1 Broadband Communication Copyright © PLANET Technology Corporation. All rights reserved.

2 2 / 53 Introduction Product Overview Product Features Comparison Solutions Roadmap

3 3 / 53 Product Overview G.SHDSL ADSL 2+ VDSL 2 ModelDescription VC-200M VC-200S VDSL2 Router (VDSL2 8a/12a/17a Profile / 1.4km, 2 RJ-11, 4-Port RJ-45 LAN) VC-202 VDSL2 Ethernet over VDSL Converter (VDSL2 12a Profile / 1.6km, Coaxial / RG-58) VC-201A VDSL2 Converter (VDSL2 17a Profile / 1.5km, 2 RJ-11, 1-Port RJ-45 LAN) VC-204 VDSL2 Bridge (VDSL2 17a Profile / 1.5km, 2 RJ-11, 4-Port RJ-45 LAN) VC-231 VDSL2 Ethernet over VDSL Bridge (VDSL2 30a Profile / 1.8km, 1 RJ-11, 1-Port RJ-45 LAN) VC-234 VDSL2 Ethernet over VDSL Bridge (VDSL2 30a Profile / 1.8km, 1 RJ-11, 4-Port RJ-45 LAN) VC-230N 11n VDSL2 Router (VDSL2 30a Profile / 1.8km, n, 2 RJ-11, 4-Port RJ-45 LAN) VC-810S VC-810S48 8-Port VDSL2 CO + 1G TP/SFP Combo Management Switch (12a / 17a, VC-810S48 supports 48V DC redundant power) VC-2400M VC-2400MR 24-Port VDSL2 + 2-Gigabit Ethernet Managed CO Switches (30a, VC-2400MR supports 48V DC redundant power) VC-2402 VC Port VDSL2 IP DSLAM / (Ikanos) (30a, 2 GbE TP/SFP, ADSL 2+ backward compatible) VC-301 VDSL2 Modem (Ikanos) (VDSL2 30a Profile / 1.8km, 1 RJ-11, 1-Port RJ-45 LAN) VDSL2

4 4 / 53 Product Overview G.SHDSL ADSL 2+ VDSL 2 ModelDescription GRT-1012-Wire G.SHDSL Bridge / Router GRT Wire G.SHDSL Bridge / Router with 4-Port Switch GRT-4024-Wire G.SHDSL Bridge / Router with 4-Port Switch GRT-5012-Wire G.SHDSL.bis Bridge / Router GRT Wire G.SHDSL.bis Bridge / Router with 4-Port Switch G.SHDSL

5 5 / 53 Product Overview G.SHDSL ADSL 2+ VDSL 2 ModelDescription CO IDL Port ADSL 2+ Hardware Stacking IP DSLAM IDL Port ADSL 2+ IP DSLAM with 1000Base-LX IDL Port ADSL 2+ IP Stacking IP DSLAM IDL Port ADSL 2+ IP / Hardware Stacking IP DSLAM ADSL 2+

6 6 / 53 Product Overview G.SHDSL ADSL 2+ VDSL 2 ModelDescription CPE ADN n Wireless ADSL 2+ Router with 4-Port 10/100Mbps (TR-069 Ready) ADE-3410 ADSL 2+ Router with 1 USB Port 10/100 Mbps (TR-069 Ready) ADE-3400 ADSL 2+ Router with 1-Port 10/100 Mbps (TR-069 Ready) ADE-4400 ADSL 2+ Router with 4-Port 10/100Mbps (TR-069 Ready) ADW g Wireless ADSL 2+ Router with 4-Port 10/100Mbps (TR-069 Ready) IAD-300 ADSL 2+ Router with 2 FXS + 2 USB Port 10/100 Mbps (TR-069 Ready) ADSL 2+

7 Product Features VDSL2 Solution

8 8 / 53 Features Brief Model Item IP DSLAMVDSL2 Switch VC-2402 VC (Ikanos) VC-2400MVC-810S Max. Speed (Downstream/ Upstream) 100M / 100M 100M / 55M Max. Distance 1.8kmPhone line 1.8kmPhone line 1.5km Co-existing with Voice VVV Profile 8~30a30a12a, 17a VDSL2 IP DSLAM / Switch Model Item VDSL2 RouterVDSL2 Bridge VC-200M VC-200S VC-230N VC-201A VC-204 VC-231 VC-234 VC-301 (Ikanos) Max. Speed (Downstream/ Upstream) 100M / 40M100M / 100M100M / 55M100M / 100M Max. Distance 1.4km1.8km Phone line 1.5km Phone line 1.8km Co-existing with Voice VVVV- Profile 8~17a30a17a30a8~30a VDSL2 Router / Bridge

9 9 / 53 VC-2402 Features VC-2402 Cost-effective VDSL 2 CO solution for SMB 24-Port VDSL2 service via POTS/ISDN user interface 10/100/1000Base-T and SFP Interface Comply with ITU-T G and G VDSL2 speed up to 100/100 Mbps 8a, 8b, 8c, 8d, 12a, 12b, 17a, and 30a profiles 1U rack mountable IP or Hardware Stacking up to 16 units Line Interface ADSL, ADSL2, ADSL 2+ (ITU-T G.992.5) backward compatible WAN 2 Gigabit Ethernet Uplink with 802.3ad LACP support 802.1d/w spanning tree (STP, RSTP) VLAN 802.1q, 512 concurrent VLAN supported VLAN stacking QinQ Port based VLAN and Tagged based VLAN IPTV IGMP proxy v1,v2,v3 IGMP snooping v1,v2,v3 QoS 802.1p ToS 1~24 Line LEDs RJ-21 Connector for PHONE RJ-21 Connector for LINE AC Power (DC Power: VC ) RJ-50 Connector for alarm 2 x Gigabit Ethernet Combo ports (10/100/1000 Base-T and SFP) RJ-45 10/100 Ethernet port RS-232 Serial Port

10 10 / 53 Features VC-2400M / VC-2400MR 24-Port VDSL2 + 2-Gigabit Ethernet Managed CO Switches IEEE standard compliant: 802.3, 802.3u, 802.3ab, 802.3z 802.3x flow control 802.1Q Tagged VLAN 802.1p Class of Service 802.1w Rapid Spanning Tree 802.1x Port-Based network access control DSL standard: ITU-T G (VDSL) ITU-T G ITU-T G VDSL2 (Profile 12a / 17a / 30a Support), Annex A Data rate: up to 1000ft 24 Full-duplex VDSL links via RJ-21 connectors 24 corresponding POTS lines via RJ-21 connectors 2-Port Gigabit TP/SFP combo interface for uplink, up to 120km Port-based/802.1Q/Q-in-Q VLAN, LACP Trunk Rate control per port for TX/RX bandwidth control Support 802.1p / IP DSCP/TOS QoS, IGMP snooping SNMP v1, v2c, v3 / RMON 1, 2, 3, 9 / SNMP Trap SSL for secure HTTPs login L2/L3/L4 ACL, Port Security and 802.1x with RADIUS authentication VC-2400MR supports 48V DC redundant power

11 11 / 53 Features VC-810S / VC-810S48 8-Port VDSL2 + 1-Gigabit Ethernet Manageable CO Switches IEEE standard compliant: 802.3, 802.3u, 802.3ab, 802.3z 802.3x flow control 802.1Q Tagged VLAN 802.1p Class of Service DSL standard: ITU-T G (VDSL) ITU-T G ITU-T G VDSL2 (Profile 12a/17a Support), Annex A 8 Full-duplex VDSL links via spring terminal block connectors 8 corresponding POTS lines via spring terminal block connectors 1-Port Gigabit TP/SFP combo interface for uplink, support for distance extension up to 120km Support 8K absolute MAC addresses; Automatic address learning and address aging Port-based/802.1Q VLAN, Trunk Rate control per port for TX/RX bandwidth control Support 802.1p QoS, IGMP snooping SNMP v1, v2c and SNMP Trap VC-810S48 supports 48V DC power VC-810S / VC-810S48 (8-Port VDSL2 + 1 Gigabit Ethernet)

12 12 / 53 Feature VC-200M / VC-200S Ethernet over VDSL2 Router VDSL-DMT ITU-T G VDSL2 (Profile 8a, 8b, 12a, 12b, 17a Support), Annex A / B Standard compliant VDSL2 support Full VDSL2 bandwidth offering speed up to 100 Mbps Network Address Translation (NAT), IP Maps, and Pinholes Network Address Port Translation (NAPT) Firewall, Virtual DMZ, and IP Pass-through support Statistic and Log Reporting Built-in POTS/ISDN splitter Switching and routing of up to 4 LAN ports VC-200M VC-200S

13 13 / 53 Features VC-230N High Bandwidth VDSL2 Router VDSL-DMT ITU-T G VDSL2 (Profile 30a Support), Annex A Full VDSL2 bandwidth of up to 30 MHz offering up to: 300M -> 100/100Mbps 1km -> 25/5Mbps Built-in POTS splitter Wireless Interface: n Draft Port 10/100Base-TX RJ-45 DHCP and DNS DMZ and Port Forwarding SPI Firewall Port / IP / MAC / URL Filtering Static Route / RIPv1 VPN (IPSec/PPTP/L2TP) pass through Static IP, DHCP Client, PPPoE, PPTP VC-230N

14 14 / 53 VDSL2 CO/CPE Ethernet over VDSL Bridge VDSL-DMT ITU-T G VDSL2 (Profile 17a Support), Annex A DIP Switch for CO/CPE Mode selection Full VDSL2 bandwidth of up to 30 MHz offering up to: 300M -> 100/60Mbps 1km -> 25/5Mbps Built-in POTS splitter Auto-MDI/MDIX for 10/100-TX port Selectable Band plan: Asymmetric Symmetric Standalone or work with PLANET MC-7/15/15R family Media Chassis (VC-201A) Features VC-201A / VC /100 TX (RJ-45) VDSL2 (RJ-11) Model VC-201AVC-204 Long Reach Connector 1x RJ-11 10/100 LAN Port 1 x RJ-454 x RJ-45 Max. Down/ Up Stream 100/60 Mbps Max. Phone wire Distance 1.5 km

15 15 / 53 VDSL2 CO/CPE Ethernet over VDSL Bridge VDSL-DMT ITU-T G VDSL2 (Profile 30a Support), Annex A DIP Switch for CO/CPE Mode selection Full VDSL2 bandwidth of up to 30 MHz offering up to: 300M -> 100/100Mbps 1km -> 25/5Mbps Built-in POTS splitter Auto-MDI/MDIX for 10/100-TX port Selectable Band plan: Asymmetric Symmetric Standalone or work with PLANET MC-7/15/15R family Media Chassis (VC-231) Features VC-231 / VC /100 TX (RJ-45) VDSL2 (RJ-11) Model VC-231VC-234 Long Reach Connector 1x RJ-11 10/100 LAN Port 1 x RJ-454 x RJ-45 Max. Down/ Up Stream 100/100 Mbps Max. Phone wire Distance 1.8 km

16 16 / 53 VDSL2 CO/CPE Ethernet over VDSL Converter VDSL-DMT ITU-T G VDSL ITU-T G ITU-T G VDSL2 (Profile 12a Support), Annex A DIP Switch for CO/CPE Mode select Full VDSL2 bandwidth of up to 30 MHz offering up to: 300M -> 100/60Mbps 1km -> 25/5Mbps Built-in POTS splitter (VC-201) Auto-MDI/MDIX for 10/100-TX port Selectable target data rate to 50/20Mbps Standalone or work with PLANET MC-7/10/15 family Media Chassis Features VC-201 / VC /100 TX (RJ-45) VDSL2 (RJ-11) Model VC-201VC-202 Long Reach Connector RJ-11Coaxial / RG-58 Max. Down/ Up Stream 100/60 Mbps Max. Fiber Distance 1 km1.6 km

17 17 / 53 Reuse Cable Applications VC-202 Analog Camera Management Supporting up to 16 cameras. Analog Camera IP Camera Cabling less IP Camera Management Supporting up to 64 cameras.

18 18 / 53 Features VC-301 High Bandwidth VDSL2 Modem: Ikanos Solution VDSL-DMT ITU-T G VDSL2 (Profile 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a Support) Full VDSL2 bandwidth of up to 30 MHz offering up to: 300M -> 100/100Mbps 1-Port 10/100Base-TX RJ-45 Complaints IEEE 802.3/802.3u ETSI TS V1.3.1 and TS V1.21 Band Plan 997 and 998 Support U0 Band Support (25KHz to 276KHz) Packet Transfer Mode Ethernet in the First Mile (PTM-EFM) Extended US0 band up to 276KHz VC-301 Rear Panel Power LAN Line

19 Product Features G.SHDSL Solution

20 20 / 53 Features Brief G.SHDSL / G.SHDSL.bis Router GRT-101GRT-401GRT-402GRT-501GRT-504 Standard G (G.SHDSL) G (G.SHDSL) G (G.SHDSL) G rev2 (G.SHDSL.bis) G rev2 (G.SHDSL.bis) DSL Interface 1x RJ-45, 2-wire 1x RJ-45, 2-wire 1x RJ-45, 4-wire 1x RJ-45, 2-wire 1x RJ-45, 4-wire LAN Interface 1 x RJ-45, 10/100M 4 x RJ-45, 10/100M 1 x RJ-45, 10/100M 4 x RJ-45, 10/100M Max. Data Rate2.3 Mbps 4.6 Mbps5.7 Mbps11.4 Mbps Max. Distance6.7 Km

21 21 / 53 Feature GRT-504 G.SHDSL.bis Bridge Router Up to 11.4Mbps data speed, max. 6.7km to extend the existing network Web configuration, virtual server, DMZ support SNMP management with SNMPv1/v2 agent and MIB II Supports port-based and IEEE 802.1Q VLAN over ATM network PPPoA and PPPoE support user authentication with PAP/CHAP/MS-CHAP Supports SPI firewall, VPN (PPTP/L2TP/IPSec) pass-through Supports ATM and IP QoS Supports RIP v1/v2 routing protocol for routing capability A pair of GRT-504 provide LAN to LAN capability Efficient IP routing and transparent learning bridge for broadband Internet connectivity 9V DC LAN Console Port : RS-232 Female (DB9) RJ-45 G.SHDSL.bis Line Interface Reset GRT-504 Rear Panel

22 22 / 53 Feature GRT-501 G.SHDSL.bis Bridge Router Up to 5.7Mbps data speed, max. 6.7km to extend the existing network Web configuration, virtual server, DMZ support Supports port-based and IEEE 802.1Q VLAN over ATM network Fully ATM protocol stack implementation over SHDSL PPPoA and PPPoE support user authentication with PAP/CHAP/MS-CHAP SNMP management with SNMPv1/SNMPv2 agent and MIB II A pair of GRT-501 provide LAN to LAN capability Efficient IP routing and transparent learning bridge for broadband Internet connectivity GRT-501

23 23 / 53 Feature GRT-401/402 G.SHDSL Bridge Router with 4-Port Switch Built-in 4-Port 10/100Mbps switch Up to 2.3Mbps (4.6Mbps for GRT-402) data speed, max. 6.7km to extend the existing network Web configuration, virtual server, DMZ support Supports port-based and IEEE 802.1Q VLAN over ATM network Fully ATM protocol stack implementation over SHDSL PPPoA and PPPoE support user authentication with PAP/CHAP/MS-CHAP SNMP management with SNMPv1/SNMPv2 agent and MIB II A pair of GRT-401 provide LAN to LAN capability Efficient IP routing and transparent learning bridge for broadband Internet connectivity GRT-401/ 402

24 24 / 53 Feature GRT-101 G.SHDSL Bridge Router Up to 2.3Mbps data speed, max. 6.7km to extend the existing network Web configuration, virtual server, DMZ support Fully ATM protocol stack implementation over SHDSL PPPoA and PPPoE support user authentication with PAP/CHAP/MS-CHAP SNMP management with SNMPv1/SNMPv2 agent and MIB II A pair of GRT-101 provide LAN to LAN capability Efficient IP routing and transparent learning bridge for broadband Internet connectivity GRT-101

25 25 / 53 Brand Features PLANET GRT-402 ZyXEL Prestige 791 Cisco 828 LAN port RJ-45 x 4 10/100Base-TX Swith RJ-45 x 1 10/100Base-TX RJ-45 x 4 10/100Base-TX Hub Max. Speed4.6Mbps2.3Mbps VPN SupportVPN Pass-ThroughN/AVPN with 3DES PPP, ATM SupportVVV NAT/DMZ/DHCPVVV FIREWALL--Stateful inspection DDNS Support-V- SNMP SupportVVV Web ManagerVVV Environmental Operating temperature: 0~45 Degree C Storage temperature: -10~70 Degree C Operating temperature: 0~40 Degree C Operating temperature: 0~40 Degree C Storage temperature: -20~65 Degree C Comparison GRT-402

26 Product Features IP DSLAM

27 27 / 53 Features Brief Model Item IDL-2402IDL-2401IDL-2400IDL-4802 DLS ports24 48 Ethernet ports1 GbE3 GbE 2 GbE Combo Max. Speed (Downstream/ Upstream) 25M / 3M25M / 2M 25M / 3M Max. Distance5.6km Web ManagementV--V Hardware Stackable -Up to 8 Units Up to 4 Units IP StackingUp to 4 Units-- Co-existing with Voice VVVV IP DSLAM

28 28 / 53 IDL-4802 Features IDL-4802 Cost-effective ADSL 2/2+ CO solution for SMB 48-Port ADSL/ ADSL2/ ADSL2+ Subscriber Interface 2 x 1000Base-T or 2 x mini-GbE Uplink Interfaces DMT data rate: Downstream up to 25 Mbps / Upstream up to 3Mbps IP or Hardware Stacking up to 4 units Full SNMP Management Local RS-232 CLI, Telnet, SNMP, SSH Firmware upgradeable via FTP Advanced Function for Broadband Service Support IEEE 802.1q Tag-based VLAN and Protocol-based VLAN Security : VLAN filtering, MAC Filtering, IP Filtering, Access Control List by MAC and IP address Traffic prioritization (802.1p) Rate limiting by MAC and IP address Link Aggregation (802.3ad) 802.1x, DHCP Server & Relay, PPPoE, MPLS, VLAN-based VPN, L3 router feature, L2TP Combo Gigabit port x 2 RJ-21 Connector for PHONE RJ-21 Connector for DSL LINE 100~240V AC Power Switch RS-232 console port Alarm I/O port FAN card connection LED for 48 ports DSL status

29 29 / 53 IDL-2402 Features IDL-2402 Cost-effective ADSL 2/2+ CO solution for SMB 24-Port ADSL/ ADSL2/ ADSL2+ Subscriber Interface 1000BaseT Interface DMT data rate: Downstream up to 25 Mbps / Upstream up to 3Mbps IP Stacking up to 4 units Full SNMP Management Local RS-232 CLI, Telnet, SNMP, SSH Firmware upgradeable via FTP Advanced Function for Broadband Service Offering Support IEEE 802.1q Tag-based VLAN and Protocol-based VLAN Security : VLAN filtering, MAC Filtering, IP Filtering, Access Control List by MAC and IP address Traffic prioritization (802.1p) Rate limiting by MAC and IP address Link Aggregation (802.3ad) 802.1x, DHCP Server & Relay, PPPoE, MPLS, VLAN-based VPN, L3 router feature, L2TP RJ-45 Uplink Port (10/100/1000Mbps) RS-232 Serial Port RJ-21 Connector for PHONE RJ-21 Connector for LINE 100~240V AC Power

30 30 / 53 Features IDL-2400 Cost Saving Solution for SMB 24 ports ADSL/ ADSL2/ ADSL2+ Subscriber Interface 1000BaseT Interface Hardware Stacking up to 8 units Full SNMP Management Local RS-232 CLI, Telnet, SNMP Firmware upload/download Advanced Function for Broadband Service Offering Support Static VLAN and Port-based VLAN Security : VLAN filtering, MAC Filtering, IP Filtering, Access Control List by MAC and IP address Traffic prioritization (802.1p) Rate limiting by MAC and IP address Link Aggregation (802.3ad) 802.1x, DHCP Server & Relay, PPPoE, MPLS, VLAN-based VPN, L3 router feature, L2TP IDL-2400 (24-Port IP DSLAM) Home Office ADSL 2+ Router 5.6 km

31 31 / 53 Features IDL-2401 Cost Saving Solution for SMB 24 ports ADSL/ ADSL2/ ADSL2+ Subscriber Interface 1000Base-LX Interface Hardware Stacking up to 8 units Full SNMP Management Local RS-232 CLI, Telnet, SNMP Firmware upload/download Advanced Function for Broadband Service Offering Support Static VLAN and Port-based VLAN Security : VLAN filtering, MAC Filtering, IP Filtering, Access Control List by MAC and IP address Traffic prioritization (802.1p) Rate limiting by MAC and IP address Link Aggregation (802.3ad) 802.1x, DHCP Server & Relay, PPPoE, MPLS, VLAN-based VPN, L3 router feature, L2TP IDL-2401 (24-Port IP DSLAM) Home Office ADSL 2+ Router 5.6 km

32 32 / 53 Comparison IDL-2402 Model PLANET IDL-2402 Draytek VigorAccess Zhone 4229-A3-530 Hardware Suscriber Interfaces 24-Port Uplink Interfaces 1 x 1000Base-T 1 x 1000Base-LX/SX1 x 1000Base-T Management Interfaces 1 x RS-232 Console 1 x 100Base-Tx 1 x RJ-45 Console 1 x RS-232 Console DSL & POTS Interfaces 2 x TELCO-50 Built-in Splitter V VV Software Downstream RateUp to 25MbpsUp to 20MbpsUp to 24Mbps CLI ManagementConsole, Telnet, SSHConsole, Telnet WEB ManagementV-V SNMPV1, V2c V MAC Address4K - IP Stacking4-- IGMPV1, V2, V3V1, V2V2 VLAN ID512 - VLAN Bridge Static / Port-based / Protocol-based / 802.1q Tag-based VLAN 802.1q VLAN Security VLAN/MAC/IP filtering Access Control List (MAC / IP / Protocol) Port Isolation MAC / Packet filteringMAC and Host Address filtering 802.1x AuthenticationV--

33 33 / 53 Comparison IDL-4802 Model Features PLANET IDL-4802 Zyxel IES-1248 D-Link DAS-3248 Hardware Chipset Broadcom 6411IPBG 12DSL- XCVR Centillim MaximusConexant Columbia SDRAM256 MB64 MB Flash32 MB4 MB8 MB Subscriber Interface48-Port Uplink Interface 2x RJ-45 (1000Base-T) 2x SFP (1000Base- T/SX/LX/EX/ZX/LHX) 2x RJ-45 (1000Base-T) Management Interface 1x RJ-45 (100Base-TX Ethernet) 1x RJ-45 (Serial Console) 1x mini RJ-11 (Serial Console) 1x RJ-45 (1000Base-T) 1x RS-232 (Serial Console) DSL & POTS Interface 2x RJ-21 LINE 2x RJ-21 PHONE 2x RJ-21 LINE 2x RJ-21 PHONE 2x RJ-21 LINE 2x RJ-21 PHONE Built-in SplitterVVV Alarm I/01x RJ-50-- Maximum Distance5.6 Km Dimension (W x D x H)482 x 265 x 66 mm (1.5U)440 x 251 x 66mm (1U)440 x 400 x 44 mm (1U) Power AC 100~240V DC -48V, 4.0A (IDL ) DC -48VAC 90~240V

34 34 / 53 Comparison IDL-4802 Model Features PLANET IDL-4802 Zyxel IES-1248 D-Link DAS-3248 Software ADSL2+ StandardITU G Annex M / L SupportAnnex M, Annex L CLI ManagementConsole, Telnet, SSHConsoleConsole, Telnet Web ManagementV-- SNMPV1, V2c StackableYes (Up to 4)No (4U / 10U)Yes (Up to 8) MAC Address4K64K6K Multicast Groups256 IGMPv1, v2, v3v2v1, v2, v3 ATM PVCs per Port888 VLAN ID VLAN BridgeStatic / Port-Based VLANTaggin VLANStatic / Port-Based VLAN QoSTraffic Priority (802.1p) Traffic priority (802.1p) Security MAC, IP, Protocol filtering Access Control List by MAC, IP, Protocol MAC filtering Port Isolation VLAN, MAC, IP filtering Access Control List by MAC, IP

35 Product Features ADSL Solution

36 36 / 53 Features Brief Model Item ADN-4000ADE-3410 ADE-4400 ADE-3400 ADW-4401IAD-300 Max. Speed (Downstream/ Upstream) 24M / 3.5M NATVVVVV FirewallVVVVV UPnPVVVVV VPN Tunnels (IPSec/PPTP) ---4 / 4- 11n Wireless APV g Wireless APV--V- LAN port41 LAN, 1 USB4 / 144 VoIP----V TR-069VVVVV Target MarketSME SOHO/ Home Use SOHO/ Home Use SOHO/ Home Use SOHO/ Home Use ADSL 2/2+ Router

37 37 / 53 Feature IAD-300A ADSL 2/2+ VoIP Router Built-in ADSL 2/2+ Modem SIP 2.0 Support Compatible with popular Internet SIP Proxy provider like FWD and Infonex Regular PSTN call with Life line support Two FXS Interface Compliant with T.38 and G.711 Fax standards QoS (Quality of Service) for excellent voice quality Provides two USB 2.0 for Print Server and Storage Built-in 4-port switch with auto MDI/MDI-X capability Supports NAT, DHCP, DMZ, virtual server Supports SPI Firewall, Access Control, Packet Filter Supports Dynamic DNS server and UPnP TR-069 Ready DSLVoIP RJ-11 Port Reset USB 1 for Storage Device (USB HD) USB 2 for Print Server Power on/off PowerLAN IAD-300A Rear Panel

38 38 / 53 Feature ADN-4000A n Wireless ADSL 2/2+ Router Built-in ADSL 2/2+ Modem IEEE b/g and n Draft 2.0 compliant (Maximum of 300Mbps supported) Farther coverage, less dead spaces, and higher throughput with 2T3R MIMO technology Supports WPS (Wi-Fi Protected Setup) Supports WPA-PSK_TKIP and WAP-PSK_AES encryption Supports SPI Firewall, Access Control, URL Filter Supports NAT, DHCP, DMZ, virtual server Supports Dynamic DNS server and UPnP TR-069 Ready ADN-4000

39 39 / 53 Feature ADE-3410A ADSL 2/2+ Router with USB port Compliant with ADSL 2+ standard Incorporates on one Ethernet port and one USB (v1.1) port Data transmission up to 24Mbps downstream and 3.5Mbps upstream Supports SPI Firewall, ACL, IP Filter Supports NAT, NAPT, DHCP server, and virtual server Supports Dynamic DNS server and UPnP TR-069 Ready ADE-3410 (Annex A, POTS)

40 40 / 53 Cost-effective ADSL 2/2+ Router Compliant with ADSL 2+ standard Backward compatible with ADSL, ADSL 2 standard Data transmission up to 24Mbps downstream and 3.5Mbps upstream Built-in 4-port switch with auto MDI/MDI-X capability (ADE-4400) Supports NAT, DHCP, DMZ, virtual server Supports SPI Firewall, ACL, IP Filter Supports Dynamic DNS server and UPnP TR-069 Ready Features ADE-3400/4400 ADE-3400 ADE-3400A (Annex A, POTS) ADE-4400 (Built-in 4-port Switch) ADE-4400A (Annex A, POTS) ADE-4400B (Annex B, ISDN)

41 41 / 53 Feature ADW-4401A g Wireless ADSL 2/2+ Router IEEE b/g standards compatible Compliant with ADSL 2+ standard Backward compatible with ADSL, ADSL 2 standard Data transmission up to 24Mbps downstream and 3.5Mbps upstream Built-in 4-port switch with auto MDI/MDI-X capability Supports IPSec and PPTP VPN Supports NAT, DHCP, DMZ, virtual server Supports SPI Firewall, Access Control, Packet Filter Supports Dynamic DNS server and UPnP SNMP management with SNMPv2 TR-069 Ready ADW-4401A (Annex A, POTS)

42 42 / 53 Comparison ADE-4400 Brand Features PLANET ADE-4400 Netgear DG834 ZyXEL Prestige 660H Hardware Ethernet portRJ-45 x4, 10/100Mbps ADSL portRJ-11 x1 Reset Button1 on rear panel Software ADSL standardADSL 2/2+ ADSL TypeAnnex A/L/M, BAnnex A, B NAT / NAPTVVV Virtual ServerVVV DMZVVV RIP 1/2VVV DHCP ServerVVV Access ControlV-V IP FilterVVV FirewallVVV UPnPVVV VPNPass through Dynamic DNSVVV SNMPV, v2-V, v1

43 Product Features Passive Optical Network (PON) Solution

44 44 / 53 GEPON PON interface complies with IEEE 802.3ah IEEE 802.3ah compliant Forward Error Correction (FEC) 128-bit Advanced Encryption Standard (AES) encryption Supports Dynamic Bandwidth Allocation (DBA) algorithms 802.1x authentication engine with remote administration for device and user authentication Supports 64 MAC Addresses Supports 802.1Q VLAN Supports 802.1P 1.5 MB of integrated buffering GE-PON SFU 1 PON port + 4 FE EPN-104 GE-PON MDU 1 PON port + 1 FE + 1 GE EPN-102 Remark: GEPON = Gigabit Ethernet Passive Optical Network

45 45 / 53 GPON Based on ITU-T G.984 GPON ONT functionality Supports for Virtual Local Area Networks (VLANs) and video services with IP Multicast, IPv4, or IPv6 A flexible rate limiting function allowing limiting traffic by priority queue, by VLAN ID, or by the total traffic Support IGMP snooping Management software packet include CLI, telnet Full management through an ONT Management and Control Interface (OMCI) protocol based on ITU-T G984.4 Forward Error Correction (FEC) coding for an improved link budget Supports Dynamic Bandwidth Allocation (DBA) algorithms 128-bit Advanced Encryption Standard (AES) encryption GPON SFU 1 PON port + 1 GE GPN-101 GPON MDU 1 PON port + 16 FE + 16 POTS GPN-216 Remark: GPON = Gigabit Passive Optical Network

46 46 / 53 GEPON / GPON Deployment Long distance Fiber Optic Solution Great quantity of Deployment High Rise Buildings Campus Residential Community Intelligent Office Buildings PON

47 Solutions

48 48 / 53 ADSL 2/2+ Solution Using VPN connection capabilities, mobile workers may attach to and access LAN resources while working at home or at branches. Sharing high-speed ADSL 2/2+ broadband Internet connection in a 10/100Mbps Fast Ethernet backbone.

49 49 / Mbps VDSL 2/ G.SHDSL Solution A pair of GRT-401/402 can be deployed to extend Internet distance via telephone line up to 6.7km. By utilizing the existing telephone line, VC-200M and VC-200S provide higher speed than Ethernet and the distance can be up to 1.4km, while voice conversion is still available over the same telephone line.

50 50 / 53 Roadmap VDSL2 / G.SHDSL VDSL2 G.SHDSL VDSL 2 Bridge / Switch VC-201 / VC /Q22009/Q3 VDSL 2 Router VC-200M / VC-200S G.SHDSL.bis Router 11.4Mbps, 4-Wire, GRT-504 L2 VDSL2 Switch 8 VDSL2 + 1-Port Gigabit TP/SFP Web Smart VC-810S/S48 L2 VDSL2 Switch 24 VDSL2 + 2-Port Gigabit TP/SFP Web Smart VC-2400M 11n VDSL2 Router 100Mbps, 30a, 4-Port VC-230N VDSL2 Modem Ikanos, 100Mbps, 30a, 1-Port, VC-301 VDSL2 Bridge 100Mbps, 30a, 1-Port VC-231 VDSL2 Bridge 100Mbps, 30a, 4-Port VC-234 VDSL2 IP DSLAM Ikanos, 24 VDSL2 + 2-Port Gigabit TP/SFP, 100Mbps, 30a VC-2402 VDSL2 Bridge 100Mbps 17a, 1 / 4-Port VC-201A / VC-204

51 51 / 53 Roadmap ADSL 2/2+ 11n ADSL 2/2+ 11n Draft 2.0, WPS, WPA / WPA2, 4 LAN, QoS ADN n VoIP Router ADSL 2/2+, 2FXS, life line, USB, Cost Effective IAD-300N ADSL 2/2+ 24-Port IP DSLAM Web UI, 1 Gigabit IDL-2402 VoIP Router ADSL 2/2+, 2FXS, life line, USB Cost Effective IAD n ADSL 2T2R, 2 USB 2.0 Host 11n ADSL 2T2R, VPN, 4 LAN, QoS 11n ADSL 1T1R, 4 LAN 11n ADSL 2T3R, 2 USB 2.0 Host, 4 LAN 2009/Q22009/Q3 11n ADSL 1T1R, 1LAN ADSL 2/2+ 48-Port IP DSLAM Web UI, 2 Gigabit IDL-4802

52 52 / 53 Roadmap GEPON / GPON GEPON MDU Teknovus TK3715, 1 FE+1GE EPN-102 GEPON SFU Teknovus TK3715, 4 FE EPN-104 GPON SFU Broadlight BL2338, 1GE GPN /Q22009/Q3 GPON MDU 16 FE + 16 POTS GPN-216 GEPON SFU 4 FE + 2 POTS + CATV GPON SFU 4 FE + 2 POTS + CATV

53
