1. Wind energy Presentation for high school pupils

2. What will we learn during the class? What are the renewable energy and wind energy? What are the sources of renewable energy? What are the disadvantages and advantages of wind energy? What are the possibilities for acquiring wind energy? What devices are used to acquire wind energy? Do we really have to use renewable energy sources?

3. What do we need energy for??? Power electrical equipment Prepare meals Heating Air-Conditioning Power industrial plants Transport It’s hard to imagine even one day without using electricity!

4. Growing population and economic development cause the predictions of increasing use of electricity.

5. Row material In the olden days wood was the basic row material for energy. It was later replaced by bituminous coal and then oil.

6. Depleting conventional sources of energy Reserves of fossil fuels are non renewable and will run out. It’s estimated that: Coal will last for around 220 years Gas for 60 years Oil for 30 – 40 years!!!

7. Climate change Use of fossil fuels contributed to increase of greenhouse gases in the atmosphere, in particular CO2. World’s emission of CO2 originating from fossil fuels, 1751 - 2006

8. Global warming Changes in the atmosphere's composition have brought global warming and climate changes. Their results may threaten human and natural environment.

9. Alternative sources of energy Renewable sources of energy RSE which have been available for hundreds thousands years are an alternative for bituminous coal. RSE will never run out and don’t cause any negative changes to the environment.

10. Sources of energy RENEWABLE Hydro energy Wind energy Solar energy Biomass energy Geothermal energy NON-RENEWABLE Bituminous coal Lignite Oil Gas Radioactive elements

11. Sources of energy RENEWABLE Hydro energy Wind energy Solar energy Biomass energy Geothermal energy NON-RENEWABLE Bituminous coal Lignite Oil Gas Radioactive elements

12. Wind energy

13. As far as 4000 years ago Babylonians used to pump water using wind turbines when irrigating fields and drying wetlands. Well before then wind was being used in ship transport. From the 6 th century Persians used to grind grain in windmills.

14. At present wind energy industry is one of the fastest developing industries.

15. Obligations towards EU 25.06.2009 new European Parliament and Council of Europe Directive on promoting energy from renewable sources came to life. According to this directive Poland has to increase share of energy from renewable sources from 3.8% to 15% by 2020.

16. Conditions favourable for the use of wind energy Constant wind Particular wind speed Wind farms usually work with the wind blowing with the speed between 5 and 25 metres/second, while the speed between 15 and 20 m/s is recognised as optimal. Too low speeds make generating electricity of satisfactory volume impossible, too high speeds (over 30 m/s) can however lead to mechanical damage of a turbine.

17. Most suitable for acquiring wind energy are: coastal areas open plains hills’ tops mountain passes

18. Poland belongs to a group of countries with an average wealth of wind energy. Using the potential of wind energy Poland could cover 17% of demand for electricity.

19. Suitable conditions for the use of wind energy are present on 1/3 of the area of Poland. According to The Institute of Meteorology and Water Management, in the area of 60,000 km², which is around 30% of Poland’s territory an average speed of wind exceeds 4m/s

20. Devices used for acquiring wind energy Wind turbine – can work individually or as part of a wind farm. Two most important elements of a wind turbine are a turbine and a generator.

21. Rotor Nacelle Tower Foundation

22. Siłownia wiatrowa 1 – foundation 2 – connection to the grid 3 – tower 4 – access ladder 5 – yaw system 6 – nacelle 7 – generator 8 – anemometer 9 – brake 10 – gear box 11 – rotor blade 12 – blade pitch mechanism 13 - hub

23. Gearbox Anemometer and Wind Vane High speed shaft Low speed shaft Rotor blades Hub blade pitch mechanism Bearings Yaw system Brake Tower Generator Nacelle

24. How does a wind turbine work?

25. Wind farms in Poland Wind farm is an installation which consists of single wind turbines with an objective of producing electricity. Concentration of turbines allows to limit the cost of construction and maintenance and also simplifies the grid. The number of wind farms in Poland is growing!

26. Capacity of wind farms in Poland [MW]

27. Biggest wind farms in Poland Margonin – 120 MW Karścino – 90 MW Tymień – 50 MW The biggest wind farm will be developed in Slupsk (320 MW) in 2014.

28. Wind farm in Tymien at the Polish Baltic coast was opened in 2006 (25 wind turbines 2 MW each = 50 MW).

29. Wind turbine capacity To produce 1 MW (megawatt), the rotor of a wind turbine should have a diameter of around 50 metres; For wind farms of 2 MW capacity Capacity with the wind speed of 5 m/s is around 200 kW (10% capacity); Capacity with the wind speed of 13 m/s - 25 m/s is 2000 kW (2 MW - 100% used capacity);

30. Small wind turbine – used to produce energy for household needs, can be installed on buildings. Investment ( circa £3,500) pays back after 5-6 years

31. Hybrid lamp

32. Wind energy – for or against?

33. Advantages of wind energy Doesn’t cause air pollution (and in particular CO2) Doesn’t contribute to depletion of reserves

34. Disadvantages of wind energy Niestabilność energii wiatrowej (brak systemów magazynowania tej energii) Negatywny wpływ na krajobraz Emituje hałas Stanowi zagrożenie dla migrujących ptaków i nietoperzy

35. Can traditional energy sources be replaced with renewables? Global demand for energy will be growing continuously. Fossil fuels reserves are depleting, and the use of it causes adverse climate changes. Everything indicates that in the future Renewable Sources of Energy will be a necessity.

36. Acquiring renewable energy Fashion in the past, necessity nowadays!

37. Thank you for your attention Photographs – source Internet
