2 What is nLight? nLight is a revolutionary digital architecture and networking technology that cost-effectively integrates time-based, daylight-based, sensor-based and manual lighting controls.

3

4 How does nLight work? nLight networks together intelligent digital devices including occupancy sensors, photocells, power packs, wall switches, dimmers, panels, and even luminaires; creating a system with an unmatched level of “distributed intelligence”

5

6 What is Distributed Intelligence? Digitally Addressable Locally makes switching & dimming control decisions Self-Commissioning Stand-alone Operation

7 nLight Enabled Devices

8 nLight-enabled Device  Model numbers start with the letter “n”  2 RJ-45 Ports  All devices consist of one or more of basic lighting control components o sensor o relay o manual control station o dimmer

9 nLight-enabled Device Model Number Lighting Control Components Sensor Relay Manual Control Station Dimmer OccupancyPhotocell nCM 9 nCM PC nPP16 nPODM nIO RT LED Basic Devices = 1 component

10 nLight-enabled Device Model Number Lighting Control Components Sensor Relay Manual Control Station Dimmer OccupancyPhotocell nCMR 9 nCMR 9 P nCMR 9 ADC nSP5 D nPODMR nPODMR D nWSD Advanced Devices = 2 or more components

11 nLight Control Zone

12  Zones are daisy-chain wired (in any order)  May have a single device  May have several different device types  May have multiple devices of the same type  Can be sub-divided into 16 channels of occupancy, photocell, and switch control  Functions stand-alone if disconnected from Gateway/SensorView

13

14 Occupancy Sensors  PIR or Dual Technology 2  Powered over CAT-5, therefore units have no neutral wire  If present, 1 or both relays can be used as a dry contact closures  Sensors that switch two phase power (208/480) also available  Remotely configurable and upgradeable  Integrated RJ45 connectors EnclosureLenses # of Relays # of Time Delays Options Photocell 0-10 VDC Dimming 1 Ceiling Mount Standard Range Extended Range High Bay 360° High Bay Aisleway 0, 1, 21, 2Yes Recessed Mount Fixture Mount Corner/Wall Wide View / Hallway _ 1YesNo Wall SwitchWall to Wall0, 1, 21, 2YesNo Embedded MountMicro 360°01YesCtrl only 1 Dimming not available with 2 pole or 208/480 devices 2 Dual Technology not available on High Bay or Hallway sensors

15 nLight Embedded Sensor (also called the micro) Provides all in one nLight sensing/photocell solution for embedding in Acuity luminaires (ie Peerless pendants) Only embedded dual tech sensor on market Single RJ-45 port typically connects to any nLight relay/dimming pack (mounted either internal or external to luminaire) CAT-5 splitter provided Model #Description nES 7PIR nES PDT 7PIR / Microphonics nES 7 ADCX PIR + Dimming Ctrl Photocell nES PDT ADCX PIR / Microphonics + Dimming Ctrl Photocell nES ADCXDimming Ctrl Photocell

16

17 Photocell Sensors  Automatic set-point programming mode  Device provides light level in foot-candles  Powered over CAT-5, therefore units have no neutral wire  1 or both relays can be used as a dry contact closures  Sensors that switch two phase power (208/480) also available  Remotely configurable and upgradeable  Integrated RJ45 connector(s) EnclosureControl Type# of Relays # of Dimming Outputs Ceiling Mount On/Off On/Off/Dimming 0, 1, 2 Recessed Mount Fixture Mount Embedded Mount On/Off/Dimming00

18

19 Relay Packs (Switching Only) & Power Supplies  Integrated RJ45 connectors, push-button, and LED  All relays are latching  Reversible relay logic Description Model # Load Rating (Amps) Supplies Network Power # of Relays Power Monitoring Option (IM) Power Pack nPP16 (SA)16Yes1 Secondary Pack nSP16 (SA)16No1 Embedded Pack nEPP5 (KO)5Yes1 480/240/208 VAC Pack nSP5 4805No1 2-Pole Secondary Pack nSP5 2P5No2 Low Voltage Auxiliary Pack nAR401No1 UL924 Emergency Pack nPP16 ER16Yes1No Power Supply nPS 80-Yes-No Embedded Power Supply nEPS 60 (KO)-Yes-No Louver Control Pack nSP5 2P LVR-No- Shade Control Pack nSHADE-No-

20 Relay / Dimming Packs  Integrated RJ45 connectors, push-button, and LED  Reversible relay logic  All relays are latching Description Model # Load Rating (Amps) Supplies Network Power # of Relays # of Dimming Outputs 0-10 VDC Embedded Pack (current monitoring option available) nEPP5 D (KO)5Yes VDC Dimming Pack nSP5 D5No11 UL924 Dimming Pack nSP5 D ER KIT5No11 2-Wire Phase Dimming Pack nSP5 PCD 2W5No11 3-Wire Phase Dimming Pack nSP5 PCD 3W5No11 MLV Dimming Pack nSP5 PCD MLV5No11 ELV Dimming Pack (120V) nSP5 PCD ELV5No11

21 Key Features: nLight-enabled control board Utilizes 4 LC&D snap link relays One 0-10 VDC dimming output per relay Integrated power supply provides both bus & auxiliary device power Operates as two devices (each with two relay/dimming outputs), that can be utilized together in a single zone or in separate zone. Electrical Specs: Relay Load (all relays normally closed latching) VAC Tungsten VAC Ballast VAC Ballast Dimming Load Each 0-10 VDC Dimming outputs can sink < 20 mA (~40 ballasts) Power Supply (120/277 VAC) Bus Power: 40 mA from each RJ-45 port Auxiliary Device Power: 200mA nPanel 4

22 nIO - Universal Input/Output Device Model #Input DescriptionOutput Description nIO0-10 VDC Input, Contact Closure 0-10 VDC  Provides an addressable 0-10 VDC dimming output for standard dimming ballasts (non-DALI)  Enables simple incremental addition of dimming zones  Interfaces 0-10 VDC dimming control signal from any non-nLight device  Interfaces a toggle or momentary contact closure input into system  Available as an inline wired device or in the power pack housing

23

24 Push-Button WallPods – Low Voltage Key Features: Traditional soft-click tactile feel Integrated LED per button 3-way configurations w/ other WallPods or nWSD Buttons are field replaceable Custom labeling will be handled by ordering replacement buttons (see datasheet) Model # On/Off Control Raise/Lower Controls nPODM10 nPODM DX11 nPODM 2P20 nPODM D*11 nPODM 2P DX22 nPODM 4P40 nPODM 4P DX44 *Provides 0-10 VDC output wires

25 Push-Button WallPods – Line Voltage Key Features: Traditional soft-click tactile feel Integrated LED per button Contains relay to switch 800W/1200W VAC 3-way configurations w/ other WallPods or nWSD Buttons are field replaceable Custom labeling will be handled by ordering replacement buttons (see datasheet) Model # On/Off Control w/ Relay Raise/Lower Controls nPODMR10 nPODMR DX11 nPODMR D*11 *Provides 0-10 VDC output wires

26 Push-Button WallPods – Scene Control Local / Remote Scene Mode Runs scenes (profiles without a schedule) that are configurable via SensorView Scenes can control devices within local zone or other remote zones Scenes for local zones are stored locally, remote scenes are stored on the Gateway LED shows which scene is currently active WallPod Mode (default) Each buttons provides On/Off operation for different channel LED indicates current state Model ## Scenes / Channels nPODM 1S1 nPODM 2S2 nPODM 4S4 nPODM 4S DX4 + on/off & raise lower

27 Touch WallPods  3-way configurations w/ other WallPods or nWSD  Remotely configurable and upgradeable  Integrated RJ45 connectors  Capacitive Touch Controls  Audible Clickers Description Model # # of On/Off Control # of Relays # of Raise / Lower Controls # of Dimming Outputs # of Scene / Preset Control Single On/Off nPOD10000 nPOD DX10100 nPOD D10110 Dual On/Off nPOD 2P20000 Scene Selector nPODS40004

28 Graphic WallPod nPOD-GFX  Full-color touch screen control  Provides functionality of 16 On/Off/Dim WallPods  Facilitates creation of up to 8 lighting presets with on/off/dim settings  Runs up to 8 scenes locally or from Gateway  Enables programming of switch tracking channel of all devices in local zone  Low voltage device mounts to a single gang switch box or ring  Micro-USB connector (behind cover plated) for simple laptop connectivity with zone  Requires separate PS-150 power supply (provided)

29 Virtual WallPods  On-screen icon version of WallPods  Available as taskbar or iPhone application MultipleSingle

30 iPhone Virtual WallPod App.

31

32 nLight Control Zone

33  Zones are daisy-chain wired (in any order)  May have a single device  May have several different device types  May have multiple devices of the same type  Can be sub-divided into 16 channels of occupancy, photocell, and switch control  Functions stand-alone if disconnected from Gateway/SensorView

34 Zones and Channels  Every nLight zone has 16 occupancy channels, 16 photocell channels, and 16 switch channels on which to communicate information  Any device with a sensor, photocell, and/or switch can broadcast each type of information on one respective channel (2 pole devices can broadcast of two channels simultaneously)  Any device with a relay and/or dimming output can listen (track) on one or more of each information type’s channels simultaneously

35 Zones and Channels - Example Example : Classroom with 4 circuits of lights (3 main rows of lights, 1 white board light) –Two occupancy sensors are needed to cover space (turn off all lights) –One dimming photocell to control two rows only –Four switches enabling individual controls of all rows and whiteboard

36 Zones and Channels - Example Physical Connections

37 Zones and Channels - Example Logical Connections

38 Example Zone Designs 1 Circuit - Relay in Power Pack

39 Example Zone Designs 2+ Circuits - Relays in Power Pack

40 Example Zone Designs 2 Distribution Circuits – Relays in both Power Pack and Sensor

41 Example Zone Designs Multi-zone Dimming

42 nLight Network Backbone

43

44

45  Backbone devices include –Bridges –Gateways

46

47 nLight Bridge Functions  Routes Information between upstream Gateways & up to 8 downstream sensor zones  Increases number of lighting zones (128 devices per port)  Acts as both a hub and router of information between zones and Gateway  Redistributes power between zones Physical Specs  8 ports (RJ-45)  Mounts to 4”x4” junction box  Powered via dedicated Power Supply

48 Bridge

49  Installation –Mounts to 4”x4” box –Serial number is on outside of unit (the reason for this is covered in commissioning section) –The fewer the bridges deep the better (see handout on trees) –Pushing the button resets bridge –No loops allowed  Powering provided by PS 150 power supply connected via terminal connections Bridge and power supply mount directly to a 4” x 4” square box

50

51 Gateway Functions  Local Control Point –Two gang low voltage device located in space –Discovers and maintains database of all network devices –Capable of managing 400 devices indirectly or 32 devices directly –Typically one per floor  Profile management –Stores all profiles created by SensorView that include a device connected to Gateway –Sends out new settings to all devices in the Group bound to a particular Profile at the times specified by that Profile –Enables profiles to be run on-demand  Network Access Point –Links Ethernet to nLight network –Contains one Ethernet port and 3 SensorNet ports  Maintains time clock

52 Gateway

53 –Local powering (via terminal connections using PS 150)

54 Gateway  Network connection –IP address can be fixed or DHCP –Derives time from network –Ethernet port connects to buildings LAN (Local Area Network)  Security –Gateway password (set via SensorView) prevents outside SensorViews from accessing network –Once password is set for one Gateway it is automatically configured as the password for all current and future Gateways on the network –4 Digit Pin Code is available to enable locking of Gateway manual interface  Installation –Discovery of network is automatic, rediscovery can be forced via MDI –Mounts to 2-gang low voltage ring

55

56 Example Network Design

57 Additional Network Design Topics

58 System Powering  All device and communication power is delivered via the CAT-5 bus that interconnects zones and Bridges.  Power is supplied by power packs (nPP16), power supplies (nPS 80), nPANELs, RTLEDs, and Bridges (via their external power supply) Note: WallPod Scene Selectors require 5 mA Wall Switch Sensors with the –NL option require 3.5 mA; Typical Power Consumption ~3mA Power Generation 6 mA nPANEL 40 mA per port RTLED 6 mA total

59 System Powering  Bridges combine system power from zones that are net contributors of power and distribute it to zones that are net consumers of power

60

61 BACnet IP Key Features: Downloadable plug-in to SensorView Enables interfacing with BMS systems via an IP connection Communicates information gathered by nLight to other building systems (such as HVAC) Translates and forwards lighting relay and other select control commands from BMS system to nLight control devices. Demonstrated compatibility to date with Siemens Apogee, Johnson Controls Metasys, and Tridium. Interoperability with other systems will be added as required.

62 Installation & Commissioning

63 Basic Steps 1.Install backbone (Gateways & Bridges) 2.Install zones w/ power packs (or supplies) 3.Install zones w/o power packs (or supplies) 4.Install SensorView 5.System check and customization Installation Commissioning

64 Installing Backbone Gateway 1.Mount and hardwire power supply 2.Mount Gateway 3.Connect Gateway & power supply with CAT-5 4.Connect Gateway to Ethernet LAN w/ CAT-5 (or direct connect to Laptop) 5.Verify unit acquired IP Address Bridge 1.Mount and hardwire power supply 2.Mount Bridge 3.Connect class 2 power wires from power supply to Bridge terminal connections 4.Once power applied verify operation by observing LED blinking 5.Connect to Gateway with CAT-5 cable according to network design 6.Repeat steps 1-5 for interconnecting additional Bridges

65 Installing Zones w/ Power 1.Install and wire all line voltage devices 2.Install low voltage devices 3.Interconnect all zone’s devices with CAT-5 cabling 4.Zone should become functional and run according to defaults* 5.Verify lighting, sensor, photocell, and switch operation 6.Plug zone into backbone via Bridge port or Gateway port 7.Note Bridge serial and port number (record on sticker and card) Optional --- Record one serial number of device in group 9.Verify correctly incremented device count on Gateway *All device tracking/broadcasting settings start in enabled state and all channels settings use Channel 1 initially

66 Installing Zones w/o Power 1.Install and wire all line voltage devices 2.Install low voltage devices 3.Interconnect all zone’s devices with CAT-5 cabling 4.Plug zone into backbone via Bridge port 5.Zone should become functional and run according to defaults* 6.Verify lighting, sensor, photocell, and switch operation 7.Note Bridge serial and port number (record on sticker and card) Optional --- Record one serial number of device in group 9.Verify correctly incremented device count on Gateway *All device tracking/broadcasting settings start in enabled state and all channels settings use Channel 1 initially

67 Installation Worksheets

68 System Startup 1.After launching SensorView verify discovery of Gateway and all devices 2.Set-up user accounts 3.Label ports with zone names 4.Edit active defaults in units 5.Perform any necessary firmware updates (extended time may be required) 6.Create Groups/Profiles per customer requests 7.Print Inventory and Profile reports 8.Perform system backup

69 CAT5 Cable Bundles Features: Pre-terminated, white, labeled “Acuity Brands Controls” Plenum rated No molded strain relief Model #Length Cables in Bundle CAT5 6IN6 IN10 CAT5 2FT2 FT15 CAT5 10FT10 FT15 CAT5 15FT15 FT15 CAT5 30FT30 FT15 CAT5 50FT50 FT15 CAT5 1FT Y*1 FT10 *Cable has a female Y Splitter end

70 Troubleshooting

71 LED indications –Sensors/Photocells SOS Blink out if bad communication –Bridge No LED blinks indicates bad cabling Rapid blinks indicates discovery Persistent and/or periodic rapid flashing means communications issue (short, cross) Activity Mode (default) Single blink indicates normal polling traffic of zone (Knight Rider sequence) Double blink indicates upstream Bridge or Gateway connection 4 blinks indicates downstream Bridge or Transceiver Device Count Mode (press button once to toggle between modes) Number of detected devices is blinked out in two digits –Power Pack Interior LED will be solid if it is polling the zone (e.g. Bridge not connected) Only one per zone at any time should be polling Exterior LED will blink at regular pace to indicate being polled

72 Methods & Indicators  Gateway Rediscovery –MDI (Main => Discover) –SensorView –Cycling power (unplug all local ports first)  Gateway IP Renewal –MDI (Main => Setup Option => Get IP (DHCP))  Bridge reset –Press and hold button for 6 seconds –SensorView –Cycle power (unplug all local ports first)  Button Mode on units with Relays –Makes push-button on unit toggle switch –Function 1, setting 5 –Short delay between press and relay switching  Restore “factory” defaults to “active” defaults on units

73 Methods & Indicators  SensorView –Status Bar –Profile states Synchronized Mismatched SensorView only Gateway only –Replace Device/Remove Devices Devices within zone that are of same type can replace an offline device –Advanced Status (requires Admin privileges) Log.aspx Health Tab

74 nLight Documentation  nLight Hardware Manual  SensorView User’s Guide  Training Presentation  SensorView Installation Instructions  Gateway Menu Map  Device Instruction Cards  Application Examples  Settings Glossary

75 © 2013 Sensor Switch
