2. HOSE ROLLS Straight roll ◦Lay the hose out straight and flat on a clean surface ◦Roll the male coupling over onto the hose to start the roll ◦Form a coil that is open enough to allow the fingers to be inserted ◦Continue to roll the coupling over onto the hose, forming an even roll ◦As the roll increases in size, keep its edge aligned on the remaining hose to make a uniform roll ◦Lay the completed roll flat on the ground ◦Using a foot, tamp any protruding coils down into the roll

4. HOSE ROLLS Donut roll ◦Method 1  Lay the section of hose flat and in a straight line  Start the roll from a point 5 or 6 feet off center towards the male coupling  Roll towards the female end  Leave sufficient space at the center loop to insert the hand for carrying  Near the completion of the roll, the male coupling is enclosed within the roll as the hose is rolled over it  Check to make sure the male coupling is inside the roll with the female coupling about 3 feet ahead of it

7. HOSE ROLLS ◦Method 2  Grasp coupling and carry it to other end  Check to make sure the looped section is laying flat, straight, and without twists  Face coupling ends and start rolling 2 ½ feet from bend towards the male coupling  Pull female side back to relieve tension  As roll approaches the male coupling, lay the roll flat on the ground and bring the female end around the male coupling to complete the roll

10. HOSE ROLLS Twin donut roll ◦Place the male and female couplings together ◦Lay the hose flat, without twisting, to form two parallel lines from the loop end to the couplings ◦Fold the loop end over and upon the two lines to start the coupling ◦Continue to roll both lines simultaneously towards the coupling ends, forming a twin roll with a decreased diameter

13. HOSE ROLLS Self-locking twin donut roll ◦Place the male and female couplings together ◦Lay the hose flat, without twisting, to form parallel lines from the loop end to the couplings ◦Move one side of the hose up and over 2 ½ to 3 feet to the opposite side without turning ◦Adjust the size of this shoulder loop to the proper length for carrying ◦Facing the coupling ends, bring the back side of the loop forward toward the couplings, and place it on top of where the hose crosses forming a loop on each side without twist

14. HOSE ROLLS  Start rolling towards the coupling ends, forming two rolls side by side  When the rolls are completed, allow the couplings to lie across the top of each roll, and adjust the loops, one short and one long, by pulling only one side of the loop through  Place the long loop through the short loop, just behind the couplings, and tighten snugly forming a shoulder sling

18. DIFFERENT TYPES OF COUPLING & UNCOUPLING PROCEDURES Coupling hose ◦Foot tilt method (one firefighter)  Stand facing the two couplings so that one foot is near the male end  Place the foot directly on the hose behind the male coupling and apply pressure to tilt it upward  Position feet apart for balance  Grasp the female end by placing one hand behind the coupling and the other hand on the coupling swivel  Bring the two couplings together and turn the swivel clockwise with the thumb to make the connection

19. Foot tilt method

20. DIFFERENT TYPES OF COUPLING & UNCOUPLING PROCEDURES ◦Two firefighter method  Male coupling ◦ While facing the assistant, grasp the male coupling with both hands ◦ Bend the hose directly behind the coupling ◦ Hold the coupling and hose tightly against the upper thigh or midsection, with the male threads outward ◦ Look in another direction while assistant aligns couplings and tightens them

21. Two firefighter method

22. DIFFERENT TYPES OF COUPLING & UNCOUPLING PROCEDURES ◦Female coupling  Grasp the female coupling with both hands  Bring both couplings together  Align them using the Higbee indicator or other method(s)  Turn the female coupling counterclockwise until a click is heard  Turn the female coupling clockwise until tightened

23. DIFFERENT TYPES OF COUPLING & UNCOUPLING PROCEDURES ◦Hose uncoupling  Knee press method ◦ Grasp the hose behind the female coupling ◦ Stand the male coupling on end ◦ Set feet well apart for balance ◦ Place one knee upon the hose and shank of the female coupling ◦ Snap the swivel quickly in a counterclockwise direction as body weight is applied to loosen the connection

24. Knee press method

25. DIFFERENT TYPES OF COUPLING & UNCOUPLING PROCEDURES  Two firefighter stiff arm method ◦ Take a firm two-handed grip on your respective coupling and press the coupling toward the other firefighter, thereby compressing the gasket in the coupling ◦ Keep arms stiff, and use the weight of both bodies to turn each hose coupling counterclockwise, thus loosening the connection

27. HOSE CARRIES Hose carry: Shoulder loads (from flat or horseshoe) ◦Attach nozzle to end of hose ◦Position carrier at tailboard facing in the direction of travel ◦Place the initial fold of hose over the carrier’s shoulder so that the nozzle can be carried chest high ◦Bring the hose from behind over the shoulder so the rear fold ends at the back of the knee ◦Complete the above procedure for each carrier until the desired length of hose is loaded ◦Uncouple the hose from the hose bed when desired length is loaded ◦Hand the coupling to the last carrier

31. HOSE CARRIES Hose carry: shoulder loads (from flat or accordion) ◦Facing the hose bed, grasp the nozzle and the number of folds needed to make the desired length ◦Pull the folds about one-third of the way out of the bed  Twist the folds into an upright position  Turn and pivot into the folds placing them on top of the shoulder  Make sure the hose is flat with the nozzle and/or coupling in front of the body

35. HOSE CARRIES Hose carry/drag ◦Stands alongside the hoseline and picks up the nozzle or coupling ◦Places the hoseline over his/her shoulder with the coupling (nozzle) in front, resting on his/her chest ◦Walks approximately 25 feet ◦Pick up hose with other hand ◦Holds the coupling in place while pulling with his/her shoulder, arms and legs dragging hose to desired location
