1. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 1 Christophe Ménézo Professor University of Savoy / LOCIE Invited by INSA Lyon-CETHIL Christophe.menezo@univ-savoie.fr RENAISSANCE LYON WP Progress and Plans WP 2: Monitoring and Analysis

2. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 2 WP 2.1 Electrical Network Planned Activities: - Platform of measurements of the impact of the PV on the electrical distribution networks (at INSA of Lyon) - Measurements of the impact of PV systems installed in Lyon-Confluence Area on the distribution network

3. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 3 WP 2.1 Electrical Network Measurement Platform at INSA Electricity quality evaluation produced by standard EN 50-160 inverter Site : Electrical Engineering Dpt Definition of platform objectives and design Supplier (Tenesol) Done

4. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 4 Measurement series led on Lyon-Confluence Network Project Submission to the National Research Agency (ANR) Agreement between EDF R&D, INES RDI, Transénergie and INPGrenoble Contact with INSA School of Electrical Engineering Master student subject WP 2.1 Electrical Network Done

5. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 5 WP 2.1 Electrical Network Planed For next 18 months Measurement Platform at INSA Electricity quality evaluation produced by standard EN 50-160 inverter Definition of the measurements protocol Installation of the platform : 2 kWc Installation of Practical Courses for Engineering Students of INSA j Done

6. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 6 Measurement series led on Lyon-Confluence Network Constructive data-gathering of the distribution network on the Lyon-Confluence area Measurement Protocol definition with EDF R&D and INSA Waiting for construction of the buildings and PhotoVoltaic systems : delay in the construction schedule for blocks A, B, C => to see other place for measurements WP 2.1 Electrical Network Planed For next 18 months

7. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 7 WP 2.2 Experience Feedback - Monitoring Planned Activities: Multiscale Monitoring -Global Monitoring -Detailed Monitoring -Localised Monitoring ENERTECH

8. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 8 Global Monitoring (promoters and dealers) - Counting and sub-counting heating room and sub-station and Solar Domestic Hot Water - Counting and under counting electricity in building Detailed Monitoring (Enertech) - By housing - Followed Consumption: Cooking, lighting, washing machine - Followed thermal evolution Localised Monitoring (INSA-CETHIL) - Some residences which have been numerically modeled WP 2.2 Experience Feedback - Monitoring First contact with Inhabitants (Hespul, Promoters; INSA, Enertech)

9. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 9 Detailed Monitoring (Enertech) : expected results (such as in Restart Project) - WP 2.2 Experience Feedback - Monitoring Domestic Hot Water Human thermal gain Cooking Common Electricity Use Apartment Electricity Use Domestic Hot Water distribution Thermal Confort

10. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 10 Tests of sensors accuracy (INSA-CETHIL) Wireless sensors WP 2.2 Experience Feedback - Monitoring MINIBAT Identification of sensors (for Air temp. and Humidity) Use of Infrared camera (inside/outside?) Large range of : Temp. ; sampling time ; autonomy

11. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 11 Analysis of progress - Delays in construction => delays for monitoring - Submission of a new schedule to the EC (in relation with WP 1.5) Plans for the next 6 months - Training session organized for sales agents - Plans depend on the delays of construction + possibilities to extend the contract - First data aquisition in almost one year (minima) WP 2.2: Quality Control and Performance Analysis

12. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 12 Analysis of progress - Strong points : Zaragosa and Lyon not in phase - Experiences of Zaragosa not highlighted enough for Lyon - Networking opportunities should be much more used (webcam exchange for regular exchange for specific topics (focus), …) WP 2.3 European Highlight

13. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 13 Plans for the next 6 months (end of year 3) - Lyon strategy complete definition and planning of phases Comparison with Zaragossa - Common identification of what has to be highlight ? Identification of strong/weak points on each side? Definition of a monitoring strategy referential? WP 2.3 European Highlight

14. RENAISSANCE : a CONCERTO project financed by the European Commission on the six framework program RENAISSANCE - LYON - FRANCE 14 Christophe MENEZO Christophe.Menezo@univ-savoie.fr Contact ENERTECH
