ATLANTIS™

3. ATLANTIS™ update Gold shaded titanium growth
SimPlant®16 Featuring ATLANTIS™Abutment
Intraoral Scanning for ATLANTIS™ abutments with iTero
ATLANTIS™ Conus abutment
ATLANTIS™ ISUS 3

4. Materials – gold shaded titanium rising
% of each is converging. Straumann 3.3 Zr leveled Zr numbers. We have a lot of clinicians who are using zirconia and love it. It’s not for everyone and for those that are not completely comfortable with the thought of zirconia, gold shaded titanium is an outstanding esthetic option. Dr Arnie Rosen tells me, it is all he will use in his practice. Speaking of Dr Rosen he will be presenting on gold shaded titanium at the ATLANTIS table in the inspiration center if you have any questions or want to learn more please stop by.

5. Digital Open Solutions
ATLANTIS™ abutments
Digital Open Solutions

6. SimPlant®16 Featuring ATLANTIS™Abutment
Talk about the Right Solutions, Right Team, Right NOW. Custom abutments with a temporary at time of surgery. And it works!!

7. Intraoral scanning for ATLANTIS™ Abutments
Increased connectivity
Increased connectivity for ATLANTIS Abutments by adding the intraoral scanning option
Starting with iTero
Our commitment to Digital Open Solutions in Intraoral scanning will start with iTero. They have been a great partner in the project and have a commitment to supporting their customers much like we do.

8. Workflow

9. ATLANTIS™ IO FLO Indications Intended use
For all positions in the mouth
Clinical invasive
Intended use
The ATLANTIS IO FLO (body and screw) should be used by clinicians during digital impression taking on implant level.
The ATLANTIS IO FLO should be used to transfer implant position(s) in the patient’s mouth to a digital model.
FOR INTERNAL USE ONLY

10. Intraoral scanning for ATLANTIS™ Abutments
Increased connectivity
Target groups
Dental clinics with access to iTero intraoral scanner
Existing ATLANTIS Abutments customers
Potential ATLANTIS Abutments customers
Dental laboratories working together with Dental clinics with iTero access

11. Intraoral scanning for ATLANTIS™ Abutments with iTero
Schedule
Beta II start in NA Feb 2014
Announcement – Chicago Midwinter Meeting and AO Seattle
April 2014
NA Pre-launch
Goal is to activate 10 clinical customers per month from Pre-Launch (April) until Global Launch - EAO 2014
Global Launch – EAO 2014

12. ATLANTIS™ Conus abutments

13. ATLANTIS Conus abutment – overdenture
What is ATLANTIS™ Conus abutment?
ATLANTIS™ Conus Abutment is a uniquely designed conical shaped abutment that incorporates a friction fit implant born prosthesis while being removable like an overdenture. This innovative conical telescopic coping technique allows optimal access for oral hygiene while providing the patient a cost effective treatment option.

14. ATLANTIS Conus abutment – overdenture
Features
Simplified restorative procedure
No adaptation of stock components
Freedom of implant connections, products and material

15. ATLANTIS Conus abutment – overdenture
Benefits
Time saving - increased profitability
Reduce chair time
For the major implant systems, a wide flexibility in therapy and design options
Implant born prosthesis not tissue born

16. ATLANTIS™ Conus abutments for attachment-retained restorations
New ATLANTIS solution
ATLANTIS™ Conus abutments for attachment-retained restorations
ATLANTIS™ Conus Abutment -overdenture For removable overdentures designed to fit ANKYLOS SynCone caps
ATLANTIS™ Conus Abutment -custom For removable bridges/ overdentures with more individual design options

17. Standardized conus solution with ANKYLOS tapered cap for SynCone
ATLANTIS Conus Abutment - overdenture core is designed to match ANKYLOS SynCone 4º caps
Caps and polymerization sleeves will not be orderable via ATLANTIS WebOrder. Customer orders caps/sleeves from local DENTSPLY Implants Representative
SynCone 4º caps –Ref #
Polymerization sleeve – Ref #
Refer to ”The SynCone concept,” ID USX
Scientific highlight available: ANKYLOS SynCone – long term clinical follow-up, ID USX

18. ATLANTIS Conus Abutment - overdenture
Parallel, one-size abutments for removable prostheses (recommended for full arch overdenture restorations)
Milled to fit SynCone 4°caps (ordered separately) Copings can also be produced manually by the customer
The position of the abutments will be in relation to the space needed for the final restoration and a diagnostic tooth set-up is always required
Abutments will be placed with margin levels as close to soft tissue level as possible

19. Design options Capture of ANKYLOS SynCone Cap
Immediate restoration (intra oral) chair side - pick up of copings to an existing denture.
Indirect (laboratory process) with or without a framework. Fabricated by the laboratory in an existing or new denture.
- Without framework - for temporary solutions

20. ANKYLOS® - SynCone® Immediate, temporary restoration
Attaching ANKYLOS® SynCone® tapered caps with retention and polymerization sleve
Preparing the prosthesis
Inserting the prosthesis
Polymerization phase
Inserting the prosthesis
For more information, visit

21. Attaching ANKYLOS SynCone tapered caps with retention and polymerization sleeve
Preparing the prosthesis
And inserting the prosthesis

22. Polymerization phase
Inserting the prosthesis

23. ATLANTIS™ ISUS - Products and Services

24. - patient-specific CAD/CAM prosthetics for all major implant systems
ATLANTIS™ ISUS and ATLANTIS™ abutments now falls under the ATLANTIS™ brand
ATLANTIS™ abutments
ATLANTIS™ ISUS

25. What is ATLANTIS™ ISUS ?
ATLANTIS™ ISUS, a full range of implant suprastructures for fixed and removable dental implant prostheses. Available for all major implant systems, ATLANTIS™ ISUS bars, bridge and hybrid solutions are produced using the latest developments in CAD/CAM technologies, and supported by computer-based industrial and medical device expertise.
Elevator Pitch
*Terms and conditions apply

26. ATLANTIS™ ISUS Features Available in titanium or cobalt-chrome
Precise, tension-free fit
Available for all major implant systems
Comprehensive 10-year warranty*
Titanium
Cobalt-chrome
*Terms and conditions apply

27. ATLANTIS™ ISUS Benefits
Wide flexibility in therapy and design for partially- and fully- edentulous patients
Implant- and/or abutment-level placement*
Fit tested by manufacturer using Sheffield fit test
*Terms and conditions apply

28. Removable Restorations Fixed Restorations
Restoration produced With Denture Materials
(Acryllic and Denture Teeth)
Restoration produced with Crown & Bridge Materials

29. Engineering: Load tests
These images represent the FEA on two different profiles prior to load testing. Load testing is conducted in order to produce “worst case scenarios.” Understanding these limitations help us provide you with the most-reliable long-term solution.

30. Engineering: Load tests
“Static” and “dynamic” load testing is used to determine:
Optimal geometry of bar profiles
Maximum survivable length of extensions
Occlusal forces = bite + chewing (forces)
Max. bite force is 220N/single tooth
Max. chewing force is 50N/single tooth
In order to get 510(k) clearance from the FDA, extensive engineering and research was conducted to understand the limits of survivability in the components – including the maximum length of extensions and the ideal geometry for bar profiles to provide long-term survivability.
Jig that holds the bar in place

31. Workflow Customer order <DRAFT - INTERNAL USE ONLY> Order entry
Shipping
ATLANTIS™ ISUS Viewer
<DRAFT - INTERNAL USE ONLY>
Scanning
Verification
CAD design
CAM manufacturing

32. ATLANTIS™ ISUS Options - implant/ abutment level
Implant* level – with or without internal connection
Combination of abutment and implant* level
Abutment level
*Implant-level placement is not recommended on ASTRA TECH Implant System™ and contraindicated on ANKYLOS®. Available on abutment-level only in North America.

33. ATLANTIS™ ISUS Prosthetic Screws
One prosthetic screw is included per implant site
Order up to one additional screw via ATLANTIS™ WebOrder
For full compatibility information, view the ATLANTIS™ ISUS systems compatibility chart – Implants and abutments
The ATLANTIS ISUS prosthetic screw is offered for all major implant systems. One screw per implant site is provided with the ATLANTIS ISUS order.
Next to the Implant selection in ATLANTIS WebOrder, it is possible to order up to (1) additional prosthetic screw per implant site.
The ATLANTIS ISUS implant suprastructures are always compatible with the implant/abutment screw from the respective manufacturer’s system.
Additional screws can be ordered from the implant system manufacturer. As a service, all screws are listed with the manufacturers REF number in the “ATLANTIS ISUS Compatibility chart – Implants and abutments”
