1. VB.NET PROGRAMMING
FINAL EXAM TEST REVIEW

2. An Introduction to VB.NET and Program Design
Chapter 1 Review
An Introduction to VB.NET and Program Design

3. Chapter One Review
Step-by-step series of instructions telling the computer what to do.
A Program
The process of writing these instructions is called what?
Programming

4. Chapter One Review People who design and write programs
Programmers or software developers
A collection of one or more programs
Applications
The process of writing applications
Program Development

5. What is Microsoft Visual Basic .NET?
A programming environment that allows you to build programs for the Windows operating system or any system that supports Microsoft’s .NET architecture.
VB.NET
VB.NET is based on the what programming langauge?
Visual Basic which evolved from BASIC
The process of writing a program using a programming language is called what?
Coding

6. Programming and Application Development
Store program
Machine Cycle – how a computer processes information -- 4 Steps!
Fetch
Decode
Execute
Store

7. Application Types Runs in a Windows Environment. Has a user-interface
Windows Applications

8. Application Types
Runs from your web browser. Converts the VB to HTML. Has a user-interface.
Web Applications

9. Application Types Have a user-interface. Runs from a command prompt.
Console Applications

10. The Development Cycle

13. Storyboard

14. The Visual Basic .NET Integrated Development Environment
Chapter 2
The Visual Basic .NET Integrated Development Environment

15. Starting Visual Basic .NET
The part of the VB.NET application that contains windows and toolbars that allow you to develop applications.
Integrated Development Environment (IDE)
A collection of code and other files that usually encompasses one program.
Project

16. Chapter Two
When the IDE is in ________ _______, you can make modifications to the forms and code of a program.
Design Time
Displays the VB.NET menu names each of which represents a list of commands that you allow you to create, edit, save, print, test and run VB.NET applications.
Menu Bar

17. Chapter Two
Contain shortcuts to commonly used commands. Standard and Layout are two most popular toolbars.
Toolbars
A grouping of projects and related files. Solutions can contain one project, like this take-home pay calculator, or many related projects, data files and graphic files.
Solution

18. Chapter Two
To test a project you _________ it. This is usually done by clicking the start button on the standard toolbar.
RUN
By running your project during the development phase, you can check for problems, or ________, that you may have introduced into your code inadvertently.
BUGS
The process of getting your code to work as expected is known as ____________.
DEBUGGING

19. Chapter Two
A characteristic or attribute of an object, such as its background color or the text that it displays.
PROPERTY
The ______________ lists the attributes for the object currently selected in the main work area.
PROPERTIES WINDOW
The Properties Windows has two parts:
__________ ______ -- displays the name of the currently selected object or control.
OBJECT BOX
__________ ___________ – displays the list of properties associated with the currently selected object or control.
PROPERTIES LIST

20. Building an Application in Visual Basic.NET
Chapter Three
Building an Application in Visual Basic.NET

21. Building an Application in the Visual Basic .NET Environment
Chapter 3
Building an Application in the Visual Basic .NET Environment

22. Chapter Three
The UI is the way the a program accepts data and instructions from the user and produces results.
User Interface
A ___________________ provides visual cues such as a menu, a button, or small pictures (called icons) to help the user enter data and give instructions to the computer.
Graphical User Interface (GUI)

23. Chapter Three
A control is said to have _____________ when it is selected on the screen.
FOCUS
Used to set the position where the application will display on run.
StartUpPosition
Allows you to set the title for a form.
Text Property
Controls the appearance of the border of a form.
FormBorderStyle
Sets the background and foreground colors for the form.
Background and Foreground

24. Chapter Three
Objects that you can add to your form.They are found on VB.Net’s Toolbox
CONTROLS
Displays text on the form that cannot be altered by the end user.
LABEL CONTROL
Displays text on the form that can be altered by end user.
TEXTBOX CONTROL
Used by the user to initiate actions called events.
BUTTON CONTROL
Used to display or allow users to enter numbers on a form. Cuts down on user’s ability to screw things up.
NUMERIC UP DOWN CONTROL

25. Chapter Three
Allows you to rename the object to something that makes more sense.
Name
Allows you to change the words that show up on the control itself. (or on the title bar of the form!).
Text
Makes it impossible for the end user to edit the text in that box.
Read Only

26. Chapter Three
Allows the programmer to control the order in which the control gets the focus when the user is tabbing.
TAB INDEX
Allows the programmer to have a control skipped during tabbing.
TAB STOP
NUMERIC UP/DOWN BOXES
Defines the current value displayed in the control
VALUE PROPERTY
Allows the programmer to define the upper and lower boundaries for the values in a NUD control.
MIN AND MAX PROPERTIES

27. CHAPTER THREE
Programmers often add comments within their code as a form of internal documentation. These are known as:
REM LINES or Comment Statements
Each comment line must begin with an ______________ or the letters ____ – which is short for “remark”.
APOSTROPHE OR REM

28. Chapter Three Messages sent to an object
EVENTS
Default event for buttons. Code will execute when user Clicks on the button.
CLICK EVENT
Instructions to the computer written at design time for the computer to execute at run time
CODE STATEMENTS

29. Writing Code in the Code Window
An error caused by code statements that violate one of the structure or syntax rules of the Visual Basic .NET language
SYNTAX ERROR
Event procedures for controls start with the word _____________ since the section is just for that one control.
PRIVATE SUB
The line that begins ____________ indicates the end of a particular event procedure.
END SUB

30. Working with Variables, Constants, Data Types and Expressions
CHAPTER FOUR
Working with Variables, Constants, Data Types and Expressions

31. Chapter Four
Presents a set of choices. Only one can be chosen at a time. Often placed in a group box.
RADIO BUTTONS
Property that keeps track of which radio button is selected.
CHECKED PROPERTY
Allows you to set a default button for a form.
ACCEPTBUTTON PROPERTY

32. Chapter Four
Represents a location in computer memory that can change values as the code executes.
VARIABLE
Represents a location in computer memory that cannot be changed during execution.
CONSTANT

33. Chapter Four
The ___________ of a variable or constant determines what kind of data it can store.
DATA TYPE
Name three common data types:
INTEGER, DOUBLE, STRING
There are rules to naming your variables:
The name must begin with a letter, not a # !
The name cannot be more than 16,383 characters. 
The name cannot contain punctuation or blank spaces.

34. Chapter Four Some variable Naming Conventions: Short == shr
Integer == int
Single == sng
Double == dbl
String == str
Object == obj

35. Chapter Four GLOBAL VARIABLES Keyword used to declare a variable. DIM
Refers to a variables ability to be accessed throughout a program. It is defined by where the variable is declared.
SCOPE
Variable that are available to all the procedures on a given form.
GLOBAL VARIABLES

36. Chapter Four
Predetermined order for performing calculations within an expression.
ORDER OF OPERATIONS
Arithmetic operators in Visual Basic
^ -- used to raise the power of an exponent
* used to multiply two numbers
/ -- used to divide 2 #’s and return a decimal result
\ -- used to divide 2 #’s and return an integer result
MOD -- Used to divide 2 #’s and return only the remainder
used to sum 2 #’s
Used to subtract 2 #’s or indicate a negative value

37. Chapter Four
Functions that are built into .NET.
INTRINSIC FUNCTIONS
This is a financial function that will return the payment for a loan based on periodic, constant payments and a constant interest rate.
PMT FUNCTION
Function that allows the programmer to determine how the output will appear on the screen.
FORMAT FUNCTION

38. Chapter 5
Decision Making

39. Chapter Five
Used in Windows applications to present lists of choices. Uses the prefix cmb.
COMBO BOX CONTROL
Used to build the list inside the combobox.
ITEMS PROPERTY
Used when there are more than two options in a decision making structure!
SELECT CASE
Provides the ability to display a message to the user in a pop-up window.
MESSAGE BOX

40. Chapter Five
When you add items to a ComboBox List VB.Net assigns each one an unique index number.
The first item is assigned an index of 0; the second item gets an index of 1; and so on.
For example: Index Numbers for Auto Loan Program
A -- Excellent Credit Rating = 0
B – Good Credit Rating = 1 etc ….
SelectedIndex is the property that keeps track of what index number is currently being accessed.
When no item is selected, the SelectedIndex property is set to -1. The following line of code would clear the ComboBox:

41. If…Then…Else Structure
Select Case Structure

42. Chapter Five Used to execute one statement or another conditionally.
IF THEN STATEMENTS
The condition follows the keyword IF
A condition is made up of two expressions and a relational (comparison) operator.
Equal = Less than or equal to <=
Less than < Greater than or equal to >=
Greater than > Not equal to <>
When you have an if…then within an if then!
NESTED IF THEN STATEMENTS

43. Coding a Select Case Statement

44. Coding a Select Case Statement

45. Chapter Five If strGender = “M” And intAge < 12 Then
Used to combine two or more conditions in an expression. All parts must be true for the True section of code to trigger!
AND LOGICAL OPERATOR
For example:
If strGender = “M” And intAge < 12 Then
MessageBox.Show(“Boys Little League”)
End if

46. Chapter Five
The process of adding strings together. It is performed with the ampersand [ &] character.
CONCATENATION
The plus sign (+) can be used instead of the (&) operator. Often times programmers avoid the + sign since it is used in mathematical problems as well.

47. Looping and Multiple Forms TEST REVIEW
Chapter 6
Looping and Multiple Forms
TEST REVIEW

48. QUESTION 1:
It’s possible to add an icon to your title bar by setting the form’s ____________ property.
Answer:
ICON

49. QUESTIONS 2 & 3: Determines how items display in the ListView Control.
ANSWER QUESTION 2:
VIEW PROPERTY
Switch to __________ if you want multiple columns to show up in the listview control.
ANSWER QUESTION 3:
DETAILS

50. QUESTION 4:
Rather than having to code changes for the width, height, and location of every control, VB.NET allows you to set a fixed location, or _____________, for controls to specified sides of a form.
ANSWER
ANCHOR

51. QUESTIONS 5 & 6: Most .NET applications contain more than one form.
ANSWER:
TRUE
If the first form is used to launch the second form it is sometimes referred to as the __________.
ANSWER
PARENT

52. QUESTIONS 7 & 8:
The ________________________ is used in applications to allow a user to specify one of two conditions, such as on or off, yes or no, or true or false.
ANSWER
CHECKBOX CONTROL
Determines whether the box is checked or not. It’s either True or False.
CHECKED PROPERTY

53. QUESTION 9:
Well, as is the case with all forms, the Today’s Sales Entry Form is a ____________, which means that an instance of the class must be declared before it can be used. This can be done with an _________________________.
ANSWER
CLASS
OBJECT VARIABLE

54. QUESTIONS 10 & 11: ANSWER NEW KEYWORD
The _______________________ determines whether the variable contains a complete instance of the object.
ANSWER
NEW KEYWORD
If the New keyword is not used, then the variable is declared for future use but no memory is set aside for the contents of the object.
If the New Keyword is used, the object is said to be _____________________ and memory is set aside for a complete copy of the object. You can’t use a new form until this is done.
Answer
INSTANTIATED

55. QUESTIONS 12 & 13
If the __________________ is used in a form’s code to open another form, then both forms still can receive focus and be accessed by the user.
This is called a ____________________ – meaning that the user can flip back and forth between the forms.
ANSWERS
Show() Method, modeless
The ______________________ is used to open a ________________ form.
This means that the user must complete the action on the modal form before they will be allowed to continue work on other forms.
Show Dialog(), modal

56. QUESTION 14
One of the most powerful aspects of computer programming is the capability of performing a set of operations repeatedly based on certain conditions.
In programming, the process of repeating a set of instructions is known as ______________.
ANSWER
LOOPING OR REPETITION

57. QUESTION 15:
This statement repeatedly executes a series of statements in the loop as long as the condition is true.
ANSWER:
DO WHILE
Two examples: (one tests at the top of the structure, one tests at the bottom of the structure)
Do While intCount <=20 Do
intCount = intCount intCount = intCount +1
Loop Loop While intCount <=20

58. QUESTION 16: This statement loops until the condition becomes true.
ANSWER:
DO UNTIL
Two examples: (one tests at the top of the structure, one tests at the bottom of the structure)
Do Until intCount >= 20 Do
intCount = intCount intCount = intCount +1
Loop Loop Until intCount >= 20

59. QUESTIONS 17 & 18:
A __________________ is a group of one or more objects that can be accessed and operated on as a single entity.
ANSWER:
COLLECTION
VB.NET assigns an unique ____________ to each item in a collection. This comes in handy when writing code for a ListView Control.
ANSWER
INDEX NUMBER

60. QUESTIONS 20, 21 & 22:
__________________ – this property always displays as the first column in the ListView Control.
If you have more than one column in a ListView control, a ________________ collection is created.
Each Item and SubItem has an ___________________
ANSWERS
TEXT PROPERTY
SUBITEMS
INDEX PROPERTY

61. QUESTION 23 & 24
For Example
lstTodaysSales.Items(1).Text = _______________
lstTodaysSales.Items(0).SubItems(2).Text = ________

62. QUESTIONS 25 & 26:
Loop that has an automatic counter and condition built in.
ANSWER:
FOR …. NEXT LOOP
List Three Benefits of For … Next Loops:
More efficient than a Do While Loop
Easier to read
Uses less memory
Faster execution

63. QUESTIONS 27 & 28: For example:
The ___________________ allows you to retrieve part of a string (from a larger string) based on a start position and the number of characters to retrieve.
ANSWER
SUBSTRING METHOD
For example:
strExample = “Christy Garrett”
strLastName = strExample.Substring ( ___ , ___)
(8, 7)

64. STUDY, STUDY, STUDY
THE TEST CAN BE TOUGH! MAKE SURE YOU READ OVER ALL OF YOUR NOTES!
