Presentation on theme: "Section 9 and 10 Ozone Depletion What is the threat from ozone depletion? Good versus bad ozone. What causes ozone depletion? What happens to ozone levels."— Presentation transcript:

1 Section 9 and 10 Ozone Depletion What is the threat from ozone depletion? Good versus bad ozone. What causes ozone depletion? What happens to ozone levels over Earths poles? Why should we be worried about ozone depletion? What are solutions to this problem?

2 Ozone Depletion What is ozone? Good versus bad ozone Where is the ozone layer Keeps out about 95% of UV rays Layer has been thinning

3 Ozone Depletion: What Causes Depletion? GM Chemist discovered Chlorofluorocarbons in 1930 (CFCs) …also known as freon Very stable Nontoxic Noncorrosive Inexpensive Dream Chemical GM Chemist discovered Chlorofluorocarbons in 1930 (CFCs) …also known as freon Very stable Nontoxic Noncorrosive Inexpensive Dream Chemical

4 Ozone Depletion: What Causes Depletion? CFCs used for: Coolant in refrigerators and air conditioners Propellant in aerosol sprays Cleaner for electronics Bubbles in plastic foams Insulations

5 Former Uses of CFCs Air Conditioners Refrigerators Spray cans Cleaners for electronic parts Sterilizing medical instruments Fumigants for granaries and cargo ships Air Conditioners Refrigerators Spray cans Cleaners for electronic parts Sterilizing medical instruments Fumigants for granaries and cargo ships

6 Ozone Depletion: What Causes Depletion? Too good to be true: 1974 study at UC Irvine indicated threat to ozone layer from CFCs Shock to the $28 billion per year CFC industry – DuPont and other chemical companies

7 Ozone Depletion: What Causes Depletion? 1)CFCs remain stable in troposphere due to unreactivity 2)Over years they get lifted into stratosphere by convection and drift 3)Once in stratosphere they break down by UV rays releasing highly reactive chlorine atoms (with others) that in a chain reaction break apart ozone 1)CFCs remain stable in troposphere due to unreactivity 2)Over years they get lifted into stratosphere by convection and drift 3)Once in stratosphere they break down by UV rays releasing highly reactive chlorine atoms (with others) that in a chain reaction break apart ozone

8 Ozone Depletion: What Causes Depletion? 4) Each CFC molecule lasts in stratosphere for years Can convert 100,000 of O 3 to O 2 during that time. DuPont and others fought findings until 1988 when they admitted problems Nobel Prize Chemistry

9

10 Ozone Depletion in the Stratosphere Fig p. 484

11 Ozone Depletion: What Causes Depletion? CFCs are not the only culprit Halons (fire extinguishers) Hydrogen chloride (space shuttle) Some natural chemicals

12 Ozone Depleting Chemicals Chlorofluorocarbons (CFCs) Halons Methyl bromide Carbon tetrachloride Methyl chloroform Hydrogen chloride

13 Ozone Hole During 4 months each year half of the ozone layer above Antarctica is depleted 1984 researchers discovered 40-50% reductions in later winter (August – November)

14

15

16

17 Ozone Hole Ozone Hole more accurate ozone thinning Polar Vortex: circular winds blowing around poles during winter isolates atmosphere. Warming at end of winter releases frozen chemicals destroying ozone

18 Ozone Hole Huge problem for parts of New Zealand, Australia South American and South Africa Similar hole but less severe over Arctic during late winter early spring Huge problem for parts of New Zealand, Australia South American and South Africa Similar hole but less severe over Arctic during late winter early spring

19

20 Loss of the Ozone Layer: Reasons for Concern Increased incidence and severity of sunburn Increase in eye cataracts Increased incidence of skin cancer Immune system suppression Increase in acid deposition Lower crop yields and decline in productivity Refer to Fig p. 486 Refer to Fig p. 486

21

22 Skin Cancers Fig p. 487

23 Solutions: Protecting the Ozone Layer 1987 Montreal Protocol 36 nations: Goal: reduce CFCs by 35% by Copenhagen Protocol accelerated phase out Good news: substitutes do exist

24 If all of the ozone-depleting substances were banned tomorrow, it would take about years for Earth to recover to pre-1975 levels.

25 Solutions: Protecting the Ozone Layer CFC substitutes Montreal Protocol Copenhagen Protocol Fig p. 489

26

27
