1. Computer Architecture
Princess Sumaya University for Technology
Computer Architecture
Dr. Esam Al_Qaralleh

3. Instruction Set Architecture
(ISA)

4. Classifying instruction set architectures Instruction set measurements
Outline
Introduction
Classifying instruction set architectures
Instruction set measurements
Memory addressing
Addressing modes for signal processing
Type and size of operands
Operations in the instruction set
Operations for media and signal processing
Instructions for control flow
Encoding an instruction set
MIPS architecture

5. Instruction Set Principles and Examples

6. Basic Issues in Instruction Set Design
What operations and How many
Load/store/Increment/branch are sufficient to do any computation, but not useful (programs too long!!).
How (many) operands are specified?
Most operations are dyadic (e.g., AB+C); Some are monadic (e.g., A B).
How to encode them into instruction format?
Instructions should be multiples of Bytes.
Typical Instruction Set
32-bit word
Basic operand addresses are 32-bit long.
Basic operands (like integer) are 32-bit long.
In general, Instruction could refer 3 operands (AB+C).
Challenge: Encode operations in a small number of bits.

7. Brief Introduction to ISA
Instruction Set Architecture: a set of instructions
Each instruction is directly executed by the CPU’s hardware
How is it represented?
By a binary format since the hardware understands only bits
Options - fixed or variable length formats
Fixed - each instruction encoded in same size field (typically 1 word)
Variable – half-word, whole-word, multiple word instructions are possible
opcode rs rt
Immediate

8. Instruction Format (encoding) Location of operands and result
What Must be Specified?
Instruction Format (encoding)
How is it decoded?
Location of operands and result
Where other than memory?
How many explicit operands?
How are memory operands located?
Data type and Size
Operations
What are supported?

9. Example of Program Execution
Command
1: Load AC from Memory
2: Store AC to memory
5: Add to AC from memory
Add the contents of memory 940 to the content of memory 941 and stores the result at 941
Fetch
Execution

10. Classifying Instruction Set Architecture

11. Instruction Set Design
The instruction set influences everything

12. Instruction Characteristics
Usually a simple operation
Which operation is identified by the op-code field
But operations require operands - 0, 1, or 2
To identify where they are, they must be addressed
Address is to some piece of storage
Typical storage possibilities are main memory, registers, or a stack
2 options explicit or implicit addressing
Implicit - the op-code implies the address of the operands
ADD on a stack machine - pops the top 2 elements of the stack, then pushes the result
HP calculators work this way
Explicit - the address is specified in some field of the instruction
Note the potential for 3 addresses - 2 operands + the destination

13. Classifying Instruction Set Architectures
Based on CPU internal storage options AND # of operands
These choices critically affect - #instructions, CPI, and cycle time

14. Operand Locations for Four ISA Classes

15. Register (register-memory)
C=A+B
Stack
Push A
Push B
Add
Pop the top-2 values of the stack (A, B) and push the result value into the stack
Pop C
Accumulator (AC)
Load A
Add B
Add AC (A) with B and store the result into AC
Store C
Register (register-memory)
Load R1, A
Add R3, R1, B
Store R3, C
Register (load-store)
Load R2, B
Add R3, R1, R2

16. Modern Choice – Load-store Register (GPR) Architecture
Reasons for choosing GPR (general-purpose registers) architecture
Registers (stacks and accumulators…) are faster than memory
Registers are easier and more effective for a compiler to use
(A+B) – (C*D) – (E*F)
May be evaluated in any order (for pipelining concerns or …)
But on a stack machine  must left to right
Registers can be used to hold variables
Reduce memory traffic
Speed up programs
Improve code density (fewer bits are used to name a register)
Compiler writers prefer that all registers be equivalent and unreserved
The number of GPR: at least 16

17. Characteristics Divide GPR Architectures
# of operands
Three-operand: 1 result and 2 source operands
Two-operand – 1 both source/result and 1 source
How many operands are memory addresses
0 – 3 (two sources + 1 result)
Load-store
Register-memory
Memory-memory

18. Pro’s and Con’s of Three Most Common GPR Computers
Register-Register: (0,3)
+ Simple, fixed length instruction encoding.
+ Simple code-generation model.
+ Similar number of clocks to execute.
- Higher instruction count.
Memory-memory: (3,3)
+ Most compact.
- Different Instruction size.
- Memory access bottleneck.
Register-Memory: (1,2)
+ Data access without loading first.
+ Easy to encode and yield good density.
- One operand is destroyed.
- Limited number of registers.

19. Memory Addressing

20. Memory Addressing Basics
All architectures must address memory
What is accessed - byte, word, multiple words?
Today’s machine are byte addressable
Main memory is organized in byte lines
Big-Endian or Little-Endian addressing
Hence there is a natural alignment problem
Size s bytes at byte address A is aligned if
A mod s = 0
Misaligned access takes multiple aligned memory references
Memory addressing mode influences instruction counts (IC) and clock cycles per instruction (CPI)

21. Big Endian: Byte 0 is most, 3 is least
Byte Ordering
Idea
Bytes in long word numbered 0 to 3
Which is most (least) significant?
Can cause problems when exchanging binary data between machines
Big Endian: Byte 0 is most, 3 is least
IBM 360/370, Motorola 68K, SPARC.
Little Endian: Byte 0 is least, 3 is most
Intel x86, VAX
Alpha
Chip can be configured to operate either way
DEC workstation are little endian
Cray T3E Alpha’s are big endian

22. Byte Ordering Example union { unsigned char c[8]; unsigned short s[4];
unsigned int i[2];
unsigned long l[1];
} dw;
c[3]
s[1]
i[0]
c[2]
c[1]
s[0]
c[0]
c[7]
s[3]
i[1]
c[6]
c[5]
s[2]
c[4]
l[0]

23. Byte Ordering on Alpha Little Endian Output on Alpha: f0 f1 f2 f3 f4
c[0]
c[1]
c[2]
c[3]
c[4]
c[5]
c[6]
c[7]
LSB
MSB
LSB
MSB
LSB
MSB
LSB
MSB
s[0]
s[1]
s[2]
s[3]
LSB
MSB
LSB
MSB
i[0]
i[1]
LSB
MSB
l[0]
Print
Output on Alpha:
Characters 0-7 == [0xf0,0xf1,0xf2,0xf3,0xf4,0xf5,0xf6,0xf7]
Shorts == [0xf1f0,0xf3f2,0xf5f4,0xf7f6]
Ints == [0xf3f2f1f0,0xf7f6f5f4]
Long == [0xf7f6f5f4f3f2f1f0]

24. Byte Ordering on x86 Little Endian Output on Pentium: f0 f1 f2 f3 f4
c[0]
c[1]
c[2]
c[3]
c[4]
c[5]
c[6]
c[7]
LSB
MSB
LSB
MSB
LSB
MSB
LSB
MSB
s[0]
s[1]
s[2]
s[3]
LSB
MSB
LSB
MSB
i[0]
i[1]
LSB
MSB
l[0]
Print
Output on Pentium:
Characters 0-7 == [0xf0,0xf1,0xf2,0xf3,0xf4,0xf5,0xf6,0xf7]
Shorts == [0xf1f0,0xf3f2,0xf5f4,0xf7f6]
Ints == [0xf3f2f1f0,0xf7f6f5f4]
Long == [f3f2f1f0]

25. Byte Ordering on Sun Big Endian Output on Sun: f0 f1 f2 f3 f4 f5 f6 f7
c[0]
c[1]
c[2]
c[3]
c[4]
c[5]
c[6]
c[7]
MSB
LSB
MSB
LSB
MSB
LSB
MSB
LSB
s[0]
s[1]
s[2]
s[3]
MSB
LSB
MSB
LSB
i[0]
i[1]
MSB
LSB
l[0]
Print
Output on Sun:
Characters 0-7 == [0xf0,0xf1,0xf2,0xf3,0xf4,0xf5,0xf6,0xf7]
Shorts == [0xf0f1,0xf2f3,0xf4f5,0xf6f7]
Ints == [0xf0f1f2f3,0xf4f5f6f7]
Long == [0xf0f1f2f3]

26. Addressing Modes Register Immediate Add R4, R3 Add R4, #3
Regs[R4]  Regs[R4]+3
Operand:3
Register
Add R4, R3
Regs[R4]  Regs[R4]+Regs[R3] R3
Operand
Registers
Register Indirect
Add R4, (R1)
Regs[R4]  Regs[R4]+Mem[Regs[R1]] R1
Operand
Registers
Memory

27. Addressing Modes(Cont.)
Direct
Add R4, (1001)
Regs[R4]  Regs[R4]+Mem[1001]
1001
Operand
Memory Indirect
Add
Regs[R4]  Regs[R4]+Mem[Mem[Regs[R3]]] R3
Operand
Registers
Memory
Memory

28. Addressing Modes(Cont.)
Displacement
Add R4, 100(R1)
Regs[R4]  Regs[R4]+Mem[100+R1]
Registers R1
100
Memory
Operand
Scaled
Add R1, 100(R2) [R3]
Regs[R1]  Regs[R1]+Mem[100+
Regs[R2]+Regs[R3]*d] R3 R2
100
Operand *d
Registers
Memory

29. Typical Address Modes (I)

30. Typical Address Modes (II)

31. Use of Memory Addressing Mode (Figure 2.7)
Based on a VAX which supported everything
Not counting Register mode (50% of all)

32. Displacement Address Size
Average of 5 programs from SPECint92 and SPECfp92.
1% of addresses > 16 bits.
Integer Average
FP Average

33. Immediate Addressing Mode
10 Programs from SPECInt92 and SPECfp92

34. Immediate Addressing Mode
50% to 60% fit within 8 bits
75% to 80% fit within 16 bits
gcc
spice
Tex

35. Short Summary – Memory Addressing
Need to support at least three addressing modes
Displacement, immediate, and register deferred (+ REGISTER)
They represent 75% -- 99% of the addressing modes in benchmarks
The size of the address for displacement mode to be at least 12—16 bits (75% – 99%)
The size of immediate field to be at least 8 – 16 bits (50%— 80%)

36. Typical types: assume word= 32 bits
Operand Type & Size
Typical types: assume word= 32 bits
Character - byte - ASCII or EBCDIC (IBM) - 4 per word
Short integer - 2- bytes, 2’s complement
Integer - one word - 2’s complement
Float - one word - usually IEEE 754 these days
Double precision float - 2 words - IEEE 754
BCD or packed decimal - 4- bit values packed 8 per word

37. Data Access Patterns

38. Short Summary – Type and Size of Operand
The future - as we go to 64 bit machines
Larger offsets, immediate, etc. is likely
Usage of 64 and 128 bit values will increase
DSPs need wider accumulating registers than the size in memory to aid accuracy in fixed-point arithmetic

39. ALU Operations

41. What Operations are Needed
Arithmetic + Logical
Integer arithmetic: ADD, SUB, MULT, DIV, SHIFT
Logical operation: AND, OR, XOR, NOT
Data Transfer - copy, load, store
Control - branch, jump, call, return, trap
System - OS and memory management
We’ll ignore these for now - but remember they are needed
Floating Point
Same as arithmetic but usually take bigger operands
Decimal
String - move, compare, search
Graphics – pixel and vertex, compression/decompression operations

42. Make them fast, as they are the common case
Top 10 Instructions for 80x86
load: 22%
conditional branch: 20%
compare: 16%
store: 12%
add: 8%
and: 6%
sub: 5%
move register-register: 4%
call: 1%
return: 1%
The most widely executed instructions are the simple operations of an instruction set
The top-10 instructions for 80x86 account for 96% of instructions executed
Make them fast, as they are the common case

43. Control Instructions are a Big Deal
Jumps - unconditional transfer
Conditional Branches
How is condition code set? – by flag or part of the instruction
How is target specified? How far away is it?
Calls
Where is return address kept?
How are the arguments passed? Callee vs. Caller save!
Returns
Where is the return address? How far away is it?
How are the results passed?

44. Breakdown of Control Flows
Call/Returns
Integer: 19% FP: 8%
Jump
Integer: 6% FP: 10%
Conditional Branch
Integer: 75% FP: 82%

45. Branch Address Specification
Known at compile time for unconditional and conditional branches - hence specified in the instruction
As a register containing the target address
As a PC-relative offset
Consider word length addresses, registers, and instructions
Full address desired? Then pick the register option.
BUT - setup and effective address will take longer.
If you can deal with smaller offset then PC relative works
PC relative is also position independent - so simple linker duty

46. Returns and Indirect Jumps
Branch target is not known at compile time
Need a way to specify the target dynamically
Use a register
Permit any addressing mode
Regs[R4]  Regs[R4] + Mem[Regs[R1]]
Also useful for
case or switch
Dynamically shared libraries
High-order functions or function pointers

47. Branch Stats - 90% are PC Relative
Call/Return
TeX = 16%, Spice = 13%, GCC = 10%
Jump
TeX = 18%, Spice = 12%, GCC = 12%
Conditional
TeX = 66%, Spice = 75%, GCC = 78%

48. Branch Distances

49. Condition Testing Options
PSW: program Switch Word

50. What kinds of compares do Branches Use?
Large comparisons are with zero

51. Direction, Frequency, and real Change
Key points – 75% are forward branch
• Most backward branches are loops - taken about 90%
• Branch statistics are both compiler and application dependent
• Any loop optimizations may have large effect

52. Short Summary – Operations in the Instruction Set
Branch addressing to be able to jump to about 100+ instructions either above or below the branch
Imply a PC-relative branch displacement of at least 8 bits
Register-indirect and PC-relative addressing for jump instructions to support returns as well as many other features of current systems ( dynamic allocations)

53. Encoding an Instruction Set

54. Encoding the ISA
Encode instructions into a binary representation for execution by CPU
Can pick anything but:
Affects the size of code - so it should be tight
Affects the CPU design - in particular the instruction decode
So it may have a big influence on the CPI or cycle-time
Must balance several competing forces
Desire for lots of addressing modes and registers
Desire to make average program size compact
Desire to have instructions encoded into lengths that will be easy to handle in a pipelined implementation (multiple of bytes)

55. 3 Popular Encoding Choices
Variable (compact code but difficult to encode)
Primary opcode is fixed in size, but opcode modifiers may exist
Opcode specifies number of arguments - each used as address fields
Best when there are many addressing modes and operations
Use as few bits as possible, but individual instructions can vary widely in length
e. g. VAX - integer ADD versions vary between 3 and 19 bytes
Fixed (easy to encode, but lengthy code)
Every instruction looks the same - some field may be interpreted differently
Combine the operation and the addressing mode into the opcode
e. g. all modern RISC machines
Hybrid
Set of fixed formats
e. g. IBM 360 and Intel 80x86
Trade-off between size of program VS. ease of decoding

56. 3 Popular Encoding Choices (Cont.)

57. An Example of Variable Encoding -- VAX
addl3 r1, 737(r2), (r3): 32-bit integer add instruction with 3 operands  need 6 bytes to represent it
Opcode for addl3: 1 byte
A VAX address specifier is 1 byte (4-bits: addressing mode, 4-bits: register)
r1: 1 byte (register addressing mode + r1)
737(r2)
1 byte for address specifier (displacement addressing + r2)
2 bytes for displacement 737
(r3): 1 byte for address specifier (register indirect + r3)
Length of VAX instructions: 1—53 bytes

58. Short Summary – Encoding the Instruction Set
Choice between variable and fixed instruction encoding
Code size than performance  variable encoding
Performance than code size  fixed encoding

59. Role of Compilers

60. Critical goals in ISA from the compiler viewpoint
What features will lead to high-quality code
What makes it easy to write efficient compilers for an architecture

61. Compiler and ISA
ISA decisions are no more for programming AL easily
Due to HLL, ISA is a compiler target today
Performance of a computer will be significantly affected by compiler
Understanding compiler technology today is critical to designing and efficiently implementing an instruction set
Architecture choice affects the code quality and the complexity of building a compiler for it

62. Make the frequent cases fast and the rare case correct
Goal of the Compiler
Primary goal is correctness
Second goal is speed of the object code
Others:
Speed of the compilation
Ease of providing debug support
Inter-operability among languages
Flexibility of the implementation - languages may not change much but they do evolve - e. g. Fortran 66 ===> HPF
Make the frequent cases fast and the rare case correct

63. Optimization Observations
Hard to reduce branches
Biggest reduction is often memory references
Some ALU operation reduction happens but it is usually a few %
Implication:
Branch, Call, and Return become a larger relative % of the instruction mix
Control instructions among the hardest to speed up

64. How can Architects Help Compiler Writers
Provide Regularity
Address modes, operations, and data types should be orthogonal (independent) of each other
Simplify code generation especially multi-pass
Counterexample: restrict what registers can be used for a certain classes of instructions
Provide primitives - not solutions
Special features that match a HLL construct are often un-usable
What works in one language may be detrimental to others

65. How can Architects Help Compiler Writers (Cont.)
Simplify trade-offs among alternatives
How to write good code? What is a good code?
Metric: IC or code size (no longer true) caches and pipeline…
Anything that makes code sequence performance obvious is a definite win!
How many times a variable should be referenced before it is cheaper to load it into a register
Provide instructions that bind the quantities known at compile time as constants
Don’t hide compile time constants
Instructions which work off of something that the compiler thinks could be a run-time determined value hand-cuffs the optimizer

66. Short Summary -- Compilers
ISA has at least 16 GPR (not counting FP registers) to simplify allocation of registers using graph coloring
Orthogonality suggests all supported addressing modes apply to all instructions that transfer data
Simplicity – understand that less is more in ISA design
Provide primitives instead of solutions
Simplify trade-offs between alternatives
Don’t bind constants at runtime
Counterexample – Lack of compiler support for multimedia instructions

67. The MIPS Architecture

68. Expectations for New ISA
Use general-purpose registers, with a load-store architecture
Support displacement (offset size12-16 bits), immediate (size 8 to 16 bits), and register indirect
Support 8-, 16-, 32-, and 64-bit integers and 64-bit IEEE 754 floating-point numbers
Support the following simple instructions: load, store, add, subtract, move register-register, and, shift, compare equal, compare not equal, branch (with a PC-relative address at least 8 bits long), jump, call, return
Use fixed instruction encoding if interested in performance and use variable instruction encoding if interested in code size
Provide at least 16 general-purpose registers (GPA) + separate floating-point registers, be sure all addressing modes apply to all data transfer instructions, and aim for a minimalist instruction set

69. Enable efficient pipeline implementation
MIPS
Simple load- store ISA
Enable efficient pipeline implementation
Fixed instruction set encoding
Efficiency as a compiler target
MIPS64 variant is discussed here

70. 32 64-bit integer GPR’s - R0, R1, ... R31, R0= 0 always
Register for MIPS
32 64-bit integer GPR’s - R0, R1, ... R31, R0= 0 always
32 FPR’s - used for single or double precision
For single precision: F0, F1, ... , F31 (32-bit)
For double precision: F0, F2, ... , F30 (64-bit)
Extra status registers - moves via GPR’s
Instructions for moving between an FRP and a GPR

71. 32-bit single precision and 64-bit double precision for FP
Data Types for MIPS
8-bit byte, 16-bit half words, 32-bit word, and 64-bit double words for integer data
32-bit single precision and 64-bit double precision for FP
MIPS64 operations work on 64-bit integer and 32- or 64-bit floating point
Bytes, half words, and words are loaded into the GPRs with zeros or the sign bit replicated to fill the 64 bits of the GPRs
All references between memory and either GPRs or FPRs are through load or stores

72. Addressing Modes for MIPS
Data addressing : immediate and displacement (16 bits)
Displacement: Add R4, 100(R1) (Regs[R4]Regs[R4]+Mem[100+Regs[R1]])
Register-indirect: placing 0 in displacement field
Add R4, (R1) (Regs[R4]Regs[R4]+Mem[Regs[R1]])
Absolute addressing (16 bits): using R0 as the base register
Add R1, (1001) (Regs[R4]Regs[R4]+Mem[1001])
Byte addressable with 64-bit address
Mode selection for Big Endian or Little Endian

73. MIPS Instruction Format
Encode addressing mode into the opcode
All instructions are 32 bits with 6-bit primary opcode

74. MIPS Instruction Format (Cont.)
I-Type Instruction
opcode rs rt
Immediate
Loads and Stores LW R1, 30(R2), S.S F0, 40(R4)
ALU ops on immediates DADDIU R1, R2, #3
rt <-- rs op immediate
Conditional branches BEQZ R3, offset
rs is the register checked
rt unused
immediate specifies the offset
Jump registers ,jump and link register JR R3
rs is target register
rt and immediate are unused but = 011

75. MIPS Instruction Format (Cont.)
R-Type Instruction
opcode rs rt
shamt rd
func
Register-register ALU operations: rdrs funct rt DADDU R1, R2, R3
Function encodes the data path operations: Add, Sub...
read/write special registers
Moves
J-Type Instruction: Jump, Jump and Link, Trap and return from exception
opcode
Offset added to PC

76. MIPS instruction MIX
SPECint2000

77. MIPS instruction MIX (Cont.)
SPECfp2000
