1. Segmentation by Clustering
EECS 274 Computer Vision
Segmentation by Clustering

2. Segmentation and grouping
Motivation: Obtain a compact representation from an image/motion sequence/set of tokens
Should support application
Broad theory is absent at present
Reading: FP Chapter 9-10, S Chapter 5
Grouping (or clustering)
collect together tokens that “belong together”
Fitting
associate a model with tokens
issues
which model?
which token goes to which element?
how many elements in the model?

3. How do they assemble?
A disturbing possibility is that they all lie on a sphere -- but then, if we didn’t know that the tokens belonged together,
where did the sphere come from?
Why do these tokens belong together (from human vision)?
because they form surfaces?
because they form the same texture?

4. Segmentation: examples
Summarizing videos: shots
Finding matching parts
Finding people
Finding buildings in satellite images
Searching a collection of images
Object detection
Object recognition

5. Models problems Forming image segments: superpixels, image regions
Fitting lines to edge points
Fitting a fundamental matrix to a set of feature points:
If the correspondence is right, there is a fundamental matrix connecting the points

6. Segmentation as clustering
Partitioning
Decompose into regions that have coherent color and texture
Decompose into extended blobs, consisting of regions that have coherent color, texture, and motion
Take a video sequence and decompose it into shots
Grouping
Collecting together tokens that, taken together, form a line
Collecting together tokens that seem to share a fundamental matrix
What is the appropriate representation?

7. General ideas Tokens Top down segmentation Bottom up segmentation
whatever we need to group (pixels, points, surface elements, etc., etc.)
Top down segmentation
tokens belong together because they lie on the same object
Bottom up segmentation
tokens belong together because they are locally coherent
These two are not mutually exclusive

8. Grouping and Gestalt Context affects how things are perceived
Gestalt school of psychology
Studying shape as a whole instead of just a collection of simple and curves
Grouping means the tendency of visual system to assemble components together and perceive them together
The famous Muller-Lyer illusion; the point is that the horizontal bar has properties that come only from its membership in
a group (it looks shorter in the lower picture, but is actually the same size) and that these properties can’t be discounted--- you can’t look at this figure and ignore the arrowheads and thereby make the two bars seem to be the same size.
Muller-Lyer illusion

9. Some Gestalt properties
emergence
reification

10. Figure and ground
A driving force behind the gestalt movement is the observation that it isn’t enough to think about pictures in terms of separating figure and ground (e.g. foreground and background). This is (partially) because there are too many different
possibilities in pictures like this one. Is a square with a hole in it the figure? or a white circle? or what?
(Left) White circle/black rectangle: which is figure (foreground) and which is ground (background)?
(Right) What object is in this picture?

11. Basic ideas of grouping in humans
Figure-ground discrimination
grouping can be seen in terms of allocating some elements to a figure, some to ground
impoverished theory
Gestalt properties
elements in a collection of elements can have properties that result from relationships (Muller-Lyer effect)
gestalt qualitat
(form quality)
A series of factors affect whether elements should be grouped together
Gestalt factors

12. Gestalt movement
Some criteria that tend to cause tokens to be grouped.

13. Examples of Gestalt factors
More such

14. Example
Occlusion cues seem to be very important in grouping. Most people find it hard to read the 5 numerals in
this picture

15. Occlusion as a cue
but easy in this

16. Grouping phenomena
The story is in the book (figure 14.7)

17. Illusory contours
Illusory contours; a curious phenomenon where you see an object that appears to be occluding.
Tokens appear to be grouped together as they provide a cue to the presence of an occluding object whose contour has no contrast

18. Background subtraction
If we know what the background looks like, it is easy to identify “interesting bits”
Applications
person in an office
tracking cars on a road
surveillance
Approach:
use a moving average to estimate background image
subtract from current frame
large absolute values are interesting pixels
trick: use morphological operations to clean up pixels

20. See caption, figure 14.10
Results using 80 x 60 frames
(a) Average of all 120 frames. (b) thresholding. (c) results with low threshold (with missing pixels) . (d) background computed using the EM-based algorithm. (e) background subtraction results (with missing pixels).

21. See caption, figure 14.11
An important point here is that background subtraction works quite badly in the presence of high spatial frequencies, because when we
Estimate the background, we’re almost always going to smooth it.
Results using 160 x 120 frames
(a) Average of all 120 frames. (b) thresholding. (c) results with low threshold (with missing pixels) . (d) background computed using the EM-based algorithm. (e) background subtraction results (with missing pixels).

22. Shot boundary detection
Find the shots in a sequence of video
shot boundaries usually result in big differences between succeeding frames
allows for objects to move within a given shot
Strategy:
compute interframe distances
declare a boundary where these are big
Possible distances
frame differences
histogram differences
block comparisons
edge differences
Applications:
representation for movies, or video sequences
find shot boundaries
obtain “most representative” frame
supports search

23. Interactive segmenation

24. Grabcut

25. Image matting

26. Superpixels

27. Segmentation as clustering
Cluster together (pixels, tokens, etc.) that belong together
Agglomerative clustering
attach closest to cluster it is closest to
repeat
Divisive clustering
split cluster along best boundary
Point-Cluster distance
single-link clustering (distance between two closest elements)
complete-link clustering (maximum distance between two elements)
group-average clustering
Dendrograms (tree diagram)
yield a picture of output as clustering process continues

28. A data set
A dendrogram

29. K-Means Choose a fixed number of clusters
Choose cluster centers and point-cluster allocations to minimize error
Can’t do this by search, because there are too many possible allocations.
Algorithm
fix cluster centers; allocate points to closest cluster
fix allocation; compute best cluster centers
x could be any set of features for which we can compute a distance (careful about scaling)

30. K-means clustering using intensity alone and color alone
Clusters on intensity
Clusters on color
I gave each pixel the mean intensity or mean color of its cluster --- this is basically just vector quantizing the image intensities/colors. Notice that there is no requirement that clusters be spatially localized and they’re not.
K-means clustering using intensity alone and color alone
(using 5 clusters)
How many clusters do we need in an image?

31. K-means using color alone, 11 segments (6 kinds of vegetables)
Clusters on color
K-means using color alone, 11 segments
(6 kinds of vegetables)

32. K-means using
color alone,
11 segments
(not using texture
or position)
- segments may be disconnected and scattered

33. K-means using color and position, 20 segments
- peppers are now separated
but, cabbage is still broken up
Here I’ve represented each pixel as (r, g, b, x, y), which means that segments prefer to be spatially coherent. These are just some of 20 segments.

34. Graph-theoretic clustering
Represent tokens using a weighted graph.
affinity matrix
similar have large weights
Cut up this graph to get connected components
with strong interior links
by cutting edges with low weights
A graph is a set of vertices V and edges E, G={V,E}
A weighted graph is one in which each edge is associated with a weight
Every graph consists of a disjoint set of connected components

35. Flow networks
A flow network G=(V,E): a directed graph, where each edge (u,v)E has a nonnegative capacity c(u,v)>=0.
If (u,v)E, we assume that c(u,v)=0.
Two distinct vertices: a source s and a sink t. s t 16 12 20 10 4 9 7 13 14

36. Maximum flow minimum cut
Also known as s-t cut
Several deterministic and randomized algorithms
Resulting Flow = 23

37. Weighted graph 9 points/pixels
9 x 9 Weighted matrix that looks like block diagonal
A cut with 2 connected components

38. (Left) a set of points (Right) affinity matrix computed with a decaying exponential distance (large values  bright pixels, and small values  dark pixels)

39. Graph cut and normalized cut
Cut a graph V into 2 connected components with minimal cost
cut(A,B):
sum of weights of all edges between A and B
assoc(A,V):
sum of all the weights associated with nodes in A

40. Affinity Intensity Distance Texture
here c(x) is a vector of filter outputs. A natural thing to do is to square the outputs of a range of different filters at different scales and orientations, smooth the result, and rack these into a vector.
Texture

41. Scale affects affinity
This is figure 14.18
σ=0.1
σ=0.2
σ=1

42. Extracting a single good cluster
Simplest idea: we want a vector a giving the association between each element and a cluster
We want elements within this cluster to, on the whole, have strong affinity with one another
We could maximize
But need the constraint
Solving constrained optimization with Lagrange multiplier
This is an eigenvalue problem - choose the eigenvector of A with largest eigenvalue
Cluster weights are the elements of the eigenvectors
 association of element i with cluster n ×
affinity between i and j ×
association of element j and cluster n

43. Example eigenvector
points
eigenvector
matrix

44. Clustering with eigenvectors
If we reorder the nodes, the rows and columns of A are shuffled
We expect to deal with a few clusters with large association
We could shuffle the rows and columns of M to form a matrix that is roughly block diagonal
Shuffling M simply shuffle the elements of its eigenvectors so
We can reason about the eigenvectors by working with a shuffled version of M

45. Example data = 1 8 7 2 9 3 2 7 affinity = 1.0000 0.0144 0.0089 0.4931
affinity =
nEigVec =

46. Example data = 1 8 2 7 9 3 7 2 affinity = 1.0000 0.4931 0.0089 0.0144
2 7
affinity =
nEigVec =

47. Eigenvectors and clusters
Eigenvectors of block-diagonal matrices consist of eigenvectors of the blocks padded with zeros
Each block has an eigenvector corresponding to a rather large eigenvalue
Expect that, if there are c significant clusters, the eigenvectors corresponding to the c largest eigenvalue

48. Large eigenvectors and clusters

49. Eigen gap and clusters
σd=0.1
σd=0.2
σd=1

50. More than two segments Two options
Recursively split each side to get a tree, continuing till the eigenvalue are too small
Use the other eigenvectors

51. Normalized cuts
Current criterion evaluates within cluster similarity, but not across cluster difference
Can also use Cheeger constant
Instead, we would like to maximize the within cluster similarity compared to the across cluster difference
Write graph as V, one cluster as A and the other as B
Maximize
i.e. construct A, B such that their within cluster similarity is high compared to their association with the rest of the graph
cut(A,B):
sum of weights of all edges between A and B
assoc(A,V):
sum of all the weights associated with nodes in A

52. Normalized cuts
Write a vector y whose elements are 1 if item is in A, -b if it’s in B
Write the matrix of the graph as W, and the matrix which has the row sums of W on its diagonal as D, 1 is the vector with all ones.
Criterion becomes
and we have a constraint
This is hard to do, because y’s values are quantized

53. Normalized cuts and spectral graph theory
Instead, solve the generalized eigenvalue problem
which gives
Now look for a quantization threshold that maximizes the criterion --- i.e all components of y above that threshold go to one, all below go to -b

54. Using affinity based on texture and intensity.
This is figure caption there explains it all.
Using affinity based on texture and intensity.
Figure from “Image and video segmentation: the normalized cut framework”,
by Shi and Malik, copyright IEEE, 1998

55. Using spatio-temoral affinity metric.
This is figure 14.24, whose caption gives the story
Using spatio-temoral affinity metric.
Figure from “Normalized cuts and image segmentation,” Shi and Malik, copyright IEEE, 2000

56. Spectral clustering
Ng, Jordan and Weiss, NIPS 01

57. Comparisons Ng, Jordan and Weiss, NIPS 01 2 clusters 2 clusters

58. Spectral graph theory See EECS 275 Lecture 23 for more detail
generalized eigenvalue problem
See EECS 275 Lecture 23 for more detail
See also Laplacian eigenmap, Laplace Beltrami operator,
Laplacian eigenmap, spectral clustering, graph cut,
minimal-cut maximum-flow, normalized cut, random walk,
heat kernel, diffusion map

59. More information
G. Scott and H. Longuet-Higgins, Feature grouping by relocalisation of eigenvectors of the proximity matrix, BMVC, 1990
F. Chung, Spectral graph theory, AMS 1997
Y. Weiss, Segmentation using eigenvectors: a unifying view, ICCV 1999
L. Saul et al., Spectral methods for dimensionality reduction, in Semisupervised learning, 2006
U von Luxburg, A tutorial on spectral clustering, Statistics and Computing, 2007

60. Related topics Watershed Multiscale segmentation
Mean-shift segmentation
Parsing tree/stochastic grammar
Graph cut
Objet cut
Grab cut
Random walk
Energy-based method
