1. Distech Controls Production Studio

2. Overview  Production Studio solution Overview  Distech Controls Products Solution  Distech Controls Production Studio  Production workflow  Getting Started  Features & Benefits  Hardware & Software Requirements

3. Distech Controls’ OEM Business The Distech Controls OEM business:  Strong R&D competencies with focus and sustained investment in both product development and continous quality  Production and test facilities focused on OEM requirements Collaboration from conception :  OEM needs / target combined with Distech Controls’ expertise (20 years in the Building Automation field) Distech Controls goes further to better support our OEM clients : PRODUCTION STUDIO  Enables the autonomous, on-demand management of all required programs for Distech Controls’ range of BACnet and LONWORKS programmable controllers (ECL/ECB series)

4. Production Studio A solution that supports OEMs’ processes:  Provides OEMs with the autonomy to manage the process, according to their needs and timing  Reduces production and logistics costs  Intuitive solution and interface  Plug and play solution Providing autonomous capacity to:  Configure a product using parameters defined in an Excel spreadsheet  Test a product according to the defined parameters  Update firmware and EC-gfxProgram graphical programming tool (in some cases)  Print the related label indicating selected configurations - controller or mechanical equipment

5. Distech Controls Products Solution Complete line of programmable controllers:  Ideal for any control requirement, ranging from 10-points to 76-points  Peer-to-peer communication for both BACnet & LonWorks  Programmable with EC-gfxProgram  50 Series of controllers with live graphics color display

6. Distech Controls Products Solution IO Points Central Plant Boilers Chillers Air Handling Units Roof Top Units Heat Pump Units Chilled Beams Fan Coil Units Variable Air Volume Boxes BACnetLonWorks ECB-600 SeriesECL-600 Series ECB-400 SeriesECL-400 Series ECB-300ECL-300 ECB-203ECL-203 ECB-103ECL-103 ECB-VAV SeriesECL-VAV Series

7. Distech Controls Products Solution EC-gfxProgram: Develop and customize program to meet the requirement of your equipment application;  Intuitive block programming tool.  Fully customizable program and functions that enables complete user control.  Over 300 objects in toolbox including: Psychometrics HVAC Mathematical Time  Live troubleshooting and monitoring functions.  Code and block library available for programming example.

8. Distech Controls Production Studio  Distech Controls Production Studio is a tool designed for OEM that need to manufacture, download and test their equipment in a production environment.  The Distech Controls Production Studio is intended minimize intervention in the process of configuring, programming and testing operation of an equipment by linking all the pieces of the puzzle together.  The goal of Distech Controls production Studio is to maximize the equipment production process and minimize the production downtime all across OEM global production workflow.

9. Production Workflow 1.Update/download controller firmware (if required) 2.Update/download equipment application program in the controller 3.Download in batch numerous equipment’s configuration parameters based on a standard Excel spreadsheet 4.Automate the test of the equipment before it leaves the factory 5.Print customizable label with company logo, location, model number, room number, QR Code etc. 6.Customize the Distech Controls Production Studio software to encounter the specific production needs

10. Getting Started Setup phase (first time only):  Create once your equipment programming template with EC-gfxProgram  Create once your equipment specific parameter template with Microsoft Excel  Define once your Workflow sequence in Distech Controls Production Studio Production phase:  Connect your controller(s) to your production PC  Start your Distech Controls Production Studio sequence  Once sequence is complete, put your label on the box and prepare your next order!

11. Features & Benefits  Computerize equipment programming and testing  Lowers OEM production cost  Connect to equipment trough a simple USB plug and play approach  Download batch parameters and configuration to multiple equipment  Reduces configuration and testing time  Print directly equipment label after each successful job  Generates detailed report log after each test and configuration sequence Time Savings Cost Savings Production Efficiency

12. Hardware & Software Requirements Hardware:  USB to RJ-11 Cable (Provided)  Zebra TM Label Printer  USB Port Software:  Production Studio (by Distech Controls)  EC-gfxProgram (by Distech Controls)  Microsoft Excel  Nice Label TM software
