2. Military Cryptographic Systems Information Assurance Module 3

3. Objectives
Students will learn about commonly used military cryptographic systems (ie. KG-84, KIV-7, KIV-19, STE, KG-75), including data rates, connection and fill requirements, and practical applications.
Provide an Overview of the DOD Cryptographic Modernization Initiative with Focus on the Army CM Program.
Be able to describe the EKMS/AKMS Programs.
At the conclusion of this block, students will be able to choose a cryptographic device to encrypt a link given the data rate, terminal equipment and transmission medium.
They will be able to explain the CM, EKMS and AKMS Programs.

4. Outline Cryptographic Standards NSA Cryptographic Types
Black/Red Signals
Military Cryptographic Equipment (Layers 1 – 3)
Telephony Cryptographic Equipment
Fill Devices
Key Generators
Cryptographic Modernization Program
Electronic/Army Key Management Systems
This next block we will discuss different types of cryptographic equipment and systems.

5. Cryptographic Standards (1 of 2)
National Security Agency (NSA)
Secret and above
Type 1 encryption required
Classified Algorithms
National Institute of Standards and Technology (NIST)
Set standards for Sensitive traffic
de facto standards organization for commercial businesses

6. Cryptographic Standards (2 of 2)
3. American National Standards Institute (ANSI)
Cryptographic standards organization for the U.S.
ANSI X9 series closely mirrors NIST’s Federal Information Processing Standard (FIPS)
4. International Organization of Standards (ISO)
X.509 and Common Criteria

7. Approved Cryptosystems
for the US Army are either:
Produced by NSA
Commercial Off the Shelf Systems approved by NSA for local purchase
Electronically generated and distributed using NSA approved key generating equipment and procedures IAW NAG 16

8. NSA Cryptographic Types
Products
US government/military for Classified Info
Only approved commercial users are defense contractors for US classified projects
US government for sensitive info
Requires US government agency sponsorship
Algorithms
Exportable only to US corporations abroad, and remain under the control of US citizen.
Exportable to any country and/or organization, except those prohibited by the US government

9. Black/Red Signals Black/Cipher Text Red/Plain Text Router
Red patch panel
KIV-7
Black patch panel
CSU/DSU
Red patch panel
Black patch panel
CSU/DSU
Router
KIV-7

10. Red/Black Installation (1 of 2)
Separation of 1 m b/w RED processor and:
BLACK equipment
BLACK wire lines that exit the inspectable space or are connected to an RF transmitter
BLACK power lines
Conductors that exit the inspectable space
Separation of 5 cm b/w RED wire line and:

11. Red/Black Installation (2 of 2)
RED and BLACK wire lines will not use a common distribution vehicle unless the power lines exiting the space are equipped with powerline filters.
Patch Panels
Jack fields should have incompatible connectors to prevent inadvertent RED to BLACK patching
Separate RED and BLACK by 1 m
1 m separation required b/w different classifications (i.e. SIPRNET and JWICS, SIPRNET and SECRET – Coalition)
SCIFs require separate red and black ground

12. Cryptographic Equipment
Layer 1 (Physical)
KG-84
KIV-7
KG-194
KIV-19
KG-95
KG-189
Layer 2 (Data link)
KG-75
KG-175 (2 and 3)
KIV-21
Layer 3 (Network)
Network Encryption System (NES)

13. KG-84 KG-84A -- 256 kbps KG-84C -- 64 kbps
Military standard DS-101 fill plug
Operates from 50 to Mbps asynchronous
Process up to 32 Kbps using internal clock
Built-in wireline modem

14. KIV-7 Four models Interoperable with KG-84 Serial Data Interfaces
KIV Kbps
KIV-7HS Mbps
KIV-7HSA/B Mbps
Interoperable with KG-84
Serial Data Interfaces
EIA-530, EIA-449, EIA-232
Removable CIK
No internal strappings
Optional Wireline Module for Tactical

15. KG-194 KG-94/94A/194/194A Operates from 9.6 kbps to 13 Mbps
Uses traditional or firefly key
Two versions -- tactical and fixed plant

16. KIV-19 Operates from 9.6 kbps to 13 Mbps
Use traditional or firefly key
Compatible with KG-194
Newest version KIV-19A

17. KG-95 DS3 encryptor Bulk Encryption Three models:
KG-95-1 operates from Mbs
KG-95-2 operates only at DS-3 rate
KG-95R two KG-95-2s together

18. KG-189 SONET Encryptor Operates at OC-3, OC-12 and OC-48
Type I encryption
Firefly key
DS-101/KSD-64

19. KG-75 (FASTLANE) ATM encryptor KG-75 - up to OC-12
KG-75A - up to OC-192
Supports up to 4094 simultaneous, cryptographically isolated ATM channels
Supports DS1, DS3, OC3C and OC12C
Supports PNNI 1.0, UNI 4.0 and SNMP
Firefly and traditional key
CYZ-10/DTD fill device

20. KG-175 (TACLANE) ATM Encryption -- 45 Mbps IP Encryption -- 7.2 Mbps
DS3 BNC connector
253 cryptographically isolated channels
IP Encryption Mbps
RJ-45 and AUI connector
UNI 4.0 and SNMPv1
Firefly and traditional key
Uses CYZ-10/DTD
E-100 version provides IP encryption up to 100 Mbps

21. KIV-21 Converts black EIA-422, DB37 HDLC into red IEEE 802.3 ethernet
Replaces KIV-7/KG-84/KG-194 and CSU/DSU for a single site
Throughput - 8 Kbps to 3 Mbps
Frame relay

22. Network Encryption System (NES)
IP Encryption
NES 4001 supports up to 3.4 Mbps
NES 4001A throughput is 4.3 Mbps
Required black and red IP addresses
FIREFLY key distribution

23. NES - Virtual Private Network
permits traffic from one network to tunnel through another network of a dissimilar security classification

24. Telephony Equipment
STU-III
STE
Omni
Secure Cell Phones
KY-68
FNBDT

25. STU-III and SDD Secure Data Device
Operate at 2.4 or 4.8 kbps code-excited line prediction (CELP)
Data transmitted at 2.4, 4.8 and 9.6 kbps
Supports the ITU-T standards
V.26bit
V.26ter
V.32
KSD-64A

26. STE Replaces STU-III and KY-68 Key is Fortezza Plus (KOV-14)
Interoperable with:
STU-III
DNVT
ISDN: NI-1, NI-2, 5ESS, DMS-100, DEFINITY
Euro ISDN
Network Interface
ISDN S/T BRI – 1B+D or 2B+D – RJ-45
PSTN – RJ-11
TRI-TAC/MSE – 4 wire line modem
EIA-232/530A
Host Interface

27. Omni Secure Terminal provides Type-1 security for voice and data
Analog and Digital network
FNBDT compliant
Compatible with POTs
and STU-III

28. Secure Cell Phones (1 of 2)
Motorola Cipher-Tac 2000
STU-III and STE compatible
Type 1 analog cellular security
sleeve slides between battery and phone to operate in secure mode
Qualcomm Qsec 800
Secure voice and data (CMDA)
Type 1 analog cellular security
requires no add-on module

29. Secure Cell Phones (2 of 2)
General Dynamics
Tri-band (GSM 900/1800/1900)
Advanced Encryption Standard (AES)
Clip-in security module
Type 1 security
Motorola Satellite Series 9505
satellite and cellular service
type 1 end-to-end security
Iridium security module attaches to it

30. KY-68 TRI-TAC and MSE Operates at 16/32 Kbps with CVSD (wideband)
Provides encryption of voice or data traffic on switched links to a circuit switch

31. Future Narrow Band Digital Terminal (FNBDT)
Designed primarily for low-bandwidth, error prone networks such as cell phones
Secure global interoperability
FNBDT is an open standard
Satisfies both NATO and individual nation objectives
Uses MELP and Forward Error Correction

32. Fill and Storage Devices
KYK-13
KOI-18
KYX-15
CYZ-10
KG-83
KGX-93
Fortezza Card
KOV-14
KSD-64A

33. KYK-13 Receive, store and load key in electronic form
Can hold six 128 bit keys
CCI is unclassified when empty -- takes on highest classification of key in memory

34. KOI-18 Used to read/transform paper key into electronic key
Can directly fill crypto equipment or load another fill device
Unclassified
No memory

35. KYX-15 Can store sixteen 128 bit keys
Unclassified when empty - takes on the highest classification of the key in memory
Used to perform OTAR
Can generate key locally when used with KG-84, KIV-7 or KY-68

36. AN/CYZ-10 Data Transfer Device (DTD) can emulate other fill devices
Receives, audits and transfers 128 bit keys with identification information
CCI and is unclassified when empty or when the CIK is removed
Referred to as an ANCD

37. Simple Key Loader (SKL)
Processor 32-bit Intel® XScale™ CPU (400 MHz)
O/S Win CE.NET (4.1)
RAM MB of SDRAM
ROM 64 MB of Flash Memory
Graphics 2-D Accelerator
Size 7” x 3.5” x 1.8”
Weight Approx 18 oz. 504 gms.

38. Fortezza Card (1 of 2) Used with DMS to encrypt/decrypt
1.5 MBs processing rate
Tamper proof/ultrasonically welded
Exportable with State Department approval
Includes RISC based processor
Spyrus
Grouptech
Mykotronx

39. Fortezza Card (2 of 2) Provides Cryptographic Functions
Public Key Exchange
Message Encryption
Digital Signature
Hashing
Timestamp
Password
Certificate
Algorithms used
KEA, Skipjack, DSA, SHA-1
Key Exchange Algorithm
Digital Signature Algorithm

40. KOV-14 (Fortezza Plus)
Special PCMCIA card - provides encryption and other security services
Used to enable STE
Classified to level of keying material
Unclassified when separated from STE
Stays with COMSEC Material Control System (CMCS) until destroyed
With operational key – classified
With seed key -- unclassified

41. KSD-64A Contains electronic fill info for STU-III
May contain classified operational key or unclassified seed key
Can operate in three modes

42. KSD-64A Modes Operational Key
Load STU-III to make direct secure calls to other STU-IIIs
Fill Device
Seed Key
Load STU-III to electronically obtain its operational key during a rekey phone call
Crypto Ignition Key (CIK)
Stores an electronic "password."
CIK is used in STU-III that shares this password to unlock the terminal's secure transmission features

43. Key Generators
KG-83
KGX-93
LMD/KP (KOK-22)

44. KG-83 TRI-TAC and stand alone applications
Generates 128 bit TEK up to Top Secret
Compatible with most COMSEC equipment that accepts 128 bit keys
Requires initial/annual certification

45. KGX-93 MSE and TRI-TAC switches Generates 128 bit key up to Top Secret
Can also store key
Requires initial/annual certification

46. Local Management Device/Key Processor (LMD/KP)
128 bit key
Key Processor
KOK-22A
Key Generation
Local key generation, distribution, auditing and reconciliation
Access to ACCOR
Tier 2 of EKMS
Can load 1000 keys at once

47. Cryptographic Modernization Program
Replacement of DOD’s aging Cryptographic Equipment Inventory to meet Current and Objective Capability Needs.
Intent is to achieve more robust security, network adaptability (Network-Centric) and performance enhanced equipment solutions.

48. Background (1 of 2) FY 99/00 MCEB and NSA Studies Concluded:
Technologically Obsolete years old
Cannot Support Network-Centric Architectures
Inventory Becoming Logistically Unsupportable
Feb 01 ASD(C3I) Arthur Money memo directs:
Road Map for Crypto Systems Upgrade/Replacement/Retirement
Services Procure Modernized Crypto in FY03-09 POM

49. Background (2 of 2) Sep 02 JRB
9 Crypto Systems as near term Modernization efforts
Approved Joint Forces Command as CRD Sponsor
Directed Joint Staffing of CM MNS and Completion of CM Implementation Plan
Nov 03 SIGCEN
BG Hicks, signed the Charter establishing the CM ICT
ICT process serves to shorten the requirements determination event of the acquisition process by employing the team approach to requirements determination.

50. Existing Deficiencies
Equipment Obsolescence
Incompatibilities with new architectures/technologies
Interoperability/Releasability problems
Restrictions on key management pose major challenges
Affects ability to support dynamic communications
Lack of programmability/flexibility
Incompatibility with modernized DOD KMI
Lack direct interfaces
Cryptographic equipment shortages
Readiness and surge capabilities affected

51. Cryptographic Inventory Posture
Unsupportable within 10 years
Supportable beyond 10 years 2% 2%
Unsupportable within 5 years
15%
43%
38%
Currently Unsupportable
Programmed Replacements
Current inventory 1.2 Million Items (Sources: ISSP Database, ATAV, MYNSN, UIT, CMCS)
Programmed Replacements JTRS, WIN-T, FCS and Other Major Programs.

52. Threat
Continuing trends reflect significantly increased risks of C4ISR, IT, and weapons systems to attacks on cryptography
Increases in computing power
Increasing reliance upon COTS systems
Service/Allied/Coalition use
Availability of Electronic Warfare Systems
Widespread distribution of Computer Network Attack (CNA) and Computer Network Exploitation (CNE) Tools

53. CM Concept Leverage Latest Technology
Develop Multi-Functional Components that Replace Entire Families of Crypto Equipment
NSA Partnership with Services on Program Development
NSA will:
- Retain Crypto Certification Approval
- Fund Services for Program Development R&D
Services will:
- Program Funding for Procurement and Fielding
- Conduct Program Development Process
- Develop Equipment Shortage/Supportability Lists
- Prepare Fielding and Transition Plans

54. CM Core Capabilities Programmable/Reprogrammable Algorithms
Capable of Receiving an Algorithm
Scalable Components
Embedded Modules (Whenever Possible)
EKMS/KMI Compliant/Capable
Network-Centric Functionality
Assured control of DOD networks
Interoperability
Physical - Form and Fit

55. Priority Nine Systems PROGRAM SERVICE LEAD UTILIZATION
IFF Mode V Navy AVN/GND-Air/Water Craft
KG-30 (NC2) Air Force Joint Interface
KI-22 (Air Force Only) Air Force N/A
KG-40 (LINK 11) Navy ADA/Joint Interface
CTIC/CDH Air Force Integrated Modules
KG-94 (Family) NSA Trunk Encryptors
NES (INE) NSA Inline Network Encryptors
STU III Replacement NSA Secure Voice/Data
KY-68/78 Army Tactical DSVT

56. EKMS and AKMS EKMS Architecture and Concepts
AKMS Description and Operational Concepts
Doctrinal Impacts
Roles/Responsibilities
Issues

57. Electronic Key Mgt System
DOD initiative to modernize management/distribution of COMSEC to support the warfighter and non-military government users.
Replaces slow cumbersome paper and manpower intensive processes of management and distribution of COMSEC material.
Increase security of key management processes
Increase responsiveness to user needs
Provide for interoperability

58. EKMS Tier Levels 0. National Security Agency (NSA)
Central Office of Record (COR)
LCMS COMSEC User Accounts
Common Fill Devices

59. EKMS Operations CF COR COR AKMS EKMS ID ACCOUNT EKMS ID ACCOUNT
TIER 0: POLICIES, MODERN KEY
COR
COR
TIER 1: COR, RA, PCM,OPM
AKMS
TIER 2: ACCOUNTS
EKMS ID ACCOUNT
EKMS ID ACCOUNT
EKMS ID
LOCAL ELEMENT
EKMS ID
LOCAL ELEMENT
LOCAL ELEMENT
NO SUBACCOUNTS
ONLY ACCOUNTS AND LOCAL ELEMENTS
LOCAL ELEMENT
LOCAL ELEMENT
TIER 3: DTD/SKL (HAND RECEIPT HOLDERS)

60. National Security Agency (NSA)
Tier 0 – NSA Central Facility
Provides for production, management, and distribution of specialized electronic cryptographic key and associated materials.
MODEM key
National Security Agency (NSA)

61. Tier 1 - Central Office of Record
CORs are focal points for production, management, auditing, and distribution of Service-Unique electronic cryptographic key and materials
Supports joint operations at theater and strategic levels
Act as alternates to the other in cases of degraded operations, activity, and geographic location
Major functional areas:
Central Office of Record (COR)
Registration Authority (RA)
Privilege Certificate Manager (PCM)
Ordering Privilege Manager (OPM)

62. Extension Tier 1 EXTENSION TIER 1
COR – Ft. Huachuca
COR – Kelly AFB
EXTENSION TIER 1
- Facilities replicate Tier 1
- Does not provide COR capability for users Installed geographically CONUS/OCONUS
in area containing concentrations of accounts

63. Tier 2 – LCMS User Accounts
Represents individual EKMS user accounts
Developed by NSA
Used by all services
Individual service policies and procedures
AKMS – Army Tier 2
outlines Army policies and
procedures

64. AKMS Replaces slow, cumbersome paper and manpower intensive processes
Provides a reliable, responsive and secure system
Implements an electronic key strategy w/in the Army
Provides Tier 0 and Tier 1 electronic interoperability
Provides COMSEC and communications planning capabilities
Provides real time key generation and distribution
To make AKMS work as a system, all three components (LCMS, ACES, DTD) are required

65. LCMS Workstation NSA and Army produced and distributed
Automated account management
Local key generation, distribution, auditing, reconciliation
Access to CF and COR

66. ACES Workstation Army produced and distributed
Designed for Cryptonet planning and management
Includes SOI/ EP planning and management
Employs ACES-specific application functions

67. Fill Device Receive, distribute, store, and manage key
Receive, transfer, and display SOI
Perform Audit
DTD
SKL

68. ACES Scenario U.S. MILITARY IS NEEDED SOMEWHERE S-3 ACES ACES OPERATOR
COMMUNICATIONS PLAN
PLAN DATA
KEY REQUIREMENTS
SHORT TITLE INFORMATION
LCMS
OPERATOR
(TIER 2)
KEYS DISTRIBUTED AS NEEDED
DTD/SKL
(TIER 3)

69. Doctrinal Impacts Accounts no longer manual
Acclaims no longer in effect
Sub-accounts no longer authorized
Key produced locally and distribution process streamlined
Electronic key transfer increased; physical key transfer decreased
Modern key ordering incorporated to mainstream

70. Roles/Responsibilities
CIO/G-6: EKMS/AKMS oversight; IA system integrator
G-2: COMSEC Policy
G-8: Program Funding
PEO C3T: Responsible PEO; DAA
PM TRCS: PM for LCMS, ACES, and DTD, under PM WIN-T
CSLA: Primary service authority role; primary Tier 1 segment (COR); EKMS subject matter experts and support to IA directorate
CECOM: Tier 1 software support activity; Tier 2 life-cycle support (minus SW)
SIGCEN: AKMS requirements and operational concepts; sustainment training

71. IA Directorate (DCD) Role
Provides EKMS/AKMS oversight
Provides representation to:
KMI Committee (KMI EC)
Joint Key Management Infrastructure Working Group EKMS Transition Team (ETT)
Tier 1 System Management Board (TSMB)
Other working groups and boards
Chairs AKM Infrastructure Working Group (AKMIWG)
Facilitates exchange of info/coordination among Army Orgs (G-8, G-2, CIO/G-6, SIGCEN, CSLA, PM WIN-T)

72. E/AKMS Issues Simple Key Loader (SKL) Testing
Tier 1 & Tier 2 phase 4 certification and accreditation
Software Support Activity (SSA)
merging of EKMS, KMI, and COMSEC modernization programs
ACES Fielding
