1. Introduction to Scientific Computing
Intro to Scientific Computing
10/9/2008
Introduction to Scientific Computing
The Title Slide: Add the name of the presentation, the appropriate division or presenter and date of the presentation.
Shubin Liu, Ph.D.
Research Computing Center
University of North Carolina at Chapel Hill
Research Computing Center, ITS

2. Course Goals
An introduction to high-performance computing and UNC Research Computing Center
Available Research Computing hardware facilities
Available software packages
Serial/parallel programming tools and libraries
How to efficiently make use of Research Computing facilities on campus

3. Agenda Introduction to High-Performance Computing Hardware Available
Servers, storage, file systems, etc.
How to Access
Programming Tools Available
Compilers & Debugger tools
Utility Libraries
Parallel Computing
Scientific Packages Available
Job Management
Hands-on Exercises– 2nd hour
The PPT format of this presentation is available here:
/afs/isis/depts/its/public_html/divisions/rc/training/scientific/short_courses/

4. Pre-requisites An account on Emerald cluster UNIX Basics
Getting started:
Intermediate:
vi Editor:
Customizing:
Shells:
ne Editor:
Security:
Data Management:
Scripting:
HPC Application:

5. About Us ITS – Information Technology Services http://its.unc.edu
Physical locations:
401 West Franklin St.
211 Manning Drive
10 Divisions/Departments
Information Security IT Infrastructure and Operations
Research Computing Center Teaching and Learning
User Support and Engagement Office of the CIO
Communication Technologies Enterprise Resource Planning
Enterprise Applications Finance and Administration

6. Research Computing Center
Where and who are we and what do we do?
ITS Manning: 211 Manning Drive
Website
Groups
Infrastructure -- Hardware
User Support -- Software
Engagement -- Collaboration

7. Intro to Scientific Computing
About Myself
9/25/20089/11/2008
10/9/2008
Ph.D. from Chemistry, UNC-CH
Currently Senior Computational Research Computing Center, UNC-CH
Responsibilities:
Support Computational Chemistry/Physics/Material Science software
Support Programming (FORTRAN/C/C++) tools, code porting, parallel computing, etc.
Offer short training courses for campus users
Conduct research and engagement projects in Computational Chemistry
Development of DFT theory and concept tools
Applications in biological and material science systems
Research Computing Center, ITS 7

8. What is Scientific Computing?
Short Version
To use high-performance computing (HPC) facilities to solve real scientific problems.
Long Version, from Wikipedia.com
Scientific computing (or computational science) is the field of study concerned with constructing mathematical models and numerical solution techniques and using computers to analyze and solve scientific and engineering problems. In practical use, it is typically the application of computer simulation and other forms of computation to problems in various scientific disciplines.

9. What is Scientific Computing?
Engineering
Sciences
Theory/Model Layer
Algorithm Layer
Scientific
Computing
Applied
Mathematics
Computer
Science
Hardware/Software
Natural
Sciences
Application Layer
From scientific discipline viewpoint
From operational viewpoint
High- Performance
Computing
Scientific
Computing
Parallel
Computing
From Computing Perspective

10. What is HPC?
Computing resources which provide more than an order of magnitude more computing power than current top-end workstations or desktops – generic, widely accepted.
HPC ingredients:
large capability computers (fast CPUs)
massive memory
enormous (fast & large) data storage
highest capacity communication networks (Myrinet, 10 GigE, InfiniBand, etc.)
specifically parallelized codes (MPI, OpenMP)
visualization

11. Why HPC?
What are the three-dimensional structures of all of the proteins encoded by an organism's genome and how does structure influence function, both spatially and temporally?
What patterns of emergent behavior occur in models of very large societies?
How do massive stars explode and produce the heaviest elements in the periodic table?
What sort of abrupt transitions can occur in Earth’s climate and ecosystem structure?
How do these occur and under what circumstances? If we could design catalysts atom-by-atom, could we transform industrial synthesis?
What strategies might be developed to optimize management of complex infrastructure systems?
What kind of language processing can occur in large assemblages of neurons?
Can we enable integrated planning and response to natural and man-made disasters that prevent or minimize the loss of life and property?

12. Measure of Performance
1 CPU, Units in MFLOPS (x106)
Machine/CPU
Type
LINPACK Performance
Peak Performance
Intel Pentium 4 (2.53 GHz)
2355
5060
Mega FLOPS (x106)
Giga FLOPS (x109)
Tera FLOPS (x1012)
Peta FLOPS (x1015)
Exa FLOPS (x1018)
Zetta FLOPS (x1021)
Yotta FLOPS (x1024)
NEC SX-6/1 (1proc. 2.0 ns)
7575
8000
HP rx5670 Itanium2 (1GHz)
  3528
4000
IBM eServer pSeries 690 (1300 MHz)
2894
5200
Cray SV1ex-1-32(500MHz)
1554
2000
Compaq ES45 (1000 MHz)
1542
2000
AMD Athlon MP1800+(1530MHz)
1705
3060
Intel Pentium III (933 MHz)
507
933
SGI Origin 2000 (300 MHz)
533
600
Intel Pentium II Xeon (450 MHz)
295
450
Sun UltraSPARC (167MHz)
237
333
Reference:

13. How to Quantify Performance? TOP500
A list of the 500 most powerful computer systems over the world
Established in June 1993
Compiled twice a year (June & November)
Using LINPACK Benchmark code (solving linear algebra equation aX=b )
Organized by world-wide HPC experts, computational scientists, manufacturers, and the Internet community
Homepage:

14. Intro to Scientific Computing
10/9/2008
TOP500:November 2007
TOP 5, Units in GFLOPS (=1024 MGLOPS)
Rank
Installatio Site
/Year
Manufacturer Computer/Procs
Rmax Rpeak 1
DOE/NNSA/LLNL United States/2007
BlueGene/L eServer Blue Gene Solution / 212,992, IBM
478, ,378 2
Forschungszentrum Juelich (FZJ) Germany/2007
JUGENE - Blue Gene/P Solution IBM
65,536
167,300
222,822 3
SGI/New Mexico Computing Applications Center (NMCAC) United States/2007
SGI Altix ICE 8200, Xeon quad core 3.0 GHz, SGI
14,336
126,900
172,032 4
Computational Research Laboratories, TATA SONS India/2007
EKA - Cluster Platform 3000 BL460c, Xeon 53xx 3GHz, Infiniband Hewlett-Packard, 14,240
,800 5
Government Agency Sweden/2007
Cluster Platform 3000 BL460c, Xeon 53xx 2.66GHz, Infiniband Hewlett-Packard, 13,728
102,800
146,430 36
University of North Carolina United States/2007
Topsail - PowerEdge 1955, 2.33 GHz, Cisco/Topspin Infiniband, Dell, 4160
28,770
Research Computing Center, ITS

15. TOP500: June 2008 Rank Site Computer/Year Vendor Cores Rmax Rpeak
Power 1
DOE/NNSA/LANL United States
Roadrunner - BladeCenter QS22/LS21 Cluster, PowerXCell 8i 3.2 Ghz / Opteron DC 1.8 GHz , Voltaire Infiniband / 2008 IBM
122,400 2
DOE/NNSA/LLNL United States
BlueGene/L - eServer Blue Gene Solution / 2007 IBM
212,992
478.20
596.38 3
Argonne National Laboratory United States
Blue Gene/P Solution / 2007 IBM
163,840
450.30
557.06 4
Texas Advanced Computing Center Univ. of Texas United States
Ranger - SunBlade x6420, Opteron Quad 2Ghz, Infiniband / 2008 Sun Microsystems
62,976
326.00
503.81 5
DOE/Oak Ridge National Laboratory United States
Jaguar - Cray XT4 QuadCore 2.1 GHz / 2008 Cray Inc.
30,976
205.00
260.20 67
University of North Carolina United States/2007
Topsail - PowerEdge 1955, 2.33 GHz, Cisco/Topspin Infiniband, Dell
4,160
28.77
38.82
Rmax and Rpeak values are in TFlops.
Power data in KW for entire system

16. TOP500: June 2009 Rank Site Computer/Year Vendor Cores Rmax Rpeak
Power 1
DOE/NNSA/LANL United States
Roadrunner - BladeCenter QS22/LS21 Cluster, PowerXCell 8i 3.2 Ghz / Opteron DC 1.8 GHz, Voltaire Infiniband / 2008 IBM
129600 2
Oak Ridge National Laboratory United States
Jaguar - Cray XT5 QC 2.3 GHz / 2008 Cray Inc.
150152 3
Forschungszentrum Juelich (FZJ) Germany
JUGENE - Blue Gene/P Solution / 2009 IBM
294912
825.50 4
NASA/Ames Research Center/NAS United States
Pleiades - SGI Altix ICE 8200EX, Xeon QC 3.0/2.66 GHz / 2008 SGI
51200
487.01
608.83 5
DOE/NNSA/LLNL United States
BlueGene/L - eServer Blue Gene Solution / 2007 IBM
212992
478.20
596.38
175
University of North Carolina United States/2007
Topsail - PowerEdge 1955, 2.33 GHz, Cisco/Topspin Infiniband, Dell
4,160
28.77
38.82

17. TOP500 History of UNC-CH Entry
List
Systems
Highest Ranking
Sum Rmax (GFlops)
Sum Rpeak (GFlops)
Site Efficiency (%)
06/2009 1
175
74.11
11/2008 88
06/2008 67
11/2007 36
06/2007 25
11/2006
104
83.49
06/2006 74
11/2003
393
439.30
36.32
06/1999
499
24.77
28.80
86.01

18. Shared/Distributed-Memory Architecture
CPU
CPU
CPU
CPU
CPU
CPU
CPU
CPU M M M M
BUS
NETWORK
MEMORY
Distributed memory - each processor
has it’s own local memory. Must do
message passing to exchange data
between processors.
(examples: Baobab, the new Dell Cluster)
Shared memory - single address space. All processors have access to a pool of shared memory. (examples: Chastity/zephyr, happy/yatta, cedar/cypress, sunny) Methods of memory access : Bus and Crossbar

19. What is a Beowulf Cluster?
A Beowulf system is a collection of personal computers constructed from commodity-off-the-shelf hardware components interconnected with a system-area-network and configured to operate as a single unit, parallel computing platform (e.g., MPI), using an open-source network operating system such as LINUX.
Main components:
PCs running LINUX OS
Inter-node connection with Ethernet,
Gigabit, Myrinet, InfiniBand, etc.
MPI (message passing interface)

20. LINUX Beowulf Clusters

21. What is Parallel Computing ?
Concurrent use of multiple processors to process data
Running the same program on many processors.
Running many programs on each processor.

22. Advantages of Parallelization
Cheaper, in terms of Price/Performance Ratio
Faster than equivalently expensive uniprocessor machines
Handle bigger problems
More scalable: the performance of a particular program may be improved by execution on a large machine
More reliable: In theory if processors fail we can simply use others

23. Catch: Amdahl's Law
Speedup = 1/(s+p/n)

24. Parallel Programming Tools
Share-memory architecture
OpenMP
Distributed-memory architecture
MPI, PVM, etc.

25. OpenMP
An Application Program Interface (API) that may be used to explicitly direct multi-threaded, shared memory parallelism
What does OpenMP stand for?
Open specifications for Multi Processing via collaborative work between interested parties from the hardware and software industry, government and academia.
Comprised of three primary API components:
Compiler Directives
Runtime Library Routines
Environment Variables
Portable:
The API is specified for C/C++ and Fortran
Multiple platforms have been implemented including most Unix platforms and Windows NT
Standardized:
Jointly defined and endorsed by a group of major computer hardware and software vendors
Expected to become an ANSI standard later???
Many compilers can automatically parallelize a code with OpenMP!

26. OpenMP Example (FORTRAN)
PROGRAM HELLO
INTEGER NTHREADS, TID, OMP_GET_NUM_THREADS,
+ OMP_GET_THREAD_NUM
C Fork a team of threads giving them their own copies of variables
!$OMP PARALLEL PRIVATE(TID)
C Obtain and print thread id
TID = OMP_GET_THREAD_NUM()
PRINT *, 'Hello World from thread = ', TID
C Only master thread does this
IF (TID .EQ. 0) THEN
NTHREADS = OMP_GET_NUM_THREADS()
PRINT *, 'Number of threads = ', NTHREADS
END IF
C All threads join master thread and disband
!$OMP END PARALLEL
END

27. The Message Passing Model
Parallelization scheme for distributed memory.
Parallel programs consist of cooperating processes, each with its own memory.
Processes send data to one another as messages
Message can be passed around among compute processes
Messages may have tags that may be used to sort messages.
Messages may be received in any order.

28. MPI: Message Passing Interface
Message-passing model
Standard (specification)
Many implementations (almost each vendor has one)
MPICH and LAM/MPI from public domain most widely used
GLOBUS MPI for grid computing
Two phases:
MPI 1: Traditional message-passing
MPI 2: Remote memory, parallel I/O, and dynamic processes
Online resources

29. A Simple MPI Code C Version FORTRAN Version #include "mpi.h"
#include <stdio.h>
int main( argc, argv )
int argc;
char **argv;
{ MPI_Init( &argc, &argv );
printf( "Hello world\n" );
MPI_Finalize();
return 0; }
include ‘mpif.h’ integer myid, ierr, numprocs call MPI_INIT( ierr) call MPI_COMM_RANK(MPI_COMM_WORLD, myid, ierr) call MPI_COMM_SIZE (MPI_COMM_WORLD, numprocs,ierr) write(*,*) ‘Hello from ‘, myid write(*,*) ‘Numprocs is’, numprocs call MPI_FINALIZE(ierr)
end
C Version
FORTRAN Version

30. Other Parallelization Models
VIA: Virtual Interface Architecture -- Standards-based Cluster Communications
PVM: a portable message-passing programming system, designed to link separate host machines to form a ``virtual machine'' which is a single, manageable computing resource. It’s largely an academic effort and there has been no much development since 1990s.
BSP: Bulk Synchronous Parallel Model, a generalization of the widely researched PRAM (Parallel Random Access Machine) model
Linda:a concurrent programming model from Yale, with the primary concept of ``tuple-space''
HPF: PGI’s first standard parallel programming language for shared and distributed-memory systems.

31. RC Servers @ UNC-CH SGI Altix 3700 – SMP, 128 CPUs, cedar/cypress
Emerald LINUX Cluster – Distributed memory, ~500 CPUs, emerald
yatta/p575 IBM AIX nodes
Dell LINUX cluster – Distributed memory 4160 CPUs, topsail

32. IBM P690/P575 SMP
IBM pSeries 690/P575 Model 6C4, Power4+ Turbo, GHz processors
- access to 4TB of NetApp NAS RAID array used for scratch space, mounted as /nas and /netscr
OS: IBM AIX 5.3 Maintenance Level 04
login node: emerald.isis.unc.edu
compute node:
yatta.isis.unc.edu 32 CPUs
P575-n00.isis.unc.edu 16 CPUs
P575-n01.isis.unc.edu 16 CPUs
P575-n02.isis.unc.edu 16 CPUs
P575-n03.issi.unc.edu 16 CPUs

33. Intro to Scientific Computing
SGI Altix 3700 SMP
10/9/2008
Servers for Scientific Applications such as Gaussian, Amber, and custom code
Login node: cedar.isis.unc.edu
Compute node: cypress.isis.unc.edu
Cypress: SGI Altix 3700bx Intel Itanium2 Processors (1600MHz), each with 16k L1 cache for data, 16k L1 cache for instructions, 256k L2 cache, 6MB L3 cache, 4GB of Shared Memory (512GB total memory)
Two 70 GB SCSI System Disks as /scr
Research Computing Center, ITS

34. Intro to Scientific Computing
SGI Altix 3700 SMP
10/9/2008
Cedar: SGI Altix Intel Itanium2 Processors (1500MHz), each with 16k L1 cache for data, 16k L1 cache for instructions, 256k L2 cache, 4MB L3 cache, 1GB of Shared Memory (8GB total memory), two 70 GB SATA System Disks.
RHEL 3 with Propack 3, Service Pack 3
No AFS (HOME & pkg space) access
Scratch Disk:
/netscr, /nas, /scr
Research Computing Center, ITS

35. Emerald Cluster
General purpose Linux Cluster for Scientific and Statistical Applications
Machine Name: emerald.isis.unc.edu
2 Login Nodes: IBM BladeCenter, one Xeon 2.4GHz, 2.5GB RAM and one Xeon 2.8GHz, 2.5GB RAM
18 Compute Nodes: Dual AMD Athlon GHz MP Processor, Tyan Thunder MP Motherboard, 2GB DDR RAM on each node
6 Compute Nodes: Dual AMD Athlon GHz MP Processor, Tyan Thunder MP Motherboard, 2GB DDR RAM on each node
25 Compute Nodes: IBM BladeCenter, Dual Intel Xeon 2.4GHz, 2.5GB RAM on each node
96 Compute Nodes: IBM BladeCenter, Dual Intel Xeon 2.8GHz, 2.5GB RAM on each node
15 Compute Nodes: IBM BladeCenter, Dual Intel Xeon 3.2GHz, 4.0GB RAM on each node
Access to 10 TB of NetApp NAS RAID array used for scratch space, mounted as /nas and /scr
Login: emerald.isis.unc.edu
Access to 7TB of NetApp NAS RAID array used for scratch space, mounted as /nas and /scr
OS: RedHat Enterprise Linux 3.0
TOP500: 395th place in the June 2003 release.

37. Dell LINUX Cluster, Topsail
520 dual nodes (4160 CPUs) Xeon (EM64T)
3.6GHz, 2MB L1 cache 2GB memory per CPU
InfiniBand inter-node connection
Not AFS mounted, not open to general public
Access based on peer-reviewed proposal
HPL: Teraflops, 74th in 2006 JuneTOP500 list and 104th in the November 2006 list and 25th in the June 2007 list (28.77 teraflops after upgrade)

38. Topsail
Login node : topsail.unc.edu GHz Intel EM64T with 2x4M L2 cache (Model E5345/Clovertown), 12 GB memory
Compute nodes : 4, GHz Intel EM64T with 2x4M L2 cache (Model E5345/Clovertown), 12 GB memory
Shared Disk : (/ifs1) 39 TB IBRIX Parallel File System
Interconnect: Infiniband 4x SDR
Resource management is handled by LSF v.7.2, through which all computational jobs are submitted for processing

39. File Systems
AFS (Andrew File System): AFS is a distributed network file system that enables files from any AFS machine across the campus to be accessed as easily as files stored locally.
As ISIS HOME for all users with an ONYEN – the Only Name You’ll Ever Need
Limited quote: 250 MB for most users [type “fs lq” to view]
Current production version openafs
Files backed up daily [ ~/OldFiles ]
Directory/File tree: /afs/isis/home/o/n/onyen
For example: /afs/isis/home/m/a/mason, where “mason” is the ONYEN of the user
Accessible from emerald, happy/yatta
But not from cedar/cypress, topsail
Not sutiable for research computing tasks!
Recommended to compile, run I/O intensive jobs on /scr or /netscr
More info:

40. Basic AFS Commands To add or remove packages
ipm add pkg_name, ipm remove pkg_name
To find out space quota/usage
fs lq
To see and review AFS tokens (read/write-able), which expires in 25 hours
tokens, klog
Over 300 packages installed in AFS pkg space
/afs/isis/pkg/
More info available at

41. Data Storage Local Scratch: /scr – local to a machine
Cedar/cypress: 2x500 GB SCSI System Disks
Topsail: /ifs1/scr TB IBRIX Parallel File System
Happy/yatta: 2x500 GB Disk Drives
For running jobs, temporary data storage, not backed up
Network Attached Storage (NAS) – for temporary storage
/nas/uncch, /netscr
>20TB of NetApp NAS RAID array used for scratch space, mounted as /nas and /scr
Shared by all login and compute nodes
(cedar/cypress, happy/yatta, emerald)
Mass Storage (MS) – for permanent storage
Mounted for long term data storage on all scientific computing
servers’ login nodes as ~/ms ($HOME/ms)
Never run jobs in ~/ms (compute nodes do not have ~/ms access)

42. Subscription of Services
Have an ONYEN ID
The Only Name You’ll Ever Need
Eligibility: Faculty, staff, postdoc, and graduate students
Go to

43. Access to Servers To Emerald ssh emerald.isis.unc.edu To cedar
ssh cedar.isis.unc.edu
To Topsail
ssh topsail.unc.edu

44. Programming Tools Compilers FORTRAN 77/90/95 C/C++ Utility Libraries
BLAS, LAPACK, FFTW, SCALAPACK
IMSL, NAG,
NetCDF, GSL, PETSc
Parallel Computing
OpenMP
PVM
MPI (MPICH, LAM/MPI, OpenMPI, MPICH2)

45. Compilers: SMP Machines
Cedar/Cypress – SGI Altix 3700, 128 CPUs
64-bit Intel Compiler versions 9.1 and 10.1, /opt/intel
FORTRAN 77/90/95: ifort/ifc/efc
C/C++: icc/ecc
64-bit GNU compilers
FORTRAN 77 f77/g77
C and C++ gcc/cc and g++/c++
Yatta/P575 – IBM P690/P575, 32/64CPUs
XL FORTRAN 77/ xlf, xlf90
C and C++ AIX xlc, xlC

46. Compilers: LINUX Cluster
Absoft ProFortran Compilers
Package Name: profortran
Current Version: 7.0
FORTRAN 77 (f77): Absoft FORTRAN 77 compiler version 5.0
FORTRAN 90/95 (f90/f95): Absoft FORTRAN 90/95 compiler version 3.0
GNU Compilers
Package Name: gcc
Current Version: 4.1.2
FORTRAN 77 (g77/f77): 3.4.3, 4.1.2
C (gcc): 3.4.3, 4.1.2
C++ (g++/c++): 3.4.3, 4.1.2
Intel Compilers
Package Name: intel_fortran intel_CC
Current Version: 10.1
FORTRAN 77/90 (ifc): Intel LINUX compiler version 8.1, 9.0, 10.1
CC/C++ (icc): Intel LINUX compiler version 8.1, 9.0, 10.1
Portland Group Compilers
Package Name: pgi
Current Version: 7.1.6
FORTRAN 77 (pgf77): The Portland Group, Inc. pgf77 v6.0, 7.0.4, 7.1.3
FORTRAN 90 (pgf90): The Portland Group, Inc. pgf90 v6.0, 7.0.4, 7.1.3
High Performance FORTRAN (pghpf): The Portland Group, Inc. pghpf v6.0, 7.0.4, 7.1.3
C (pgcc): The Portland Group, Inc. pgcc v6.0, 7.0.4, 7.1.3
C++ (pgCC): The Portland Group, Inc. v6.0, 7.0.4, 7.1.3

47. LINUX Compiler Benchmark
Absoft ProFortran 90
Intel FORTRAN 90
Portland Group FORTRAN 90
GNU FORTRAN 77
Molecular Dynamics (CPU time)
4.19 (4)
2.83 (2)
2.80 (1)
2.89 (3)
Kepler (CPU Time)
0.49 (1)
0.93 (2)
1.10 (3)
1.24 (4)
Linpack (CPU Time)
98.6 (4)
95.6 (1)
96.7 (2)
97.6 (3)
Linpack (MFLOPS)
182.6 (4)
183.8 (1)
183.2 (3)
183.3 (2)
LFK (CPU Time)
89.5 (4)
70.0 (3)
68.7 (2)
68.0 (1)
LFK (MFLOPS)
309.7 (3)
403.0 (2)
468.9 (1)
250.9 (4)
Total Rank 20 11 12 17
For reference only. Notice that performance is code and compilation flag dependent. For each benchmark, three
identical runs were performed and the best CPU timing was chosen among the three and then listed in the Table.
Optimization flags: for Absoft -O, Portland Group -O4 -fast, Intel -O3, GNU -O

48. Profilers & Debuggers SMP machines LINUX Cluster
Happy/yatta: dbx, prof, gprof
Cedar/cypress: gprof
LINUX Cluster
PGI: pgdebug, pgprof, gprof
Absoft: fx, xfx, gprof
Intel: idb, gprof
GNU: gdb, gprof

49. Utility Libraries Mathematic Libraries IMSL, NAG, etc.
Scientific Computing
Linear Algebra
BLAS, ATLAS
EISPACK
LAPACK
SCALAPACK
Fast Fourier Transform, FFTW
BLAS/LAPACK, ScaLAPACK
The GNU Scientific Library, GSL
Utility Libraries, netCDF, PETSc, etc.

50. Utility Libraries SMP Machines
Yatta/P575: ESSL (Engineering and Scientific Subroutine Library), -lessl
BLAS
LAPACK
EISPACK
Fourier Transforms, Convolutions and Correlations, and Related Computations
Sorting and Searching
Interpolation
Numerical Quadrature
Random Number Generation
Utilities

51. Intro to Scientific Computing
Utility Libraries
10/9/2008
SMP Machines
Cedar/Cypress: MKL (Intel Math Kernel Library) 8.0,
-L/opt/intel/mkl721/lib/64 -lmkl -lmkl_lapack -lsolver -lvml -lguide
BLAS
LAPACK
Sparse Solvers
FFT
VML (Vector Math Library)
Random-Number Generators
Research Computing Center, ITS

52. Utility Libraries for Emerald Cluster
Mathematic Libraries
IMSL
The IMSL Libraries are a comprehensive set of mathematical and statistical functions
From Visual Numerics,
Functions include
- Optimization - FFT’s
- Interpolation - Differential equations
- Correlation - Regression
- Time series analysis - and many more
Available in FORTRAN and C
Package name: imsl
Required compiler: Portland Group compiler, pgi
Installed on AFS ISIS package space, /afs/isis/pkg/imsl
Current default version 4.0, latest version 5.0
To subscribe IMSL, type “ipm add pgi imsl”
To compiler a C code, code.c, using IMSL:
pgcc -O $CFLAGS code.c -o code.x $LINK_CNL_STATIC

53. Utility Libraries for Emerald Cluster
Mathematic Libraries
NAG
NAG produces and distributes numerical, symbolic, statistical, visualisation and simulation software for the solution of problems in a wide range of applications in such areas as science, engineering, financial analysis and research.
From Numerical Algorithms Group,
Functions include
- Optimization - FFT’s
- Interpolation - Differential equations
- Correlation - Regression
- Time series analysis - Multivariate factor analysis
- Linear algebra - Random number generator
Available in FORTRAN and C
Package name: nag
Available platform: SGI IRIX, SUN Solaris, IBM AIX, LINUX
Installed on AFS ISIS package space, /afs/isis/pkg/nag
Current default version 6.0
To subscribe IMSL, type “ipm add nag”

54. Utility Libraries for Emerald Cluster
Scientific Libraries
Linear Algebra
BLAS, LAPACK, LAPACK90, LAPACK++, ATALS, SPARSE-BLAS, SCALAPACK, EISPACK, FFTPACK, LANCZOS, HOMPACK, etc.
Source code downloadable from the website:
Compiler dependent
BLAS and LAPACK available for all 4 compiler at AFS ISIS package space, gcc, profortran, intel and pgi
SCALAPACK available for pgi and intel compilers
Assistance available if other versions are needed

55. Utility Libraries for Emerald Cluster
Scientific Libraries
Other Libraries: not fully implemented yet and thus please be cautious and patient when using them
FFTW
GSL
NetCDF
NCO
HDF
OCTAVE
PETSc ……
If you think more libraries are of broad interest, please recommend to us

56. Parallel Computing SMP Machines: OpenMP Compilation:
Use “-qsmp=omp” flag on happy
Use “-openmp” flag on cedar
Environmental Variable Setup
setenv OMP_NUM_THREADS n
MPI
Use “-lmpi” flag on cedar
Use MPI capable compilers, e.g., mpxlf, mpxlf90, mpcc, mpCC
Hybrid (OpenMP and MPI): Do both!

57. Parallel Computing With Emerald Cluster
Setup
MPI Implementation
MPICH/MPICH2
MPI-LAM
MPI Package to be “ipm add”-ed
mpich
mpi-lam
Vendor\Programming Language
F77
F90 C
C++
F77
F90 C
C++
GNU Compilers √ √ √ √ √ √
Absoft ProfFortran Compilers √ √ √ √ √ √ √ √
Portland Group Compilers √ √ √ √ √ √ √ √
Intel Compilers √ √ √ √ √ √ √ √

58. Parallel Computing With Emerald Cluster
Setup
Vendor \ Language
Package Name
FORTRAN 77
FORTRAN 90 C
C++
GNU
gcc
g77
gcc
g++
Absoft ProfFortran
profortran
f77
f95
Portland Group
pgi
pgf77
pgf90
pgcc
pgCC
Intel
intel_fortran
intel_CC
ifc
ifc
icc
icc
Commands for Parallel MPI Compilation
mpich or
mpi-lam
mpif77
mpif90
mpicc
mpiCC

59. Parallel Computing With Emerald Cluster
Setup
AFS Packages to be “ipm add”-ed
Notice the order: Compiler is always added first
Add ONLY ONE compiler into your environment
COMPILER
MPICH/MPICH2
MPI-LAM
GNU
ipm add gcc mpich
ipm add gcc mpi-lam
Absoft ProFortran
ipm add profortran mpich
ipm add profortran mpi-lam
Portland Group
ipm add pgi mpich
ipm add pgi mpi-lam
Intel
ipm add intel_fortran intel_CC mpich
ipm add intel_fortran intel_CC mpi-lam

60. Parallel Computing With Emerald Cluster
Compilation
To compile an MPI Fortran 77 code, code.f, and to form an executable, exec %mpif77 -O -o exec code.f
For a Fortran 90/95 code, code.f90, and to form an executable, exec %mpif90 -O -o exec code.f90
For a C code, code.c, and to form an executable, exec %mpicc -O -o exec code.c
For a C++ code, code.cc, and to form an executable, exec %mpiCC -O -o exec code.cc

61. Scientific Packages Available in AFS package space
To subscribe a package, type “ipm add pkg_name” where “pkg_name is the name of the package. For example, “ipm add gaussian”
To remove it, type “ipm remove pkg_name”
All packages are installed at the /afs/isis/pkg/ directory.
For example, /afs/isis/pkg/gaussian.
Categories of scientific packages include:
Quantum Chemistry
Molecular Dynamics
Material Science
Visualization
NMR Spectroscopy
X-Ray Crystallography
Bioinformatics
Others

62. Scientific Package: Quantum Chemistry
Software
Package Name
Platforms
Current Version
Parallel
ABINIT
abinit
LINUX
4.3.3
YES (MPI)
ADF
adf
LINUX
Yes (PVM)
Cerius2
cerius2
LINUX
4.10
Yes (MPI)
GAMESS
gamess
LINUX
Yes (MPI)
Gaussian
gaussian
LINUX
03E01
Yes (OpenMP)
MacroModel
macromodel
IRIX
7.1 No
MOLFDIR
molfdir
LINUX
2001 NO
Molpro
molpro
LINUX
2006.6
Yes (MPI)
NWChem
nwchem
LINUX
5.1
Yes (MPI)
MaterialStudio
materisalstudio
LINUX
4.2
Yes (MPI)
CPMD
cpmd
LINUX
3.9
YES (MPI)
ACES2
aces2
LINUX
4.1.2 No

63. Scientific Package: Molecular Dynamics
Software
Package Name
Platforms
Current Version
Parallel
Amber
amber
LINUX
9.1
MPI
NAMD/VMD
namd,vmd
LINUX
2.5
MPI
Gromacs
gromcs
LINUX
3.2.1
MPI
InsightII
insightII
IRIX
2000.3 --
MacroModel
macromodel
IRIX
7.1 --
PMEMD
pmemd
LINUX
3.0.0
MPI
Quanta
quanta
IRIX
2005
MPI
Sybyl
sybyl
LINUX
7.1 --
CHARMM
charmm
LINUx
3.0B1
MPI
TINKER
tinker
LINUX
4.2 -- O o
LINUX
9.0.7 --

64. Molecular & Scientific Visualization
Software
Package Name
Platforms
Current Version
AVS
avs
LINUX
5.6
AVS Express
Avs-express
LINUX
6.2
Cerius2
cerius2
IRIX/LINUX
4.9
DINO
dino
IRIX
0.8.4
ECCE
ecce
LINUX
2.1
GaussView
gaussian
LINUX/AIX
4.0
GRASP
grasp
IRIX
1.3.6
InsightII
insightII
LINUX
2000.3
MOIL-VIEW
Moil-view
IRIX
9.1
MOLDEN
molden
LINUX
4.0
MOLKEL
molkel
IRIX
4.3
MOLMOL
molmol
LINUX
2K.1
MOLSCRIPT
molscript
IRIX
2.1.2
MOLSTAR
molstar
IRIX/LINUX
1.0

65. Molecular & Scientific Visualization
Software
Package Name
Platforms
Current Version
MOVIEMOL
moviemol
LINUX
1.3.1
NBOView
nbo
LINUX
5.0
QUANTA
quanta
IRIX/LINUX
2005
RASMOL
rasmol
IRIX/LINUX/AIX
2.7.3
RASTER3D
raster3d
IRIX/LINUX
2.7c
SPARTAN
spartan
IRIX
5.1.3
SPOCK
spock
IRIX
1.7.0p1
SYBYL
sybyl
LINUX
7.1
VMD
vmd
LINUX
1.8.2
XtalView
xtalview
IRIX
4.0
XMGR
xmgr
LINUX
4.1.2
GRACE
grace
LINUX
5.1.2
IMAGEMAGICK
Imagemagick
IRIX/LINUX/AIX
GIMP
gimp
IRIX/LINUX/AIX
1.0.2 XV xv
IRIX/LINUX/AIX
3.1.0a

66. NMR & X-Ray Crystallography
Software
Package Name
Platforms
Current Version
CNSsolve
cnssolve
IRIX/LINUX
1.1
AQUA
aqua
IRIX/LINUX
3.2
BLENDER
blender
IRIX
2.28a
BNP
bnp
IRIX/LINUX
0.99
CAMBRIDGE
cambridge
IRIX
5.26
CCP4
ccp4
IRIX/LINUX
4.2.2
CNX
cns
IRIX/LINUX
2002
FELIX
felix
IRIX/LINUX
2004
GAMMA
gamma
IRIX
4.1.0
MOGUL
mogul
IRIX/LINUX
1.0
Phoelix
phoelix
IRIX
1.2
TURBO
turbo
IRIX
5.5
XPLOR-NIH
Xplor_nih
IRIX/LINUX
2.11.2
XtalView
xtalview
IRIX
4.0

67. Scientific Package: Bioinformatics
Software
Package Name
Platforms
Current Version
BIOPERL
bioperl
IRIX
1.4.0
BLAST
blast
IRIX/LINUX
2.2.6
CLUSTALX
clustalx
IRIX
8.1
EMBOSS
emboss
IRIX
2.8.0
GCG
gcg
LINUX
11.0
Insightful Miner
iminer
IRIX
3.0
Modeller
modeller
IRIX/LINUX
7.0
PISE
pise
LINUX
5.0a
SEAVIEW
seaview
IRIX/LINUX
1.0
AUTODOCK
autodock
IRIX
3.05
DOCK
dock
IRIX/LINUX
5.1.1
FTDOCK
ftdock
IRIX
1.0
HEX
hex
IRIX
2.4

68. Why do We Need Job Management Systems?
“Whose job you run in addition to when and where it is run, may be as important as how many jobs you run!”
Effectively optimizes the utilization of resources
Effectively optimizes the sharing of resources
Often referred to as Resource Management Software, Queuing Systems, or Job Management System, etc.

69. Job Management Tools PBS - Portable Batch System
Open Source Product Developed at NASA Ames Research Center
DQS - Distributed Queuing System
Open Source Product Developed by SCRI at Florida State University
LSF - Load Sharing Facility
Commercial Product from Platform Computing, Already Deployed at UNC-CH ITS Computing Servers
Codine/Sun Grid Engine
Commercial Version of DQS from Gridware, Inc. Now owned by SUN.
Condor
A Restricted Source ‘Cycle Stealing’ Product From The University of Wisconsin
Others Too Numerous To Mention

70. Operations of LSF Submission host Master host Execution host queue
other
hosts
Master host
other
hosts
Execution host 3
LIM
MLIM
LIM
Load
information 4 2 5
SBD
Batch API
MBD 11 8 9
Child SBD 1 6 7
queue 10 12
bsub app
RES
LIM – Load Information Manager
MLIM – Master LIM
MBD – Master Batch Daemon
SBD – Slave Batch Daemon
RES – Remote Execution Server 13
User job

71. Intro to Scientific Computing
Common LSF Commands
10/9/2008
lsid
A good choice of LSF command to start with is the lsid command
lshosts/bhosts
shows all of the nodes that the LSF system is aware of
bsub
submits a job interactively or in batch using LSF batch scheduling and queue layer of the LSF suite
bjobs
isplays information about a recently run job. You can use the –l option to view a more detailed accounting
bqueues
displays information about the batch queues. Again, the –l option will display a more thorough description
bkill <job ID# >
kill the job with job ID number of #
bhist -l <job ID# >
displays historical information about jobs. A “-a” flag can displays information about both finished and unfinished jobs
bpeek -f <job ID#>
displays the stdout and stderr output of an unfinished job with a job ID of #.
bhpart
displays information about host partitions
bstop
Suspend a unfinished jobs
bswitch
switches unfinished jobs from one queue to another
Research Computing Center, ITS

72. More about LSF Type “jle” -- checks job efficiency
Type “bqueues” for all queues on one cluster/machine (-m); Type “bqueues -l queue_name” for more info about the queue named “queue_name”
Type “busers” for user job slot limits
Specific for Baobab:
cpufree -- to check how many free/idle CPUs avaialble
pending -- to check how many jobs are still pending
bfree – to check how many free slots available “bfree –h”

73. LSF Queues Emerald Clusters
Description
int
Interactive jobs
now
Preemptive debugging queue, 10 min wall-clock limit, 2 CPUs
week
Default queue, one week wall-clock limit, up to 32 CPUs/user
month
Long-running serial-job queue, one month wall-clock limit, up to 4 jobs per user
staff
ITS Research Computing staff queue
manager
For use by LSF administrators

74. How to Submit Jobs via LSF on Emerald Clusters
Jobs to Interactive Queue
bsub -q int -m cedar -Ip my_interactive_job
Serial Jobs
bsub -q week -m cypress my_batch_job
Parallel OpenMP Jobs
setenv OMP_NUM_THREADS 4
bsub -q week -n 4 -m cypress my_parallel_job
Parallel MPI Jobs
bsub -q week -n 4 -m cypress mpirun -np 4 my_parallel_job

75. Peculiars of Emerald Cluster
CPU Type
Resources -R
Parallel Job Submission
esub -a
Wrapper
Xeon 2.4 GHz
Xeon24, blade,…
lammpi
mpichp4
lammpirun_wrapper
mpichp4_wrapper
Xeon 2.8 GHz
Xeon28, blade,…
Xeon 3.2 GHz
Xeo32, blade,…
16-Way IBM P575
p5aix,…
Notice that -R and -a flags are mutually exclusive in one command line.

76. Run Jobs on Emerald LINUX Cluster
Interactive Jobs
bsub -q int -R xeon28 -Ip my_interactive_job
Syntax for submitting a serial job is:
bsub -q queuename -R resources executable
For example
bsub -q week -R blade my_executable
To run a MPICH parallel job on AMD Athlon machines with, say, 4 CPUs,
bsub -q idle -n 4 -a mpichp4 mpirun.lsf my_par_job
To run LAM/MPI parallel jobs on IBM BladeCenter machines with, say, 4 CPUs:
bsub -q week -n 4 -a lammpi mpirun.lsf my_par_job

77. Final Friendly Reminders
Never run jobs on login nodes
For file management, coding, compilation, etc., purposes only
Never run jobs outside LSF
Fair sharing
Never run jobs on your AFS ISIS home or ~/ms. Instead, on /scr, /netscr, or /nas
Slow I/O response, limited disk space
Move your data to mass storage after jobs are finished and remove all temporary files on scratch disks
Scratch disk not backed up, efficient use of limited resources
Old files will automatically be deleted without notification

78. Online Resources Get started with Research Computing:
Programming Tools
Scientific Packages
Job Management
Benchmarks
High Performance Computing

79. Short Courses Introduction to Scientific Computing
Introduction to Emerald
Introduction to Topsail
LINUX: Introduction
LINUX: Intermediate
MPI for Parallel Computing
OpenMP for Parallel Computing
MATLAB: Introduction
STATA: Introduction
Gaussian and GaussView
Introduction to Computational Chemistry
Shell Scripting
Introduction to Perl
click “Current Schedule of ITS Workshops”

80. Intro to Scientific Computing
10/9/2008
Please direct comments/questions about research computing to Please direct comments/questions pertaining to this presentation to
In order for create a section divider slide, add a new slide, select the “Title Only” Slide Layout and apply the “Section Divider” master from the Slide Design menu. For more information regarding slide layouts and slide designs, please visit
Research Computing Center, ITS

81. Hands-on Exercises If you haven’t done so yet
Subscribe the Research Computing services
Access via SecureCRT or X-Win32 to emerald, topsail, etc.
Create a working directory for yourself on /netscr or /scr
Get to know basic AFS, UNIX commands
Get to know the Baobab Beowulf cluster
Compile OpenMP codes on Emerald
Compile serial and one parallel (MPI) codes on Emerald
Get familiar with basic LSF commands
Get to know available packages available in AFS space
Submit jobs via LSF using serial or (OpenMP/MPI)parallel queues
The WORD .doc format of this hands-on exercises is available here:
/afs/isis/depts/its/public_html/divisions/rc/training/scientific/short_courses/labDirections_SciComp_2009.doc
