1
M.Rogha M.D Isfahan university of medical sciences
Anatomy of the Ear M.Rogha M.D Isfahan university of medical sciences
2
Major Divisions of the Ear
Peripheral Mechanism Central Mechanism Outer Ear Middle Ear Inner Ear VIII Cranial Nerve Brain
3
External ear, Auris externa
Auricula Meatus acusticus externus Middle ear, Auris media Cavitas tympani Membrana tympanica Ossicula auditus Tuba auditiva Inner ear, Auris interna Labyrinthus membranaceus - Labyrinthus vestibularis - Labyrinthus cochlearis Labyrinthus osseus - Vestibulum - Canales semicirculares ossei - Cochlea - Meatus acusticus internus
4
Pinna External Auditory Meatus Outer Ear Pinna Preauricular Tags
Preauricular Pits EAM Cerumen Pinna External Auditory Meatus Function EAM resonance
5
Function of Outer Ear Collects sound Localization Resonator Protection
6
Pinna The visible portion that is commonly referred to as "the ear"
Helps localize sound sources Directs sound into the ear Each individual's pinna creates a distinctive imprint on the acoustic wave traveling into the auditory canal
7
External Auditory Meatus
Extends from the pinna to the tympanic membrane About 26 mm in length and 7 mm in diameter in adult ear. Size and shape vary among individuals. Protects the eardrum Resonator Provides about 10 decibels (dB) of gain to the eardrum at around 3,300 Hertz (Hz). The net effect of the head, pinna, and ear canal is that sounds in the 2,000 to 4,000 Hz region are amplified by 10 to 15 dB. Sensitivity to sounds greatest in this frequency region Noises in this range are the most hazardous to hearing
8
Outer ear Tissues: elastic cartilage covered with skin A. Meatus acusticus externus besides the hair follicles and fat glands contains: Glandulae ceruminosae – modified sweat glands on the lateral wall of the canal. Сerumеn (ear wax) combination of wax and fat glands secret and desquamated epithelial cells.
9
Middle Ear Tympanic Cavity Tympanic Membrane Ossicles Middle Ear Muscles Eustachian Tube Mastoid
10
Function of Middle Ear Conduction Protection Transducer Amplifier
Conduct sound from the outer ear to the inner ear Protection Creates a barrier that protects the middle and inner areas from foreign objects Middle ear muscles may provide protection from loud sounds Transducer Converts acoustic energy to mechanical energy Converts mechanical energy to hydraulic energy Amplifier Transformer action of the middle ear only about 1/1000 of the acoustic energy in air would be transmitted to the inner-ear fluids (about 30 dB hearing loss)
11
Tympanic cavity Volume – 1.5 ml Form – flatten drum
Structure – six walls: - Lateral - Medial - Anterior - Posterior - Superior - Inferior
12
Lateral wall
13
Tympanic Membrane Separates outer ear from middle ear
Barrier from foreign objects Cone-shaped in appearance about 17.5 mm in diameter Vibrates in response to sound waves. The membrane movement is incredibly small as little as one-billionth of a centimeter
14
Tympanic membrane Two parts: Pars flaccida – upper, thin, loose
Pars tensa – lower, tense Three layers: 1. Outer, cutaneous – continuation of the canal skin. No hairs and glands. 2. Middle, fibrous – elastic fibers. 3. Inner, mucous – tympanic cavity lining
15
Medial wall, paries labyrinthicus
Most complex. On this wall are distinguished: -fenestra vestibuli -fenestra cochleae -promontorium -prominentia canalis semicircularis lateralis - prominentia canalis facialis Superior wall, paries tegmentalis Separates tympanic from cranial cavity. Children less than 2 years – infections of the middle ear can pass to the cranial cavity.
16
Inferior wall, paries jugularis
Separates tympanic cavity from fossa jugularis Anterior wall, paries caroticus Separates tympanic cavity from canalis caroticus canalis musculotubularis Posterior wall, paries mastoideus Composed of: Styloid complex of Procter Antrum mastoideum Fossa incudis
17
Auditory (Eustachian) tube
Connects tympanic cavity with pharynx Two openings: ostium pharyngeum tubae ostium tympanicum tubae. Two parts: bony cartilagenous Function: Equalizes pressure on both sides of tympanic membrane for optimal hearing.
18
Ossicles Malleus (hammer) Incus (anvil)
Stapes (stirrup) smallest bone of the body
19
Inner Ear Auditory Vestibular Vestibular Cochlear semicircular canals
utricle and saccule Cochlear traveling wave pathologies Auditory Vestibular
20
Inner ear Two compartments: (а) Bony labyrinth and
(b) Membraneous labyrinth. Bony labyrinth: complex cavity in dense bone (pars petrosa) Parts of the bony labyrinth: a.Vestibulum. b. Semicircular canals. c.Cochlea.
21
Vestibulum and semicircular canals
Bony labyrinth. Labyrinthus osseus Vestibulum and semicircular canals
22
Vestibulum Two walls: External and internal. External wall has
Fenestra vestibuli. Internal wall has: Recessus ellipticus Recessus sphericus Recessus cochlearis Maculae cribrosae superior, medius, inferior
23
Openings into vestibulum
a. Fenestra vestibuli. b. Fenestra cochleae. c. Openings (5) of the semicircular canals d. Aqueductus vestibuli
24
Semicircular canals 3: anterior, posterior and lateral.
Have ampulla and crus. Canalis semicircularis lateralis –horizontal. - eminentia canalis semicircularis lateralis on the medial wall of tympanic cavity. Canalis semicircularis anterior –frontal. - eminentia arcuata on pars petrosa of os temporale. Canalis semicircularis posterior –sagittal
25
Labyrinthus osseus. Cochlea Meatus acusticus internus
26
Cochlea Cone-shaped: base and apex. Canalis spiralis cochleae
- promontorium, on the medial wall of tympanic cavity. Modiolus - canales longitudinales modioli. Lamina spiralis ossea hamulus Divides canalis spiralis cochleae into: Scala tympani Scala vestibuli
27
Labyrinthus membranaceus
28
Function of Inner Ear Converts mechanical sound waves to neural impulses that can be recognized by the brain for: Hearing Balance
29
Membraneous labyrinth. Labyrinthus membranaceus
Closed system of sacs and ducts underling the bony labyrinth. Filled with endolymph. Two parts: vestibular & cochlear.
30
Vestibular labyrinth Composed of : Two bags - sacculus et utriculus
Three ductus semicirculares One ductus endolymphaticus.
31
Cristra ampullaris
32
Balance Linear motion Rotary motion
33
Sensory cells (Epitheliocytus pilosus)
34
Macula utriculi (sacculi)
Otoliths. Statoconia
35
Static balance Maculae react to gravitational forces and participate in maintaining the static balance.
36
Dynamic balance Cristae ampullares react to rotatory movements and paticipate in dynamic balance.
37
Cochlea The cochlea resembles a snail shell and spirals for about 2 3/4 turns around a bony column Within the cochlea are three canals: Scala Vestibuli Scala Tympani Scala Media
38
Cochlear labyrinth Spiral canal - ductus cochlearis.
Occupies scala media of the spiral canal. Has two blind ends - cecum vestibulare and cecum cupulare. Has three walls: paries vestibularis paries externus paries tympanicus- organ of Corti, basal membrane
39
Organ of Corti End organ of hearing
40
Organ of Corti
41
Sensory cells of the organ of Corti
