1. Leading Integration Solutions Provider Turn-key solution for Wireless / Wire-Line ISP and Telephony class 5 systems

2. Navigation Menu Company Profile WISP Turn-key Solution WISP Components Overview Performance Chart Network Layout NOC Resources Screen-shots

3. Quality Assurance Functionality, Networking... System Integration 3Com Israel, Tadiran Electronics, Harel Computers, InspiAir, Netcom, IBM, Expand Networks,Binat... VoIP Telephony Fionetic, Malibu... Research and Development ECI, Emblaze-VCON, Resolute Networks, Outsourcing Go Networks, Marvell, 012, Hot, Cellcom, RADLAN, Resolute Networks, SDS, Scopus... Company Profile

4. Remote-Access Cloud PPTP and L2TP VPNs, Captive Portal, IPSec VPNs and PPPoE Core Applications DHCP Servers, RADIUS AAA, Transparent Proxy, NMS, Media Proxy, Media GW,Bandwidth Management, QOS, Video Streaming Customer Care Billing and Provisioning, ERP and CRM Systems Security and Assessment IDS, SPI Firewalls, Layer-7 Firewalls, Monitoring tools, Attacks Assessment DRP – Disaster Recovery Plan Delta backup strategy, Risk Assessment, Identifying Threats, Emergency Response WISP Package

5. Up-to 3000 Users Servers Requirements: 1x VPN Server 1x DHCP and Captive Portal 1x Billing and Database 1x RADIUS 1x IDS and Security 1x Transparent Proxy Up-to 15000 Users Additional Servers: 2x VPN Server 1x Billing and Database 1x RADIUS Up-to 100000 Users (and more) 5x VPN Server Note: The reference is only for 'core' servers and not including extra value servers which are still part of the complete WISP setup. WISP Package Performance Chart

6. WISP Package Network Layout NMS Soft Switch Media GW RADIUS Firewall Media Proxy DHCP Billing and Database DSL/Cable Fixed Wireless Firewall Bandwidth Management Transparent Proxy Internet Link IDS User Access Captive Portal VPN

7. The Network Operation Centre provides centralize monitoring over networking resources. Real-time graphs, tables and on-screen information about the network behaviour gives the technical staff the ability to conclude and make decisions on how to properly diagnose networking issues and to treat them. The NOC software can monitor network services by ports or reachable servers in general, host resources like processors load, memory and temperature. Defining network hierarchy and hosts dependency. Contact notifications via email, sms, phone, etc and escalation groups. Support for redundant and distributed monitoring servers. Ticketing system to acknowledge problems via web interface. WISP Package NOC Resources

8. WISP Package Screen-shots MRTG – Multi Router Traffic Grapher

9. WISP Package Screenshots NMS – Network Management System

10. WISP Package Screenshots NMS – Network Management System

11. WISP Package Screenshots RADIUS Management

12. WISP Package Screenshots RADIUS Management

13. WISP Package Screenshots RADIUS Management

14. WISP Package Screenshots Servers racks

15. WISP Package Screenshots Servers racks

16. WISP Package Screenshots Servers racks

17. WISP Package Screenshots Servers racks

18. WISP Package Screenshots NOC Room
