1. Charlotte Oskarsson Sales presentation
RTP
Charlotte Oskarsson
Sales presentation
DISCLAIMER:
The Title slides in this template are not compatible when converted to, for example, Apple devices or uploaded on WebEx. The logo box will be covered by the picture. To add the logo box on top of the picture, click View, Slide Master and copy the box. Close the Master View and paste the box to the slide. Make sure the text boxes are placed in the front.

3. RTP – What is IT?
RTP (Rapid Torque Pneumatic) is a pneumatic nutrunner which fastens and loosens bolts within a torque range of 500 – 8 100 Nm (all models are not launched)
Torque is set by a pressure regulator and the reaction force is handled by a reaction arm. A torque chart is supplied with the tool in order to adjust specific torque values
All RTP tool kit´s includes an FRL (Filter, Regulator, Lubricator) a 13 mm hose with applicable nipple and an standard reaction bar
The tool is designed for flange-related and other bolting applications in the Oil & Gas, Power Generation and Wind Energy segments. It will also be used in reman (remanufacturing), repair, maintenance and service applications in the Mining and Off-road segments
Approximately 10 000 tightening's, maintenance interval 4 – 5 000 tightening's

4. Pneumatic Tools Background Huge potential in the Oil & Gas market
70 – 80% of the bolting market is related to the oil and gas industry
Oil and Gas are the biggest source of energy and will increase in the future
High demand of safety and reliability hence pneumatic tool, low pressure
BOP:s and Christmas trees are crucial in oil and gas exploration and production
Hydraulic Wrenches
Hydraulic Tensioners
Pneumatic RTP
Other Pneumatic
Material Removal
4 200
1 400
500
900

5. Fabrication & Maintenance
Offering a complete solution
Bolting
Hydraulic tensioners
Bolting
Hydraulic torque wrenches
Bolting
Nutrunners
Aftermarket
Service
Calibration
Rental
Accessories
Air line
Pumps
Sockets
Assembly
Nuntrunners
Impact wrenches
Material removal
Grinders
Cut off’s
Sanders
Material removal
Chipping
Scaling
Beveling

6. Key components RTP Circlip Reaction bar Square drive1 2 3 4 5 6 7 1
Circlip 2
Reaction bar 3
Square drive 4
Reaction bar spline 5
Gear unit 6
Swivel unit 8 7
Motor housing unit 9 8
Push button 9
Reversing lever 10
Silencer 10 11 11
Inlet adapter

7. Main Features RTP 4100HR25 Slim gear pack Swiveling gear rim
To be competitive, our gear pack diameter is among the smallest on the market
Swiveling gear rim
Gear unit and reaction bar can freely rotate from the motor housing unit saving total tightening time
Efficient and proven motor and handle design
The LMS 8 (impact wrench) series motor and handle is the drive concept. The LMS 8 motor is a well performing air motor, with high speed and low weight
Exchangeable drive
Exchangeable drive to service the anvil
FRL Stand
Regulator, filter and lubricator in industrial durable design
New reaction bar
Thin and lightweight reaction bar made in strong Weldox material

8. Features, benefits and customer values
Slim gearpack
Weldox reaction bar
LMS(well proven design) handle
Exchangeable drive 1”
FRL stand
Benefit
Small CS distance
Higher strength
Robust
One component exchange
Decreases wear
Customer value
Accessibility
Low weight and less operator strain
Increased lifetime
Lower repair cost
Uptime

9. Installation Plug & Play
Slide the reaction bar over the splines and secure with a circlip
Attach the socket and secure with the locking pin and O-ring. Never use oversized sockets/extensions (see recommended socket dimensions)
Install the nipple delivered with the tool
Keep the air pressure closed when mounting the hose on the FRL unit
Mount the hose that comes with the kit on the FRL unit and the tool

10. Installation Plug & Play Open the air pressure valve
Set the air pressure by lifting the knob and turning it. Secure the knob by pushing it down until there is a click sound
Check the trigger function by pushing it in
Set torque on the pressure regulator by lifting the knob and turning it while the tool is running freely
When required torque is set secure the knob by pushing it down

11. Example of Torque chart
RTP 1300 HR20

12. Torque chart
RTP 4100 HR25

13. Applications For rough industrial environments
General Industry (flange related)
MRO (Maintenance, Repair & Overhaul)
Wind Energy
Refinery
Petrochem
Pipeline
Oilfield
Power Generation
Mining and Off-road Reman (Remanufacturing) centers
Construction
Maintenance
Quality

14. Applications Flange related
Commonly used on low-pressure pipe flanges in refinery/chemical plant, FPSO, Oil Rigs
Opening and closing industrial valves
Applications are tightening of Pipe Flanges, Compressor Cover, Clamp, heavy vehicle wheel nuts and Valves. (1”-2” bolt sizes)
Wellhead rentals. BOP´s (Blow out preventers) and Christmas trees in the oil and gas industry
Steel construction

15. Applications Mining and Railroad MRO
Maintenance of trucks, excavators and crushers
Assemble frogs and switch for railroads
Track pad bolts
Final drive segment bolts

16. RTP nutrunner kit
Data EU US

17. Accessories INCLUDED When ordering a kit! Standard FRL Standard S-bar
Nipple
RTP 1300 / 4100
Ordering No
RTP 1300
Ordering No
RTP 4100
Ordering No
RTP 1300 /4100
ErgoNIP 10US, NPT
Ordering No

18. Optional Accessories Why compromise when you can optimize!
Trigger guard and Swivel
Non-standard reaction bars
Non-standard reaction bars
RTP 1300
RTP 4100
Steel bar
Ordering No
Steel bar
Ordering No
Sliding drive
Ordering No
Sliding drive
Ordering No
RTP 1300/ 4100
MultiFlex swivel
Ordering No
Trigger guard
Ordering No
Square bracket
Ordering No
Square bracket
Ordering No

19. RTP Order numbers RTP 1300 HR20 RTP 4100 HR25 Leaflet
Kit nr:
Tool nr:
RTP 4100 HR25
Kit nr:
Tool nr:
Leaflet
Order number: US version
Order number: UK version
Animation and film
Will be uploaded on the Market Support Database

20. Dimensional Drawing
RTP 1300 S-bar

21. Dimensional Drawing
RTP 4100 S-bar

22. What differs RTP from LTP?
LTP61 vs RTP 4100
LTP Nm
RTP 4100 HR25
Ø mm
Ø 80 mm
Twin stage motor
1 ½” square drive
14 kg
Shut off
Assembly tool
Lifelength tightenings
1 motor
1” square drive
8.5 kg
Stall type
Maintenance tool
Lifelength tightenings

23. Competitor comparison
Competitor comparison 3000 Ft. lb., Catalogue data

24. Competitor comparison
Competitor comparison 1000 Ft lb., Catalogue data

25. No of tightening's before breakage
Competitor data
Measured in house
Tool model
Metric model name
Imperial model name
RPM
Weight, kg A D C C2 B Cs
TorqueNm
3 bar
Torque, Nm
6.3 bar
No of tightening's before breakage
Weight reaction bar, kg
Length, mm
Heightmm
Width motor house, mm
Height motor house, mm
Gear house, mm
Gear housemm
RTP 1300 20
3.7
248
210 68 69 34
560
1300
 0.76
RTP 4100 10
8.7
335
220 85 84 42
1850
4100
 2.00
RAD 34 GX
RAD 34GX
RAD 25GX 12
6.35
240
102 78 39
2015
3505
24060
3.05
RAD 20 DX
RAD 20DX
RAD 15DX
3.95
190
230 70 77
34.5
1136
5.5bar1976
1.7
RAD 4000
RAD 30 14
305
270 97
115 80 40
3600
12500
2.2
RAD 80DX
RAD 60DX
6.6
300
260 94
123
101
50.7
3400
7711
23500
 4.40
PTM92
PTM 30
8.6
380 56 92 46
2001
4000
1.34
PTM72
PTM
100 6
325 55 72 36
690
1350
0.67
PTM 60
6.5
360
1004
2000
J-Gun 1
3.55
200
180 90 66 33
772
1588
0.6
J-Gun 3 2
5.75
250 81
40.5
1978
3958
1.5
