WTX 8.4.1.1 Release Contents Sunil Dandamudi – Architect, WebSphere Transformation Extender sdandamu@us.ibm.com.

Similar presentations


Presentation on theme: "WTX 8.4.1.1 Release Contents Sunil Dandamudi – Architect, WebSphere Transformation Extender sdandamu@us.ibm.com."— Presentation transcript:

1 WTX Release Contents Sunil Dandamudi – Architect, WebSphere Transformation Extender

2 Agenda Release Details Contents Q& A

3 Productivity - PARSE Syntax : = PARSE (TEXT BLOB)
A Parse function allows to parse and validate a data stream and associate the data structure with the a type structure on the LHS. Syntax : = PARSE (TEXT BLOB) Return a parsed and validated data structure

4 Productivity - PARSE Reduced complexity while dealing with data retrieved through External Functions (GET, RUN, DBQUERY) that needs to be parsed and mapped Improves performance where data objects are currently parsed multiple times in parent/run maps Supports Data Audit on type objects Trace is available as part of corresponding output card trace Map fails with Error Code 27 , Output Type contains Errors

5 Productivity - PARSE Usage Pattern = PARSE (TEXT BLOB)
= PARSE (TEXT BLOB) + RULE  Not Supported = RULE + PARSE (TEXT BLOB)  Not Supported

6 Productivity - PARSE Objects Populated with data
=PARSE(GET("SPE", "-DURL jdbc:derby://localhost:1527/spe2;user=derbyuser;password=derbyuser -DBDRIVER org.apache.derby.jdbc.ClientDriver -MAP parsewds -TRANSFORM -T", Input))

7 Productivity - ASFUNCTION
Introducing ASFUNCTION Function A “ASFUNCTION” function allows to behave a functional map as a function in map rule Syntax : = ASFUNCTION(Function map) Returns the data from the functional map as inline to the invoking map rule

8 Productivity - ASFUNCTION
Supported only when a functional map returns a Item Concept has been introduced in as a general functional map behavior, but backed out due to mapping disruptions to our customers Usage Patterns = RULE + ASFUNCTION () + RULE Reduces mapping complexity when dealing with data returned from a functional map to be used as part of a rule

9 Productivity - XVALIDATE
Enhanced XVALIDATE function to support XML snippets The XML document no longer need a Prolog to be validated through XVALIDATE functions

10 Native XML – XSDL Hints xsi:schemaLocation
Added Support for two new properties on Native XML output card xsi:schemaLocation xsi:noNamespaceSchemaLocation The values specified for these properties will appear in the root of the xml document Refer to XML Specification for more details on these properties

11 Productivity – TEST DATA
Introduced Test Data Generation in Type Designer Allows user to generate a test data for a specific group or item Allows users to save the test data artifacts for further customization based on the needs. Generate test data for first choice and the first partitioned group Allows users to generate test data for optional elements and adds default data rules for items

12 Productivity – TEST DATA
Select a group or item and use Generate Test Data context menu

13 Adapter – SPE The Standards Processing Engine (SPE) adapter connects WTX with Standards Processing Engine (SPE). System Requirement : The Standards Processing Engine (SPE) adapter function requires the installation of Standards Processing Engine and a solution Pack Standards Processing Engine (SPE) adapter commands fall into two categories: Data harness functions Adapter action commands.

14 Adapter – SPE Adapter Command Line for SPE connectivity User Name
DBURL Identifies the SPE database by either the database URL or the file URL of a configuration file that contains the database connection information. If you specify a configuration file, the SPE adapter uses only the database connection information in the configuration file. The adapter ignores any -DBDRIVER, -DBUSER, -DBPSWD, or -DBSCHEMA keywords on the adapter command line. The -DBURL keyword is required DBUSER User Name DBPSWD User Passoword DBDRIVER Driver Name DBSCHEMA Specifies the name of the SPE database schema.

15 Adapter – SPE Adapter Command Line options for SPE Map
Specifies the name of the map in the SPE database or, for WebSphere Transformation Extender maps only, the file URL of the map on the local file system. The -MAP keyword is required for TRANSFORM command DOCID Specifies the document ID of the document in memory that overrides the first input card of the map KEEP Retains the documents that are returned in the SPE response by storing the documents ALLDOCS Specifies that SPE is to return all documents in the XML response file, including type=INTERMEDIATE documents BATCH Specifies the document ID of a single document to de-envelope

16 Adapter – SPE Adapter Command Line options for SPE SENDER
Specifies the document sender that is used to locate the envelope information in the SPE database. RECEIVER Specifies the document receiver that is used to locate the envelope information in the SPE database ALIAS Specifies the acceptor look-up alias to locate the envelope information in the SPE database.

17 Adapter – SPE Data harness functions read and write to the underlying SPE database through a data harness, and are valid only when a map is running under SPE. GetBinaryDocument Retrieves the specified binary document. This command is valid in a GET function. getEnvelope Retrieves the specified field from an envelope. This command is valid in a GET function.

18 Adapter – SPE setCorrelation
Updates the Standards Processing Engine correlation table with the specified name/value pair for the document. getProcessData Retrieves process data from the XML document object model (DOM) specified by the XPath setProcessData Stores process data from the current field into the XML DOM that is

19 Adapter – SPE getCodeListItemBySenderCode
Retrieves a trading-partner code-list entry from SPE by sender code. getCodeListItemByReceiverCode Retrieves process data from the XML document object model (DOM) specified by the XPath getTransactionRegister Compares the fields that you loaded into the Transaction Register with the input data, returns a code, and clears the Transaction Register

20 Adapter – SPE setTransactionRegister
Gets a delimiter from an SPE document envelope. This command is valid in a GET function.. validateCodeWords Validates a series of code words defined by a delimited string

21 Adapter – SPE Adapter action commands are valid in maps that are running on WTX Launcher, Command Server, or the TX Programming Interface ADOC The -ADOC command adds one or more files on the file system as a document in memory and returns the document ID to the map GDOC The -GDOC command returns data from a document in memory or file system based on the document ID

22 Adapter – SPE ADOC The -ADOC command adds one or more files on the file system as a document in memory and returns the document ID to the map UDOC The -UDOC command replaces an existing document in memory with a new one and returns the new document ID. RDOC The -RDOC command removes one or more documents from memory. By default, documents are removed from memory when map processing completes.

23 Adapter – SPE TRANSFORM
The -TRANSFORM (-TFM) command runs a map on the Standards Processing Engine (SPE) and returns a response from SPE in XML format. The -TRANSFORM command can run a WebSphere Transformation Extender map, a Sterling B2B Integrator map, or an XSLT map. De-Envelope The -DEENVELOPE (-DENV) command de-envelopes a document as specified in the Standards Processing Engine (SPE) database and returns a response from SPE in XML format

24 Adapter – SPE Envelope The -ENVELOPE (-ENV) command envelopes a document as specified in the Standards Processing Engine (SPE) database and returns a response from SPE in XML format

25 Adapter – SPE The Adapter commands returns a XML response file contains the document IDs of the enveloped documents. The metadata schema of the XML response is defined by the wtx_install_dir\Response.xsd file. Users needs to map the Response file to a Output card and use the SPE adapter to process the data WTX SPE Adapter documentation has a details lay out of the functions and their parameters

26 Adapter – SPE (Response Message)
Status Status Message returned by SPE Advanced Status Advanced Status message returned by SPE Report Return Translation Report from SPE Process Parameters process parameters - similar to Process Data name/value data Version Version number of the Response Schema Transform Correlation Gets the correlation object instances associated with transformations for a specific objectID Documents SPE Documents are returned as DOC ID to the map Correlations A list containing the correlations returned by SPE

27 Adapter – SPE (DE-Envelope)
Add Card (Response Schema as Root) Invoke SPE Adapter (Card Adapter, GET) Wrap GET with PARSE Based on Response Status, Retrieve each document by using SPE adapter with GDOC command. The Document IDs are part of the Response object on the card

28 Adapter – SPE (Transform)
Add Card (Response Schema as Root) Invoke SPE Adapter (Card Adapter, GET) Wrap GET with PARSE Based on Response Status, Retrieve the document by using SPE adapter with GDOC command. The Document ID is part of the Response object on the card Note : WTX map overrides first input card and last output card as part of Transform

29 Adapter – SPE (Envelope)
Add Card (Response Schema as Root) Invoke SPE Adapter (Card Adapter, GET) Wrap GET with PARSE Based on Response Status, Retrieve each document by using SPE adapter with GDOC command. The Document IDs are part of the Response object on the card

30 Adapter – SPE Snapshot =PARSE(GET("SPE", "-DURL jdbc:derby://localhost:1527/spe2;user=derbyuser;password=derbyuser -DBDRIVER org.apache.derby.jdbc.ClientDriver -MAP parsewds -TRANSFORM -T", Input))

31 SPE – Design Studio Enhanced Design Studio to integrate with Standards Processing Engine XSLT, Sterling and WTX map can be checked in to SPE Database XSLT, Sterling and WTX map can be tested on SPE Engine Allows to configure multiple databases to test SPE on. This simplifies on-boarding multiple SPE environments (Test, Development and Production) with ease New Category

32 SPE – Design Studio (Preferences)
SPE added to Design Studio Preferences Available only when SPE is installed Available with WTX Design Studio Allows to configure database settings, Deployment , Test and Logging Options New Preference for SPE

33 SPE – Design Studio (Preferences - Connectivity)
Allows to Define SPE Database Connectivity information Multiple Database connections can be setup for each user environment

34 SPE – Design Studio (Preferences)
Deploy Default comments for check-ins Unique Reference Identifier Test Default Input/Output files generated for SI and XSLT WTX Resource Registry Configuration Logging Session Logs Log Levels

35 SPE – Design Studio Allows to Check-in XSLT Sterling WTX
Allow to Test maps inline on SPE engine

36 Interoperability – RUN MAPS CACHE
Run Map can be cached while running maps through WTXAP (WTX for Application Programming) and WTXIS (WTX for Integration Servers) Edit dtx.ini and specify the maximum number of run map to be cached. ;use the following to define the max number of RUN maps to be cached in the memory ;default value is 300, minimum value is 10 ;set this value to -1 to disable RUN map caching RunMapCacheMaxNum=300

37 Interoperability – DYNAMIC MAP CACHE (WMB/ IIB)
The WMB/IIB Local Environment (LE.WTX.DynamicMapName) is used with LE.WTX.DynamicMap and cacheMap switch. If cacheMap is set on a DynamicMap, and there is a DynamicMapName, caching will be honored DynamicMapName is limited to 32 characters.

38 Interoperability – DYNAMIC MAP CACHE (WMB/ IIB)
When using LE.WTX.Dynamic Map, the default map location will be: MQSI_WORKPATH/common/log/WTX/<ExeGrpName>/<FlowName>/<WTXMapNodeName>/<MapName> If cacheMap switch is on a DynamicMap, and there is no DynamicMapName , behavior is as prior - it will not cache the map. eg : SET OutputLocalEnvironment.WTX.DynamicMapName = 'PreProcessEDI' Any RUN maps required by the LE.WTX.DynamicMap, will be relative to the default map location.

39 Interoperability – DYNAMIC MAP CACHE (WMB/ IIB)
Once a DynamicMap with a DynamicMapName is run with cacheMap, the DynamicMap does not have to be retrieved from a repository on an upstream node for subsequent invocations, although, the DynamicMap LE must still be passed in (at least one "bogus" byte) along with the DynamicMapName that was previously used. SET OutputLocalEnvironment.WTX.DynamicMap = X'00';

40 Interoperability – Product Support
WMB /IIB Sterling Integrator Business Processor Advanced 8.5 IBM Integration Designer 8.5 IBM DB2 10.5 IBM Pure Systems V1.1 FP1/FP2 -- Pending Certification Smart Cloud Orchestrator v2.3 (SCO) – Pending Certification

41 Security – NIST COMPLIANCE
TLS V1.2 Protocol and NIST Compliance The advanced TLS V1.2 protocol and NIST compliance security mode are now supported by the HTTP and FTP Adapters as well as the Launcher Agent Introducing GSKIT security module that provides this higher level of SSL/TLS security, but will only be activated once the accompanying IBM GSKit product is installed and configured. If the IBM GSKit is not installed and configured on the library path of your platform, the legacy TLS/SSL module, will continue to be used.

42 Security – NIST COMPLIANCE
The IBM GSKit installation modules are provided in the "GSKit" sub-directory location of the WTX installation The IBM GSKit also provides X.509 certificate generation capabilities. An example is also available that will guide you along the installation and setup steps that are required to ensure that existing and new maps can be seamlessly run with greater levels of SSL/TLS-based security

43 Transformation & Standards Packs
New GA pack products… IBM Standards Processing Engine Pack for Healthcare Payer IBM Standards Processing Engine Pack for Supply Chain EDI Updated pack products … Healthcare WTX Pack for HIPAA EDI and WTX Pack for HL and WTX Pack for NCPDP and Supply Chain EDI WTX Pack for EDI (Pack for ASC X12, Pack for EDIFACT, Pack for TRADACOMS) WTX Trading Manager WTX Pack SAP R Financial Services and Insurance WTX Pack for SWIFT 4.3.2 WTX Pack for SEPA 4.3.2 WTX Pack for FIX 4.2.6 WTX Pack for ACORD Insurance Sterling Integrator SWIFT/NACHA

44 IBM SPE Pack for Healthcare Payer
New Content… All Functionality in the WTX Pack for HIPAA EDI …PLUS WEDI/SNIP Type 5 External Code Set Validation Choice of supplied Code Sets or Pattern Match enablement for commonly applied validations Partner/Message Type configuration WEDI/SNIP Levels 1-5 selections Claim Specific processing options Acknowledgement Reporting selections Partner/Message Type specific processing enablement Deenvelope (Debulk) Processing Transformation Designation (using WTX, SI Mapper or XSLT) Envelope (Bulk) Processing Partner/Message Type specific acknowledgments Control Number Schemes Syntax Overrides

45 IBM SPE Pack for Supply Chain EDI
New Content… Partner/Message Type configuration Acknowledgement Reporting selections Partner/Message Type specific processing enablement Deenvelope (Debulk) Processing Transformation Designation (Using WTX, SI Mapper or XSLT) Envelope (Bulk) Processing Partner/Message Type specific acknowledgments Control Number Schemes Syntax Overrides

46 WTX Pack for ACORD Insurance 1.0.3
New Content… ACORD DTCC Example DTCC Data Structures for parsing and transformation DTCC to/from ACORD XML TXLife format Updated Content… Updated ACORD PCS Version Support Updated ACORD TXLife Version Support Updated ACORD RLC Version Support

47 WTX Pack for HIPAA EDI 4.4.1.1 WTX Pack for HIPAA EDI 4.4.1.2
New Content… Full Health Insurance Exchange (HIX) Payment 820 support – X306 Example HIX 834 Enrollment support X220A1 Example parsing, and transformation using the CMS FFE WTX Pack for HIPAA EDI New Content… Full ASC X12 PACDR Support Professional Claim Post Adjudication Reporting – X298 Institutional Claim Post Adjudication Reporting – X299 Dental Claim Post Adjudication Reporting – X300 Example HIX 834 Enrollment support X220A1 Example parsing, and transformation using the CMS FFE Updated Content… Extension of Configurable Rules module Support Rule Driven WEDI/SNIP type 2 rules Continued support of WEDI/SNIP type 3 and 4 configuration

48

49
