1. Connectivity Packages

2. Connectivity package overview
A collection of software and information related to a specific IED (Intelligent Electronic Device), providing means for system products and tools to connect and interact with the IED’s.
Main benefits:
ABB: Development and release independency between IED’s and system/tool products while maintaining a high integration level
Customer: Ease and simplify the engineering process
System & tools utilizing the connectivity package:
COM 610
SPA ZC-40x (IEC 61850/SPA gateway)
MicroSCADA Pro: SYS 600 and COM 500

3. Content of a Connectivity Package
Description of IED functionality and capabilities
Object Types for device integration. These object types defines the properties for device related object, e.g. the protocols that are supported by the IED
IED specific visual elements e.g. object icon, graphical symbols, faceplates, etc.

4. Connectivity Package Delivery
The connectivity packages are delivered free of charge from the following locations:
Internet download - ABB Library under each IED product (e.g. REF 543 under downloads/software )
CE Engineering database

5. Connectivity Package Releases
The first first connectivity packages are released for the products
Connectivity Package for REF 541/543/545 rev. 3.0 (SPA and LON)
Connectivity Package for REM 543/545 rev. 2.5 (SPA and LON)
The range of supported IED’s, systems and tools as well as functionality of connectivity packages will be expanded as the project goes on

6. Usage in tools and systems
COM 610 Connectivity Packages are used for configuring COM 610 to communicate and interact with SPA- and LON -devices (note: one option is also to use COM 610 via IEC to SPA-device that uses SPA-ZC 40x)
SPA-ZC 40x Connectivity Packages are used for configuring SPA-ZC 40x (used protocols are SPA and IEC 61850). Combination of SPA-ZC 40x and COM 610 is also supported as mentioned above.
SYS 600 and COM 500 Connectivity Packages are used for configuring IEC OPC server (usually done by importing the export-file generated from configuration of SPA-ZC 40x)

7. Connectivity Packages Usage Example 1
CET*) for COM 610
COM 610
SPA / LON /
IEC etc
CAP 505
.ar-file
SCL
SCL
SCL
*) Communication Engineering Tool
Connectivity Package

8. Connectivity Packages Usage Example 2
CET in SYS 600
CET for COM 610
SCL-
file
CET for SPA-ZC 40x
SYS 600
COM 610
IEC 61850
Connectivity Package
CAP 505
.ar-file
SPA -
ZC 40x
SPA -
ZC 40x
SCL
SCL
SCL
