3. Simplified SQL Performance Management in Oracle Database 11g
Pete Belknap

4. The following is intended to outline our general product direction
The following is intended to outline our general product direction. It is intended for information purposes only, and may not be incorporated into any contract. It is not a commitment to deliver any material, code, or functionality, and should not be relied upon in making purchasing decisions. The development, release, and timing of any features or functionality described for Oracle’s products remains at the sole discretion of Oracle.

5. Agenda SQL Tuning Challenges Oracle Database 11g Solutions Q & A
Automatic SQL Tuning
Improvements to SQL Tuning Advisor
Fully automating SQL tuning
Real-time SQL Monitoring
Track high response-time SQL
Find the most expensive plan operation
Q & A

6. SQL Tuning Challenges
Oracle Database 10g introduced SQL advisors to simplify application and SQL tuning
Remaining challenges
SQL Tuning still reactive
Painful to find and investigate long-running SQL
Oracle Database 11g solutions
Automatic SQL Tuning
Real-time SQL Monitoring

7. <Insert Picture Here>
Automatic SQL Tuning
<Insert Picture Here>
The Self-Managing Database

8. Challenges of Manual SQL Tuning
Requires expertise in several domains
SQL optimization: adjust the execution plan
Access design: provide fast data access
SQL design: use appropriate SQL constructs
Time consuming
Plans are complicated
Each SQL statement is unique and each execution can be different
Potentially large number of statements to tune
Testing proposed changes is labor-intensive
Many possible ways to a solution
Never ending task
SQL workload always evolving
Plan regressions

9. Simplifying SQL Tuning SQL Tuning Advisor, since Oracle Database 10g
Recommendations
Automatic Tuning Optimizer
SQL Tuning Advisor
Statistics Analysis
Gather Missing or Stale Statistics
SQL Profiling
Create a SQL Profile
DBA
Access Path Analysis
Add Missing Indexes
SQL Structure Analysis
Modify SQL Constructs

10. SQL Profiling Technology Transparent SQL tuning
No SQL Profile
SQL Profiling
Use SQL Profile (future executions)
SQL Profile
use ? ? ?
Plan 3
Plan 2
Plan 1
Search Space
add ? ? ? ? ?
Plan 3 ?
Search Space
Plan 3
Plan 1
Plan 2
Plan 1
Plan 2
Validates estimates using dynamic sampling and partial execution
Validates only relevant estimates

11. SQL Profiling Technology (2) Trying alternative plans (new in 11g)
Profile Selection
(3)
(1)
Estimate
Correction
Correction Factors
Alternative Plan Analysis
Corrections + O_F_E
Corrections + O_F_E
(2)
Corrections + O_F_E 8.1.7
Alternate Plan Set
Try some interesting alternatives: plans from old releases
Feed correction factors into alternative plan selection
But which is the best?

12. Testing SQL Profiles (1) Measuring actual benefit with test-execution (new in 11g)
Naïve: Execute in Order P1 P2
Finish, P2 wins!
But what if P1 never completes?
Timeout! P1
It would be great to run them concurrently…. P1 P2
P2 wins, kill P1!
But then I take 2 CPUs, and N in the general case…

13. Testing SQL Profiles (2) Measuring actual benefit with test-execution
Solution: Tournament Execution P1 P2
Round 1:
15 sec P1 P2
Round 2:
30 sec
16 sec
Your winner, with a knockout in the second round, P2!

14. Testing SQL Profiles (3) Choosing appropriate metrics, comparison strategy
“Winner” and “Loser” depends on your point of view
Need a statistic that is repeatable and comprehensive.
ELAPSED_TIME: comprehensive, but includes row lock waits; I/O time depends on buffer cache state. Not repeatable.
CPU_TIME: very repeatable, but not comprehensive for I/O.
BUFFER_GETS: very repeatable, but ignores CPU expense; overly pessimistic for some plans
Combine the best elements of each
CPU_TIME should improve (most reliable statistic)
Benefit Reported: ratio of CPU_TIME + BUFFER_GETS*10ms
Conservatively consider every buffer get to be an I/O, but allow large CPU improvements to overrule small buffer gets regressions

15. Improvements in Oracle Database 11g Better SQL Profiling
SQL Tuning
Recommendations
Automatic Tuning Optimizer
SQL Tuning Advisor
Gather Missing or Stale Statistics
Statistics Analysis
SQL Profiling
Create a SQL
Profile
show verified benefit
Fix potential regression after upgrade
Verify benefit through test-execution
DBA
Access Path Analysis
Add Missing Indexes
SQL Structure Analysis
Modify SQL Constructs

16. Agenda SQL Tuning Challenges Oracle Database 11g Solutions Q & A
Automatic SQL Tuning
Improvements to SQL Tuning Advisor
Fully automating SQL tuning
Real-time SQL Monitoring
Track high response-time SQL
Find the most expensive plan operation
Q & A

17. SQL Tuning in Oracle Database 10g End-to-end Workflow
Evaluate
Recommendations
DBA
Implement
DBA
Workload
Generate
Recommendations
SQL Tuning Advisor
SQL Tuning Candidates
DBA
Invoke Advisor
ADDM
one hour
AWR
A good end-to-end solution, but manual intervention is required

18. Improvements in Oracle Database 11g Fully-Automated Tuning Workflow
Implement
SQL Profiles
Test SQL Profiles
Workload
Generate
Recommendations
SQL Tuning Candidates
Choose Candidate SQL
one week
AWR
It’s Automatic!
DBA
View Reports / Control Process

19. Picking Candidate SQL (1)
S4, 1 minute
Week’s Top SQL,
Ordered by DB Time
S3, 5 minutes
S2, 8 minutes
S1, 10 minutes
I could just pick from the top down…
AWR
But I will miss SQLs with important hotspots!
AWR
Average Exec
Hourly
Daily
Weekly
Let’s try a more balanced approach:
OK, but where do I start?

20. Picking Candidate SQL (2)
AWR
Weekly
Average Exec
Daily
Hourly
Candidate List
20%
10%
65% 5%
Eventually we need one list to tune from: merge the buckets.
All buckets are not created equal: focus on the week, but don’t forget about the others.
Focus on the SQLs we have not seen recently: Don’t re-tune SQLs if nothing has changed!

21. Tuning Flow Tuning activities per SQL
Candidate SQLs
Store reporting data
Fetch next SQL
Accept Profile
Tune SQL
If < 3X benefit, recommend for DBA consideration
Fix potential regressions
Look for indexes, statistics, as with standard tuning
Require 3X benefit
Both CPU and I/O times must improve
Evaluate Profile
Tournament competition

22. Focus on SQL Profiles First step in automating SQL tuning
Auto-testing/implementing is limited to profiles because:
No lengthy, expensive set-up process (building an index takes time)
Private to the current compilation
No change to user SQL (does not change semantics)
SQL-level recommendation, can be effectively tested
Easily reversed by the DBA
Testing is done for regular SQL Tuning Advisor tasks as well!

23. Automatic SQL Tuning Defaults Sensible defaults with flexible configurations
Out-of-the-box defaults:
Runs in each maintenance window (MAINTENANCE_WINDOW_GROUP)
SQL profiles are tested but not implemented
DBA can configure using EM:
Whether / When / How long it runs
Resources it uses
Whether it implements profiles
How many profiles it implements

24. Automatic SQL Tuning Task

25. Automatic SQL Tuning Configuration

26. Automatic SQL Tuning Result Summary

27. Automatic SQL Tuning Result Recommendations

28. Automatically Tuned SQL Details Drilldown

29. Conclusions Manual SQL tuning is painful even for the experts
Oracle 10g SQL Tuning Advisor quickly gives DBA good choices
Oracle 11g Automatic SQL Tuning automates the process by making the easy decisions
DBA can control as much of the process as he wants

30. Q
& A

31. Real-Time SQL Monitoring
<Insert Picture Here>
Shining new light on SQL Performance

32. Problem: Managing High Response-Time SQLs
Monitoring: tracking high response-time SQL
What is that expensive SQL (ETL, DDL, batch, report, …) I started up to?
Do I have any high response-time SQL running on my OLTP system?
Any SQL executing parallel?
Investigating: why is this execution so expensive?
Plan has hundreds of operations -- where is the time being spent?
Why is a particular operation so expensive?
SQL runs parallel, is DOP appropriate? is there a skew?
 What is going on inside a SQL execution???
Single
SQL
Execution

33. Solution: Real-time SQL Monitoring Looking inside the SQL
Enabled out-of-the-box with no performance impact
Automatically monitors SQL executions that:
consume more than 5 seconds of CPU or I/O time
are running parallel: PQ, PDML, PDDL
Monitors each execution independently
Exposes monitoring statistics at multiple levels
Global execution level
Plan operation level (Plan Tuning)
Parallel Execution level (PX Tuning)
Guides your tuning efforts
Single
SQL
Execution

34. How does it work?
t = 5
t = 6
t = 7
PGA
SGA
Update execution statistics in PGA continuously
After 5 seconds for serial / immediately for parallel, target for monitoring (reserve SGA space)
Push statistics to SGA every second
Separate entries for each Parallel Execution Server
Each execution of each SQL identifiable in ASH via execution key
PX Servers share an execution key, but have a different Session ID
Statistics available for at least 5 minutes
Not vulnerable to cursor age-outs

35. New Statistics Exposed
For each SQL Execution (V$SQL_MONITOR):
Resource Consumption: ELAPSED_TIME, CPU_TIME, FETCHES, BUFFER_GETS, DISK_READS, DIRECT_WRITES, APPLICATION/CONCURRENCY/CLUSTER/USER_IO_WAIT_TIME, PLSQL/JAVA_EXEC_TIME
For each Plan Operation (V$SQL_PLAN_MONITOR):
Production: STARTS (#executions), OUTPUT_ROWS
Memory/Temp usage: WORKAREA_MEM, WORKAREA_TEMPSEG
For each second of session activity (V$ACTIVE_SESSION_HISTORY):
SQL Execution Key: SQL_ID, SQL_EXEC_START, SQL_EXEC_ID
Row source information: SQL_PLAN_LINE_ID/OPERATION/OPTIONS

36. V$ Additions New V$ Views added; existing views supplemented
V$ACTIVE_SESSION_HISTORY (SAMPLE_TIME, SESSION_ID, SESSION_SERIAL#) With Execution Key, Plan Line ID/Operation
DBA_HIST_ACTIVE_SESS_HISTORY (DBID, SNAP_ID, INSTANCE_NUMBER, SAMPLE_TIME, SESSION_ID, SESSION_SERIAL#)
V$SESSION (SID, SERIAL#) With Execution Key
V$SQL_MONITOR (SQL_ID, SQL_EXEC_START, SQL_EXEC_ID)
V$SESSION_LONGOPS (SID, SERIAL#, OPNAME) With Execution Key, Plan Line ID/Operation
V$SQL_PLAN_MONITOR (SQL_ID, SQL_EXEC_START, SQL_EXEC_ID, PLAN_LINE_ID)
V$SQL_PLAN (SQL_ID, CHILD_NUMBER, PLAN_HASH_VALUE, ID)

37. How do I use it?
11g Enterprise Manager Grid Control ( DB Control)
Additional reporting (available today): DBMS_SQLTUNE.REPORT_SQL_MONITOR
Get reports in HTML, XML, or Text

38. Enterprise Manager Flow (1)
SQL Details
Monitoring Details
Top Activity
Session Details

39. Enterprise Manager Flow (2)
Monitoring List
Monitoring Details

40. SQL Monitoring List

41. SQL Monitoring Details Core concepts

42. SQL Monitoring Details Core concepts

43. SQL Monitoring Details Core concepts

44. SQL Monitoring Details Core concepts

45. SQL Monitoring Details (Parallelism) Core concepts

46. SQL Monitoring Details (Parallelism) Core concepts

47. SQL Monitoring Details (Parallelism) Core concepts

48. SQL Monitoring Details Big Plans

49. SQL Monitoring Details Big Plans

50. SQL Monitoring Details Big Plans

51. SQL Monitoring Details Big Plans

52. SQL Monitoring Details Big Plans

53. SQL Monitoring Details Poor Indexing

54. SQL Monitoring Details Partially Parallelized

55. SQL Monitoring Details Partially Parallelized

56. SQL Monitoring Details Partially Parallelized

57. SQL Monitoring Details FORCE PARALLEL QUERY PARALLEL 4

58. SQL Monitoring Details FORCE PARALLEL QUERY PARALLEL 4

59. SQL Monitoring Details Advanced PQ Skews

60. SQL Monitoring Details Advanced PQ Skews

61. SQL Monitoring Details Advanced PQ Skews

62. SQL Monitoring Details Advanced PQ Skews

63. Conclusion Real-Time SQL Monitoring is
Monitoring and tuning for high response-time SQLs
New, fine-grained SQL statistics
tracked automatically
updated while the SQL runs
highly visible and accessible
at no cost to your production system
The only way to know what’s happening inside single SQL execution
The quickest way to the root cause of a performance problem: If you can find the problem, you can fix it!

64. Q
& A
