50 63 80
100
125
140
200
FXSQ-A
Cooling capacity [kW]
1.7
2.2
2.8
3.6
4.5
5.6
7.1
9.0
11.2
14.0
16.0
20.0
Heating capacity [kW]
1.9
2.5
3.2
4.0
5.0
6.3
8.0
10.0
18.0
23.0
15 class unit especially developed for small or well-insulated
rooms, such as hotel bedrooms, small offices, etc.
Title - Internal use only

6. The new Concealed Ceiling Unit (MSP)
FBQ-D / FXSQ-A
A++ /A+
top efficiency label in the market!
Slimmest unit in the market! (only 245 mm)
Improved ESP!
TOP in the market!
Improved Sound Level!
One of the most quite units in the market!
Title - Internal use only

7. New Concealed Floor Standing Unit02
New Concealed Floor Standing Unit
FNQ-A & FXNQ-A
Title - Internal use only

8. The new Concealed Floor Standing Unit
FNQ-A / FXNQ-A
Slimmest unit in the market: fits in even into smaller installation spaces
Ideal for building into window-sils/furniture/walls
Improved ESP allows flexible installation & increased application coverage
Improved sound level
Ideal unit for installation in offices, hotel and residential applications. Blends unobtrusively with any interior décor: only the suction and discharge grilles are visible.
Title - Internal use only

9. The new Concealed Floor Standing Unit
FNQ-A / FXNQ-A
Launch Date: June 2015
Capacity class 15 20 25 35 42 50 60 71
100
125
140
200
250
FNQ-A (+ RXS-L)
Cooling capacity [kW]
1.5
2.0
2.4
3.4
4.2
5.0
6.0
7.1
10.0
12.5
14.0
20.0
25.0
Heating capacity [kW]
1.7
2.5
3.2
4.0
5.4
5.8
7.0
8.2
11.2
16.0
23.0
28.0
Capacity class 15 20 25 32 40 50 63 71 80
100
125
140
200
FXNQ-A
Cooling capacity [kW]
1.5
2.2
2.8
3.6
4.5
5.6
7.1
8.0
9.0
11.2
14.0
16.0
22.4
Heating capacity [kW]
1.7
2.5
3.2
4.0
5.0
6.3
10.0
12.5
18.0
25.0
Title - Internal use only

10. Improved Siesta SkyAir Cassette03
Improved Siesta SkyAir Cassette
ACQ-D
Title - Internal use only

11. New Siesta SkyAir Cassette
ACQ-D
Improved outlook & design
Improved outlook of decoration panel (rougher surface)
Improved cassette body quality
Smoother metal edges
More sturdy drain pan
Improved knock out holes
Improved hinge location  Easier installation!
(New decoration panel: ADP125B, combineable with both ACQ*C and ACQ*D)
Title - Internal use only

12. New Siesta SkyAir Cassette
ACQ-D
Launch Date: January 2015
Capacity class 15 20 25 35 42 50 60 71
100
125
140
200
250
ACQ-D
Cooling capacity [kW]
1.5
2.0
2.4
3.4
4.2
5.0
6.0
7.1
10.0
12.5
14.0
20.0
25.0
Heating capacity [kW]
1.7
2.5
3.2
4.0
5.4
5.8
7.0
8.2
11.2
16.0
23.0
28.0
Title - Internal use only

13. New Siesta SkyAir Cassette
ACQ-D
Improvements on the technical specificiations
Improved efficiency
Piping improvements
Max. OU-IU level difference on size 71 increased to 30m up from 15m
Max. OU-IU piping length on size 71 increased to 50m up from 30m
Title - Internal use only

14. 04 VRV IV S-Series Mini VRV & Mini VRV Compact RXYSQ-T & RXYSCQ-T
Title - Internal use only

15. VRV IV S-Series Mini VRV & Mini VRV Compact
RXYSQ-T & RXYSCQ-T
Compact Mini VRV (RXYSCQ-T)
New compact & lightweight Mini VRV unit!
System for large residential & light commercial applications
Provides climate control for up to 9 indoors
Mini VRV IV (RXYSQ-T)
Current Mini VRV range will be upgraded with VRV IV technology  (VRT)
Increased nominal & seasonal effciency
Extended range! Large Mini VRV IV units (8 – 10 – 12 HP) – (3phase only)
82,3 cm
Specifications
RXYSQ-T
RXYSCQ-T
Capacity
4/5/6 HP
4/5 HP (1ph only)
HxWxD (mm)
1345x900x320
823x940x460
Weight (kg)
120 88
Shortest VRV unit in the market!
4HP
5HP
6HP
8HP
10HP
12HP
Sales Launch:
Autumn 2015
Mid of 2015
Title - Internal use only

16. 05 Extended control possibilities of AHU applications
New Control Box & Expansion Valve
Title - Internal use only

17. Extended control possibilities of AHU applications
New Control Box & Expansion Valve
New Expansion Valves
New Control Boxes
Control Boxes
Control Type
EKEXV400/500 Connection
EKEQMCB
X-Control & Y-Control NO
EKEQFCB
EKEQMCBA
X-Control & Y-Control & W-Control
YES
EKEQFCBA
With the new EKEXV400/500 expansion valves and the new EKEQFCBA control box, it is now possible to construct systems of up to 54 HP (150 kW nominal cooling capacity) as condensing units for AHU applications.
All the products except EKEQFCB are available from now onwards.
Title - Internal use only

18. Extended control possibilities of AHU applications on VRV
Benefits of the W-Control
The new W-Control divides the 0-10V input signal range into 5 capacity steps. Each capacity step corresponds to a certain evaporation / condensation temperature.
System maintains this certain temperature by adjusting the refrigerant temperature
Compressors are automatically regulated according to the Te or Tc  no fixation of the compressor frequency.
W-Control has better reliability and more stable discharge air temperature (adjusts refr. temperature rather than the compressor frequency)
Comparison with the X-Control
X-Control requires custom programming of a PLC controller
X-Control is more precise when programmed well
X-Control is capable of reaching lower minimum capacities
W-Control is simpler to implement
The control logic allows to use commercial off-the-shelf DDC controllers without the need of reprogramming.
Title - Internal use only
