3. Frog Anatomy Guide Externals Mouth Muscles Internals Virtual Dissection

4. External Anatomy Guide Mouth MusclesInternalsGuide 1.External Nares 2.Floor of oral cavity 3.tympanium 1.Cloaca 2.Gastrocnemius muscle 3. Webbed Foot Click once to see key

5. Mouth Anatomy Guide MusclesInternalsGuideExternals a. Esophagus opening b. Vomerine teeth 1. Grove of the maxilla 2. Maxillary teeth 3. Internal nare 4. Eye ball 5. Eustachian tube opening 6. Jaw ridge 7. Underside of the tongue 8. Glottis 9. Cut muscle and bone Click once to see key

6. Muscles Anatomy Guide ExternalsMouthInternalsGuide 1. Nictictating membrane 3. Deltoid 4. Triceps brachii 5. Triceps femoris 6. Semimembranosus 7. Gracilis minor 8. External Oblique 9. Gastrocnemius 53. Achilles tendon Click once to see key

7. Internal Anatomy Guide ExternalsMouthMusclesGuide Internal Organs Male Internals Female Internals

8. Internal Organs 38. Auricle (atrium) 39. Ventricle 40. Conus arteriosus 41. Aortic arches 42. Lung 43. Liver 44. Gall bladder 46. Small intestine 47. Large intestine 49. Spleen 50. Kidney 51. Fat bodies 52. Urinary bladder 55. Adrenal gland 56. testis InternalsClick once to see key

9. Male Internal Organs Internals 45. Stomach 46. Small intestine 47. Large intestine 48. Pancreas 49. Spleen 50. Kidney 55. Adrenal 56. Testis 57. Vestigial oviducts Click once to see key

10. Female Internal Organs Internals Click once to see key 45. Stomach 46. Small intestine 47. Large intestine 48. Pancreas 49. Spleen 51. Fat bodies 52. Urinary bladder 58. Ovary 59. Oviduct

11. http://www.froguts.com/flash_content/index.html Select the link below, demos, and then frog to participate in a virtual dissection!! Guide
