1. magicolor 6110 Color Laser Print System
All specifications are subject to change without notice.

2. magicolor 6110 Print System
Best value 11"x17"/A3 network color laser printer with impressive speed and print quality for both business and design applications.
Large format color printing is the premier solution for businesses that want network color printing.
The magicolor 6110 represents the best value, feature for feature, among the choices of ledger/A3 solutions available for businesses today.

3. MINOLTA-QMS Color Laser Printers
magicolor 2200 DeskLaser
magicolor 2200
magicolor 330
magicolor 6100 DeskLaser
magicolor 6110
NEW!
5 ppm color
20 ppm b&w
letter / A4
1200 dpi
Windows
5 ppm color
20 ppm b&w
letter / A4
dpi
Multi-platform
4 ppm color
16 ppm b&w
13 x 19-inch
1200 dpi
Multi-platform
6 ppm color
24 ppm b&w
13 x 19-inch
1200 dpi
Windows
6 ppm color
24 ppm b&w
13 x 19-inch
1200 dpi
Multi-platform
The magicolor 6110 occupies a position at the top of the line of our family of magicolor printing solutions.
Small Business
Mid-Large Business
Graphics
Small Business
Mid-Large Business
Graphics

4. Market Positioning General business market Graphics market
Office documents
Marketing communications
Targeted customer communications
Graphics market
Design
Desktop publishing
Pre-press proofing
Who needs ledger/A3 color printing? The general business market does because the larger format means that whatever type of document a business wants to print, this page size can hold it. Whether it’s office documents and reports or short-run, targeted communications directed to a company’s top customers, the magicolor 6110 can do it all in full color. The multiprotocol connectivity of the CrownNet interface and the productivity-enhancing versatility of the Crown II controller combine to make the magicolor 6110 a perfect fit for any business trying to find new ways to communicate more efficiently and economically.
The graphic arts market needs it because layouts/comps rarely come in letter/A4 sizes. The magicolor 6110 supports page sizes up to 13x19 for the important tasks that are a part of every day in the life of graphic designers. The built-in color management systems of the magicolor 6110 – ColorSync, ICM, color rendering dictionaries, and PANTONE – help the graphic artist and designer achieve the results they want.
Charts, newsletters, brochures… the magicolor 6110 can do it all

5. magicolor 6110 Print System
6110 GN
$4,499
1200 dpi
256 MB
Optional
Ethernet, parallel, serial
250 sheets
13 x 19-inch
Price
Resolution
RAM
Internal Disk
Interfaces
Paper Input
Max. Page Size
Executive summary.
Prices subject change without notice.

6. General Printer Features
Engine
Standard
6 ppm color
24 ppm b&w
1200 dpi
Ethernet (10/100BaseTX), parallel, serial interfaces
QuickChange consumables
Up to 75,000 prints / month monochrome; up to 18,750 prints / month color
Optional
Token-Ring, DECnet-TCP/IP, LocalTalk, SCSI interfaces
The printer is capable of printing color letter-size pages at 6 pages per minute or ledger/A3 size pages at 3 pages per minute. When printing in black-and-white (as the majority of office document pages are likely to be) the magicolor 6110 produces 24 pages per minute. The printer delivers images at 1200 dpi resolution. When printing at this resolution, the magicolor 6110 does not slow down its printing speed (as some other color laser printers do). The magicolor 6110 offers two interfaces as standard equipment: a bi-directional IEEE 1284 parallel port and a 10/100BaseTX “Fast” Ethernet multiprotocol network interface. Including a network interface for free has become a hallmark of MINOLTA-QMS color printers for business. This feature alone makes installing and using the magicolor 6110 easy. The interface also supports multiple network protocols to make it easy to work with the variety of computer systems and networks any business might use. In addition to the one standard network interface, businesses can add one optional network interface for more complex computing environments.
Ease-of-use has always been a major concern of color printer users. The magicolor 6110 features the revolutionary QuickChange system for toner cartridge replacement. Cartridges slide in and out of color coded slots in the front of the printer making it easy for anyone in the office to replace toner when necessary.
The printer’s duty cycle of 75,000 black-and-white prints or 18,750 color prints per month puts the magicolor 6110 in a class with other large workgroup or mid-size business printers on the market today.

7. General Printer Features
Controller
Standard
Crown III technology
200 MHz RISC processor
PostScript Level 3, PCL 6, PDF emulations
256 MB RAM
Optional
ImageServer, LN03+, CGM, QUIC-II languages
384 MB RAM
Internal hard disk
The controller is the “brain” of the printer and the brain of the magicolor 6110 is powered by the MINOLTA-QMS Crown III architecture. Crown III is a multitasking printer system that improves the productivity of the business by operating the printer at peak efficiency. The magicolor 6110 features a new 200MHz processor for fast interpreting of even complex color documents. Multiple emulations on board allow the magicolor 6110 to work with a variety of software applications. The 192MB of RAM that come standard with the magicolor 6110 enable it to print full color images at 1200 dpi even at the largest paper sizes.
For increased performance, options are available for the magicolor 6110:
ImageServer emulation for fast printing of document image files (CCITT G4/TIFF B&W files)
LN03+ emulation for Digital Equipment Company printer compatibility
CGM emulation for printing computer graphic metafile format
QUIC-II emulation compatible with QMS Lasergrafix laser printers
Extra memory for high-resolution printing on all sizes even in duplex mode and for increased performance on busy networks (standard PC-100 DIMMs)
Internal hard disk for storing dowloaded fonts, forms, and overlays as well as for use as virtual memory in busy networks

8. General Printer Features
Paper Handling
Standard
250-sheet input
250-sheet output
Up to 13" x 19" (330 x 482 mm) page sizes
Optional
1,250-sheets input
Automatic duplexing
Digital copying and scanning
Printer stand
In any busy office, the paper handling capacity of the office printer will be an important issue for all users. The magicolor 6110 comes with one paper input cassette that holds up to 250 sheets of paper in all supported sizes (up to 13x19). It also includes an adapter for this tray to allow printing on a variety of the most popular envelope sizes. The output tray (on top of the printer) holds up to 250 sheets of paper.

9. Performance Speed Crown III Technology 6-12 ppm color 24 ppm b&w
Multitasking
Efficient Document printing
The speed of the magicolor 6110 relies on the Crown III technology. Speed is more than just pages per minute.
Crown III is a multitasking architecture. It keeps all facets of the printer operating at peak efficiency in order to produce more DOCUMENTS PER DAY not just more pages per minute.
Electronic collation provides an excellent example of this productivity. Send the document only once to the magicolor 6110 and the printer reproduces the requested number of copies (all ORIGINALS!) automatically. This reduces network traffic, making the network operate more efficiently, saves time by producing the prints while the user goes on to other tasks, and continues to accept documents from other users on the network at the same time.

10. Performance NEW PostScript 3 PCL 6 PDF HP-GL Line printer
The magicolor 6110 now includes PostScript Level 3 as well as many other of the most popular printer languages as standard features. Multiple resident printer languages make compatibility with multiple applications easy for the customer.

11. Durable, Easy Color Printing
Duty Cycle
Up to 75,000 prints / month monochrome
Up to 18,750 prints / month color
QuickChange consumables
14,000 black prints
Up to 8,500 cyan, magenta, or yellow prints
notification
Immediate alert for empty toner or paper tray
Notification when document printed
Proof-Then-Print
Helps prevent unnecessary printing to save money
When evaluating color printers for business use, customers look for both durability and ease-of-use. The magicolor 6110 satisfies both requirements.
Its duty cycle is 75,000 prints (letter/A4) per month. In average color printing, that means the magicolor 6110 has the capability of printing up to 18,750 color prints per month.
The QuickChange consumables on the magicolor 6110 minimize maintenance worries. Now anyone in the office can change a toner cartridge. Each cartridge is color-coded and keyed to its physical location in the printer. All cartridges insert from the front of the printer so there’s no need to be a contortionist just to keep the printer in top condition. The high-capacity black cartridge also helps keep the productivity of the magicolor 6110 up.
In the event of an empty toner cartridge or paper tray or other condition with the printer, the magicolor 6110 immediately sends out an notice to a designated recipient. This productivity enhancement helps minimize downtime in a busy network environment by alerting the appropriate person of the action needed to rectify the situation.
The magicolor 6110 will also notify a designated person when a particular document has printed. This improves remote printing across the network.
Proof-Then-Print helps prevent wasted prints when producing multiple document sets. Select proof-then-print and specify the number of copies desired, the magicolor 6110 prints one copy for your approval. If you want to proceed with printing the remainder of the documents, press a button on the printer’s control panel and the 6110 automatically finishes the requested number of copies.

12. Networking CrownNet for Ethernet: 10/100BaseTX Parallel: Plug and Play
TCP/IP, NetBEUI / NetBIOS, IPX/SPX, EtherTalk support
NEW IPP (Internet Printing Protocol) support
Parallel: Plug and Play
Serial
The proven simultaneous multiprotocol interface, CrownNet, is included with the magicolor CrownNet supports the most popular network protocols simultaneously.
New with the introduction of the magicolor 6110 is support for IPP. IPP allows easy printing over the internet or intranet for users of Windows 2000.

13. Everyone can print at the same time!
The biggest benefit of CrownNet is – as it always has been – everyone on the network can print to the magicolor 6110 at the same time. CrownNet takes care of spooling documents into the printer and off the network. No computer system or document is held back. In this way, CrownNet improves the network traffic flow in the customer’s network and helps improve productivity.
Everyone can print at the same time!

14. Paper Handling 250-sheet cassette (standard)
accepts all supported page sizes
500-sheet lower paper feeder (optional)
add up to two for 1,250-sheet max. paper input
eliminates frequent tray refilling
Standard
Optional
Robust paper handling on the magicolor 6110 means fewer interruptions to refill paper trays.
The 250-sheet standard input tray supports all paper sizes up to 13x19.
Add up to to two more trays of 500 sheets each to bring the paper input capacity up to the printer’s 1,250-sheet maximum.

15. Paper Handling Duplexer (optional) Optional
Easily create brochures, newsletters, reports
Saves paper
Decreases mailing costs
Decreases filing volume
Enables longer periods between refilling cassettes
Requires at least 1
Duplexing saves money on paper and delivers documents that look more professional. Add an automatic duplex printing module and the magicolor 6110 takes care of printing on both sides of the paper (even on the largest paper sizes) automatically!
The automatic duplex printing option requires at least one optional paper tray.

16. Paper Handling Supports up to 13 x 19-inch media
Perfect for full-bleed ledger-size designs, posters, newsletters
Supports a range of print media
Plain paper, transparency, labels, thick stock, glossy stock, envelopes
NEW LaserLuster print mode
Produces higher gloss output
The new LaserLuster print mode produces documents with a glossier look even on regular paper. Select LaserLuster for those documents that need extra appeal to impress special clients.
The magicolor 6110 also supports a wide range of media types in weights up to 90lb Index.

17. Paper Handling SC-210 Digital Copier/Scanner (optional)
Use the printer to conveniently make full-color copies
Ideal solution when electronic source files aren't available
Also functions as desktop scanner
25-sheet Automatic Document Feeder available for copying multi-page documents
For more convenience, add the SC-210 Digital Copier/Scanner.
The SC-210 attaches to the parallel interface of the magicolor 6110 and functions like a color copier for those documents where a digital original is not available. The SC-210 makes full color and monochrome copies of documents up to 8½x14. A 25-sheet automatic document feeder is also available for copying multipage documents.
The SC-210 may also be attached to a PC and function as a TWAIN-compatible scanner.

18. Printer Management PageScope Management Software
Browser-based graphical software for network administrators
Easily monitor printer status, set parameters
Manage any MIB-II compliant network printers, copiers, and devices
PageScope provides a web-based, simple yet robust printer management utility for network administrators looking for a solution to printer management.
PageScope is easy to use, secure, and compliant with recognized network management standards (SNMP) which means that it can manage any network printer that’s compliant with those same standards.
(See the PageScope white paper for more details.)
PageScope's graphical display simplifies printer management.

19. Printer Management CrownView Printer-based Web Page
Web-based printer management and monitoring for all users
Features gas gauge displays for monitoring consumable levels
notification of offline condition
For those who use the magicolor 6110 on a daily basis there’s CrownView.
CrownView is the printer-based web page that lets users know important information about the status of the printer and their documents.
One of the most helpful features of the CrownView page is the consumables status. The user can instantly see the approximate level of toners through easy-to-read “gas gauges.”
Another productivity-enhancing feature is the automatic notification of a responsible person in the event of an offline condition such as an empty paper tray or paper jam.
CrownView lets all users access printer information quickly.

20. Printer Management NEW Printer Driver
NEW multi-platform Windows driver supports Windows 95/98/Me, NT 4.0, and Windows 2000
With the introduction of the magicolor 6110, MINOLTA-QMS also introduces a new unified, multi-platform printer driver. This driver has the same user interface across all the major computer systems in use today. This driver means that, whatever the platform, the user will always know how to print to the magicolor This driver also means that converting from one platform to another will be less stressful and will occur with less downtime because the driver will look the same to the user.
Same look and feel across Windows platforms.

21. Color Management
Built-in color management system works with customers’ applications
Compatible with popular host-based management systems
ColorSync
ICM
PANTONE
QCOLOR automatic color control for business users
The magicolor 6110 continues the tradition of MINOLTA-QMS as a leader in color printing techology. The built-in color management features make accurate, quality color prints as easy as possible.
The profiles included with the printer allow it to work with the most popular host-based color management systems:
ColorSync 2.6
AGFA ColorTune
Corel 7.0 and 8.0
Pantone CMS
Color Solutions ColorBlind
Kodak KCMS
But for many users, color management is not a primary concern. For most business users, getting the best color out of the printer should be automatic. With the magicolor 6110, it is! QCOLOR color control automatically senses the elements on the document pages (text, graphics, photo images) and sets the printer to produce those pages at the best color quality. This makes printing in full color very simple for even those who’ve never used color in their documents before.

22. Especially for Business
The key features businesses will most enjoy
Built-in networking cuts costs and improves printer sharing
QCOLOR technology improves general color printing results for novice color printer user
High volume duty cycle & fast monochrome print speed = excellent general-purpose office print system

23. Especially for Design & Publishing
The key features graphics professionals will most enjoy
Large paper size support and high resolution means excellent choice as low cost proofing device
PostScript 3 support means compatibility with applications
Automatic duplexing and electronic collation means low cost, short run, full color printing
LaserLuster mode provides high quality appearance for low cost
Built-in color management systems provide easier, accurate color printing
