1. Cloud Computing

2. “Cloud computing is simply a buzzword used to repackage grid computing and utility computing, both of which have existed for decades.”
whatis.com
Definition of Cloud Computing

3. Cloud Computing
Cloud computing is a model for enabling convenient, on-demand network access to a shared pool of configurable computing resources (e.g., networks, servers, storage, applications, and services) that can be rapidly provisioned and released with minimal management effort or service provider interaction.
This cloud model promotes availability and is composed of five essential characteristics, three service models, and four deployment models.

5. History
“Cloud“ used as a metaphor for the Internet, based on the cloud drawing used in the past to represent the telephone network; later to depict the Internet in computer network diagrams as an abstraction of the underlying infrastructure it represents.
Details abstracted from end-users, who no longer have need for expertise in, or control over, the technology infrastructure "in the cloud" that supports them.

6. Evolution of cloud computing

7. Comparison Mainframe computer Autonomic computing Client–server
Cloud computing shares characteristics with:
Mainframe computer
Autonomic computing
Client–server
Grid computing
Peer-to-peer

8. Foundational Elements of Cloud Computing
Primary Technologies
Other Technologies
Virtualization
Grid technology
Service Oriented Architectures
Distributed Computing
Broadband Networks
Browser as a platform
Free and Open Source Software
Autonomic Systems
Web 2.0
Web application frameworks
Service Level Agreements

9. The Traditional Server Concept
Web Server
Windows
IIS
App Server
Linux
Glassfish
DB Server
Linux
MySQL
Windows
Exchange

10. Traditional Server Concept Explained
Servers considered as a whole unit that includes the hardware, the OS, the storage, and the applications.
Often referred to by their function i.e. the Exchange server, the SQL server, the File server, etc.
If the File server fills up, or the Exchange server becomes overtaxed: must add in a new server.

11. Traditional Server Concept Contd.
Unless there are multiple servers, if a service experiences a hardware failure, the service is down.
Can implement clusters of servers to make them more fault tolerant.
Even clusters have limits on their scalability, and not all applications work in a clustered environment.

12. Pros and Cons Pros Easy to conceptualize Fairly easy to deploy
Easy to backup
Virtually any application/service can be run from this type of setup
Cons
Expensive to acquire and maintain hardware
Not very scalable
Difficult to replicate
Redundancy is difficult to implement
Vulnerable to hardware outages
In many cases, processor is under-utilized

13. And if something goes wrong ...
Web Server
Windows
IIS
App Server
DOWN!
DB Server
Linux
MySQL
Windows
Exchange

14. The Virtual Server Concept
Virtual Machine Monitor (VMM) layer between Guest OS and hardware

15. Close-up
* adapted from a diagram in VMware white paper, Virtualization Overview
Clustering
Service Console
Server 1
Guest OS
Server 2
Guest OS
VMM (Virtual Machine Monitor)
x86 Architecture
Intercepts hardware requests

16. The Virtual Server Concept
Virtual servers seek to encapsulate the server software away from the hardware
This includes the OS, the applications, and the storage for that server.
A virtual server can be serviced by one or more hosts, and one host may house more than one virtual server.

17. Virtual Server Concept Contd.
Virtual servers can still be referred to by their function i.e. server, database server, etc.
If the environment built correctly, virtual servers will not be affected by the loss of a host.
Hosts may be removed and introduced almost at will to accommodate maintenance.

18. Virtual Server Concept Contd.
Can be scaled out easily.
If the resources supporting a virtual server are being taxed too much, admin can adjust the amount of resources allocated to that virtual server
Server templates can be created in a virtual environment to be used to create multiple, identical virtual servers
Virtual servers themselves can be migrated from host to host almost at will.

19. Pros and Cons Pros Resource pooling Highly redundant Highly available
Rapidly deploy new servers
Easy to deploy
Reconfigurable while services are running
Optimizes physical resources by doing more with less
Cons
Slightly harder to conceptualize
Slightly more costly (must buy hardware, OS, Apps, and now the abstraction layer)

20. The Cloud’s “Snowball Effect”
Maturation of Virtualization Technology
Virtualization enables Compute Clouds
Compute Clouds create demand for Storage Clouds
Storage + Compute Clouds create Cloud Infrastructure
Cloud Infrastructure enables Cloud Platforms & Applications
Multiple Cloud types lead to Cloud Aggregators
Niche requirements enable Cloud Extenders

21. Characteristics Cost claimed to be reduced.
Reliability improved if multiple redundant sites used.
Performance monitored, and consistent and loosely coupled architectures constructed using web services as the system interface.
Security could improve due to centralization of data, increased security-focused resources, etc.
Maintenance is easier: do not need to be installed on each user's computer.

22. Layers
Client
Computer hardware and/or computer software relying on cloud computing for application delivery.
Application
Application services (SaaS).
Platform
Platform services (PaaS).
Infrastructure
Infrastructure services (IaaS).
Server
Computer hardware, software products specifically designed for delivery of cloud services.

23. Service Model Architectures

24. Cloud Service Delivery Models
IaaS: Infrastructure as a Service
provisions computing resources within provider's infrastructure upon which they can deploy and run arbitrary software, including OS and applications.
PaaS: Platform as a Service
can create custom applications using programming tools supported by the provider and deploy them onto the provider's cloud infrastructure.
SaaS: Software as Service
use provider’s applications running on provider's cloud infrastructure.

25. Three Features of Mature SaaS Applications
Scalable
Handle growing amounts of work in a graceful manner
Multi-tenancy
One application instance may be serving hundreds of companies
Opposite of multi-instance where each customer is provisioned their own server running one instance
Metadata driven configurability
Instead of customizing the application for a customer (requiring code changes), one allows the user to configure the application through metadata
Source: Scalable definition, André B. Bondi, 'Characteristics of scalability and their impact on performance', Proceedings of the 2nd international workshop on Software and performance, Ottawa, Ontario, Canada, 2000, ISBN X, pages
Source: Three attributes for SaaS, Architecture Strategies for Catching the Long Tail, Frederick Chong and Gianpaolo Carraro Microsoft Corporation April 2006, 25 25

26. SaaS Maturity Levels Level 1: Ad-Hoc/Custom Level 2: Configurable
Level 3: Configurable, Multi-Tenant-Efficient
Level 4: Scalable, Configurable, Multi-Tenant-Efficient
Source: Architecture Strategies for Catching the Long Tail, Frederick Chong and Gianpaolo Carraro Microsoft Corporation April 2006, 26
Source: Microsoft MSDN Architecture Center 26

27. Platform-as-a-Service (PaaS)
Definition
– Platform providing all the facilities necessary to support the complete process of building and delivering web applications and services, all available over the Internet
– Entirely virtualized platform that includes one or more servers, operating systems and specific applications

28. PaaS Example: Google App Engine
Service that allows user to deploy user’s Web applications on Google's very scalable architecture
Providing user with a sandbox for user’s Java and python application that can be referenced over the Internet
Providing Java and Python APIs for persistently storing and managing data (using the Google Query Language or GQL)

29. Infrastructure-as-a-Service (IaaS)
Definition
– Provision model in which an organization outsources
the equipment used to support operations, including
storage, hardware, servers and networking
components.
– Also known as Hardware as a Service (HaaS).
– Service provider owns the equipment; responsible for housing, running and maintaining it.
– Client typically pays on a per-use basis.

30. IaaS Contd.

31. Characteristics of Infrastructure-as-a-Service (IaaS)
Utility computing and billing model
Automation of administrative tasks
Dynamic scaling
Desktop virtualization
Policy-based services
Internet connectivity

32. Service Delivery Model Examples
Amazon
Google
Microsoft
Salesforce
SaaS
PaaS
IaaS

33. 4 Cloud Deployment Models
Private cloud
enterprise owned or leased
Community cloud
shared infrastructure for specific community
Public cloud
Sold to the public, mega-scale infrastructure
Hybrid cloud
composition of two or more clouds

34. Common Cloud Characteristics
Cloud computing often leverages:
Massive scale
Homogeneity
Virtualization
Resilient computing
Low cost software
Geographic distribution
Service orientation
Advanced security technologies

35. Web-Scale & Large data centers Problems
Characteristics:
Definitely data-intensive
May also be processing intensive
Examples:
Crawling, indexing, searching, mining the Web
“Post-genomics” life sciences research
Other scientific data (physics, astronomers, etc.)
Sensor networks
Web 2.0 applications

36. How much data? Wayback Machine has 3 PB + 100 TB/month (2009)
Google processes 20 PB a day (2008)
“all words ever spoken by human beings” ~ 5 EB
NOAA has ~1 PB climate data (2007)
CERN’s LHC generates 15 PB a year (2010)
640K ought to be enough for anybody.

37. Large Data Centers Web-scale problems? Throw more machines at it!
Clear trend: centralization of computing resources in large data centers
Important Issues:
Redundancy
Efficiency
Utilization
Management

38. The “Cloud” = 10X Improvements
Ease of Use
Scalability
Risk
Reliability
Cost

39. Ease of Use Deploy infrastructure with a mouse or API
Cloud computing providers deliver applications via the internet, which are accessed from web browsers and desktop and mobile apps
Do it yourself remotely from anywhere anytime

40. Scalability
Dynamic provisioning of resources on a fine-grained, self-service basis near real-time, without users having to engineer for peak loads
Control your infrastructure with your app

41. RISK Risk Nothing to buy Cancel immediately
Change instantly, even operating systems
Throw it out
Rebuild it instantly after testing
RISK

42. Reliability Based on enterprise grade hardware Design for failures:
Automatically spin up replacements
Use multiple clouds

43. Cost Control Cost Many systems have variable demands
Batch processing (e.g. New York Times)
Web sites with peaks (e.g. Forbes)
Startups with unknown demand (e.g. the Cash for Clunkers program)
Reduce risk
Don't need to buy hardware until you need it

44. Business Agility More than scalability - elasticity!
Ely Lilly in rapidly changing health care business
Used to take months to give a department a server cluster, then they would hoard it!
Using EC2, about 5 minutes!
And they give it back when they are done!
Scaling back is as important as scaling up

45. Stick to Business
Most companies don't WANT to do system administration
Forbes says:
We are is a publishing company, not a software company
But beware:
Do you really save much on sys admin?
You don't have the hardware, but you still need to manage the OS!

46. Provisioning Service Advantages Rapid reconstitution of services
Enables availability
Provision in multiple data centers/multiple instances
Advanced honey net capabilities
Challenges
Impact of compromising the provisioning service

47. Data Storage Services Advantages Challenges
Data fragmentation and dispersal
Automated replication
Provision of data zones (e.g., by country)
Encryption at rest and in transit
Automated data retention
Challenges
Isolation management / data multi-tenancy
Storage controller
Single point of failure / compromise?
Exposure of data to foreign governments

48. Cloud Processing Infrastructure
Advantages
Ability to secure masters and push out secure images
Challenges
Application multi-tenancy
Reliance on hypervisors
Process isolation / Application sandboxes

49. Cloud Support Services
Advantages
On demand security controls (e.g., authentication, logging, firewalls…)
Challenges
Additional risk when integrated with customer applications
Needs certification and accreditation as a separate application
Code updates

50. Cloud Network and Perimeter Security
Advantages
Distributed denial of service protection
VLAN capabilities
Perimeter security (IDS, firewall, authentication)
Challenges
Virtual zoning with application mobility

51. The NIST Cloud Definition Framework
Hybrid Clouds
Deployment
Models
Community
Cloud
Private Cloud
Public Cloud
Service
Models
Software as a Service (SaaS)
Platform as a Service (PaaS)
Infrastructure as a Service (IaaS)
Resource Pooling
Broad Network Access
Rapid Elasticity
Measured Service
On Demand Self-Service
Essential
Characteristics
Cloud diagram idea inspired by Maria Spinola
Low Cost Software
Virtualization
Service Orientation
Advanced Security
Massive Scale
Resilient Computing
Homogeneity
Geographic Distribution
Common
Characteristics
Based upon original chart created by Alex Dowbor -

52. Cloud Computing Case Studies

53. Google Cloud Started with Google Apps Platform as Service later on
Replace office software
Gmail
Google Docs (word processing and spreadsheets)
Google video for business
Google sites (intranet sites and wikis)
Google Cloud Connect
500,000+ organizations use Google Apps
GE moved 400,000 desktops from Microsoft Office to Google Apps

54. Microsoft Azure Services
Azure™ Services Platform

55. Windows Azure Applications, Storage, and Roles
Three core components: Compute, Storage and Fabric n m
Web Role
Worker Role LB
Cloud Storage (blob, table, queue)
Source: Microsoft Presentation, A Lap Around Windows Azure, Manuvir Das

56. Amazon Cloud Amazon cloud components Elastic Compute Cloud (EC2)
Simple Storage Service (S3)
SimpleDB
New Features
Availability zones
Place applications in multiple locations for failovers
Elastic IP addresses
Static IP addresses that can be dynamically remapped to point to different instances (not a DNS change)

57. Amazon Cloud Users: New York Times and Nasdaq
Both companies used Amazon’s cloud offering
New York Times
Used EC2 and S3 to convert 15 million scanned news articles to PDF (4TB data)
Took 100 Linux computers 24 hours (would have taken months on NYT computers
“It was cheap experimentation, and the learning curve isn't steep.” – Derrick Gottfrid, Nasdaq
Nasdaq
Uses S3 to deliver historic stock and fund information
Millions of files showing price changes of entities over 10 minute segments
“The expenses of keeping all that data online [in Nasdaq servers] was too high.” – Claude Courbois, Nasdaq VP
Created lightweight Adobe AIR application to let users view data

59. Salesforce Cloud
Started with information management service that could replace traditional business software technology
Pioneered software-as-a-service market (esp. CRM tools)
5,000+ Public Sector and Nonprofit Customers use Salesforce Cloud Computing Solutions
Moving beyond SaaS into the platform-as-a-service market

60. Salesforce.com in Government
President Obama’s Citizen’s Briefing Book
134,077 Registered Users
1.4 M Votes
52,015 Ideas
Peak traffic of 149 hits per second
US Census Bureau Uses Salesforce.com Cloud Application
Project implemented in under 12 weeks
2,500+ partnership agents use Salesforce.com for 2010 decennial census
Allows projects to scale from 200 to 2,000 users overnight to meet peak periods with no capital expenditure

61. VMware Cloud (vCloud) Goal:
“Federate resources between internal IT and external clouds”
Application portability
Elasticity and scalability, disaster recovery, service level management
vServices provide APIs and technologies

62. Case Study: IBM-Google Cloud
Google and IBM plan to roll out a worldwide network of servers for a cloud computing infrastructure
Initiatives for universities
Architecture
Open source
Linux hosts
Xen virtualization (virtual machine monitor)
Apache Hadoop (file system)
“open-source software for reliable, scalable, distributed computing”

63. Facebook’s Use of Open Source and Commodity Hardware
400 million users + 250,000 new users per day
100,000 transactions per second, 10,000+ servers
Built on open source software
Web and App tier: Apache, PHP, AJAX
Middleware tier: Memcached (Open source caching)
Data tier: MySQL (Open source DB)
Thousands of DB instances store data in distributed fashion (avoids collisions of many users accessing the same DB)

64. Are Hybrid Clouds in our Future?
OpenNebula
Zimory
IBM-Juniper Partnership
VMWare Vcloud

65. Thank You
Blogote
