1. DirectX® And Streaming Video Drivers Jeff Noyle, Development Lead Gary Sullivan, Software Design Engineer William Messmer, Software Design Engineer Eric Rudolph, Software Design Engineer Microsoft Corporation

3. Speakers
“DirectX Graphics Drivers,” Jeff Noyle, Lead Developer, DirectDraw®/Direct3D®, Microsoft Corporation
“DirectX VA Video Acceleration Drivers,” Gary Sullivan, Software Design Engineer, DMD Video Services Group, Microsoft Corporation
“Writing AVStream Minidrivers for Windows® XP,” William Messmer, Software Design Engineer, Digital Audio-Video, Microsoft Corporation
“Testing Your WDM Driver with DirectShow®,” Eric Rudolph, SDE, DirectShow Editing Services, Microsoft

4. DirectX Graphics Drivers Jeff Noyle Development Lead DirectDraw/Direct3D Microsoft Corporation

5. Prerequisites I’m assuming
Basic familiarity with DirectDraw and Direct3D concepts:
System Architecture
Surfaces
Page flipping
The DDK can be hard to read

6. Agenda Single-source issues Windows 9x issues OS-independent issues
DirectX 7.0 implementation details
Changes in DirectX 8.0
What can you do next?

7. Single-Source Issues Stuff you should know if you want one code-base to support Windows 9x OS versions and Windows NT® OS versions

8. Allocating System Memory Per-Surface
(Do NOT use this process to allocate surface memory itself...See later)
Normally system memory is charged against a particular process
Can’t free it in some other process (as in ctrl-alt-del mechanism)
Use EngAllocPrivateUserMem and EngFreePrivateUserMem
Uses DirectDraw object to locate proper process context

9. YUV/FOURCC Surfaces System memory YUV/FOURCC surfaces on NT systems
DirectDraw Kernel-mode “pretends” that these surfaces are 8bpp RGB for the purposes of allocating memory
DXTn:
Height: height in 4x4 blocks
Width: width in blocks * sizeof(block)
You must undo these transformations at CreateSurface time

10. YUV/FOURCC Surfaces
NT kernel mode doesn’t understand any FOURCC formats, so:
The driver must handle video memory allocation for these types
The driver must handle Lock for these types

11. Windows 2000 Issue (Fixed In Windows XP)
During allocation of an AGP surface...
If the driver fails to allocate and:
returns DDHAL_DRIVER_HANDLED
AND sets an error code in ddRVal
AND sets the surface’s lpVidMemHeap to non-zero
Then the system will ignore the error
So NULL the lpVidMemHeap on error!

12. Atomic Surface Creation
On Windows 9x, drivers are given a list of surfaces
On Windows NT, drivers are given surfaces one-at-a-time, unless:
Driver reports GUID_NTPrivateDriverCaps
and sets DDHAL_PRIVATECAP_ ATOMICSURFACECREATION

13. Windows NT Extra
You can use the GUID_NTPrivateDriverCaps to request notification of primary surface:
Set DDHAL_PRIVATECAP_ NOTIFYPRIMARYCREATION

14. Windows 9x Issues

15. System-To-Video Blts
To speed up some titles, implement system-to-video blts
All you need to implement is SRCCOPY, no stretch
But you should implement sub-rects
DirectDraw assumes your driver requires system memory to be pagelocked during Blt
If this is not true, set DDCAPS2_NOPAGELOCKREQUIRED

16. OS-Independent Issues

17. HeapVidmemAllocAligned
It’s an “Eng” function in Windows NT versions
It’s a ddraw.dll export in Windows 9x
You can use this to allocate surface memory
You must have passed the heap to DirectDraw previously
You must fill in the fpHeapOffset, fpVidmem and lpVidmemHeap of the surface

18. Heap Offsets Explained
Return values from
HeapVidmemAllocAligned
are these offsets:
fpEnd
(points TO
last byte)
Heap
(Note fpStart is set to 0x1000
by DirectDraw for AGP heaps)
Surface
Return value from
HVMAA and fpHeapOffset
fpStart
“0”

19. DDSCAPS_VIDEOMEMORY
Remember that this includes AGP unless combined with DDSCAPS_LOCALVIDMEM
At GetAvailDriverMem time, a request that specifies DDSCAPS_VIDEOMEMORY (and not any explicit type: local or non-local) should include both types in the total

20. GetScanLine Implement this, if you can!
DirectX 8.0 uses it a lot for presentation-Blt timing
Set DDCAPS_READSCANLINE, so DirectX 8.0 knows

21. CreateSurfaceEx More on this later
NEVER fail CreateSurfaceEx for system memory surfaces, even if you don’t understand the pixel format
Just return DDHAL_DRIVER_HANDLED and DD_OK
(Otherwise new system-memory formats used by the reference rasterizer can’t be created)

22. Alpha-In-The-Primary
If your driver can do this in 32bpp:
Create an A8R8G8B8 render target
Blt that to the primary surface IGNORING the alpha channel
(And stretch/shrink (please))
Then you should set:
DDHALINFO.vmiData.ddpfDisplay. dwFlags |= DDPF_ALPHAPIXELS
DDHALINFO.vmiData.ddpfDisplay. dwRGBAlphaBitMask = 0xFF000000

23. Windowed Applications And Blt Queuing
Don’t allow “many” presentation-blts in your queue
That is, don’t allow a large latency between scheduling and retiring a presentation-blt
WHQL enforces low latency for DirectX 8.0 drivers
Check DDBLT_PRESENTATION, and don’t allow more than three
More info in ddraw.h

24. DDBLT_WAIT And DDBLT_DONOTWAIT
Drivers should never look at these
They are set by the application/ DirectDraw runtime
They are handled by the DirectDraw runtime
Sometimes DirectDraw spins, and wants to do that in user-mode
Applies to DDFLIP_WAIT as well

25. DDBLT_ASYNC Ignore this flag
Always perform your blts asynchronously, if possible

26. What Are DDROPS? We don’t know either
An idea of the original designer of DirectDraw, but never implemented or specified
In short: ignore!

27. Blt And YUV Surfaces
DirectShow can gain performance benefits if it knows it can use Blt to copy Overlay surfaces
Check to see if you can support DDCAPS2_COPYFOURCC
This means you can SRCCOPY, no sub-rects, no stretch, no overlap between two FOURCC surfaces of the same type

28. Update Overlay, Etc.
If multiple overlays are created, but you have hardware for only one:
Succeed all CreateSurface calls
Fail the UpdateOverlay call

29. Flip Flags DDFLIP_NOVSYNC
This means: flip immediately; do not wait for vertical blank
The hardware must be capable of re-latching the new primary surface address immediately, or at least on the next scanline
In other words, don’t allow the remaining raster scans to read from the old back buffer

30. Flip Flags DDFLIP_INTERVALn
Please don’t implement by busy-waiting in the driver
But please do implement if your hardware can defer flips for n frames

31. Gamma Ramps
DirectDraw and Direct3D’s gamma ramps are passed through the GDI DDI call SetDeviceGammaRamp
This call is poorly prototyped
This is the struct you will be passed:
struct {
WORD red[256]; //WORDs not BYTEs
WORD green[256];
WORD blue[256]; };

32. DirectX 7.0 Implementation Details

33. Overview Of DirectX 7.0 Model
Direct3D refers to surfaces via “handles”
Driver keeps a look-up table indexed by handle
Driver keeps everything it needs to know about a surface in this table

34. CreateSurfaceEx Called after CreateSurface
Assigns a Direct3D-allocated handle to the surface(s)
Driver runs attachment lists, creates internal structures for each surface in list

35. CreateSurfaceEx Is Hard
Driver has to run surface attachment list
Z buffer might be attached, or separate surface
Cubic Environment Maps are the hardest...

36. Cubemap Attachments (Abstract View)
Positive X
Mip Sub-
Level
Negative X
Mip Sub-
Level
Positive Y
Mip Sub-
Level
...
...
...
...

37. Cubemaps (Struct View)
Positive X
lpAttachList
lpLink
lpAtt..
lpLink
lpAtt..
lpLink
lpAtt..
lpLink
lpAtt..
Positive Y
lpAttachList
+ X Mip
Negative X
lpAttachList
lpLink
lpAtt..
lpAttachList
lpLink
lpAtt..
+ X Mip
- X Mip
lpAttachList

38. Drivers Cannot
Keep pointers to DirectDraw’s surface structures in their own structures
Flip confusion (explained later)
Overhead
Under DirectX 8.0, we don’t keep the DirectDraw structure
...So DirectX 8.0 drivers CAN’T store pointers – they will crash

39. Flip Confusion Explained
User Mode
Front Buffer
Handle A
User Mode
Back Buffer
Handle A
Before Flip:
Driver
Surface A
Driver
Surface B

40. After Flip User Mode Front Buffer Handle B User Mode Back Buffer
Handle A
The user-mode
structures now
refer to different
pieces of memory.
=> You cannot store
pointers to the
user-mode structs
in the driver structs.
Driver
Surface A
Driver
Surface B

41. Aliasing: What It Is Video memory is a shared resource
On mode switch, all must be given up
But the application may be writing directly to video memory
We re-map the application’s view of video memory to a dummy page, then allow the mode switch to proceed
Only done at app’s request: DDLOCK_NOSYSLOCK

42. Aliasing: How It’s Done
When the driver returns a pointer to video memory at CreateSurface time:
The offset into the frame buffer is calculated, and then an equivalent aliased pointer is returned to the application
If the pointer lies outside of video memory, no aliasing is done (we don’t know enough to do so)

43. Aliasing: How To Break It
On Windows NT systems, the driver must NOT return a pointer outside of video memory at Lock time
This pointer will not be aliased
The application will crash if a mode switch happens
Drivers should allocate system memory at CreateSurface time (PLEASE_ALLOC_USERMEM)

44. Changes For DirectX 8.0

45. Driver Capabilities Are Constant Across Modes
This means everything in D3DCAPS8
The caps are allowed to be “nothing” in some modes, e.g., 24bpp
You are allowed to support different back buffer formats
That is, the one that matches the front buffer

46. Pixel Formats In DirectX 8.0
Goodbye DDPIXELFORMAT
Hello D3DFORMAT
All FOURCCs are D3DFORMATs
D3DFMT has this form
Byte 3 Byte 2 Byte 1 Byte 0
Vendor ID (0=Microsoft) Nonzero Format
(Use your PCI Vendor ID) => FOURCC Number

47. D3DFORMAT Examples D3DFMT_A1R5G5B5 IHV-defined Format FOURCC “UYVY”
0xACAT0001
(PCI ID 0xACAT, not FOURCC, format 1)
FOURCC “UYVY” 0x
(Byte 2 is non-zero)

48. IHV-Def’d Texture Formats
Since Direct3D doesn’t understand
These formats cannot be “managed”
Applications can lock these surfaces directly
(In fact this is the only way to fill such surfaces with data)

49. DirectX 8.0 Format Op-list
The format op-list tells DirectX 8.0 everything about capabilities that vary with surface format
For each format, the driver sets bits that indicate:
Can Texture from this format
Render to this format
Switch display mode to this format
Has caps in modes of this format

50. Format Op-List Tricks
The runtime searches for the first entry that has all required capabilities
Example: Application wishes to render to 565 texture
Runtime will search for an Op-List entry with:
D3DFORMAT_OP_TEXTURE | D3DFORMAT_OP_OFFSCREEN _RENDERTARGET

51. Format Op-List Tricks Driver A can render to 565 texture
Sets this entry:
Format = D3DFMT_R5G6B5
Ops = D3DFORMAT_OP_TEXTURE | D3DFORMAT_OP_OFFSCREEN _RENDERTARGET

52. Format Op-List Tricks
Driver B can NOT render and texture from the same surface, but can do both operations individually
Sets TWO entries
Format1 = D3DFMT_R5G6B5
Ops1 = D3DFORMAT_OP_TEXTURE
Format2 = D3DFMT_R5G6B5
Ops2 = D3DFORMAT_OP_OFFSCREEN _RENDERTARGET

53. What Can You Do Next? If you develop DX Graphics Drivers:
You need a relationship with Microsoft’s DirectX team, and should contact IHV Program Manager:
Michele Boland
Install and run against DEBUG runtimes
Available in the DirectX SDK
Will output debug messages for common errors

54. DirectX VA Video Acceleration Drivers Gary Sullivan GarySull@microsoft
DirectX VA Video Acceleration Drivers Gary Sullivan Software Design Engineer DMD Video Services Group Microsoft Corporation

55. Agenda DirectX VA design and status
Current and future requirements and tests
Future plans and potential extensions
What can you do next?

56. DirectX VA Prime Directive
Decouple software decoder operation from hardware accelerator design to achieve full interoperability
Any other
MPEG-2
MPEG-4
DirectX VA
H.263++
MPEG-1
H.261
Motion Comp
Inverse DCT
VLD

57. What Is DXVA? What Can It Achieve?
Interoperable interface between video decoding software and advanced- capability graphics accelerators
Increases video capability for the consumer’s PC
Increases the demand for advanced graphics accelerators and video applications
Decreases implementation effort for software decoder writers
Decreases support burden for graphics accelerator companies
Decreases testing burden for OEMs

58. DirectX VA General Status
Spec went 1.0 with DirectX 8.0 Beta 2 (October ’00)
See
OEMs love it – it enables separate WHQL qualification of decoders and drivers
Software decoder companies are developing with it (Mediamatics, Intervideo, Ravisent, Cyberlink, MGI/Zoran, MbyN, …)
Hardware accelerator companies are supporting it in drivers (ATI, Nvidia, Intel, SiS, S3, SiliconMotion, …)

59. DirectX VA Capabilities
Emphasis on MPEG-2 and DVD “sub-picture”
Support of all important video coding standards (H.261, H.263, MPEG-1, MPEG-2, MPEG-4)
And some non-standard variations on the standards
Alpha graphic blending (e.g., DVD subpicture)
Three basic degrees of decoding configuration capability:
Motion compensation on accelerator with host residual difference decoding
Motion compensation and IDCT on accelerator
Full raw bitstream decoding
Externally-defined encryption support

60. How Does DXVA Operate?
Operation with Windows 2000 Overlay Mixer (OVM) or new Windows XP Video Mixing Renderer (VMR)
Requires DirectX 8.0 or Windows XP
Decoders use it through existing Windows 2000 “IAMVideoAccelerator” API
Drivers use it through corresponding Windows 2000 “MoComp” DDI
DirectVA specifies payload content of data buffers that previously had accelerator-specific formats

61. Host Versus Accelerator Functional Split
Bitstream processing either on host or accelerator
Accelerator handles the primary data flow and performs the intensive signal processing
PCI/AGP is the bridge between the two
Reconstruction loop maintained in graphics Accelerator memory
Host processing converts standard-specific streams into generic Accelerator work units

62. Today’s DirectX VA (Content Protection Supported Outside of Scope)
Compressed Video
Source
Variable-Length
Decoding
Residual Difference
Decoding (IDCT)
Motion
Compensation
Sum & Clip
Frame Storage
OVM/VMR/3D
Graphic
Source
Graphic Decoder
Graphic Blending
(Content Protection Supported Outside of Scope)

63. Constrained Parameter Profiles
Strategy is to define a general interface and a number of constrained-parameter profiles, with decoder data structure configuration settings
Profiles defined:
MPEG-2 Main Profile with and without DVD Subpicture
Several H.263/MPEG-4 profiles
MPEG-1
H.261 with and without deblocking post-processing

64. Defined Buffer Types Picture-level decoding parameter buffers
Buffers for bitstream decoding:
Bitstream data buffers
Bitstream slice control buffers
Inverse quantization matrix buffers
Buffers for macroblock-level decoding:
Macroblock control buffers
Residual difference data buffers
Buffers for graphic blending:
Alpha+YUV graphic buffers
AI44 graphic buffers
DVD DPXD graphic buffers
DVD highlight definition buffers
DVD display control command buffers
Alpha blend combination buffers
Deblocking filter control buffers
Picture resampling buffers
Read-back data buffers

65. DXVA Requirement Plans Primary Goals
Clear specification for MPEG-2 interoperability (and front-end DVD subpicture) is the primary goal
Driver and decoder that claim video acceleration must support DXVA
Specific “minimal interoperability set” for each defined profile

66. July ’01 Stated Requirements
MPEG2_A and MPEG2_C required
MPEG1_A required
H263_A required (?!)
Arithmetic accuracy required
IDCT accuracy required
Picture resolutions up to 720x576
Uncompressed surface types must include NV12 in supported list
Must have “front end” capability to convert to YUY2 from format in use

67. July ’01 Actual Tests StRowe test decoder developed
Test driver also developed
Released DCT400 driver tests cover MPEG2_A, _B, _C, _D profiles
Pass/Fail based on MPEG2_A and _B
Tests are currently of functional operation and visual performance
Contact us (?!) if any test problems
Don’t ship untested features (?!)

68. Structure Of Motion Comp Data
All standards send only luma motion vectors, deriving chroma vectors from luma vectors
Each standard derives chroma vectors in its own way
Switches for configuring the motion comp are provided to minimize host “translation” requirements
MPEG-2 Dual-Prime motion vectors derived on host

69. DXVA Macroblock Control Example
/* Basic form for P and B pictures */
typedef struct _DXVA_MBctrl_P_OffHostIDCT_1 {
WORD wMBaddress;
WORD wMBtype;
DWORD dwMB_SNL;
WORD wPatternCode;
UINT8 NumCoef[6];
DXVA_MVvalue MVector[4];
} DXVA_MBctrl_P_OffHostIDCT_1;

70. Structure Of Residual Data Background (1 of 2)
Things that vary within and across standards:
Coefficient scan schemes
Intra Coefficient prediction schemes
VLC schemes
Inverse quantization schemes
Mismatch-control schemes …
These things need lots of logic – not always justified for accelerator implementation

71. Structure Of Residual Data Background (2 of 2)
Things that do not vary within and across standards
IDCT definition
Conformance rules may slightly differ – but multi-standard conformance not a big problem
Many zero-valued coefficients
Predicted-versus-Intra operation
Only a few currently-specified inverse scans

72. Structure Of Residual Data The Chosen Method
Keep standard-specific issues on the host to the extent possible
Support host-based or accelerator-based IDCT
Send only non-zero coefficients
Send index or run-length for coefficients

73. Residual Difference Example (Off-Host IDCT 16b TCOEFF)
typedef struct _DXVA_TCoefSingle {
WORD wIndexWithEOB;
SHORT TCoefValue;
} DXVA_TCoefSingle, *LPDXVA_TCoefSingle;
/* Macros for Reading EOB and Index Values */
#define readDXVA_TCoefSingleIDX(ptr) ((ptr)->wIndexWithEOB >> 1)
#define readDXVA_TCoefSingleEOB(ptr) ((ptr)->wIndexWithEOB & 1)
/* Macros for Writing EOB and Index Values */
#define writeDXVA_TCoefSingleIndexWithEOB(ptr, idx, eob) ((ptr)->wIndexWithEOB = ((idx) << 1) | (eob))
#define setDXVA_TCoefSingleIDX(ptr, idx) ((ptr)->wIndexWithEOB |= ((idx) << 1))
#define setDXVA_TCoefSingleEOB(ptr) ((ptr)->wIndexWithEOB |= 1)

74. Decoding Configurations (Part 1 of 2)
Bitstream decoding vs. Host VLD
Encryption:
Bitstream data if bitstream decoding
Macroblock control commands and/or residual difference data if Host VLD
Type of encryption protocol supported
For Host VLD:
Host-based residual difference decoding versus Accelerator-based residual difference decoding versus both
Macroblock control commands in raster-scan order versus arbitrary order

75. Decoding Configurations (Part 2 of 2)
For host-based residual difference decoding
8b vs. 16b differences
If 8b differences, overflow supported, or not
If 8b differences, subtract second pass, or not
Interleaved chroma or not
Host clips range of data, or not
Intra residuals unsigned, or not
For accelerator-based difference decoding
Specific IDCT support
Inverse scan on host or accelerator
Coefficients sent in groups of four, or singly

76. Alpha Blending Configurations
AYUV alpha blend graphic loading
AI44 or IA44 +palette or DPXD+Highlight or AYUV
Alpha blend combination operation:
Front-end versus back-end
Picture resizing or not
Only use picture destination area or not
Graphic resizing or not
Whole plane alpha or not

77. Longer Term Requirements
Include H263_A, _B, _C in tested requirements
Include mathematical motion comp and IDCT accuracy in tests
Add speed performance testing
Picture resolutions up to 1920x1088
Six or more uncompressed surfaces
Specific FOURCC surface types for uncompressed surfaces

78. Kill Superfluous Configs
bConfigRasterOrder = 0
bConfigResidDiffHost = 1
(bConfigResid8Subtraction = 1 with bConfigSpatialResid8 = 1) or (bConfigResidDiffHost = 1 with (bConfigSpatialResid8 = 0 and bConfigSpatialHost8or9Clipping = 0))
bConfigIntraResidUnsigned = 0
bConfigSpatialResidInterleaved = 0
bConfigHostInverseScan = 0
bConfig4GroupedCoefs = 0

79. Enhance Blending Configs
Eliminate duplication of AI44 & IA44 (bConfigDataType = 0 & 1)
Require both AYUV and AI44/IA44 (bConfigDataType = 3 and 0/1)
Require front-end blend (bConfigBlendType = 0)
bConfigPictureResizing = 1
bConfigOnlyUsePicDestRectArea = 0
bConfigGraphicResizing = 1
bConfigWholePlaneAlpha = 1

80. Hot Issue: WMV/H.263/MPEG-4
Codecs beyond MPEG-2 need support
H263_A profile needs:
Different derivation of chroma motion
H263_B profile needs:
Rounding control
Motion vectors over picture boundaries
8x8 motion vectors
Alternative inverse scan (or host inverse scan)
H263_C profile needs:
Deblocking filter support (also in H263_B?!)

81. Desirable Future Extensions
De-interlacing
Interoperable encryption / DRM
Compressed-video encoding (including ME, DCT, and so on)
Inverse-telecine
Hue/contrast/brightness/gamma/color corrections
Future decoding methods (MPEG-4v2, WMV, H.26L)
Frame rate conversion
Precise separable re-sampling
Gen lock/frame rate synchronization
TV out control

82. New GUIDs Reducing Memory Use
Add three new GUIDs to parallel MPEG2_A, MPEG2_B, and MPEG2_D
New GUID adds raw bitstream decoding to the “minimal interoperability set” of the corresponding existing GUID
Driver with raw bitstream support then need not allocate buffers for macroblock-level processing with these GUIDs
Drivers could also not expose bitstream processing with existing GUIDs to save memory

83. Interoperable Encryption
Define an interoperable encryption scheme
Much like the old draft DXVA scheme
Certificates for establishing trust (perhaps X.509 or something else rather than old draft scheme)
RSA key exchange
AES (RIJNDAEL) content encryption

84. Other In-Scope Additions
Add new features for other codecs – WMV, H.26L, MPEG-4v2, etc.
1/4-sample motion comp
Added motion comp sizes and shapes
New inverse transforms (e.g., 4x4)
Fine granularity scalability
Global motion comp
Studio profile features
More possible GUIDs for precise codec/configuration needs

85. New Video Building Blocks
Deinterlacing
Inverse Telecine
Frame rate conversion
Contrast/Brightness/Gamma/Color
Precisely-specified resampling
Video compression encoding

86. Deinterlace/ Inverse Telecine
Deinterlace is crucial
Becoming a standard feature of high-end consumer TVs
1080i in weave can look awful
1080i in bob can look wrong too
Deinterlace can be useful for either decoding or encoding

87. Hypothetical DXVA Structure
Interoperable DRM/Conditional Access/Content Protection/Encryption
Today’s Scope of
DirectX VA
De-interlace /
Inverse Telecine
Frame Rate
Conversion ?
OVM/VMR/3D
Color Conversions
& Adjustments ??
Scaling
???

88. Video Encoding ? Uncompressed Video Source Motion Estimation
Frame Storage
Inverse Telecine /
De-interlace
Motion
Compensation
Sum and Clip
Color Conversions
And Adjustments
Mode & Motion
Vector Decision
Residual Difference
Transform (DCT)
Quantization
Residual Difference
Decoding (IDCT)
Variable Length
Encoding ?

89. What Can You Do Next? (To All) Give Us Your Proposals
About any difficulties/problems in design
About encryption design
About new in-scope feature needs
About how to support new features
Deinterlace/inverse telecine
Encoding
Frame rate conversion
Contrast/Brightness/Gamma/Color
Resampling

90. What Can You Do Next? (For Graphic Accelerator Designers)
Make your MPEG-2 and DVD subpicture DXVA solution rock-solid, fully-tested with every available decoder, and frighteningly fast
Fully support YUV surfaces as textures for input to 3-D
Conversion to RGB, and so on
Design maximal WMV/H.263/MPEG-4 feature support into your next generation
But don’t expose them unless fully tested
Move to the preferred configurations and uncompressed surface types
Support new memory-conserving GUIDs

91. Writing AVStream Minidrivers For Windows XP William Messmer, SDE Digital Audio-Video Microsoft Corporation

92. Agenda AVStream minidriver architecture Data processing
When and why to use AVStream
Exposing minidriver functionality
Data processing
Writing a minidriver: key issues and pitfalls
Walk through sample code
Common problems and mistakes
DirectX 8.0 versus Windows XP
What can you do next?

93. Why AVStream THE next generation class driver
More efficient streaming
Reduces the amount of minidriver code
Simplifies development; faster to market
One minidriver, one model – no more confusion over stream class versus port class
New features, new technologies will only be supported in AVStream; stream and port class, however, are still supported!

94. When To Use AVStream BDA Drivers New Device Types Combined A/V devices
Which are not already written to stream class or port class
Combined A/V devices
Kernel Software Transforms
Audio Global Effects (GFX) Filters
No necessity to port existing stream or port class drivers

95. Minidriver Architecture
Functionality is exposed as a tree hierarchy described through static descriptors
Device – described by Device Descriptor
Filter Factory – creates a type of Filter
Filter – described by Filter Descriptor
Pin Factory – creates a type of Pin
Pin – described by Pin Descriptor
Functionality provided through static dispatch and automation tables

96. Minidriver Architecture
Device
Filter Factory
>= 1
Device Descriptor
Device Dispatch
Add Device
Filter Create
Device Dispatch
Filter Descriptor
Filter Dispatch
Filter Automation
Pin Create
Filter Dispatch
Pin Factory
Filter
>= 1
Pin Descriptor
Pin Dispatch
Pin Automation
Pin Dispatch
Pin
>= 1
Minidriver Provided Table
Public AVStream Construct
Private AVStream Construct
Key:
Minidriver Dispatch Routine

97. Exposing Minidrivers Expose your driver to AVStream
Call KsInitializeDriver in DriverEntry passing your Device Descriptor
Return the status from KsInitializeDriver
AVStream handles PnP to get your driver set up; minidriver gets calls through device dispatch
Filter Factories set up by AVStream during Add Device and Start Device

98. Exposing Minidrivers
AVStream creates filters/pins based on descriptors
Minidriver receives creation dispatch
Creation dispatch associates minidriver specific context with object
Object bags available as containers for dynamic memory like contexts
AVStream handles cleanup of objects based on bags
No forgetting to free dynamic memory

99. Minidriver Architecture
Sample Code (Exposing Functionality)

100. Data Processing AVStream queues data/buffers
Minidriver queues not necessary
Cancellation handled in the queue
Data exposed through two abstractions: stream pointers and process pins
Stream pointers are robust and allow versatile queue management; typically used in hardware drivers
Process pins work purely at a single buffer level making for very simple software transforms

101. Design Issues Two distinct ways to handle data processing
Filter-Centric processing
Specify filter process dispatch
Pin-Centric processing
Specify pin process dispatches
The choice of which to use will influence design greatly

102. Filter-Centric Processing
Filter is called to process data in a context where data is available on all required pins
Typically used for software transforms
Stream pointer use not required
Processing based on an index of process pins
Index/pins stable during processing
Minidriver does transform, specifies how many bytes of each buffer used

103. Process Pins One per pin – points back to the pin
Contains a stream pointer if needed
Contains a buffer virtual address and size for data manipulation
Informs the process routine of the pin’s relationships with other pins
InPlaceCounterpart – other pin in an in-place transform pair
CopySource – pin data is copied from
DelegateBranch – pin that delegates frames (in the same pipe)

104. Transform Example INPUT OUTPUT IN OUT 1920 Bytes Data
1. Frame(s) arrive
Frame
Gone
Frame
(1920)
Frame
(960)
Frame
Gone
Frame
(2880)
2. Filter is called to process.
Filter sees two process pins:
3. Process Pins Point to Buffers
Frame
(1100)
Frame
(140)
4. Filter performs transform;
Sets 1920 bytes used on input and output
5. Filter is called back;
more data to transform IN
OUT
1920 Bytes Data
2880 Bytes Buffer
6. Process Repeats Similarly
1100 Bytes Data
960 Bytes Buffer

105. Pin-Centric Processing
Each pin called to process data in a context independent of other pins
Typically used for hardware drivers
Data accessed through stream pointer abstraction

106. Stream Pointers Reference a single frame in a queue
Hold that frame in the queue
Can be in multiple states
Locked – referenced data is safe to access; Irp cannot be cancelled
Unlocked – not guaranteed to even reference data; Irp can be cancelled
Can be cloned to create new pointers into the data stream
Can schedule time-outs

107. Stream Pointers
Contain two offsets into the data stream for ease of in-place use
Address data at one of two granularities:
Byte – access via virtual address
Mapping – access via logical DMA address
KSPIN_FLAG_GENERATE_MAPPINGS
Minidriver usable context available per stream pointer

108. Stream Pointers And Queues
Oldest Frames
Frame
(1)
(0)
Leading
Edge
Frame
(1)
(0)
Leading
Edge
Trailing
Frame
(1)
(2)
(3)
Leading
Edge
Clone
Clones
Newest Frames

109. Direct DMA Example QUEUE
1. Frame(s) arrive; minidriver called to process
2. Processing routine acquires leading edge
KsPinGetLeadingEdgeStreamPointer
Frame
(2)
Frame
(1)
Frame Gone
Frame
(1)
Frame
3. Leading edge is cloned
KsStreamPointerClone
Frame
Frame
(2)
Frame
Gone
Frame
(1)
Frame
(1)
4. DMA Hardware is programmed
5. Leading edge is advanced
Frame
(1)
Frame
(2)
Frame
Frame
Gone
Frame
(1)
6. Process may repeat for more frames
7. Hardware interrupts for DMA completion
8. ISR Schedules a DPC
9. DPC releases the associated frames
KsStreamPointerDelete
10. May need to continue processing
KsPinAttemptProcessing

110. Data Frame Control Held non-cancelable for a period
Use locked stream pointers
Consider stream pointer timeouts
Can relinquish claim with callback
Use unlocked stream pointers with a cancel callback
Periodic access where frame can disappear between accesses
Use unlocked stream pointers and lock periodically

111. Processing Decisions Filter-Centric Pin-Centric
All pins are involved in the decision
Each pin type can have separate requirements
One pin not fulfilling requirements will veto processing for the entire filter
Pin-Centric
Only one pin is involved in the decision
Each pin type can have separate requirements which do not influence other pins

112. When Processing Happens
Default case (no pin flags)
Attempt made when frame arrives and leading edge points to no frame
Attempt will succeed if
Involved pin(s) are >= KSSTATE_PAUSE
Involved pin(s) all have data
Continuing processing
STATUS_SUCCESS returned from dispatch and conditions still met

113. Adjusting Processing KSPIN_FLAG_ _INITIATE_PROCESSING_ON_EVERY…
Every frame arrival initiates
_DO_NOT_INITIATE_PROCESSING
No frame arrival initiates
PROCESS_IN_RUN_STATE_ONLY
Pin must be in KSSTATE_RUN
FRAMES_NOT_REQUIRED…
Data is not required on this pin

114. Adjusting Processing Some mentioned flags useful for pin-centric
Most flags useful for filter-centric where all pins are involved in the decision as to when to process data
See the DDK for a complete description of flags
Understand when processing happens based on your flags!

115. Adjusting Processing Processing can happen in a DPC!
KSFILTER_FLAG_DISPATCH_LEVEL_PROCESSING
KSPIN_FLAG_DISPATCH_LEVEL_ PROCESSING
Dispatch level processing still synchronized
Processing mutex still held during dispatch level processing
Can still be used to synchronize with processing
Data manipulation (stream pointer) API fully dispatch level ready!

116. Walkthrough Sample Code
Pin-centric sample code

117. Common Problems Internal mutexes are exposed
Three mutex types in a hierarchy
Device Mutex
Filter Control Mutex
Processing Mutex
Some calls require mutexes held
Sometimes AVStream holds the mutex for you; sometimes you must hold the mutex!
See the DDK for this!

118. Common Problems Mutex Rules
Do NOT take mutexes out of order: device then control then processing
Do NOT take a mutex and call out – not for properties, not for anything!
Walking the object hierarchy requires mutexes held:
Device Mutex – device down to filter
Filter Control Mutex – filter down to pins

119. Common Problems
Do not traverse the object tree (filters and pins) during processing!
KsFilterGetFirstChildPin
KsPinGetNextSiblingPin
Pin-centric filters should not need to do this; filter-centric filters have the process pins index

120. DirectX 8.0 Versus Windows XP
Mutexes in DirectX 8.0 are fast mutexes
Certain APIs require mutexes held
Client must be careful of when to acquire mutexes!
Mutexes in Windows XP are full mutexes
Completely backwards compatible with DirectX 8.0 drivers
Less APIs require mutex acquisition
Mutex acquisition more lenient

121. DirectX 8.0 Versus Windows XP
New flags in Windows XP
_SOME_FRAMES_REQUIRED…
One or more pin instances of this type requires frames
Can be programmatically done in DirectX 8.0
_PROCESS_IF_ANY_IN_RUN_STATE
One or more pin instances of this type must be >= KSSTATE_RUN; others must be >= KSSTATE_PAUSE
Processing routine must check in DirectX 8.0

122. What Can You Do Next? Install the DirectX 8.0 or Windows XP DDK
Try out the samples in the DDK
Write AVStream minidrivers for new hardware!

123. Testing your WDM Driver with DirectShow
Eric Rudolph System Design Engineer DirectShow Editing Services Microsoft Corporation

124. Agenda
DirectShow supports capture from 1394, USB, analog video/audio, TV tuner, and custom devices
Demonstrate the use of the DirectShow-based generic graph editor, GraphEdt, as a WDM driver test tool
Walk through sample code that uses the GraphBuilder COM object

125. What tools exist to test your driver?
Included in DX8: GraphEdt.exe, a generic graph editor
Also in DX8: AmCap.exe, a simple capture application
New for Windows XP: Still Image devices show up in the shell (Explorer)
New for Windows XP: Movie Maker (on Start Menu)

126. GraphEdt Overview Ships with DX8
Provides UI to build dataflow graphs and then uses DirectShow to run, pause, and stop the data
Views different filter categories
Capture, compressor, crossbar, DMO, and so on
Connects different filters together
Accesses property pages
Writes out files
Controls 1394 devices

127. GraphEdt Filter Categories
Categories enable you to easily find a particular type of DirectShow filter
Many categories predefined in ksuuids.h & uuids.h
WDM drivers have many of their own categories
Capture devices can show up in both non-WDM and WDM categories
As you add/remove WDM devices, if they send device notifications, they will auto show/hide from category lists

128. GraphEdt Property Pages
The filter itself can expose multiple property pages
Each pin can expose 1 or more property pages
When you query an output pin’s property pages, you will see 1 extra page per pin which lists available output media connection types
Capture property pages are often exposed by capture applications (using standard DirectShow methods), so make them look nice!
Example property page

129. GraphEdt Property Pages And Media Types
Output pins provide one or more media types
Input pins normally do not provide a list of types, but instead accept types
When you render a pin, DirectShow will try to find appropriate filters to render
When you try to connect two pins, DirectShow will find try and find intermediate filters
The media types must agree between any output pin and its connected input pin
Buffers are also negotiated
The different media types Indeo 5.11 decompressor provides

130. Common Problems Hot unplug while streaming
Device add/remove while streaming
Enter hibernation while streaming
Multiple camera enumeration
Multiple camera streaming (one driver, multiple devices)
Video shows up black or wrong
Changing display props while streaming
Overlay and DDraw issues

131. GraphEdt Demos Part 1
Capture from USB, both with 1 pin and with 2 pins (capture & preview)
DV capture and device control
Device Insertion / Removal and how the Graph refreshes

132. GraphEdt Demos Part 2 How to write AVI, WAV, and WM files
New Video Mixing Renderer has slightly different connection model than old Video Renderer
How to force a filter to produce a media type with a Type Enforcer
Timestamps are important!
Using .GRF files

133. Sample Code Using the GraphBuilder COM Object
CaptureGraphBuilder makes connecting capture devices easy
See the AmCap sample code in the DX8/DirectShow SDK directory
Sample code walkthrough

134. What Can You Do Next?
Test your WDM drivers! Under many different conditions!
Read up on the DX8 docs, they’re great!
DirectShow contact:
Get on the DirectX A/V list
