2. Overview Characteristics and Capabilities of Generators TQG MEP 831A
MEP 803A/813A
MEP 805B/815B
MEP 806B/ 816B
MEP 807A
AMMPS
MEP 1030/ 1031
MEP 1040/ 1041
MEP 1050/ 1051
MEP 1060/ 1061
MEP 1070/ 1071

4. Tactical Quiet Generators (TQG)
CHARACTERISTICS
Tactical Quiet Generators (TQG)

5. MEP-831A

6. MEP-831A (Cont.) 3,000 Watt/60Hz Skid mounted 304 lbs dry/334 lbs wet
34.8” long, 27.8” wide, 26.5” tall
Six lifting handles/four tie down rings
Manually lifted/moved by forklift

7. MEP-831A (Cont.) Hinged enclosure Thermostatically controlled
Single cylinder, air cooled, direct injection
4 stroke Yanmar diesel engine
3000 to 3600 RPM
Oil capacity 1.2 quarts

8. MEP-831A (Cont.) 4 gal fuel tank/.5 GPH Aux fuel connection
DF1, DF2, or JP-8
24VDC cranking system
Permanent magnet alternator with frequency converter
2-plug GFCI, single phase, 2 wire 120VAC 31 amps
Single phase, 3 wire, 120/240VAC 16 amps

10. MEP-803A

11. MEP-803A (Cont.)
10,000 watt/60Hz
Fully enclosed, self contained, skid mounted
1140 lbs. dry/1242 lbs. wet
32” wide, 37” tall, and 62” long
Can be mounted on a M116A3 trailer

12. MEP-803A (Cont.)
Onan, naturally-aspirated, 4 cylinder, 4 cycle, liquid cooled
1745 to 1800 RPM
Oil Capacity 5.9 quarts/25-60 PSI
Cooling system 8.2 quarts/170°F - 200°F

13. MEP-803A (Cont.) 9 gallon fuel tank/.99 GPH Aux fuel connection
DF1, DF2, JP-4, JP-5 or JP-8
24VDC cranking system. 2 12V batteries connected in series

14. MEP-803A (Cont.) Generator is Drip-proof Synchronous Brushless
Three phase
Fan cooled
120VAC single phase 104 amps
120/240VAC single phase 34 amps
120/208VAC three phase 52 amps

16. MEP-813A

17. MEP-813A (Cont.) 10kW (10,000 watt) 400Hz
Fully enclosed, self contained, skid mounted
1170 lbs. dry/1272 lbs. wet
32” wide, 37” tall, and 62” long
Can be mounted on a M116A3 trailer

18. MEP-813A (Cont.)
Onan, naturally-aspirated, 4 cylinder, 4 cycle, liquid cooled
1745 to 1800 RPM
Oil Capacity 5.9 quarts/25-60 PSI
Cooling system 8.2 quarts/170°F - 200°F

19. MEP-813A (Cont.) 9 gallon fuel tank/1.07 GPH Aux fuel connection
DF1, DF2, JP4, JP5, or JP8
24VDC cranking system. 2 12V batteries connected in series

20. MEP-813A (Cont.) Generator : Drip-proof Synchronous Brushless
Three phase
Fan cooled
120VAC single phase 104 amps
120/240VAC single phase 34 amps
120/208VAC three phase 52 amps
MEP-813A same as 803 except Hz

22. MEP-805B

23. MEP-805B (Cont.) 30kW (30,000 watt)/50-60Hz
Fully enclosed, self contained, skid mounted, portable unit
Digital Control System (DCS)
2732 lbs. dry/2931 lbs. wet
79.9” long, 35.7” wide, and 55” tall
Moved utilizing a forklift
Mounted on a M353 trailer

24. MEP-805B (Cont.)
John Deere 4045TF151, 4 cylinder, 4 cycle, 3.9 liter turbocharged, liquid cooled diesel engine
RPM
Oil capacity is 15 quarts/25-60 PSI
Cooling system capacity is 15.5 quarts/170°F -200°F

25. MEP-805B (Cont.) 23 gallon fuel tank/ 2.6 GPH Aux fuel connection
DF1, DF2, JP4, JP5, or JP8
24VDC cranking system
2-12V batteries connected in series

26. MEP-805B (Cont.)
Generator is single bearing, drip-proof, synchronous, brushless, three phase, fan cooled generator
60Hz 120/208VAC 104 amps
60Hz 240/416VAC 52 amps
50Hz 120/208VAC 86 amps
50Hz 240/416VAC 43 amps

28. MEP-815B

29. MEP-815B (Cont.) 30kW (30,000 watt)/400Hz
Fully enclosed, self contained, skid mounted, portable unit
Digital Control System (DCS)
2732 lbs. dry/2931 lbs. wet
79.9” long, 35.7” wide, and 55” tall
Moved utilizing a forklift
Mounted on a M353 trailer

30. MEP-815B (Cont.)
John Deere 4045TF151, 4 cylinder, 4 cycle, 3.9 liter turbocharged, liquid cooled diesel engine
RPM
Oil capacity is 15 quarts/25-60 PSI
Cooling system capacity is 15.5 quarts/170°F -200°F

31. MEP-815B (Cont.) 23 gallon fuel tank/2.60 GPH Aux fuel connection
DF1, DF2, JP4, JP5 or JP8
24VDC cranking system
2-12V batteries connected in series

32. MEP-815B (Cont.)
Generator is single bearing, drip-proof, synchronous, brushless, three phase, fan cooled generator
400Hz 120/208VAC 104 amps
400Hz 240/416VAC 52 amps
MEP 815B exact replica of MEP 805B except it is 400Hz

34. MEP-806B

35. MEP-806B (Cont.) 60kW (60,000 watt)/50/60Hz
Fully enclosed, self contained skid mounted, portable unit
Digital Control System (DCS)
3556 lbs. dry/3992 lbs. wet
87” long, 35.7” wide, and 59” tall
Moved by forklift
Mounts on a M353 trailer

36. MEP-806B (Cont.)
John Deere 6068TF151, 6 cylinder, 4 cycle, 5.9 liter turbocharged, liquid cooled diesel engine
RPM
Oil system capacity 18 quarts/25-60 PSI
Cooling system capacity 20.5 quarts/ 170°F -200°F

37. MEP-806B (Cont.) 43 gallon fuel tank/5.06 GPH Aux fuel connection
DF1, DF2, JP4, JP5 or JP8
24VDC cranking system
2-12V batteries connected in series

38. MEP-806B (Cont.)
Generator is single bearing, drip-proof, synchronous, brushless, three phase, fan cooled generator
60Hz 120/208VAC 208 amps
60Hz 240/416VAC 104 amps
50Hz 120/208VAC 173 amps
50Hz 240/416VAC 86 amps

40. MEP-816B

41. MEP-816B (Cont.) 60kW (60,000 watt)/400Hz
Fully enclosed, self contained skid mounted, portable unit
Digital Control System (DCS)
3606 lbs. dry/4042 lbs. wet
87” long, 35.7” wide, and 59” tall
Moved by forklift
Mounts on a M353 trailer

42. MEP-816B (Cont.)
John Deere 6068TF151, 6 cylinder, 4 cycle, 5.9 liter turbocharged, liquid cooled diesel engine
RPM
Oil system capacity 18 quarts/25-60 PSI
Cooling system capacity 20.5 quarts/ 170°F -200°F

43. MEP-816B (Cont.) 43 gallon fuel tank/5.37 GPH Aux fuel connection
DF1, DF2, JP4, JP5 or JP8
24VDC cranking system
2-12V batteries connected in series

44. MEP-816B (Cont.)
Generator is single bearing, drip-proof, synchronous, brushless, three phase, fan cooled generator
400Hz 120/208VAC 208 amps
400Hz 240/416VAC 104 amps
Exact replica of the MEP-806B except it is 400Hz

46. MEP-807A

47. MEP-807A (Cont.) 100kW (100,000 watt)/50-60Hz
Fully enclosed, self contained skid mounted, portable unit
Electronic Modular Control Panel (EMCP)
5500 lbs. dry/ 6100 lbs. wet
106” long, 40” wide, and 65” tall
Moved by forklift

48. MEP-807A (Cont.)
Caterpillar 3126B, 6 cylinder, 4 cycle, 7.25 liter turbocharged, liquid cooled diesel engine
1800 RPM 60Hz-1500 RPM 50Hz
Oil system capacity 30 quarts/35-70 PSI
Cooling system capacity 38 quarts/ 170°F -200°F

49. MEP-807A (Cont.) 66 gallon fuel tank/ 8hr continuous operation
Aux fuel connection
DF1, DF2, JP4, JP5 or JP8
24VDC cranking system
2-12V batteries connected in series

50. MEP-807A (Cont.)
Generator is single bearing, drip-proof, synchronous, brushless, three phase, fan cooled generator
60Hz 120/208VAC 347 amps
60Hz 240/416VAC 174 amps
50Hz 120/208VAC 289 amps
50Hz 240/416VAC 145 amps

52. Advanced Mobile Medium Power Source (AMMPS)
CHARACTERISTICS
Advanced Mobile Medium Power Source (AMMPS)

53. AMMPS Generator Sets Sizes: 5kW, Mode I and II Modes:
I — 50/60 Hertz (Hz)
II — 400Hz

54. Model Numbers (Cont.) 5kW 10kW 50/60 Hz – MEP 1030 50/60 Hz – MEP 1040

55. Model Numbers (Cont.) 15kW 50/60 Hz – MEP 1050 400 Hz – MEP 1051 30kW

56. Model Numbers (Cont.)
60 kW
50/60 Hz – MEP 1070
400 Hz – MEP 1071

57. Physical Characteristics

58. Physical Characteristics (Cont.)

59. Physical Characteristics (Cont.)

61. Advanced Mobile Medium Power Source (AMMPS)
CAPABILITIES
Advanced Mobile Medium Power Source (AMMPS)

62. The engine provides the mechanical energy to rotate the main generator.
5kW
3 cylinder .9L Kubota D902
10kW
3 cylinder, 1.5L Yanmar 3TNV84T
15kW
4 cylinder, 2.0L Yanmar 4TNV84T
30kW
4 cylinder, 3.3L Cummins QSB 3.3
60kW
4 cylinder, 4.5L Cummins QSB 4.5

63. Internal fuel assembly
Internal fuel Tank – Sized to allow 8 hours of 75% load.
24 VDC fuel pump
In line fuel filter
Fuel/water separator
Fuel Cooler (30 and 60 kW only)

64. Advanced Mobile Medium Power Source (AMMPS) Capabilities (Cont.)
SIZE
MODEL
MODE
HERTZ
FUEL
GAL
CONSUMPTION
5kW
MEP-1030
I - 50/60
3.8
.38 GPH
MEP-1031
II- 400
.42 GPH
10kW
MEP-1040
6.3
.61 GPH
MEP-1041
II - 400
.74 GPH
15kW
MEP 1050
8.6
.89 GPH
MEP-1051
1.01 GPH

65. Advanced Mobile Medium Power Source (AMMPS) Capabilities (Cont.)
SIZE
MODEL
MODE
HERTZ
FUEL
GAL
CONSUMPTION
30kW
MEP-1060
I - 50/60
16.7
1.8 GPH
MEP-1061
II - 400
2.07 GPH
60kW
MEP-1070
34.7
3.5 GPH
MEP-1071
3.99 GPH

66. External Fuel Assembly
Provides supply/ withdraw connection points.
24v DC fuel pump
In- line fuel filter
Pump activates at 75% fuel level
Deactivates at 100% fuel level

67. Alternating Current (AC) Generator Assembly
Converts rotating mechanical energy into electrical energy.
Refer to Table 5.

68. Digital Control System
Micro processor based control
6.5 inch Liquid Crystal Display
Powered by the generators 24VDC system
Provides limited remote operation capability

69. Output Box Assembly Located on right side of generator
Distributes electricity through output terminal board.

71. Demonstration

73. Summary Characteristics & Capabilities of Generators TQG MEP 831A
MEP 803A/813A
MEP 805B/815B
MEP 806B/ 816B
MEP 807A
AMMPS
MEP 1030/ 1031
MEP 1040/ 1041
MEP 1050/ 1051
MEP 1060/ 1061
MEP 1070/ 1071
