Module 1: Siebel 7.7 on the Microsoft Platform

Module 1: Siebel 7.7 on the Microsoft Platform
4/20/2017 Module 1: Siebel 7.7 on the Microsoft Platform Siebel Global Deployments 1-Hogan Siebel

Siebel on Microsoft Siebel has run on Microsoft servers since first released Siebel is optimised and stable on the Microsoft platform All tiers of Siebel architecture supported on Microsoft platform Database Server - SQL Server Application Server - Windows Server Web Server - IIS Client - Internet Explorer

Siebel Analytics on Microsoft
Siebel Analytics is Siebel’s Business Intelligence (OLAP) Product Separate technical architecture to Siebel CRM (OLTP) Similar 4-tier web architecture Separate web, application and database servers Integrated with Siebel CRM client or standalone client All tiers supported on Microsoft platform Includes SQL Server 2000 for database Originally developed on Microsoft platform Analytics is optimised and stable on the Microsoft platform

Siebel 7.7 on the Microsoft Platform
Scalability / Performance / Availability Siebel Technical Architecture Covering Siebel 7.7 CRM Follow down through application stack Focus on new functionality in 7.7 Database covered in separate session

Introduction to Siebel Architecture From the Browser to the Web Server Web Server Scalability and Availability From the Web Server to the Siebel Server < Break > Siebel Server Scalability Siebel Server Availability

Siebel 7 Infrastructure Overview
Mobile Client Connected Web User (Employee) Connected Web User (External) PDA Wireless Web Browser UI Browser User Interface Browser User Interface Browser User Interface Object Manager WAP Gateway Server Data Manager Load Balancer Siebel Enterprise Central Siebel DB Server Object Manager Data Manager Siebel Web Server Extension Web Server SIEB SYNC Local DB Gateway Name Server Siebel Remote Voice Interaction Interaction External Applications Siebel eAI Siebel Replication Regional Siebel DB Server

Major Client Types All accessed through a browser
High Interactivity (Employee facing) Very demanding on browser Can only run on strictly defined browser configurations Rich user interface Standard Interactivity (Customer facing) Less demanding on browser Can run on wide variety of browsers Standard web user interface Mobile Client Has local copy of Siebel database Local server functionality Uses High Interactivity interface

Siebel Enterprise Server – SWSE
4/20/2017 Siebel Enterprise Server – SWSE Siebel Web Server Extensions (SWSE) Web Server Plug-In Manages communications to Siebel Enterprise Includes cache for static files (images, etc) IIS Web Server SWSE Gateway Name Server Enterprise Server Siebel Server Siebel Server Component Component Component Component 1-Hogan Siebel

Architecture Overview – Siebel Server
4/20/2017 Architecture Overview – Siebel Server Framework for running server components Obtains configuration information from the Gateway Name Server Runs as a Windows service Siebel Enterprise Server is a logical grouping of Siebel Servers IIS Web Server SWSE Gateway Name Server Enterprise Server Siebel Server Siebel Server Component Component Component Component 1-Hogan Siebel

Architecture Overview –Server Components
Siebel 4/20/2017 Architecture Overview –Server Components Server Program executed as Task Examples: Object Manager - User Sessions Workflow Process Manager - Business Processes File System Manager - Access to attachments IIS Web Server SWSE Gateway Name Server Enterprise Server Siebel Server Siebel Server Component Component Component Component 1-Hogan Siebel

Siebel Enterprise Server – Gateway Name Server
4/20/2017 Siebel Enterprise Server – Gateway Name Server Holds Enterprise Configuration Stores component definitions, parameters, and connectivity information Stored in siebns.dat file Dynamically registers Siebel Server and component availability IIS Web Server SWSE Gateway Name Server Enterprise Server Siebel Server Siebel Server Component Component Component Component 1-Hogan Siebel

Architecture Overview – Server Component Types
Siebel 4/20/2017 Architecture Overview – Server Component Types Background Background operations for the Siebel Server. Runs until you explicitly stop the task, or until the Siebel Server itself is shut down. Interactive Start automatically in response to client requests. Run as long as the client maintains the session, and end when the client disconnects. Batch Execute in response to requests. Batch mode component tasks execute until they finish processing. 1-Hogan Siebel

Architecture Overview – Component Execution Platforms
Siebel 4/20/2017 Architecture Overview – Component Execution Platforms Single Threaded Single threaded components have one execution stream per process. So each operating system process supports a single Siebel Task. i.e. EIM Multi-Threaded Multi-threaded components have multiple execution streams within a single process. So each operating system process can support multiple Siebel Tasks. i.e. Object Managers 1-Hogan Siebel

Introduction to Siebel Architecture From the Browser to the Web Server Web Server Scalability and Availability From the Web Server to the Siebel Server Siebel Server Scalability Siebel Server Availability

Network Scalability –Browser Settings
Don’t clear cache except when necessary Ensure ‘Empty Temporary Internet Files Folder when browser is closed’ option is not enabled.

Network Scalability – Content Expiration
Uncached GET: ‘icon.gif’ 25KB RESPONSE: ‘icon.gif’ DATE: 10/10/03 09:25:08 LAST-MODIFIED: 10/08/03 07:14 icon.gif DATE: 10/08/03 07:14

GET: ‘icon.gif’ IF-MODIFIED-SINCE: 10/10/03 09:25 Cached 2KB RESPONSE: Not-modified icon.gif DATE: 10/10/03 09:25 icon.gif DATE: 10/08/03 07:14

Cached with Expiration 0KB icon.gif DATE: 10/10/03 09:25 EXPIRES: 10/12/03 14:13:08 icon.gif DATE: 10/08/03 07:14

IIS Settings Set Content Expiration 2 days is typical setting Set through Internet Information Services Administration HTTP Headers > Content Expiration

Network Scalability – Web Server
Use HTTP keep-alive Reduces the need to negotiate TCP sessions for each HTTP message

Network Scalability – Compression
Compression (Static Content) Performed by web server (IIS)

Network Performance – Compression
Compression (Dynamic Content) Performed by SWSE Typically gives 50% reduction in data volumes Low CPU overhead Do not use web server dynamic compression (application files) Enabled through SWSE configuration file (‘eapps.cfg’) [Defaults] DoCompression = TRUE

Web Server Scalability
SWSE implemented as Plug-In to IIS 6 Full access to scalability features of IIS Multi-threading Processor affinity Large memory caching

Web Server Scalability
Can use Load Balancing to scale across multiple web servers Any load balancer can be used i.e. Microsoft Network Load Balancing (NLB) No need for session persistence Except when SSL used May not have all content available from all web servers i.e. Different object managers accessed through different groups of web servers In this case the load balancer will need to support layer 7 (content) switching

Web Server Load Balancing
Siebel 4/20/2017 Web Server Load Balancing Server Manager GUI Web Client Wireless Client Mobile Web Client Handheld Client Dedicated Web Client Wireless Gateway Server Mobile SQL DB CE Web Servers with SWSE Load Balancer Gateway Name Server Load Balancers Siebel Enterprise Server Siebel Servers Server Manager Siebel file System Siebel Database 1-Hogan Siebel

Web Server Availability
Can be clustered (Microsoft Server Cluster) but Load Balancing preferable Any load balancer can be used No special load balancer requirements for high availability Sessions should be maintained if a web server fails No need for users to log in again May need to login again if using: SSL CTI

Web Server Availability
Siebel 4/20/2017 Web Server Availability Server Manager GUI Web Client Wireless Client Mobile Web Client Handheld Client Dedicated Web Client Wireless Gateway Server Mobile SQL DB CE Web Servers with SWSE Load Balancer Gateway Name Server Load Balancers Siebel Enterprise Server Siebel Servers Server Manager Siebel file System Siebel Database 1-Hogan Siebel

Background – Siebel Server Load Balancing
Siebel 7.5 and prior integrates with Resonate Central Dispatch for Server Load Balancing Required for any customer load balancing 2 or more web servers OR application servers Siebel 7.7 supports two mechanisms for Server Load Balancing Siebel-Provided load balancing Third Party (Standard) HTTP Load Balancers F5 Big-IP initial solution for certification Resonate no longer supported Can optionally still be used as an unsupported 3rd party load balancer

Background – Siebel Server Load Balancing
New Component Siebel Connection Broker (SCB) Accepts all connections for Object Managers Listens on a single static port Default: 2321 No need for many dynamic ports Simplifies connectivity between web servers and Siebel Servers

Siebel Architecture – Siebel 7.0.x and 7.5.x
HTTP Load Balancer Web Browser HTTP HTTPS HTTP HTTPS Web Server Web Server Web Server Web Server SWSE SWSE SISNAPI VIP/VPort Resonate Central Dispatch SISNAPI Listening Ports Listening Ports OM OM OM OM OM OM Comp. SRB SRB Siebel Server Siebel Server SISNAPI

Siebel Architecture – Siebel 7.7 Third Party HTTP Load Balancer
Web Browser HTTP HTTPS HTTP HTTPS Web Server Web Server Web Server Web Server SWSE SWSE SISNAPI VIP/VPort HTTP Load Balancer SISNAPI Listening Port Listening Port Siebel Server Siebel Server SCBroker SCBroker OM OM OM OM OM OM SRB SRB Comp. SISNAPI

Siebel Architecture – Siebel 7.7 Siebel-Provided Load Balancing
HTTP Load Balancer Web Browser HTTP HTTPS HTTP HTTPS SWSE Web Server Web Server Web Server Web Server SWSE SISNAPI SISNAPI Listening Port Listening Port Siebel Server SCBroker Siebel Server SCBroker OM OM OM OM OM OM SRB Comp. SRB SISNAPI

Technical Benefits of Siebel 7.7 Load Balancing Support
Lowers the total cost of ownership Offers flexibility in choosing application server load balancing Designed to interoperate with Standard HTTP load balancers Can use advanced network features of Microsoft Platform No more limitation on NIC support Support for NIC Teaming Support for IPSec Speed up Siebel Server startup/shutdown Lowers the overall complexity of Siebel Environment

When to implement server load balancing
Load balancing multiple Siebel Application Servers Run the same object manager across multiple Siebel Servers Load balancing multiple Web Servers Load balancing Siebel Servers is no longer mandatory, as SISNAPI reconnect will work in any scenario

Implementation – Initial Connection
SWSE Web Server Web Server Load balancer determines which Siebel Server to connect to SCBroker OM Siebel Server SCBroker OM Siebel Server

Implementation – Retry
SWSE Web Server Web Server Initial connection fails Component unavailable Retry must go to different server i.e. Round Robin SCBroker OM Siebel Server SCBroker OM Siebel Server

Implementation – Reconnect
SWSE Web Server Web Server Reconnect must go to the same server Existing connection lost SCBroker OM Siebel Server SCBroker OM Siebel Server

Three Types of Connection to Support
Initial Connection When a session is first started Can go to any eligible Siebel Server Should apply any load balancing algorithm required Retry When an initial connection fails Must retry a different Siebel Server Use ‘round-robin’ to achieve this Reconnect When existing session lost Must reconnect to same server – no load balancing at all

Siebel Native Load Balancing Features
Replace the load balancing feature provided by Resonate Central Dispatch Without the maintenance overhead of Resonate No cost for third party load balancers Distributes new SISNAPI connection request in a round robin fashion across Siebel Servers Proven to work well for most Siebel deployments Supports SISNAPI reconnect out of box Built into Siebel Web Server Extension Configuration resides in the web server

Siebel Native Load Balancing Implementation
Performed in the SWSE Allocates sessions to Siebel Servers in turn New concept of “Virtual Server” Logical grouping of Siebel Servers Defined in ‘lbconfig.txt’ file Referenced in ‘eapps.cfg’ file instead of Gateway/VIP Can manually create virtual servers Useful for spreading different user communities across different groups of Siebel Servers

Siebel Native Load Balancing Implementation
Load Balancing File (lbconfig.txt) Can be automatically generated through Siebel Server Manager # generate lbconfig Defines virtual server(s) Can use different virtual servers for different applications <VirtualServer>=<ID>:<Host>:<Port>; <ID>:<Host>:<Port> i.e. VirtualServer1=1:SiebSrvr1:2321;2:SiebSrvr2:2322 VirtualServer2=1:SiebSrvr1:2321;2:SiebSrvr3:2321 OM Connect Strings (eapps.cfg) Use Virtual Servers as Enterprise hosts Call Center: siebel.TCPIP.none.none://VirtualServer1/Siebel/SCCObjMgr Sales: siebel.TCPIP.none.none://VirtualServer2/Siebel/SSEObjMgr

Third Party HTTP Load Balancing Features
Provides the same basic load balancing functionality as Siebel-Provided Load Balancing Can distribute load using variety of criteria Provides advanced network administration and monitoring capabilities Can monitor application server availability and route accordingly Provides flexible configuration options Allows customer to segment load balanced Siebel Servers Can be integrated with other third party monitoring and management tools Provides more security features Depending on specific load balancer

Third Party Load Balancer Implementation
Initial Connection Should apply any load balancing algorithm required 1 rule needed per component Retry Must use ‘round-robin’ algorithm Reconnect Must reconnect to same server – no load balancing at all 1 rule needed per server

Required rules included in ‘lbconfig.txt’ file Must manually implement for unsupported load balancers #Section two -- 3rd Party Load Balancer Rules #Component Rules: /siebel/eServiceObjMgr_enu/=host1:2321;host2:2321; /siebel/SCCObjMgr_enu/=host1:2321;host3:2321; #Server Rules: */!1.*=host1:2321; */!2.*=host2:2321; */!3.*=host3:2321; #Round Robin Rules: /siebel/eServiceObjMgr_enu/RR=host1:2321;host2:2321; /siebel/SCCObjMgr_enu/RR=host1:2321;host3:2321;

Must be able to process different URL forms to recognise different rule types Component Rules (Initial Connect): /<ent>/<component>/=<host1>:<port1>;<host2>:<port2>; Example: /prod/SCCObjMgr_enu/=svr1:2321;svr2:2321; Server Rules (Reconnect): */!<serverid>.*=<host>:<port>; Example: */!1.*=svr1:2321; Round Robin Rules (Retry): /<ent>/<component>/RR=<host1>:<port1>;<host2>:<port2> Example: /prod/SCCObjMgr_enu/RR=svr1:2321;svr2:2321;

Third Party Load Balancer Support
F5 BigIP Supported Support available through Siebel Documented integration with Siebel using perl scripts Tested with Siebel Siebel supported with other load balancers Siebel doesn’t directly support other load balancers Must refer to load balancer vendor for support Manual integration required to implement load balancing rules for Siebel Instructions for integration with Siebel may not be available See Siebel Supported Platforms documentation for current status

Siebel-Provided or Third Party HTTP Load Balancing?
Is a third-party HTTP load balancer already in use? Are the capabilities offered by third party HTTP load balancer needed? Load balancing Security Management and Monitoring Size of the deployment does not necessarily matter

Siebel-Provided or Third Party HTTP Load Balancing?
Central Dispatch Siebel-Provided Third Party Installation/ Configuration Sometimes complex Part of Siebel Install Varies by customer Load balancing Resource-based Round-Robin Response & Resource-based Monitoring Proprietary Resonate Interface Part of Siebel Server Admin Extensive 3rd party int. support Scalability Up to 64 node per site No hard limit Limited by HW capacity

Time for a Break…

Component Scalability
Scaling within a server Multi-threaded components Siebel Connection Broker Scaling across servers Load balancing Focus on Object Managers (user sessions)

Scaling Within a Siebel Server
Multi-Threaded Components Create multiple threads (Tasks) & processes (MTServers) Control distribution through component parameters Single Threaded Components Create multiple processes (Tasks) Some components are limited i.e. Transaction Processor – max 1 per server Workflow Monitor Agent – max 1 per policy group per Enterprise Can be started manually, through Server Request Broker, or automatically (‘Default Tasks’ parameter)

Multi-Threaded Components
Can have multiple processes as well as multiple threads Important to control ratio of threads to processes Can have major impact on performance Determined primarily by rate of switches between threads 100:1 good starting point for Client Object Managers Assumes 30sec think time, for 15 sec think time use 50:1 Can set additional processes to spawn on demand Will always start minimum number specified Will start additional processes as needed to maintain process:thread ratio Limit on maximum number of processes

Multi-Threaded Component Parameters
Siebel 4/20/2017 Multi-Threaded Component Parameters Typically set per component Maximum number of tasks (MaxTasks) Maximum number of Tasks per component per server One thread per task Some additional background “system” threads - not counted by MaxTasks 1-Hogan Siebel

Multi-Threaded Component Parameters
Siebel 4/20/2017 Multi-Threaded Component Parameters Maximum number of Multi-Threaded servers (MaxMTServers) An MTServer is a multi-threaded component process This defines the maximum number of MTServers per component per server Minimum number of Multi-Threaded servers (MinMTServers) This defines the minimum number of MTServers per component per server Sets the number of MTServers started on server startup 1-Hogan Siebel

Configuring the Object Managers
Siebel 4/20/2017 Configuring the Object Managers Set MaxTasks = peak concurrent users No need to assign separate tasks for Anonymous users from Siebel 7.7 Anonymous users are used for login screens before user authenticates Typically set to 10%-15% of concurrent user count Siebel 7.0.x & 7.5.x needed a pool of tasks for anonymous sessions included in the total available tasks Should leave headroom for uneven load balancing Consider allowing for failure of a server User load will need to be supported with one less server 1-Hogan Siebel

Configuring the Object Managers
Siebel 4/20/2017 Configuring the Object Managers Set MaxMTServers = MaxTasks / 100 An MTServer is equivalent to single process 100 : 1 ratio is assuming “average” 30 second think time between user operations If average user think time is 15 seconds then ratio is 50 : 1 ( 50% of 100:1) If average user think time is 60 seconds then ratio is 200 : 1 (200% of 100:1) Set MinMTServers = MaxMTServers Setting MinMT Servers < MaxMTServers may cause delay of service for “new” users as MTServer gets initialized. 1-Hogan Siebel

Multi-Threaded Component Parameter Example
Siebel 4/20/2017 Multi-Threaded Component Parameter Example Object Manager configuration for 800 Call Center users Concurrent Users 800 Call Center Users Headroom 140 5% leeway 100 for server failure MaxTasks 940 Object Manager Round up to maintain 100:1 ratio MaxTasks 1000 MaxMTServers 10 100:1 MinMTServers 10 1-Hogan Siebel

Memory Scalability Multi-Process, Multi-Threaded model
Multi-threaded components support many concurrent operations in a single process All threads in a process share the same memory space Multiple processes can be deployed, each with multiple threads Each Process has a separate memory space

Object Manager Memory Scalability
Per-Process (MTServer) Memory Typically MB Allocated when process starts up Per-Thread (Task) Memory Typically 5-12MB Allocated first time task starts Not released when task exits So 100:1 Task:MTServer requires about 1GB Note: These values vary considerably with different deployments

Memory Scalability on Windows
No single process needs a large memory space Each Windows process can use up to 4GB of memory 2GB User, 2GB Kernel (3GB User, 1GB Kernel with ‘/3GB’ switch) If a single Siebel process needs more than 1.5GB there’s normally something wrong No need for large process memory model (‘/3GB’ switch) No benefit for Siebel software Siebel will always use 2GB allocation regardless No need for 64-bit support Would provide native support for larger memory space per process 64-bit Windows server not currently supported for Siebel software (but supported for SQL Server)

Windows Server 2003 provides up to 64GB RAM for Siebel Operating system manages memory allocation Can use PAE for access to large memory capacities For servers with over 4GB RAM ‘/PAE’ switch in ‘boot.ini’ file Total server memory shared across many Processes Process limited to 4GB, not the server

1GB – Object Manager 4GB 1GB – Object Manager 1GB – Object Manager 1GB – Object Manager 0.5GB – System/Misc.

8GB Can continue scaling beyond 8GB to larger memory models 1GB – Object Manager 1GB – Object Manager 1GB – Object Manager 1GB – Object Manager /PAE Switch 1GB – Object Manager 1GB – Object Manager 1GB – Object Manager 0.5GB – System/Misc.

Load balancing between processes
A single Object Manager component typically has many processes (MTServers) on a server Need a mechanism to distribute sessions evenly across processes Before 7.7 done through operating system features Often led to unequal distribution and degraded scalability Siebel Connection Broker component Accepts new connections for al OM processes All components Hands off to individual processes Based on number of concurrent sessions on each process

Internal Object Manager Load Balancing
Web Server Sales OM Siebel Server Siebel Connection Broker Sales Object Manager Sales Object Manager Sales Object Manager Service Object Manager

Siebel Connection Broker Service Object Manager
Internal Object Manager Load Balancing Web Server Sales OM Siebel Server Siebel Connection Broker Sales Object Manager Sales Object Manager Sales Object Manager Service Object Manager

Siebel Connection Broker Service Object Manager
Internal Object Manager Load Balancing Web Server Service OM Siebel Server Siebel Connection Broker Sales Object Manager Sales Object Manager Sales Object Manager Service Object Manager

Multi-Threaded Component Scalability
Siebel 4/20/2017 Multi-Threaded Component Scalability Enterprise Server Vertical Scalability Siebel Server Siebel Server Sales Object Manager Sales Object Manager Sales Object Manager Horizontal Scalability 1-Hogan Siebel

Enterprise-Wide Scalability
Siebel 4/20/2017 Enterprise-Wide Scalability Web Client Load Balancing Web Server + SWSE Load Balancing Enterprise Server Siebel Server Server SCB SCB Sales Object Manager Process Thread 1-Hogan Siebel

Siebel Server Availability
As well as scalability also need to consider server availability Some of the same features which provide scalability can also enhance availability

Siebel Server Availability – Siebel Server Failure
Server Manager GUI Web Client Wireless Client Mobile Web Client Handheld Client Dedicated Web Client Wireless Gateway Server Mobile SQL DB CE Web Servers with SWSE Load Balancer Gateway Name Server Load Balancers Siebel Enterprise Server Siebel Servers Server Manager Siebel file System Siebel Database

Siebel Server Availability – Siebel Server Failure
Server Manager GUI Web Client Wireless Client Mobile Web Client Handheld Client Dedicated Web Client Web Server Load Balancing User logs in again Wireless Gateway Server Mobile SQL DB CE Web Servers with SWSE Third Party load balancers Load Balancer Gateway Name Server Load Balancers Logs in to different Siebel Server Siebel Enterprise Server Siebel Servers Server Manager Siebel file System Siebel Database

Siebel Server Availability - Load Balancer Failure
4/20/2017 Siebel Server Availability - Load Balancer Failure Server Manager GUI Web Client Wireless Client Mobile Web Client Handheld Client Dedicated Web Client Wireless Gateway Server Mobile SQL DB CE Web Servers with SWSE Load Balancer Gateway Name Server Load Balancers Siebel Enterprise Server Siebel Servers Server Manager Siebel file System Siebel Database Note: This assumes redundant third-party load balancers are used 1-Hogan Siebel

Siebel Server Availability
4/20/2017 Siebel Server Availability Load Balancing provides High Availability for Object Managers What about other Components? Can use Distributed Services Components running on more than one server Components called as server requests through Server Request Broker Built-in to Siebel Server architecture – no additional configuration required Can use failover clusters 1-Hogan Siebel

Distributed Services Web client requests Assignment task
Web Server Web client requests Assignment task Siebel Enterprise Server Assignment Manager Service Request Broker determines if Assignment Task is available locally Object Manager If yes, then the task is run locally SRBroker SRBroker SRBroker Workflow Process Manager Workflow Process Manager Assignment Manager

Web client requests Workflow task
Distributed Services Web Client Web Server Web client requests Workflow task Siebel Enterprise Server Service Request Broker determines if Workflow Process Mgr is available locally Assignment Manager Object Manager No, tasks are assigned on a round-robin basis to servers that have Workflow Process Mgr. running SRBroker SRBroker SRBroker Workflow Process Manager Workflow Process Manager Assignment Manager

Web client requests Assignment task
Distributed Services Web Client Web Server Web client requests Assignment task Siebel Enterprise Server Service Request Broker determines if Assignment Task is available locally Assignment Manager Assignment Manager Object Manager Local Assignment Manager component is unavailable, so request routed to other Assignment Manager SRBroker SRBroker SRBroker Workflow Process Manager Workflow Process Manager Assignment Manager

Failover Clusters - Usage
Siebel 4/20/2017 Failover Clusters - Usage Gateway Name Server Siebel File System Siebel Server Siebel Remote Workflow Policies Dynamic Assignment And others….. Siebel Database Server 1-Hogan Siebel

Failover Clusters - Introduction
Siebel 4/20/2017 Failover Clusters - Introduction Service available from one server Siebel implement through failover clusters (Microsoft Server Clusters) Siebel services restart on other physical server Can be accessed through same network name / IP address on either physical server Failover is transparent and automatic 1-Hogan Siebel

Failover Services – How they work
Storage Network Processes Physical Server Storage Network Processes Physical Server Storage Network Processes Logical Server Shared Storage

Failover Services – Cluster Deployment Models
Active-Passive Application only live on one host in cluster Other host acts as warm standby only No performance degradation on failover Low return on investment on second server Physical Logical

Active-Active Applications live on both hosts in cluster Performance degraded on failover due to additional load Better return on investment on second server Logical Physical

Physical Server Physical Server Gateway Name Server Logical Server Siebel File System Logical Server Siebel Server Logical Server Siebel Server Logical Server

Installing Siebel on Microsoft Server Clusters
Clustered Software must always be installed on clustered disks Do not install Siebel on quorum disk Clustered IP Addresses/Network names must always be used to access clustered Siebel resources Otherwise resource can’t be accessed after failover Always give clustered Gateway IP/Name

Cluster Groups should be configured before installing Siebel Use separate group to Administration/Quorum group Each group must have: Disk(s) IP Address Network Name Always use domain accounts

Integration with Microsoft Server Clusters
Siebel uses Generic Service resource type Each siebel item (Gateway/Server) has simple interaction with Windows Server Can be controlled through single Process (siebsvc) run as service No need for custom resource type, and no plans to provide Get service name from Registry or service properties [HKEY_LOCAL_MACHINE\System\CurrentControlSet\Services] Gateway : gtwyns Server : siebsrvr_<Ent>_<Srvr> i.e. siebsrvr_EntSieb752_srvr1

Sample Cluster Resources – Siebel Server

Non-Standard Cluster Resource Settings Siebel Server Services Restarts - Threshold: 10 Try & restart the Siebel Server 10 times before failing over. Gives any time needed for a Gateway to start. Pending Timeout – 300 seconds Allows 300 seconds for a Siebel Server to shutdown before being marked as failed

Installing Siebel on Clusters - Issues
Siebel Server Host Parameter Set to physical hostname of server installed upon Prevents Server Manager from connecting when server on other node Change through Server Manager: change param Host= virtualhost_name for serverlogical_Siebel_Server name

Installing Siebel on Clusters - Issues
Network Name Siebel must use cluster network name Must ensure that ‘Use Network Name for Computer Name’ tick box selected in Siebel Server service resource Requires Network Name and IP Address resource dependencies (NT Only)

Clustering the Siebel File System
Just need a clustered network share Use the ‘File Share’ cluster resource type Siebel File System must reside on a clustered disk

Any Questions….

Module 1: Siebel 7.7 on the Microsoft Platform
4/20/2017 Module 1: Siebel 7.7 on the Microsoft Platform Siebel Global Deployments 1-Hogan Siebel

Network Performance – Siebel Configuration
Browser Validation Reduces the need for server communications to validate data entry Implement through browser script Immediate Posting of Changes Where the ‘Immediate Post Changes’ flag is set against a field data will be transferred whenever a field is changed Incurs additional round trip with approx 2KB data Keep to no more than two Applets per View Minimize Popups Limit columns in List Applets

Network Performance – Siebel Settings
View Caching View definitions cached in browser memory From Siebel 7.7 disk caching also available Requires approx 3MB memory per view Typically around 10 memory cached views is enough Uses LRU algorithm to maintain cache contents Personalization and Applet Toggles won’t use view caching

Network Performance – Siebel Settings
View Caching Enabled through Object Manager configuration (.cfg) file setting [SWE] EnableViewCache=TRUE Controlled through: User Preferences > Behaviour > View Cache Size Default: 10

Server Request Broker Used to start synchronous Siebel Server tasks
Server Request Broker & Server Manager are the only components which directly start tasks. New in Siebel 7 Replaces Server Request Manager (SRMSynch) in Siebel 2000 Background component Multi-threaded component Need to set MaxTasks accordingly

Server Request Broker Manages requests from other Components
Will try to service request locally If component is available on same Siebel Server then this is always used If not available locally then will use other Siebel Servers Maintains internal table of components available on each Siebel Server Will route requests round Siebel Servers in turn Multi-threaded component May need to increase MaxTasks Should always be running on all servers

Server Request Processor
Used to start asynchronous Siebel Server tasks Manages queued requests Calls SRBroker to manage task execution Background component

Siebel Server – Server Request Broker
Run Assignment Task Assignment Manager Object Manager Is Assignment available on this server? Run Assignment on local server Server Request Broker Server Request Broker Server Request Broker Workflow Process Manager Assignment Manager Workflow Process Manager

Siebel Server – Server Request Broker
Run Workflow Process Assignment Manager Object Manager Is Workflow Manager available on this server? Server Request Broker Server Request Broker Server Request Broker Which other servers have workflow online? Choose server on round-robin basis Workflow Process Manager Assignment Manager Workflow Process Manager

Server Request Processor
Processes asynchronous requests Request submitted by creating record in table S_SRM_REQUEST Server Request Processor reads from table Request must: Be active (reached activation time) Not be specified for a different Siebel Server Not being processed by other Server Request Processor Eligible requests submitted through Server Request Broker Normally runs on all Siebel Servers

Siebel Server – Server Request Processor
Sleep Interval SRProc S_SRM_REQUEST Request Queue SRBroker Task

Performance and Scalability
Architecture Overview Component Scalability Scalability Across Components Network Scalability Performance Optimization Performance Management

Connection Pooling Siebel 7 can pool sessions at two levels:
Web server to Siebel Enterprise SISNAPI Connection Pooling Multiple SISNAPI (Siebel) sessions through one TCP session Reduces operating system overhead and network traffic Enabled by default Set to 20 Controlled by component parameter: ‘Number of Sessions per SISNAPI Connection’ Siebel Object Manager to Database Database connection pooling SQL traffic for multiple Siebel users through one database session Reduces session overheads on database server Disabled by default Suitable for larger deployments (over 500 concurrent users)

Database Connection Pooling
Connections use native database protocols Some components directly access native protocol Object Managers Siebel 7 supports its own database connection pooling Used for connections from Object Managers Two types of connection Shared – for general transactions Specialized – for long running Not always appropriate Should carefully evaluate tradeoffs Benefits of less database sessions to maintain Risk of database session contention

Database Connection Pooling
Database session uses login for first user to establish session Database connection pooling controls Defined as component parameters Set to ‘-1’ to disable (default) Specialized (Dedicated) Database sessions All valid per component process (MT Server) per Siebel Server MaxTrxDbConns - Maximum number of specialized DB sessions MinTrxDbConns - Minimum number of specialized DB sessions to be kept in pool Shared Database sessions Valid per component per Siebel Server MaxSharedDbConns - Maximum number of shared DB sessions MinSharedDbConns - Minimum number of shared DB sessions to be kept in pool

Database Network Architecture
Client Connections Siebel Server Server Request Processor Object Manager Shared Shared Specialized Native Database Connectivity (ODBC for SQL Server) Siebel Database Threads (sessions) Processes (components)

Module 1: Siebel 7.7 on the Microsoft Platform

Similar presentations

Presentation on theme: "Module 1: Siebel 7.7 on the Microsoft Platform"— Presentation transcript:

Similar presentations

About project

Feedback

Log in

Auth with social network:

Module 1: Siebel 7.7 on the Microsoft Platform

Similar presentations

Presentation on theme: "Module 1: Siebel 7.7 on the Microsoft Platform"— Presentation transcript:

Similar presentations

About project

Feedback
