1. European-wide field trials for residential fuel cell micro-CHP
Commercial in Confidence
All technical information displayed in this presentation is confidential and should not be used for any other purposes than scoping potential for commercial agreements, or entering into commercial discussions.
The research leading to these results has received funding from the European Union´s 7th Framework Programme (FP7/ ) for the Fuel Cells and Hydrogen Joint Undertaking Technology Initiative under Grant Agreement Number

2. Agenda Brief presentation of the project
Overview of FC m CHP technology and its benefits
Technology deployed under ene.field
Typical agreements between ene.field manufacturers and associated field partners
Comments (EE):
NOTE this presentation is intentionally extensive. Slides can be removed depending on how relevant they are for the audience and / or time allocated for the presentation.
Typical use for this presentation could be Conferences, Regional workshops etc.

3. Brief presentation of the project
Agenda
Brief presentation of the project
Overview of FC m CHP technology and its benefits
Technology deployed under ene.field
Typical agreements between ene.field manufacturers and associated field partners 3

4. Introduction to ene.fieldv
ene.field is the largest European demonstration of the latest smart energy solution for private homes, fuel cell micro-CHP.
It will deploy up to 1,000 Fuel Cell heating systems in 12 key European member states.
Project duration of 5 years. Systems will be demonstrated for 2 to 3 years.
Outputs of the project include: Detailed performance data, lifecycle cost and environmental assessments, market analysis, commercialisation strategy.
project goal
• market launch of fuel cell systems in Europe
• creation of European supply chains
• development of commercial models
• installation of around fuel cell systems in Europe
Countries where units are currently expected to be installed 4

5. ene.field is a European platform for FC mCHP
The consortium brings together 26 partners including:
the leading European FC micro-CHP developers,
leading European utilities,
leading research institutes,
partners in charge of dissemination and coordination of the project.
The consortium brings together all of the leading European fuel cell micro-CHP developers under a single partnership and combines them with some of the leading European utilities. In addition, there are several research partners to be able to produce world leading data and research in a number of diverse areas. Some other partners will be in charge of the dissemination and coordination of the project.
The Fuel Cells and Hydrogen Joint Undertaking (FCH JU) is committing c. €26 million to ene.field under the EU's 7th Framework Programme for funding research and development. 5

6. Overview of FC m CHP technology and its benefits
Agenda
Brief presentation of the project
Overview of FC m CHP technology and its benefits
Technology deployed under ene.field
Typical agreements between ene.field manufacturers and associated field partners 6

7. Fuel Cell micro Combined Heat and Power systems (FC mCHP) 1/2v
System description
Produce both heat and electricity for a building using a single fuel. Primarily produces electricity with heat being produced as a by-product.
Well suited to the retrofit market and compatible with new build properties.
Noise and vibration free source of power.
Low local emissions
When heat demand is too large for the system the peak demand boiler will switch on and provide heat. This peak demand boiler operates like a conventional gas boiler.
Source: Fuel Cell Handbook (fifth edition), EG&G Services Parsons, Inc., and Fundamental physics and chemistry of direct electrochemical oxidation in SOFC (see 7

8. Fuel Cell micro Combined Heat and Power systems (FC mCHP) 2/2v
FC description
Combines hydrogen produced from the fuel and oxygen from the air to produce power, heat and water through an electrochemical reaction.
Can operate on a variety of fuels, including:
natural gas (L and H),
biofuels and
hydrogen
Standard Fuel Cell system
Source: Fuel Cell Handbook (fifth edition), EG&G Services Parsons, Inc., and Fundamental physics and chemistry of direct electrochemical oxidation in SOFC (see 8

9. A growing market and interest for FC mCHPv
The last 5 years have seen a steep increase in sales worldwide as well as the implementation of numerous schemes to incentivise the uptake of mCHP.
Countries with incentives for mCHP
FC mCHP sales worldwide
Type of support
Country
Tax support
Belgium, Italy, Luxembourg, Netherlands, Spain, UK.
Feed-in-tariff
Austria, France, Germany, Hungary, Italy, Netherlands, Slovenia, Spain, UK.
Certificate scheme
Belgium.
Capital grant
Italy, Netherlands, UK.
Other
Belgium, France, Germany, Hungary, Ireland, Luxembourg, Netherlands, Slovenia, Spain.
Source: Code project at (table) and data from Delta Energy & Environment at (Graph).

10. A growing interest at the European policy level
Energy Efficiency Directive (2012/27/EU)
Defines micro-CHP as a cogeneration unit with a maximum capacity below 50 kWe.
Member States shall conduct a comprehensive assessment of introducing high-efficiency CHP & DHC, which shall also consider the potential for micro-CHP.
Member States are encouraged to facilitate the grid connection to micro-cogeneration units.
Simplified notification “install and inform” procedure for the installation of micro-CHP is recommended.
Energy performance of Buildings Directive (2010/31/EU)
Cogeneration, including micro-CHP, is part of the toolbox of energy efficient measures to improve the energy efficiency in buildings.
European Parliament Microgeneration Resolution (adopted on 12th September 2013)
Calls on the Commission to put more emphasis on realising the potential of small scale technologies, including micro-CHP.
Micro-CHP is mentioned as an important small scale technology to save energy in buildings, contributing together with renewables to zero- or positive- energy buildings. v

11. Why are policy makers and industry pursuing CHP? 1/2
Carbon savings, reduced local emissions & energy efficiency
FC mCHP can achieve carbon savings of up to 50%1.
FC mCHP transfers electricity generation to the local level and alleviates transmission losses.
In the EU, the building sector is responsible for:
40% of energy consumption
36% of total CO2 emissions.
Challenges
Benefits
1. compared with a natural gas condensing boiler and European grid mix electricity 11

12. Why are policy makers and industry pursuing CHP? 2/2
FC mCHP can produce low cost electricity from gas.
FC mCHP can address renewable intermittency and nuclear inflexibility.
FC mCHP can provide a flexible response to real time prices via smart metering.
FC mCHP can empower consumers by giving them control of their electricity bills.
Cost savings, markets development & smart grid application
Rapidly increasing electricity demand.
Integration of high capacity of intermittent renewables on electricity grids.
Required investment in grid reinforcement, storage and generating capacity.
Required application to support smart grid infrastructure.
Challenges
Benefits 12

13. An efficient way to produce and deliver energy
Micro CHP allows decentralised generation of heat and power at peak time.
High electrical / thermal efficiencies.
Decentralised supply of heat / electricity.
No losses from transportation.
Reduce CO2 associated with energy production at peak time.
Less constraints for grid operation.
CHP is the most efficient way to deliver / produce energy as it is based on simultaneous production of electricity and thermal energy used to meet local loads.
Source: H2FC SUPERGEN at (illustration and data for graph), 13

14. Advanced and innovative technologies
FC mCHP also generates less harmful emissions for the environment and for people’s health (CO2, PM, Sox, etc.).
FC mCHP has a higher overall efficiency than a traditional boiler or even than other mCHP solutions.
CO2 savings potential
*) Calculated according to residual power value method
Source: Callux project, 2012

15. Technology deployed under ene.field
Agenda
Brief presentation of the project
Overview of FC m CHP technology and its benefits
Technology deployed under ene.field
Typical agreements between ene.field manufacturers and associated field partners

16. Technical characteristics of systems in ene.fieldv
The systems deployed in ene.field present a good coverage of various type of requirements thanks to a wide range of technology, size and fuels.

17. A cost effective solution for a low carbon energy production
Cost savings
Savings in energy costs for end-users (average est. between €800 and €1,200*):
High overall efficiency of the system
Displaced cost of electricity
Additional savings thanks to national grants for low carbon technologies.
Carbon savings (CO2 emissions)
Can achieve carbon savings of up to 50%* when compared with a natural gas condensing boiler.
No soot / PM and limited nitrogen oxides (NOx) and carbon monoxide (CO) emissions.
* Depending on household characteristics, location, national prices and grant(s) available.
Savings vary depending on national energy mix and local utilities prices.

18. Examples of field trialsv
Mr. Schröter, owner of Schröter Haustechnik:
“I want to support new technologies like the fuel cell that improves energy efficiency in homes, reduces CO2 emissions and contributes to the success of the energy transition”.
Mr. Aberl:
“We wanted to get involved with this innovative fuel cell cogeneration system tailored for single family homes and achieve significant energy savings“.
Elcore 2400 system at family Aberl installed by the
company Schröter Haustechnik
The house of family Aberl (Munich region)
Single-family home
Mid-terrace house
120m² living space
300W electrical power (base load energy demand)
600W thermal output (warm water / heating)
Source: Elcore, Press release 06/09/13.

19. Examples of field trialsv
Mr. Bossler:
“I immediately proposed to my family that we apply to take part in the test when I read about the Municipal Works’ invitation. I am promising myself lower heating costs and, by generating current at the same time, even further cost savings. Now I can’t wait to see the results,”
BAXI INNOTECH, the Homburg Municiple Works and family Bossler are backing fuel cells for heat and power generation in the home: Wolfgang Ast, Managing Director of the Homburg Municipal Works, Friedrich and Julia Bossler and Guido Gummert, Managing Director of BAXI INNOTECH ( from left to right)
Source: Baxi Innotech, Press release 06/09/13.

20. Agenda
Brief presentation of the project
Overview of FC m CHP technology and its benefits
Technology deployed under ene.field
Typical agreements between ene.field manufacturers & associated field partners 20

21. Co-ordination and communication with ene.field
Roles and responsibilities sharing between field partner and ene.field project partners v
Field partners are supported at all the stages by the manufacturer(s) they are collaborating with. The manufacturer are coordinating all exchanges with ene.field.
Site selection
field partner
Installation of units
CHP supplier
and field partner
Monitoring and maintenance
CHP supplier and field partner
Upgrade at end of trial
Manufacture of units
CHP Supplier
Field support
Optimisation
Ongoing operation
Trial agreement
Co-ordination and communication with ene.field 21

22. Opportunities to become an Associated Field Partner
Associated field partners are field partners that contribute to the project and in return benefit from specific advantages otherwise only accessible to project partners. v
Advantages
Basic requirements*
They have the opportunity to gain:
access to processed data from all trials in the project / information exchanges,
familiarity with this new technology and prepare for wider market entry,
valuable market and product insights by interacting with a flagship European project and key market players and,
use of the ene.field branding.
The basis requirements to benefit of this status are to:
find a minimum of 5 sites and to take part in the trial*,
work with systems’ manufacturers on the site selection and setting up of the units and,
collaborate with the manufacturer to establish monitoring activities required by the project.
* Please note field partners can deploy less than 5 units but will not benefit from the same advantages as Associated Field Partners.

23. Ene.field manufacturer(s) Associated field partner
Detail of typical services included in commercial offer*
Ene.field manufacturer(s)
Associated field partner
Production delivery and installation
Manufacture
Delivery
Supply of the connections
Site selection e.g support for integration in existing building infrastructure
Installation of FC
Training
Provide training for local for installation and troubleshooting
Professional training of staff
Attend training
Service & maintenance
Deal with trouble shooting (2st level repair)
24h emergency hotline (2nd level support)
Online supervision incl. 24h message system
Deal with trouble shooting (1st level repair)
Broadband for issues with customers (1st level support)
Marketing
Support for partner-marketing
Operation
Optimization of system operation (depends on the system
Monitoring activities
Decommissioning
* Please note that the details of the commercial offer will vary between manufacturers. Details of agreements should be discussed with each manufacturer.

24. Dissemination offer to associated field partners 1/2v
This offer includes deliverables, reports and marketing information and tools the use of which is otherwise restricted to ene.field partners.
Access to project’s deliverables
Database of energy demand profiles,
Report on technical performance,
Summary of issues encountered,
Surveys and Barriers Report,
LCC and LCA
Report on economics of mCHP to 2030,
Report on EU FC mCHP supply chain,
Report on the policy requirements for mCHP,
Report on macro-economic & environmental impact.
Access to processed data from all trials
Checklist- e.g. gas connection, region, time scale for installation etc.
Biannual reports will be generated with data from the field trials (based on anonymised data)
Specific contents of reports will analyse the units deployed in the field overall and by climate zone and details aggregated and mean running hours, efficiency, electricity and heat produced.

25. Dissemination offer to associated field partners 2/2v
This offer includes deliverables, reports and marketing information and tools the use of which is otherwise restricted to ene.field partners.
Access information (meetings & seminars)
Invitation to specific dissemination events organised ahead of the annual assemblies.
Opportunity to receive information and results from the field trials.
Invitation to join the utilities working group.
Dependent on manufacturer: invitation to specific seminars organised by manufacturer(s) they are conducting field trials with.
Use of the ene.field branding
Dedicated page on the ene.field website ( with your logo.
Access to dissemination material and specific logo to recognise your contribution.
Checklist- e.g. gas connection, region, time scale for installation etc.
Final logo design to be determined

26. ene.field – coordination team contact detailsv
Please do not hesitate to contact us if you wish to get additional information about the ene.field systems or would like to be put in contact with one or several of the FC mCHP manufacturers involved in the project.
COGEN Europe is the project co-ordinator and the leader of the dissemination Work Package.
Element Energy is the work package leader coordinating the implementation of the demonstration sites under ene.field.
Fiona Riddoch (ene.field Coordinator)
Direct line:
Lisa Ruf (Field trial management)
Direct line: +44(0)

28. ANNEX

29. An efficient way to produce and deliver energy
Micro CHP allows decentralised generation of heat and power at peak time.
Reduce CO2 associated with energy production at peak time.
Less constrains for grid operation.
Source: H2FC SUPERGEN at (illustration and data for graph), 29

30. Advanced and innovative technologies
Boiler
Stirling mCHP
Ene.field
System efficiency (LHV)
90%
up to 95%
Electrical efficiency (LHV) 0%
16.5%
up to 45%
Comparing efficiency and CO2 savings from various mCHP technologies
The efficiency % shown on this graph for FC systems are calculated as the average of the efficiency of the systems deployed in ene.field
Source: Element Energy, 2013 (Table) and data from Delta Energy & Environment (Graph) at

31. Cerapower FC10 Logapower FC10
Technical characteristics of systems in ene.field
GAMMA PREMIO
Cerapower FC10 Logapower FC10
Dantherm
Elcore 2400
Galileo 1000 N
Inhouse 5000+
ENGEN 2500
Vaillant G5+
LT PEM
SOFC
HT PEM
1 kW
700W kW
300W
1kW
5kW
2.5kW
Natural Gas
Natural Gas, Gas
Natural Gas + Biogas
Natural gas+ Biogas
Natural gas + Biogas + H2
Floor
 Floor
Wall
Baxi Innotech
Bosch Thermotechnik
Dantherm Power
Elcore
Hexis
RBZ
SOFC Power
Vaillant

32. Allocation of sensors in ACOS700 – Detailed monitoring
Meter
Types
Variables measured 1
Gas
Consumption peak load boiler 2
Consumption FC 3
Electricity
Power consumption FC / Power export FC 4
Power consumption house / Power export house 5
Heat
Heat output FC / Outgoing temperature / Return temperature / Flow rate 6
Heat output peak load boiler / Outgoing temperature / Return temperature / Flow rate 7
Heat output hot water / Hot water temperature / Cold water temperature / Flow rate 8
Heat output space heat / Outgoing temperature / Return temperature / Flow rate 9
Temperature
Temperature outside / Relative air humidity 10
Temperature inside / Relative air humidity

33. Monitoring requirements specific to ene.field
All installations are monitored for a two year minimum period, creating a highly valuable dataset on product performance.
This raw data will be analysed throughout the project and will form the basis of a series of technical and market studies.
This will allow the partners to understand how the technology can be integrated into a range of house types, performance under real thermal demands, aspects of the consumer attitudes toward the technology and the interactions with the local electricity supply network.
ACOS700 aka “Callux-box” from IDS GmbH (source: IDS)
Communication gateway/data logger for collecting and archiving in database servers. It includes:
2 Ethernet ports (ETH 0 and ETH1),
a wireless communication port (M-Bus),
internal communication networks (S1 and S2),
a mini-USB service port for direct connection,
a plug in electrical power connection (PWR).
