2. MEMORY MODE
The HAAS Control Series

3. SLIDE LEGEND To advance through the presentation click
PRESS
THREE TIMES
TO GET TO
THIS PAGE
(Continued on
next slide)
Note:
ACTIONS
To advance through the presentation click
on your left mouse button or press <ENTER>.
To exit press <ESC>.
KEYS
INSTRUCTIONS
INFORMATION
OTHER INFORMATION

4. MEMORY MODE
This module is intended to provide you with a familiarization
of the Memory Mode on the Haas Control

5. Here is where you find the Memory Buttons
There are eight different keys under the “Display” area. Some of these have several functions or screens.
Apr-17

6. Memory Buttons
MEMORY:
SINGLE BLOCK:
DRY RUN:
OPTIONAL STOP:
BLOCK DELETE:
Pressing the memory button on the control will display the current program for running when you press <CYCLE START>.
The current program is the one that has been selected in LIST PROGRAMS.

7. The selected program is ready to run.
Memory Button:
MEMORY Button:
The selected program is ready to run.
Press
<CYCLE START>
PROGRAM (MEM) O N00000
O (MILL LAB PROG 1) ;
G01 Z F7. ;
G01 X Y ;
G01 X ;
G01 X Y ;
G01 X ;
G01 X ;
G01 X Y ;
G03 X Y R0.02 ;
F4 FOR PROG REVIEW

8. Single Block Button: SINGLE BLOCK Button: Used like a toggle switch.
The control will execute one block of program then stop; every press of <CYCLE START> will execute one more block.
With
Setting 104: Jog Handle to Single Block ON
Press
<CYCLE START>
Then rotate the Jog Handle CCW to run the program. Each click of the handle will execute 1 block.
CW = Feed Hold
PROGRAM (MEM) O N00000
O (MILL LAB PROG 1) ;
G01 Z F7. ;
G01 X Y ;
G01 X ;
G01 X Y ;
G01 X ;
G01 X ;
G01 X Y ;
G03 X Y R0.02 ;
F4 FOR PROG REVIEW
SINGBK
Excellent for checking out your program when in Graphics Mode

9. Dry Run Button: DRY RUN Button: Used in Memory or MDI mode.
Used to check a program using reduced speeds and feeds.
All rapids and feed rates are run at the rate selected with the JOG speed keys.
Press
Select the speed.
<HAND CNTL SPIN>
Adjust with Jog Handle
PROGRAM (MEM) O N00000
G01 Z F7. ;
G01 X Y ;
G01 X ;
G01 X Y ;
G01 X ;
G01 X ;
G01 X Y ;
G03 X Y R0.02 ;
DRY RUN SPEED 1.
O (MILL LAB PROG 1) ;
DRYRUN

10. Optional Stop Button: OPTIONAL STOP Button:
When an M01 command is encountered in the program, then a program stop will be executed.
Press
<CYCLE START>
to continue.
PROGRAM (MEM) O N00000
G01 Z F7. ;
G01 X Y ;
G01 X ;
G01 X Y ;
G01 X ;
M01 G01 X (Optional Stop);
G01 X ;
G01 X Y ;
G03 X Y R0.02 ;
F4 FOR PROG REVIEW
O (MILL LAB PROG 1) ;
OPTSTP

11. Block Delete Button: BLOCK DELETE Button:
When a program block begins with a slash (/) it will be ignored (i.e., that program block will not execute).
PROGRAM (MEM) O N00000
G01 Z F7. ;
G01 X Y ;
G01 X ;
G01 X Y ;
G01 X ;
/G01 X (Block Delete) ;
G01 X ;
G01 X Y ;
G03 X Y R0.02 ;
F4 FOR PROG REVIEW
O (MILL LAB PROG 1) ;
BLKDEL

12. Prepared by Haas Automation Training Department Oxnard, CA 93030
