Presentation on theme: "Gas Production and Consumption in Bangladesh"— Presentation transcript:
1Gas Production and Consumption in Bangladesh 13 April 2017BangladeshInternational Workshop on Energy Statistics24-26 Sep, Beijing, ChinaCollection and Compilation of Data onGas Production and Consumptionin BangladeshMd. Mahbub SarwarGeneral ManagerProduction & Marketing DivisionBangladesh Oil, and and Mineral Corporation(Petrobangla)September, 2012
2Primary Energy Scenario 2011 Commercial -65%Biomass – 35%Share of Commercial Energy (Total =23.4 MTOE)
3Gas Sector at a Glance Total Gas Fields 25 Producing Gas Fields 19 Producing Gas Wells84Daily Gas Production2260 MMscfdTotal Gas Reserve (Proven + Provable)TCFGas Production Since inception (upto June 2012)10.51 TCFRemaining Reserve (Proven + Provable)16.37 TCFCurrent Gas Demand2500+ MMscfdDaily Gas Shortfall240+ MMscfdGas Customers2.35 Millions
9Energy & Mineral Resources Division 13 April 2017Energy & Mineral Resources DivisionSylhet Gas Fields Ltd.Bangladesh Petroleum Expl. & Prod. Co. Ltd.Bangladesh Gas Fields Co. Ltd.Barapukuria Coal Mining Co. Ltd.Rupantarita Prakritic Gas Co. Ltd.Titas Gas T & D Co. Ltd.Gas Transmission Co. Ltd.Pashchimanchal Gas Co. Ltd.Jalalabad Gas T & D System Ltd.Bakhrabad Gas Distribution Co. Ltd.Maddhyapara Granite Mining Co. LtdPETROBANGLAProductionMiningCNG & LPGDistributionExploration& ProductionTransmissionKarnaphuly Gas Distribution Co. Ltd.Sundarban Gas Co. Ltd.
10INTERNATIONA OIL COMPANY OPERATING UNDER PETROBANGLAPETROBANGLACHEVRONTULLOWSANTOSNIKOCONOCO PHILIPS
12DATA COLLECTION & COMPILATION :DailyGas & Condensate ProductionDaily gas Consumption- Power plant-wise- Fertilizer Factory-wise- Non- BulkPeriodical Data Compilation :MIS Report- Monthly & Yearly Production & Consumption of Gas, Condensate & Products, Revenue, Customer Base, Pipeline , Statistics of new Connection, UFG, Activities on Environment & SafetyAnnual Report
13DAILY DATA COLLECTION & COMPILATION A. PRODUCTION DATAPeriod24 Hours (8:00 hours of previous day to 8:00 hours day of reporting daySourceProducing FieldsCompilation ProcedureField personnel or Field Manager prepares 24 hours gas & condensate production report on the basis of production meter reading; sends to the company head office through wireless, phone, fax & by 9 am everyday.Companies’ Data compilation centres send daily gas & production report to Production & Marketing Division, Petrobangla by 10-11am everyday through phone and .Petrobangla compiles all production data field-wise under each company, calculates nationwide production, circulates the to the higher authorities and uploads it at the Perobanlga website (www.petrobangla,org.bd/.UnitsGas Production in MMSCFD and Condensate in BBLD
14DAILY DATA COLLECTION & COMPILATION B. Consumption DataPeriod24 Hours (8:00 hours of previous day to 8:00 hours day of reporting daySourceDistribution companiesCompilation ProcedureCompany representatives records hourly gas consumption by individual power plants and fertilizer factories, they send these to the central data compilation unit (load dispatch centre) at the company head office.Consumption figures for non-bulk sector (industry, captive power, domestic, CNG etc) are calculated on the basis of throughput at the CGS, TBS, and DRS etc. In charge of the these stations transmits these data to the load dispatch centre.The load dispatch centre prepares a hourly log sheet everyday which contains details information on gas amount and pressure and calculates daily consumption.
15DAILY DATA COLLECTION & COMPILATION Load dispatch centre of the company sends daily consumption data to Production & Marketing Division, Petrobangla by 10-11am everyday through phone and .Petrobangla compiles all consumption data customer category wise (power, fertilizer and non-bulk) under each company in the Daily Production and Consumption Report, calculates nationwide consumption, circulates the to the higher authorities and uploads it at the Perobanlga website (www.petrobangla,org.bd/.UnitsGas Consumption in MMSCFDDaily Report
16Management Information System (MIS) Report ProcedureEach Production as well as Distribution Company has an MIS department which is responsible for preparing a monthly MIS report for the company.MIS report prepared by the company is circulated to company authorities, Petrobangla authorities and to the MIS department of Petrobangla.On the basis of the MIS reports of the companies, MIS department of Petrobangla prepares central MIS report which contains nationwide gas, condensate, condensate products and sales data in addition to other technical and financial information.MIS reports of the companies are uploaded at the respective company website while MIS report prepared by Petrobangla is uploaded at Petrobangla website (www. petrobangla.org.bd)Units :Gas : MMSCM (Million standard cubic metre),Condensate: Thousand litres
17LIMITATIONSMeasurement of Non-bulk small Customers such as Industrials, Commercial are often Inaccurate, because of Mechanical Meter.Almost all the Domestic Customers are Un-mettered, resulting in Inefficient Use.
