1. Sage CRM Developers Course
Validation Rules and
Table and Entity Level Scripts

2. Looking ahead to the classes
DP01: Introduction to the Development Partner Program DP02: Entities and the Data Model (Part 1 of 2) DP03: Entities and the Data Model (Part 2 of 2) DP04: Implementing Screen Based Rules (Part 1 of 2) DP05: Implementing Screen Based Rules (Part 2 of 2) DP06: Screen and User Independent Business Rules DP07: Workflow (Part 1 of 2) DP08: Workflow (Part 2 of 2) DP09: Using the API Objects in ASP Pages (Part 1 of 2) DP10 : Using the API Objects in ASP Pages (Part 2 of 2)
DP11: Using the Component Manager DP12: Programming for the Advanced Manager DP13: Using the Web Services API DP14: Using the Web Services API (Part 2 of 2) DP15: Coding the Web Self Service COM API (Part 1 of 2) DP16: Coding the Web Self Service COM API (Part 2 of 2) DP17: Using the .NET API (Part 1 of 2) DP18: Using the .NET API (Part 2 of 2)

3. Agenda Validation Rules Screen and User Independent Business Rules
Table Level and Entity Level Scripts including future change in support for Detached/Delayed Table Level scripts
Objects Available
Differences between Values() and FormValues() Collections
Availability of Contextual Information
Rollback behaviour

5. Validate Script What are the Objects Available?
Core Jscript Objects
Extensibility Module Objects
ActiveX Objects
What is the Scope of Effect?
What are the limitations?

6. Complex Rules
Validation Rules can support complex multi- row and inter-table rules Example Wave Budget Validation Rule
var wavebudgetentered = Values('wave_budget'); var myRecordId = CRM.GetContextInfo('Campaigns','camp_campaignid'); var campaignsbudget = CRM.GetContextInfo('Campaigns','camp_budget'); var myRecord = CRM.FindRecord('Waves','wave_campaignid='+myRecordId); var totalwavesbudget = 0 var brokebudgetbyamount = 0; while (!myRecord.eof) { totalwavesbudget += Number(myRecord.wave_budget); myRecord.NextRecord(); } totalwavesbudget += Number(wavebudgetentered); if (totalwavesbudget >campaignsbudget) brokebudgetbyamount = totalwavesbudget - campaignsbudget; Valid = false; ErrorStr = 'You have broken the campaign budget by ' + brokebudgetbyamount; else Valid = true;
Validation rules can make use of other Server objects. For example we might want to implement the following business rule:
"Customer Care cases can only be entered for Companies that are of type 'Customer' & that have an agreed SLA."
The rule has to be written with the screen which is used to enter the case. I'll put the rule on the case_referenceid field. This is for convenience as I am not interested in that field's data.
Within Validation scripts (& table/entity & workflow scripts) this context is accessed via the eWare object.
For example in our rule:
var companyid = CRM.GetContextInfo('company','comp_companyid')
The two parameters are the 'entity' & the 'entity primary key'. This can then allow us to retrieve more details about the company. We will use the eWareRecordBlock object for this. This data handling object will allow use to retrieve the correct company record.
var companyRecord = CRM.FindRecord('company', 'comp_companyid='+companyid);
The record is retrieved so we can check the properties:
var companyid = CRM.GetContextInfo('Company', 'comp_companyid')
var companyRecord = CRM.FindRecord('Company','comp_companyid='+companyid);
if (companyRecord.comp_type == 'Customer' && companyRecord.comp_slaid >0) {
Valid = true; }
else
Valid = false;
ErrorStr = 'Cases can only be created for Companies that are Customers with an agreed SLA'

7. Validation Rules and onChange Rules
The field may only contain letters and numbers
var strRuleMessage = 'Field may only contain Letters and Numbers'; re =/[^A-Za-z0-9]/; r = this.value.match(re); if (r) { window.alert(strRuleMessage); }
var strRuleMessage = "Field may only contain Letters and Numbers";
var strFieldData = Values("comp_customfield");
re =/[^A-Za-z0-9]/;
r = strFieldData.match(re);
if (r) {
Valid = false;
ErrorStr = strRuleMessage;}
The field may only contain uppercase or lowercase letters.
var strRuleMessage = 'The field may only contain uppercase or lowercase letters';
re =/[^A-Za-z]/;
r = this.value.match(re);
if (r) {
window.alert(strRuleMessage); }
if (r){
The field may only contain numeric characters.
var strRuleMessage = 'The field may only contain numeric characters';
re =/[^0-9]/;

8. Using Validation Rules for other purposes
Validation on Search Screens
Validation rules are checked on submission of a search screen even though in this case no data is being inserted or updated.
For example the code below on the comp_name will ensure that it can't be left blank when searching for companies.
if (!Values("comp_name")) { Valid = false; ErrorStr = "you must fill in this field"; }
Example Validation Log Script
The example below only needs to log which fields have changed not every field in the screen so we first need to know what fields are in the screen and then examine each field in turn. To do this I've used the fact that the screen object (EntryGroup block) is an enumerable object.
var ForReading = 1, ForWriting = 2, ForAppending = 8; var TristateUseDefault = -2, TristateTrue = -1, TristateFalse = 0; var mySystemObject = new ActiveXObject("Scripting.FileSystemObject"); var myFile = mySystemObject.GetFile("c:/customlogs/TEST.TXT"); var myFileTextStream = myFile.OpenAsTextStream(ForAppending, TristateUseDefault); var oldName = ""; var myBlock = CRM.GetBlock("CompanyBoxLong"); var myE = new Enumerator(myBlock); while (!myE.atEnd()) { oldName = CRM.GetContextInfo("company",myE.item()); if (oldName != Values(myE.item())) { myFileTextStream.WriteLine(oldName +"/"+Values(myE.item())+" changed by "+CurrentUser.user_logon); } myE.moveNext(); } myFileTextStream.Close();

9. Table and Entity Level Scripts

10. Four Types of Table/Entity Script
Table Level
Detached Table Level (Deprecated in Sage CRM v7.2)
Developers should remove Detached Table Level scripts. Use Escalation rules and other scripts where possible.
Entity Level
Entity Level with Rollback
Table Level Scripts can't block database actions but they are very useful for changing or inserting data.
For example where data is being inserted by a third party system then table level scripts will still fire.
Entity Level Scripts can be set to rollback if an error occurs.
Entity Level Scripts with rollback work on
Company
Person
Address

11. Objects used in Internal Scripting
Main Objects
Other Objects
EntryGroup block is enumerable and it may provide us within a TableLevel script a simple way of checking if certain fields exist on the screen to see if they have changed value.

12. Entity Level Script Firing Points
Screen
System Action
EntityScript
Function
New Company
Newcompany
Company
InsertRecord()
Change Company
Companysummary
UpdateRecord()
Delete Company
DeleteRecord()
New Individual
Newindividual
Person
Change Person
PersonSummary
Delete Person
Personsummary
Edit Phone/
Phone
New Address
Address
Edit Address
Delete Address

13. Values() Usage Values() FormValues() Reassign Values
Access QueryString
Create Script
Can see data in form in View mode not Edit or Save
Can see data in form in Save mode not View or Edit
No both
Values () – yes
FormValues - no
Validate Script
All submitted data defined in blocks used in form
Table level Script
Only data in entity screen block e.g. company not address info
Yes Values()
No FormValues() -errors
Values () – no

14. FormValues() and Values()
The Values() collection
Allows access the data within the fields associated with the EntryBlock (screen) used to build the edit screen for current record.
E.g. editing a company record you would use the CompanyBoxLong screen.
The FormValues() collection
Allows access the data from within the whole of the HTML form submitted.
This means in a screen like the new Company screen when you are actually inserting data to several tables (Company, Person, Address etc) then you can access any of the submitted data.
E.g. So in an InsertRecord event function of an Company Entity script we could access the submitted address information: var strPostCode = FormValues("addr_postcode");

15. Validating Phone Numbers and Email Addresses
We can use an "Entity Level script with Rollback". Entity Level with Rollback scripts can be used when we want to stop an action happening if there is a validation error or other error with the script. Need to consider Data Entry Data Update

16. Table Level Scripts Example Rule
If the company is reassigned then reassign all opportunities for that company to that new personid.
The GetContextInfo() method returns the originally assigned user and the Values() collection contains the inbound userid data. When they are different, the record has been reassigned.
if (CRM.GetContextInfo('Company','comp_primaryuserid') != Values('comp_primaryuserid')) {
var myCompRecordId = CRM.GetContextInfo('company','comp_companyid');
var strSQL = "oppo_status = 'In Progress' and oppo_primarycompanyid="+myCompRecordId;
var myOppoRecord = CRM.FindRecord('opportunity', strSQL);
while (!myOppoRecord.EOF)
myOppoRecord.oppo_assigneduserid = Values('comp_primaryuserid')
myOppoRecord.NextRecord(); }
myOppoRecord.SaveChanges();
if (CRM.GetContextInfo('Company','comp_primaryuserid') != Values('comp_primaryuserid')) {
var myCompRecordId = CRM.GetContextInfo('company','comp_companyid');
//This returns the primary key information
var myOppoRecord = CRM.FindRecord('opportunity','oppo_primarycompanyid='+myCompRecordId);
while (!myOppoRecord.EOF)
myOppoRecord.oppo_assigneduserid = Values('comp_primaryuserid')
myOppoRecord.NextRecord(); }
myOppoRecord.SaveChanges();
Note
This contains pre update values
CRM.GetContextInfo('company','comp_primaryuserid')
This contains the new passed in values
Values('comp_primaryuserid')
Also Table/Entity level scripts can chain. A script can cause change in table that will fire a script, that will fire a script....

17. Rollback & Table Level Scripts
Only Entity Level Scripts can rollback
Values() collection contains the new values
CRM.GetContextInfo() returns the old value
Therefore you are be able to do this...
if (Values('data_whatever')==invalidValue) {
Valid = false;
ErrorStr = CRM.GetTrans('capt_family','capt_code');
Values('data_whatever') = CRM.GetContextInfo('mytable','data_whatever'); }

18. Update of Data not submitted from Screen
The Values() collection can be extended to set a value for a field not in the screen. function UpdateRecord() { // Handle update record actions here var strCompany = Values("comp_name"); Values("comp_name") = strCompany.toUpperCase(); Values("comp_mailrestriction") = 'Y'; }

19. Insert & PostInsert functions
Two 'Insert' event functions available to you within table level scripts.
InsertRecord()
InsertRecord() event fires as the record is created but before the database insert, therefore the new unique id for the record is unknown.
PostInsertRecord().
Have access to the records newly created unique id.
But can’t use
CRM.GetContextInfo('datatable','data_dataid')
Record is new and is not in context at that moment.
Neither can we use
Values() collection
Id has not been passed into the system.

20. Use of the WhereClause
In a PostInsertRecord() function To obtain the newly created record id. Use system variable called 'WhereClause'. Contains after the creation of the record the literal string 'dataid=value' e.g 'lead_leadid=507'.

21. Variables & Objects P O Field Level Scripts Create Change Validate
Table/Entity Scripts
CurrentUser P
Valid O
ErrorStr
Values() & FormValues()
WhereClause

22. External Triggering of Table Level scripts
Possible to trigger any Table Level script event function
Triggered by
COM API calls
ASP page extensions
Self Service extensions
Windows script
Mail Manager Scripts
SOAP Web Service calls
.NET API calls
Note: Table Level scripts may not be triggered by changes made by Exchange & ERP sync engines

23. ScriptCommonFunctions
In registry
ScriptCommonFunctions
reg key value
utils\myfunctions.js
Put filename you want. Assumed to be in the custompages folder or use path to subfolder.
Functions in the file will be added to every table level script at execution.
Note: May clash with existing ERP integration e.g. Sage 300 ERP

24. Q&A
