1. Microfluidic Biochips: Design, Programming, and Optimization Bill Thies Joint work with Vaishnavi Ananthanarayanan, J.P. Urbanski, Nada Amin, David Craig, Jeremy Gunawardena, Todd Thorsen, and Saman Amarasinghe Indian Statistical Institute March 2, 2011

2. Microfluidic Chips Idea: a whole biology lab on a single chip
Input/output
Sensors: pH, glucose, temperature, etc.
Actuators: mixing, PCR, electrophoresis, cell lysis, etc.
Benefits:
Small sample volumes
High throughput
Geometrical manipulation
Portability
Applications:
Biochemistry Cell biology
Biological computing
1 mm
10x real-time

3. Application to Rural Diagnostics
Disposable
Enteric Card
PATH, Washington U. Micronics, Inc.,
U. Washington
Targets:
- E. coli, Shigella,
Salmonella, C. jejuni
DxBox
U. Washington, Micronics, Inc.,
Nanogen, Inc.
Targets:
- malaria (done)
- dengue, influenza, Rickettsial diseases,
typhoid, measles (under development)
CARD
Rheonix, Inc.
Targets:
- HPV diagnosis
- Detection of specific gene sequences

4. Moore’s Law of Microfluidics: Valve Density Doubles Every 4 Months
Source: Fluidigm Corporation (

5. Moore’s Law of Microfluidics: Valve Density Doubles Every 4 Months
Source: Fluidigm Corporation (

6. Current Practice: Manage Gate-Level Details from Design to Operation
For every change in the experiment or the chip design:
fabricate
chip
1. Manually draw in AutoCAD
2. Operate each gate from LabView

7. Abstraction Layers for Microfluidics
Silicon Analog
Protocol Description Language
- architecture-independent protocol description C
Fluidic Instruction Set Architecture (ISA)
- primitives for I/O, storage, transport, mixing
x86
Pentium III, Pentium IV
chip 1
chip 2
chip 3
Fluidic Hardware Primitives
- valves, multiplexers, mixers, latches
transistors, registers, …

8. Abstraction Layers for Microfluidics
Contributions
Protocol Description Language
- architecture-independent protocol description
BioCoder Language
[J.Bio.Eng. 2010]
Optimized Compilation
[Natural Computing 2007]
Fluidic Instruction Set Architecture (ISA)
- primitives for I/O, storage, transport, mixing
Demonstrate Portability
[DNA 2006]
Micado AutoCAD Plugin
[MIT 2008, ICCD 2009]
chip 1
chip 2
chip 3
Digital Sample Control Using Soft Lithography
[Lab on a Chip ‘06]
Fluidic Hardware Primitives
- valves, multiplexers, mixers, latches

9. Droplets vs. Continuous Flow
Digital manipulation of droplets on an electrode array [Chakrabarty, Fair, Gascoyne, Kim, …]
Pro:
Reconfigurable routing
Electrical control
More traction in CAD community
Source: Chakrabarty et al, Duke University
Continuous flow of fluids (or droplets) through fixed channels [Whitesides, Quake, Thorsen, …]
Pro:
Smaller, more precise sample sizes
Made-to-order availability [Stanford]
More traction in biology community

10. Primitive 1: A Valve (Quake et al.)
Control Layer
0. Start with mask of channels
Flow Layer

11. Primitive 1: A Valve (Quake et al.)
Control Layer
1. Deposit pattern on silicon wafer
Flow Layer

12. Primitive 1: A Valve (Quake et al.)
Control Layer
2. Pour PDMS over mold
- polydimexylsiloxane: “soft lithography”
Thick layer (poured)
Thin layer (spin-coated)
Flow Layer

13. Primitive 1: A Valve (Quake et al.)
Control Layer
3. Bake at 80° C (primary cure), then release PDMS from mold
Flow Layer

14. Primitive 1: A Valve (Quake et al.)
Control Layer
4a. Punch hole in control channel 4b. Attach flow layer to glass slide
Flow Layer

15. Primitive 1: A Valve (Quake et al.)
Control Layer
5. Align flow layer over control layer
Flow Layer

16. Primitive 1: A Valve (Quake et al.)
Control Layer
6. Bake at 80° C (secondary cure)
Flow Layer

17. Primitive 1: A Valve (Quake et al.)
7. When pressure is high, control channel pinches flow channel to form a valve
Control Layer
pressure actuator
Note that this can be done in university facilities in about two days, with marginal cost of less than a dollar.
Flow Layer

18. Primitive 2: A Multiplexer (Thorsen et al.)
Bit 2
Bit 1
Bit 0
flow layer
control layer 1 1 1
Control lines can cross flow lines
- Only thick parts make valves
Output 7
Output 6
Output 5
Input
Output 4
Logic is not
complimentary
To control n flow lines,
need 2 log2 n control lines
Output 3
Output 2
Output 1
Output 0

19. Primitive 2: A Multiplexer (Thorsen et al.)
Bit 2
Bit 1
Bit 0
flow layer
control layer 1 1 1
Control lines can cross flow lines
- Only thick parts make valves
Output 7
Output 6
Output 5
Input
Output 4
Logic is not
complimentary
To control n flow lines,
need 2 log2 n control lines
Output 3
Output 2
Output 1
Output 0
Example: select 3 = 011

20. Primitive 2: A Multiplexer (Thorsen et al.)
Bit 2
Bit 1
Bit 0
flow layer
control layer 1 1 1
Control lines can cross flow lines
- Only thick parts make valves
Output 7
Output 6
Output 5
Input
Output 4
Logic is not
complimentary
To control n flow lines,
need 2 log2 n control lines
Output 3
Output 2
Output 1
Output 0
Example: select 3 = 011

21. Primitive 2: A Multiplexer (Thorsen et al.)
Bit 2
Bit 1
Bit 0
flow layer
control layer 1 1 1
Control lines can cross flow lines
- Only thick parts make valves
Output 7
Output 6
Output 5
Input
Output 4
Logic is not
complimentary
To control n flow lines,
need 2 log2 n control lines
Output 3
Output 2
Output 1
Output 0
Example: select 3 = 011

22. Primitive 3: A Mixer (Quake et al.)
1. Load sample on bottom
2. Load sample on top
3. Peristaltic pumping
Rotary Mixing

23. Primitive 4: A Latch (Our contribution)
Purpose: align sample with specific location on device
Examples: end of storage cell, end of mixer, middle of sensor
Latches are implemented as a partially closed valve
Background flow passes freely
Aqueous samples are caught
Sample
Latch

24. Primitive 4: A Latch (Our contribution)
Purpose: align sample with specific location on device
Examples: end of storage cell, end of mixer, middle of sensor
Latches are implemented as a partially closed valve
Background flow passes freely
Aqueous samples are caught
Sample
Latch

25. Primitive 5: Cell Trap
Several methods for confining cells in microfluidic chips
U-shaped weirs - C-shaped rings / microseives
Holographic optical traps - Dialectrophoresis
In our chips: U-Shaped Microseives in PDMS Chambers
Source: Wang, Kim, Marquez, and Thorsen, Lab on a Chip 2007

26. Primitive 6: Imaging and Detection
As PDMS chips are translucent, contents can be imaged directly
Fluorescence, color, opacity, etc.
Feedback can be used to drive the experiment

27. Abstraction Layers for Microfluidics
Protocol Description Language
- architecture-independent protocol description
Fluidic Instruction Set Architecture (ISA)
- primitives for I/O, storage, transport, mixing
chip 1
chip 2
chip 3
Fluidic Hardware Primitives
- valves, multiplexers, mixers, latches

28. Driving Applications
1. What are the best indicators for oocyte viability?
With Mark Johnson’s and Todd Thorsen’s groups
During in-vitro fertilization, monitor cell metabolites and select healthiest embryo for implantation
2. How do mammalian signal transduction pathways respond to complex inputs?
With Jeremy Gunawardena’s and Todd Thorsen’s groups
Isolate cells and stimulate with square wave, sine wave, etc.
New part of first – mention cell traps
New part of second – mention sensing

29. Video courtesy David Craig
Driving Applications
1. What are the best indicators for oocyte viability?
With Mark Johnson’s and Todd Thorsen’s groups
During in-vitro fertilization, monitor cell metabolites and select healthiest embryo for implantation
2. How do mammalian signal transduction pathways respond to complex inputs?
With Jeremy Gunawardena’s and Todd Thorsen’s groups
Isolate cells and stimulate with square wave, sine wave, etc.
New part of first – mention cell traps
New part of second – mention sensing
Video courtesy David Craig

30. CAD Tools for Microfluidic Chips
Goal: automate placement, routing, control of microfluidic features
Why is this different than electronic CAD?
Different medium, different set of design rules, qualitative difference between flow layer and control layer
Rapid design cycle

31. CAD Tools for Microfluidic Chips
Goal: automate placement, routing, control of microfluidic features
Why is this different than electronic CAD? Control ports (I/O pins) are bottleneck to scalability
Pressurized control signals cannot yet be generated on-chip
Thus, each logical set of valves requires its own I/O port
2. Control signals correlated due to continuous flows
 Demand & opportunity for minimizing control logic
Different medium, different set of design rules, qualitative difference between flow layer and control layer
Rapid design cycle
pipelined flow
continuous flow

32. Our Technique: Automatic Generation of Control Layer

33. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA

34. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA

35. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA

36. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves

37. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves

38. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves 3. Infer control sharing

39. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves 3. Infer control sharing

40. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves 3. Infer control sharing 4. Route valves to control ports

41. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves 3. Infer control sharing 4. Route valves to control ports

42. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves 3. Infer control sharing 4. Route valves to control ports

43. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves 3. Infer control sharing 4. Route valves to control ports 5. Generate an interactive GUI

44. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves 3. Infer control sharing 4. Route valves to control ports 5. Generate an interactive GUI

45. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves 3. Infer control sharing 4. Route valves to control ports 5. Generate an interactive GUI

46. Our Technique: Automatic Generation of Control Layer
1. Describe Fluidic ISA 2. Infer control valves 3. Infer control sharing 4. Route valves to control ports 5. Generate an interactive GUI

47. 1. Describe a Fluidic ISA Sequential flow P1  P2
Hierarchical and composable flow declarations
Sequential flow P1  P2
AND-flow F1 Λ F2
OR-flow F1 \/ F2
Mixing mix(F)
Pumped flow pump(F)
P1 P2 F1 F2 F1 F1 or F2 F2 F F

48. 1. Describe a Fluidic ISA

49. 1. Describe a Fluidic ISA mix-and-store (S1, S2, D) {
1. in1  top  out
2. in2  bot  out
3. mix(top  bot-left  bot-right  top)
4. wash  bot-right  top  bot-left  store }
50x real-time

50. 2. Infer Control Valves

51. 2. Infer Control Valves

52. 2. Infer Control Valves

53. 3. Infer Control Sharing

54. 3. Infer Control Sharing

55. 3. Infer Control Sharing

56. 3. Infer Control Sharing

57. 3. Infer Control Sharing

58. 3. Infer Control Sharing

59. 3. Infer Control Sharing

60. 3. Infer Control Sharing

61. 3. Infer Control Sharing

62. 3. Infer Control Sharing Column Compatibility Problem - NP-hard
- Reducible to graph coloring

63. 3. Infer Control Sharing Column Compatibility Problem - NP-hard
- Reducible to graph coloring

64. 3. Infer Control Sharing Column Compatibility Problem - NP-hard
- Reducible to graph coloring

65. 3. Infer Control Sharing Column Compatibility Problem - NP-hard
- Reducible to graph coloring

66. 3. Infer Control Sharing Column Compatibility Problem - NP-hard
- Reducible to graph coloring

67. 4. Route Valves to Control Ports
Build on recent algorithm for simultaneous pin
assignment & routing
[Xiang et al., 2001]
Idea: min cost - max flow
from valves to ports
Our contribution: extend algorithm to allow sharing
– Previous capacity constraint on each edge:
– Modified capacity constraint on each edge:
Solve with linear programming, allowing sharing where beneficial
f1 + f2 + f3 + f4 + f5 + f6 ≤ 1
max(f1, f4) + max(f2 , f3) + f5 + f6 ≤ 1

68. 4. Route Valves to Control Ports
Build on recent algorithm for simultaneous pin
assignment & routing
[Xiang et al., 2001]
Idea: min cost - max flow
from valves to ports
Our contribution: extend algorithm to allow sharing
– Previous capacity constraint on each edge:
– Modified capacity constraint on each edge:
Solve with linear programming, allowing sharing where beneficial
f1 + f2 + f3 + f4 + f5 + f6 ≤ 1
max(f1, f4) + max(f2 , f3) + f5 + f6 ≤ 1

69. Micado: An AutoCAD Plugin
Implements ISA, control inference, routing, GUI export
Using slightly older algorithms than presented here [Amin ‘08]
Parameterized design rules
Incremental construction of chips
Realistic use by at least 3 microfluidic researchers
Freely available at:

70. Cell Culture with Waveform Generator
Courtesy David Craig

71. Cell Culture with Waveform Generator
Courtesy David Craig

72. Embryonic Cell Culture
Courtesy J.P. Urbanski

73. Embryonic Cell Culture
Courtesy J.P. Urbanski

74. Metabolite Detector
Courtesy J.P. Urbanski

75. Metabolite Detector
Courtesy J.P. Urbanski

76. Open Problems Automate the design of the flow layer
Hardware description language for microfluidics
Define parameterized and reusable modules
Replicate and pack a primitive as densely as possible
How many cell cultures can you fit on a chip?
Support additional primitives and functionality
Metering volumes
Sieve valves
Alternate mixers
Separation primitives …

77. Conclusions: Microfludics CAD
Microfluidics represents a rich new playground for CAD researchers
Two immediate goals:
Enable designs to scale
Enable non-experts to design own chips
Micado is a first step towards these goals
Hierarchical ISA for microfluidics
Inference and minimization of control logic
Routing shared channels to control ports
Generation of an interactive GUI
Say at end: we have end-to-end system working
Courtesy J.P. Urbanski

78. Abstraction Layers for Microfluidics
Protocol Description Language
- architecture-independent protocol description
Fluidic Instruction Set Architecture (ISA)
- primitives for I/O, storage, transport, mixing
chip 1
chip 2
chip 3
Fluidic Hardware Primitives
- valves, multiplexers, mixers, latches

79. Toward “General Purpose” Microfluidic Chips

80. A Digital Architecture
Recent techniques can control independent samples
Droplet-based samples
Continuous-flow samples
Microfluidic latches
In abstract machine, all samples have unit volume
Input/output a sample
Store a sample
Operate on a sample
Challenge for a digital architecture: fluid loss
No chip is perfect – will lose some volume over time
Causes: imprecise valves, adhesion to channels, evaporation, ...
How to maintain digital abstraction?
[Fair et al.]
[Our contribution]
[Our contribution]
Microfluidics different in that basically analog
- fluids can flow anywhere, mix together, etc.
Cells may be permanently stored in fluidic storage

81. Maintaining a Digital Abstraction
Krishna Palem, moving it up the hierarchy by having randomized gates

82. Maintaining a Digital Abstraction
Electronics
Microfluidics
Soft error Handling?
High-Level
Language
Expose loss in language
- User deals with it ? ? ?
Randomized
Gates [Palem]
Instruction Set Architecture (ISA)
Expose loss in ISA - Compiler deals with it
Krishna Palem, moving it up the hierarchy by having randomized gates ? ? ?
Replenish fluids?
- Maybe (e.g., with water)
- But may affect chemistry
Replenish charge (GAIN)
Hardware
Loss of charge
Loss of fluids

83. Towards a Fluidic ISA
Microfluidic chips have various mixing technologies
Electrokinetic mixing
Droplet mixing
Rotary mixing
Common attributes:
Ability to mix two samples in equal proportions, store result
Fluidic ISA: mix (int src1, int src2, int dst)
Ex: mix(1, 2, 3)
To allow for lossy transport, only 1 unit of mixture retained
[Levitan et al.]
[Fair et al.]
[Quake et al.]
Storage Cells 1 2 3 4
Mixer

84. Implementation: Oil-Driven Chip
Inputs
Storage Cells
Background Phase
Wash Phase
Mixing
Chip 1 2 8
Oil —
Rotary

85. Implementation: Oil-Driven Chip
mix (S1, S2, D) {
1. Load S1
2. Load S2
3. Rotary mixing
4. Store into D }
50x real-time
Inputs
Storage Cells
Background Phase
Wash Phase
Mixing
Chip 1 2 8
Oil —
Rotary

86. Implementation 2: Air-Driven Chip
Inputs
Storage Cells
Background Phase
Wash Phase
Mixing
Chip 1 2 8
Oil —
Rotary
Chip 2 4 32
Air
Water
In channels

87. Implementation 2: Air-Driven Chip
mix (S1, S2, D) {
1. Load S1
2. Load S2
3. Mix / Store into D
4. Wash S1
5. Wash S2 }
50x real-time
Inputs
Storage Cells
Background Phase
Wash Phase
Mixing
Chip 1 2 8
Oil —
Rotary
Chip 2 4 32
Air
Water
In channels

88. “Write Once, Run Anywhere”
Example: Gradient generation
Hidden from programmer:
Location of fluids
Details of mixing, I/O
Logic of valve control
Timing of chip operations
Fluid yellow = input (0);
Fluid blue = input(1);
for (int i=0; i<=4; i++) {
mix(yellow, 1-i/4, blue, i/4); }
Will use as running example throughout the talk
Decreasing amounts of yellow, increasing amounts of blue
450 Valve Operations

89. “Write Once, Run Anywhere”
Example: Gradient generation
Hidden from programmer:
Location of fluids
Details of mixing, I/O
Logic of valve control
Timing of chip operations
Fluid yellow = input (0);
Fluid blue = input(1);
for (int i=0; i<=4; i++) {
mix(yellow, 1-i/4, blue, i/4); }
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
450 Valve Operations

90. “Write Once, Run Anywhere”
Example: Gradient generation
Hidden from programmer:
Location of fluids
Details of mixing, I/O
Logic of valve control
Timing of chip operations
Fluid yellow = input (0);
Fluid blue = input(1);
for (int i=0; i<=4; i++) {
mix(yellow, 1-i/4, blue, i/4); }
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
450 Valve Operations

91. “Write Once, Run Anywhere”
Example: Gradient generation
Hidden from programmer:
Location of fluids
Details of mixing, I/O
Logic of valve control
Timing of chip operations
Fluid yellow = input (0);
Fluid blue = input(1);
for (int i=0; i<=4; i++) {
mix(yellow, 1-i/4, blue, i/4); }
450 Valve Operations
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(4, LOW); setValve(5, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);

92. “Write Once, Run Anywhere”
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
Direct Control valve actuations - only works on 1 chip

93. Gradient Generation in Fluidic ISA
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
setValve(0, HIGH); setValve(1, HIGH);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, LOW);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, LOW); setValve(11, HIGH);
setValve(12, LOW); setValve(13, HIGH);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, LOW); setValve(17, LOW);
setValve(18, LOW); setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
wait(2000);
setValve(14, HIGH); setValve(2, LOW);
wait(1000);
setValve(4, HIGH); setValve(12, LOW);
setValve(16, HIGH); setValve(18, HIGH);
setValve(19, LOW);
setValve(0, LOW); setValve(1, LOW);
setValve(2, LOW); setValve(3, HIGH);
setValve(4, LOW); setValve(5, HIGH);
setValve(6, HIGH); setValve(7, LOW);
setValve(8, LOW); setValve(9, HIGH);
setValve(10, HIGH); setValve(11, LOW);
setValve(12, LOW); setValve(13, LOW);
setValve(14, LOW); setValve(15, HIGH);
setValve(16, HIGH); setValve(17, LOW);
setValve(18, HIGH); setValve(19, LOW);
input(0, 0);
input(1, 1);
input(0, 2);
mix(1, 2, 3);
mix(2, 3, 1);
input(1, 3);
input(0, 4);
mix(3, 4, 2);
mix(3, 4, 5);
input(1, 4);
mix(4, 5, 3);
mix(0, 4);
abstraction
Direct Control valve actuations - only works on 1 chip
Fluidic ISA - 15 instructions - portable across chips

94. Gradient Generation in Fluidic ISA
input(0, 0);
input(1, 1);
input(0, 2);
mix(1, 2, 3);
mix(2, 3, 1);
input(1, 3);
input(0, 4);
mix(3, 4, 2);
mix(3, 4, 5);
input(1, 4);
mix(4, 5, 3);
mix(0, 4);

95. Abstraction 1: Managing Fluidic Storage
Fluid[] out = new Fluid[8];
Fluid yellow, blue, green;
out[0] = input(0);
yellow = input(0);
blue = input(1);
green = mix(yellow, blue);
out[1] = mix(yellow, green);
out[2] = mix(yellow, blue);
out[3] = mix(blue, green);
out[4] = input(1);
input(0, 0);
input(1, 1);
input(0, 2);
mix(1, 2, 3);
mix(2, 3, 1);
input(1, 3);
input(0, 4);
mix(3, 4, 2);
mix(3, 4, 5);
input(1, 4);
mix(4, 5, 3);
mix(0, 4);
Fluidic
ISA
1. Storage
Management
Programmer uses location-independent Fluid variables
Runtime system assigns & tracks location of each Fluid
Comparable to automatic memory management (e.g., Java)

96. Fluid[] out = new Fluid[8];
Fluid yellow, blue, green;
out[0] = input(0);
yellow = input(0);
blue = input(1);
green = mix(yellow, blue);
out[1] = mix(yellow, green);
out[2] = mix(yellow, blue);
out[3] = mix(blue, green);
out[4] = input(1);

97. Abstraction 2: Fluid Re-Generation
Fluid[] out = new Fluid[8];
Fluid yellow, blue, green;
out[0] = input(0);
yellow = input(0);
blue = input(1);
green = mix(yellow, blue);
out[1] = mix(yellow, green);
out[2] = mix(yellow, blue);
out[3] = mix(blue, green);
out[4] = input(1);
Fluid[] out = new Fluid[8]; Fluid yellow = input(0); Fluid blue = input(1); Fluid green = mix(yellow, blue);
out[0] = yellow;
out[1] = mix(yellow, green);
out[2] = green;
out[3] = mix(blue, green);
out[4] = blue;
2. Fluid Re-Generation
Programmer may use a Fluid variable multiple times
Each time, a physical Fluid is consumed on-chip
Runtime system re-generates Fluids from computation history

98. Fluid[] out = new Fluid[8]; Fluid yellow = input(0); Fluid blue = input(1); Fluid green = mix(yellow, blue);
out[0] = yellow;
out[1] = mix(yellow, green);
out[2] = green;
out[3] = mix(blue, green);
out[4] = blue;
2. Fluid Re-Generation

99. Abstraction 3: Arbitrary Mixing
Fluid[] out = new Fluid[8]; Fluid yellow = input (0); Fluid blue = input (1);
out[0] = yellow;
out[1] = mix(yellow, 3/4, blue, 1/4);
out[2] = mix(yellow, 1/2, blue, 1/2);
out[3] = mix(yellow, 1/4, blue, 3/4);
out[4] = blue;
3. Arbitrary Mixing
Fluid[] out = new Fluid[8]; Fluid yellow = input(0); Fluid blue = input(1); Fluid green = mix(yellow, blue);
out[1] = mix(yellow, green);
out[2] = green;
out[3] = mix(blue, green);
2. Fluid Re-Generation
Allows mixing fluids in any proportion, not just 50/50
Fluid mix (Fluid F1, float p1, Fluid f2, float F2)
 Returns Fluid that is p1 parts F1 and p2 parts F2
Runtime system translates to 50/50 mixes in Fluidic ISA
Note: some mixtures only reachable within error tolerance 

100. Abstraction 3: Arbitrary Mixing
Fluid[] out = new Fluid[8]; Fluid yellow = input (0); Fluid blue = input (1);
out[0] = yellow;
out[1] = mix(yellow, 3/4, blue, 1/4);
out[2] = mix(yellow, 1/2, blue, 1/2);
out[3] = mix(yellow, 1/4, blue, 3/4);
out[4] = blue;
3. Arbitrary Mixing
Fluid[] out = new Fluid[8]; Fluid yellow = input(0); Fluid blue = input(1); Fluid green = mix(yellow, blue);
out[1] = mix(yellow, green);
out[2] = green;
out[3] = mix(blue, green);
2. Fluid Re-Generation
Allows mixing fluids in any proportion, not just 50/50
Fluid mix (Fluid F1, float p1, Fluid f2, float F2)
 Returns Fluid that is p1 parts F1 and p2 parts F2
Runtime system translates to 50/50 mixes in Fluidic ISA
Note: some mixtures only reachable within error tolerance 

101. Abstraction 3: Arbitrary Mixing
Fluid[] out = new Fluid[8]; Fluid yellow = input (0); Fluid blue = input (1);
out[0] = yellow;
out[1] = mix(yellow, 3/4, blue, 1/4);
out[2] = mix(yellow, 1/2, blue, 1/2);
out[3] = mix(yellow, 1/4, blue, 3/4);
out[4] = blue;
Fluid[] out = new Fluid[8]; Fluid yellow = input (0); Fluid blue = input (1);
for (int i=0; i<=4; i++) {
out[i] = mix(yellow, 1-i/4, blue, i/4); }
3. Arbitrary Mixing
4. Parameterized Mixing
“on the left, exactly mirrors underlying hardware”
“on the right, added parameters to mix instruction”
Allows mixing fluids in any proportion, not just 50/50
Fluid mix (Fluid F1, float p1, Fluid f2, float F2)
 Returns Fluid that is p1 parts F1 and p2 parts F2
Runtime system translates to 50/50 mixes in Fluidic ISA
Note: some mixtures only reachable within error tolerance 

102. Algorithms for Efficient Mixing
Mixing is fundamental operation of microfluidics
Prepare samples for analysis
Dilute concentrated substances
Control reagant volumes
How to synthesize complex mixture using simple steps?
Many systems support only 50/50 mixers
Should minimize number of mixes, reagent usage
Note: some mixtures only reachable within error tolerance  N
Analogous to ALU operations on microprocessors
Note: important to mix on-chip
Otherwise reagants leave system whenever mix needed
Enables large, self-directing experiments
Interesting scheduling and optimization problem

103. Why Not Binary Search?
3/8 1
1/2
1/4
1/2
3/8
5 inputs, 4 mixes

104. Why Not Binary Search? 3/8 1 1/2 3/4 3/8 4 inputs, 3 mixes 1/2 1/4 1/2
3/8 1
1/2
3/4
3/8
4 inputs, 3 mixes
1/2
1/4
1/2
3/8
5 inputs, 4 mixes

105. Min-Mix Algorithm Simple algorithm yields minimal number of mixes
For any number of reagents, to any reachable concentration
Also minimizes reagent usage on certain chips

106. Min-Mix Algorithm: Key Insights
The mixing process can be represented by a tree. A B B A
5/8 A, 3/8 B

107. Min-Mix Algorithm: Key Insights
The mixing process can be represented by a tree.
The contribution of an input sample to the overall mixture is 2-d, where d is the depth of the sample in the tree d
2-d A 3
1/8 B 2
1/4 B 1
1/2 A
5/8 A, 3/8 B

108. Min-Mix Algorithm: Key Insights
The mixing process can be represented by a tree.
The contribution of an input sample to the overall mixture is 2-d, where d is the depth of the sample in the tree
In the optimal mixing tree, a reagent appears at depths corresponding to the binary representation of its overall concentration. d
2-d A 3
1/8
5 = 101 1
3 = 011 1 B 2
1/4 B 1
1/2 A
5/8 A, 3/8 B

109. Min-Mix Algorithm Example: mix 5/16 A, 7/16 B, 4/16 C
To mix k fluids with precision 1/n:
Min-mix algorithm: O(k log n) mixes
Binary search: O(k n) mixes 4 3 2 1
1/16
1/8
1/4
1/2 d
2-d A B A B B B A B C A B C
A=5 B=7 C=4
= = =0100
[Natural Computing 2007]

110. Related Work
Algorithms for microfluidic sample preparation [Sudip Roy et al.]
Aquacore – builds on our work, ISA + architecture [Amin et al.]
Automatic scheduling of biology protocols
EDNAC computer for automatically solving 3-SAT [Johnson]
Compile SAT to microfluidic chips [Landweber et al.] [van Noort]
Mapping sequence graphs to grid-based chips [Su/Chakrabarty]
Custom microfluidic chips for biological computation
DNA computing [Grover & Mathies] [van Noort et al.] [McCaskill] [Livstone, Weiss, & Landweber] [Gehani & Reif] [Farfel & Stefanovic]
Self-assembly [Somei, Kaneda, Fujii, & Murata] [Whitesides et al.]
General-purpose microfluidic chips
Using electrowetting, with flexible mixing [Fair et al.]
Using dialectrophoresis, with retargettable GUI [Gascoyne et al.]
Using Braille displays as programmable actuators [Gu et al.]
Aquacore – storageless operands, variable-volumes, evaluate on some assays
First category sits above our system
Second category sits below our system
Third category, we’re not necessarily competing – trying to build common layer that can target any

111. Conclusions: Fluidic ISA
Fluidic ISA gives flexibility to evolve underlying hardware
Including various device technologies
It remains to be seen to what degree the functionality of chips can be standardized
May need to reconsider abstractions for analog machines
Opportunities for future work
Rich extensions to mixing algorithms
Schedule separate protocols onto shared hardware, maximizing utilization of shared resource (e.g., thermocycler)
Parallelize single protocol across people or chips
Dynamic optimization of slow co-processors (lazy vectorization)?

112. Abstraction Layers for Microfluidics
Protocol Description Language
- architecture-independent protocol description
Fluidic Instruction Set Architecture (ISA)
- primitives for I/O, storage, transport, mixing
chip 1
chip 2
chip 3
Fluidic Hardware Primitives
- valves, multiplexers, mixers, latches

114. “Immunological detection
“Immunological detection ... was carried out as described in the Boehringer digoxigenin-nucleic acid detection kit with some modifications.”

115. Papers from Nature, Spring 2010
- Main paper
- References
- Ref. papers
Papers from Nature, Spring 2010

116. Problems with Existing Descriptions of Protocols
Incomplete
Cascading references several levels deep
Some information missing completely
Ambiguous
One word can refer to many things
E.g., “inoculate” a culture
Non-uniform
Different words can refer to the same thing
E.g., “harvest”, “pellet down”, “centrifuge” are equivalent
Not suitable for automation

117. BioCoder: A High-Level Programming Language for Biology Protocols
In biology publications, can we replace the textual description of the methods used with a computer program?
1. Enable automation
via microfluidic chips
2. Improve reproducibility
of manual experiments
Standardized
Subject to analysis
Subject to automation

118. Related Work
EXACT: EXperimental ACTions ontology as a formal representation for biology protocols [Soldatova et al., 2009]
Robot Scientist: functional genomics driven by macroscopic laboratory automation [King et al., 2004]
PoBol: RDF-based data exchange standard for BioBricks

119. The BioCoder Language
BioCoder is a protocol language for reuse & automation
Independent of chip or laboratory setup
Initial focus: molecular biology
Implemented as a C library
Used to express 65 protocols, 5800 lines of code
Restricted backend: automatic execution on microfluidic chips
General backend: emit readable instructions for human
Validation
Used to direct actions of scientists in the lab (IISc)
Used to control microfluidic chips (MIT)
Standardizing online Wiki; interest from Berkeley, UW, UMN…

120. BioCoder Language Primitives
Declaration / measurement / disposal
declare_fluid
declare_column
measure_sample
measure_fluid
volume
discard
transfer
transfer_column
declare_tissue
Combination / mixing
- combine
- mix
combine_and_mix
addto_column
mixing_table
Centrifugation
- centrifuge_pellet
centrifuge_phases
centrifuge_column
Temperature
- set_temp
use_or_store
autoclave
Timing
- wait
time_constraint
store_until
inoculation
invert_dry
Detection
- ce_detect
gas_chromatography
nanodrop
electrophoresis
mount_observe_slide
sequencing

121. Example: Plasmid DNA Extraction
I. Original protocol (Source: Klavins Lab)
Add 100 ul of 7X Lysis Buffer (Blue) and mix by inverting the tube 4-6 times. Proceed to step 3 within 2 minutes.
II. BioCoder code
FluidSample f1 = measure_and_add(f0, lysis_buffer, 100*uL);
FluidSample f2 = mix(f1, INVERT, 4, 6);
time_constraint(f1, 2*MINUTES, next_step);
III. Auto-generated text output
Add 100 ul of 7X Lysis Buffer (Blue).
Invert the tube 4-6 times.
NOTE: Proceed to the next step within 2 mins.

122. Example: Plasmid DNA Extraction
Auto-Generated Dependence Graph

123. 1. Data Types Stock Sample Fluid Solid FluidSample SolidSample
conceptually infinite volume
finite volume
Stock
Sample
Fluid
Solid
FluidSample
SolidSample
declare_fluid instruction
measure instruction
other instructions
Can measure symbolic volume
which is resolved by compiler / runtime system depending on eventual uses

124. 2. Standardizing Ad-Hoc Language
Need to convert qualitative words to quantitative scale
Example: a common scale for mixing
When a protocol says “mix”, it could mean many things
Level 1: tap
Level 2: stir
Level 3: invert
Level 4: vortex / resuspend / dissolve
Similar issues with temperature, timing, opacity, …
And you find similar things for temperature (bunsen burner, room temperature, ice, liquid nitrogen, etc.)

125. 3. Separating Instructions from Hints
How to translate abstract directions?
“Remove the medium by aspiration, leaving the bacterial pellet as dry as possible.”
Hints provide tutorial or self-check information
Can be ignored if rest of protocol is executed correctly
Separating instructions and hints keeps language tractable
Small number of precise instructions
Extensible set of hints
Centrifuge(&medium, ...);
hint(pellet_dry)
Aspirate and remove medium.
Leave the pellet as dry as possible.
About 20 hints total

126. 4. Generating Readable Instructions
In typical programming languages, aim to define the minimal set of orthogonal primitives
However, for generating readable protocols, separating primitives can detract from readability
Original: “Mix the sample with 1uL restriction enzyme.”
BioStream with orthogonal primitives:
FluidSample s1 = measure(&restriction_enzyme, 1*uL);
FluidSample s2 = combine(&sample, &s1);
mix(s2, vortex);
Measure out 1uL of restriction enzyme.
Combine the sample with the restriction enzyme.
Mix the combined sample by vortexing.

127. 4. Generating Readable Instructions
In typical programming languages, aim to define the minimal set of orthogonal primitives
However, for generating readable protocols, separating primitives can detract from readability
Original: “Mix the sample with 1uL restriction enzyme.”
BioStream with compound primitives:
combine_and_mix(&restriction_enzyme, 1*uL, &sample, vortex);
Add 1uL restriction enzyme and mix by vortexing.

128. 4. Generating Readable Instructions
In typical programming languages, aim to define the minimal set of orthogonal primitives
However, for generating readable protocols, separating primitives can detract from readability
Original: “Mix the sample with 1uL restriction enzyme.”
BioStream with compound primitives:
combine_and_mix(&restriction_enzyme, 1*uL, &sample, vortex);
Add 1uL restriction enzyme and mix by vortexing.
General approaches:
Detect combined operations with policies (peekhole optimizer)
Define a standard library that combines primitive operations

129. 4. Generating Readable Instructions
mixing_table_pcr(7,20,array_pcr,initial_conc, final_conc,vol);
And symbolic volumes

130. 5. Timing Constraints
Precise timing is critical for many biology protocols
Minimum delay: cell growth, enzyme digest, denaturing, etc.
Maximum delay: avoid precipitation, photobleaching, etc.
Exact delay: regular measurements, synchronized steps, etc.
May require parallel execution
Fluid f1 = mix(…); useBetween(f1, 10, 10);
Fluid f2 = mix(…); useBetween(f2, 10, 10);
Fluid f3 = mix(f1, f2); f1 f2 10 10 f3

131. Scheduling the Execution
Scheduling problem has two parts:
A. Given dependence graph, find a good schedule
B. Extract dependence graph from the program

132. A. Finding a Schedule Abstract scheduling problem:
Given task graph G = (V, E) with [min, max] latency per edge
Find shortest schedule (V  Z) respecting latency on each edge
 Case 1: Unbounded parallelism
Can express as system of linear difference constraints
Solve optimally in polynomial time
 Case 2: Limited parallelism
Adds constraint: only k vertices can be scheduled at once
Can be shown to be NP-hard (reduce from PARTITION)
Rely on greedy heuristics for now

133. B. Extracting Dependence Graph
Static analysis difficult due to aliasing, etc.
Requires extracting precise producer-consumer relationships
Opportunity: Perform scheduling at runtime, using lazy evaluation
Microfluidic operations are slow  computer can run ahead
Build dependence graph of all operations up to decision point
Hazard: constraints that span decision points
Dynamic analysis cannot look into upcoming control flow
We currently prohibit such constraints – leave as open problem

134. Benchmark Suite
65 protocols
5800 LOC

135. Plasmid DNA Extraction
214 lines

136. PCR
73 lines
repeat
thermocycling

137. Molecular Barcodes
200 lines
Preparation
+ PCR (2)

138. DNA Sequencing
Preparation
144 lines
PCR
PCR
PCR
PCR
Analysis

139. Instruction Usage

140. Validating the Language
Eventual validation: automatic execution
But BioCoder more capable than most chips today
Need to decouple language research from microfluidics research
Initial validation: human execution
In collaboration with Prof. Utpal Nath’s lab at IISc
Target Plant DNA Isolation, common task for summer intern
Biologist is never exposed to original lab notes
To the best of our knowledge, first execution of a real biology protocol from a portable programming language
Original Lab Notes
BioCoder
Code
Auto-Generated Protocol
Execution in Lab

141. Exposing Ambiguity in Original Protocols?
Add 1.5 vol. CTAB to each MCT and vortex. Incubate at 65° C for mins
Add 1 vol. Phenol:chloroform:isoamylalcohol: 48:48:4 and vortex thoroughly
Centrifuge at 13000g at room temperature for 5 mins
Transfer aqueous (upper) layer to clean MCT and repeat the extraction using chloroform: Isoamyalcohol: 96:4
Coding protocols in precise language removes ambiguity and enables consistency checking

142. Growing a Community

143. Growing a Community

144. Growing a Community

145. Future Work Backends for BioStream Reliability and troubleshooting
Generate graphical protocol
Generate a microfluidic chip to perform protocol
Reliability and troubleshooting
Verify that protocol is safe, correct, obeys timing constraints
If protocol fails, automatically suggest troubleshooting routine
Building a knowledge base
Encode experimental results in addition to protocols
Search for a protocol based on input/output relationship
Revision control for biology protocols

146. Conclusions Abstraction layers for programmable microfluidics
Microfluidic CAD tools
General-purpose chips
Fluidic ISA
BioCoder language
Vision for microfluidics: everyone uses standard chip
Vision for software: a defacto language for experimental science
Download a colleague’s code, run it on your chip
Compose modules and libraries to enable complex experiments that are impossible to perform today
Say at end: we have end-to-end system working
