1. Solving for A Cutting Data Table Which Formula Should I Use?

2. What is In a Cutting Data Chart Number of Teeth Dia. Of Pitch Tooth Form Whole Depth Chordal Thickness Chordal Addendim Pitch Diameter Circular Thickness

3. Sample Problem A Spur Gear has 60 Teeth of 5 Diametral Pitch. Look at the Cutting Data Table and place the Information Into it

4. Fill In the Table & Determine What Formulas are Needed for the Rest Number of Teeth 60 Dia. Of Pitch 5 Tooth Form Involute Whole Depth Chordal Thickness Chordal Addendim Pitch Diameter Circular Thickness

5. Number of Teeth 60 Dia. Of Pitch 5 Tooth Form Involute Whole Depth 2/P Chordal Thickness D sin (90/N) Chordal Addendim a + ½ D[1-cos(90/N) ] Pitch Diameter N/P Circular Thickness ∏ D/N

6. NEXT Complete the Calculations in an Order That Works For You

7. Place Information Into The Table Number of Teeth 60 Dia. Of Pitch 5 Tooth Form Involute Whole Depth.4 Chordal Thickness.225 Chordal Addendim.3141 Pitch Diameter 12 Circular Thickness.2618
