1. A Probabilistic Framework for Semi-Supervised Clustering
Sugato Basu
Mikhail Bilenko
Raymond J. Mooney
Deptment of Computer Sciences
University of Texas at Austin
Presented by Jingting Zeng

2. Outline
Introduction
Background
Algorithm
Experiments
Conclusion

3. What is Semi-Supervised Clustering?
Use human input to provide labels for some of the data
Improve existing naive clustering methods
Use labeled data to guide clustering of unlabeled data
End result is a better clustering of data

4. Motivation Large amounts of unlabeled data exists
More is being produced all the time
Expensive to generate Labels for data
Usually requires human intervention
Want to use limited amounts of labeled data to guide the clustering of the entire dataset in order to provide a better clustering method

5. Semi-Supervised Clustering
Constraint-Based:
Modify objective functions so that it includes satisfying constraints, enforcing constraints during the clustering or initialization process
Distance-Based:
A distance function is used that is trained on the supervised dataset to satisfy the labels or constraint, and then is applied to the complete dataset

6. Method
Use both constraint-based and distance based approaches in a unified method
Use Hidden Markov Random Fields to generate constraints
Use constraints for initialization and assignment of points to clusters
Use an adaptive distance function to try to learn the distance measure
Cluster data to minimize some objective distance function

7. Main Points of Method Improved initialization:
Initial clusters are formed based on constraints
Constraint sensitive assignment of points to clusters
Points are assigned to clusters to minimize a distortion function, while minimizing the number of constraints violated
Iterative Distance Learning
Distortion measure is re-estimated after each iteration

8. Constraints Pairwise constraints of Must-link, or Cannot-link labels
Set M of must link constraints
Set C of cannot link constraints
A list of associated costs for violating Must-link or cannot-link requirements
Class labels do not have to be known, but a user can still specify relationship between points.

9. HMRF

10. Posterior probability
This problem is an “incomplete-data problem”
Cluster representative as well as class labels are unknown
Popular method for solving this type of problem is Expectation Maximization
K-Means is equivalent to an EM algorithm with hard clustering assignments

11. Must-Link Violation Cost Function
Ensures that the penalty for violating the must-link constraint between 2 points that are far apart is higher than between 2 points that are close
Punishes distance functions in which must-link points are far apart

12. Cannot-Link Violation Cost Function
Ensures that the penalty for violating cannot-link constraints between points that are nearby according to the current distance function is higher than between distant points
Punishes distance functions that place 2 cannot link points close together

13. Objective Function Goal: find minimum objective function
Supervised data in initialization
Constraints in cluster assignments
Distance learning in M step

14. Algorithm EM framework Initialization step: E step: M step:
Use constraints to guide initial cluster formations
E step:
minimizes objective function over cluster assignment
M step:
Minimizes objective function over cluster representatives
Minimizes objective function over the parameter distortion measure

15. Initialization Initialize:
Form transitive closure of the must-link constraints
Set of connected components consisting of points connected by must-link constraints
y connected components
If y < K (number of clusters), y connected neighborhoods used to create y initial clusters
Remaining clusters initialized by random perturbations of the global centroid of the data

16. What If More Neighborhoods Then Clusters?
If y > K (number of clusters), k initial clusters are selecting using the distance measure
Farthest first traversal is a good heuristic
Weighted variant of farthest first traversal
Distance between 2 centroids multiplied by their corresponding weights
Weight of each centroid is proportional to the size of the corresponding neighborhood.
Biased to select centroids that are relatively far apart and of a decent size

17. Initialization Continued
Assuming consistency of data:
Augment set M with must-link constraints inferred from transitive closure
For each pair of neighborhoods Np ,Np’ that have at least one cannont link constraint between them, add connot-link constraints between every member of Np and Np’ .
Learn as much about the data through the constraints as possible

18. Augment set M a b c
Must-link
Must-link
Inferred Must-link

19. Augment Set C a b c
Must-link
Cannot-link
Inferred Cannot-link

20. E-step Assignments of data points to clusters
Since model incorporates interactions between points, computing point assignments to minimize objective function is computationally intractable
Iterated conditional models, belief propagation, and linear programming relaxation
ICM: uses greedy strategy to sequentially update the cluster assignment of each point while keeping other points fixed.

21. M-step
First, cluster representatives are re-estimated to decrease objective function
Constraints do not factor into this step, so it is equivalent to K-Means
If parameterized variant of a distance measure is used, it is updated here
Parameters can be found through partial derivatives of distance function
Learning step results in modifying the distortion measure so that similar points are brought closer together, while dissimilar points are pulled apart

22. Results KMeans – I – C – D : KMEANS – I- C: KMEANS –I :
Complete HMRF- KMeans algorithm, with supervised data in initialization(I) and cluster assignment(C) and distance learning(D)
KMEANS – I- C:
HMRF-KMeans algorithm without distance learning
KMEANS –I :
HMRF-KMeans algorithm without distance learning and supervised cluster assignment

23. Results

24. Results

25. Results

26. Conclusion
HMRF-KMeans Performs well (compared to naïve K-Means) with a limited number of constraints
The goal of the algorithm was to provide a better clustering method with the use of a limited number of constraints
HMRF-KMeans learns quickly from a limited number of constraints
Should be applicable to data sets where we want to limit the amount of labeling needed to be done by humans, and constraints can be specified in pairwise labels

27. Questions
Can all types of constraints be captured in pairwise associations?
Hierarchal structure?
Could other types of labels be included in this model?
Use class labels as well as pairwise constraints
How does this model handle noise in the data/labels?
Point A has must link constraint to Point B, Point B has must list constraint to Point C, Point A has Cannot-link constraint to point C

28. More Questions How does this apply to other types of Data?
Authors mention wanting to try applying method to other types of data in the future, such as gene representation
Who provides weights for function violations, and how are weights determined?
Only compared with naïve KMeans method
How does it compare with other semi-supervised clustering methods?

29. Reference
S. Basu, M. Bilenko, and R.J. Mooney, “A Probabilistic Framework for Semi-Supervised Clustering,” Proc. 10th ACM SIGKDD Int'l Conf. Knowledge Discovery and Data Mining (KDD), Aug

30. Thank you!
