2. CA ERwin r8 installing the application things you should know before installing your CA ERwin r8 Data modeling application

3. welcome CA ERwin Data Modeler r8: Installing the Application Text-only option What we will cover Description of the CA ERwin r8 installation package What is different in r8 installation package? Prerequisites Running the install Installation options Technical notes

4. r8 is a new application CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 is a new application The CA ERwin Data Modeler r8 applications can coexist with all prior versions of CA ERwin Data Modeler From the installation perspective, ERwin Data Modeler r8 is totally unrelated to any prior installations of ERwin Data Modeler or Model Manager. Text-only option

5. r8 is a new application CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 is a new application It is installed to a different folder than previous versions Text-only option

6. r8 is a new application CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 is a new application It is installed to a different folder than previous versions Text-only option

7. r8 is a new application CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 is a new application It creates it’s own program group Text-only option

8. r8 is a new application CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 is a new application It creates it’s own program group Text-only option

9. r8 is a new application CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 is a new application It creates a new entry in Add or Remove Programs so it will not upgrade any earlier ERwin application Text-only option

10. r8 is a new application CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 is a new application It creates a new entry in Add or Remove Programs so it will not upgrade any earlier ERwin application Text-only option

11. no need to remove earlier versions CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 & r7 are happy together You can install CA ERwin Data Modeler without removing your earlier versions. You can then continue to use both applications on the same machine. Text-only option

12. r8 is a new application CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 is a new application CA ERwin r8 requires its own license It will not recognize licenses for r7 or any earlier versions Text-only option

13. note to users of Crystal Reports CA ERwin Data Modeler r8: Installing the Application If you have CA ERwin Data Modeler r7.3 with Crystal Reports If you have an existing installation of CA ERwin Data Modeler r7.3 and have installed the bundled version of Crystal Reports, do not remove your CA ERwin r7.3 application prior to installing r8. Doing so will remove you copy of Crystal Reports which you will then have to reinstall. Text-only option

14. several applications in one CA ERwin Data Modeler r8: Installing the Application Text-only option One Application—Many Jobs

15. one installation – multiple applications CA ERwin Data Modeler r8: Installing the Application CA ERwin Data Modeler r8 is all-inclusive The single CA ERwin Data Modeler r8 application combines in one package what has previously required multiple applications and, therefore, multiple installations. The single CA ERwin r8 installation can provide the functionality of: The ERwin Trial (Eval) and Community Editions (CE) CA ERwin Data Modeler CA ERwin Model Navigator CA ERwin Model Manager Text-only option

16. one installation – multiple applications CA ERwin Data Modeler r8: Installing the Application Licensing is the key With CA ERwin Data Modeler r8, the available features and functions are controlled through licensing. Although two machines may have identical installations of ERwin r8, the available applications may be entirely different depending upon the licenses available on each machine. Details on the new ERwin r8 licensing are documented separately. Text-only option

17. CA ERwin Model Manager & Data Modeler CA ERwin Data Modeler r8: Installing the Application This bears repeating… CA ERwin Model Manager is no longer a separate application When you have installed ERwin Data Modeler r8, you have installed ERwin Model Manager r8! There is no separate installation for CA ERwin Model Manager r8 All Model Manager administrative functions including: mart connectivity, mart creation, mart initialization are available through the single CA ERwin Data Modeler r8 application. The Model Manager administrative functions will be available only on those machines that have a special “Initializer” license. Text-only option

18. installing CA ERwin Data Modeler r8: Installing the Application Text-only option Running the Installation

19. before we get started… CA ERwin Data Modeler r8: Installing the Application CA ERwin r8 installation requirements Although no special privileges are required to use the ERwin r8, full Administrator privileges are required during the installation process. Because some local user information is created during the installation, it is best to logon as the primary ERwin Data Model user prior to invoking the installation. If the primary ERwin data modeler does not have sufficient privileges, the “Run As…” option may be used the local Administrator account. Please make sure that the target PC meets the minimum requirements for drive space, memory and performance (please see the Release Notes for details). Text-only option

20. the installation package CA ERwin Data Modeler r8: Installing the Application Text-only option The CA ERwin Data Modeler r8 installation The CA ERwin Data Modeler r8 installation is available is available as a executable (downloadable from the CA Support website) or from a DVD. If you’re using a DVD and have “Autorun” enabled, the installation will open when you insert the disk. For most users: locate and invoke the ERwin installation executable.

21. installing CA ERwin Data Modeler r8 CA ERwin Data Modeler r8: Installing the Application Text-only option Let’s install!

22. read & accept the End User’s License Agreement (EULA) CA ERwin Data Modeler r8: Installing the Application Text-only option After some initialization, you will be presented with the EULA

23. read & accept the End User’s License Agreement (EULA) CA ERwin Data Modeler r8: Installing the Application Text-only option After some initialization, you will be presented with the EULA You must scroll to the bottom to activate the “I agree” button.

24. provide your Customer Information CA ERwin Data Modeler r8: Installing the Application Text-only option Next you will be asked to provide your name and that of your organization.

25. optionally change the installation folder CA ERwin Data Modeler r8: Installing the Application Text-only option By clicking “Change…” you can select an alternate installation folder.

26. the custom setup dialog CA ERwin Data Modeler r8: Installing the Application Text-only option The Custom Setup dialog allows you to select which components are to be included in this installation.

27. the custom setup dialog CA ERwin Data Modeler r8: Installing the Application Text-only option Navigator users must select the Model Navigator component

28. the custom setup dialog CA ERwin Data Modeler r8: Installing the Application Text-only option Navigator users must select the Model Navigator component

29. ready to install CA ERwin Data Modeler r8: Installing the Application Text-only option Click “Install” to begin copying files to your machine.

30. installing… please wait CA ERwin Data Modeler r8: Installing the Application Text-only option The installation process will continue

31. finished! CA ERwin Data Modeler r8: Installing the Application Text-only option Click “Finish” to complete the installation process.

32. final notes CA ERwin Data Modeler r8: Installing the Application Text-only option Final Notes

33. the installation is complete CA ERwin Data Modeler r8: Installing the Application Text-only option CA ERwin Data Modeler r8 has been successfully installed! At this point, CA ERwin Data Modeler r8 will have been successfully installed. A temporary limited-license is provided with the initial installation. If you do not have a permanent license you may obtain one by contacting CA Licensing through CA Technical Support.

34. support.ca.com CA ERwin Data Modeler r8: Installing the Application Text-only option Support for CA ERwin Data Modeler is always available! Information on CA licensing—including how to obtain or upgrade an ERwin license—is always available on the internet through: http://support.ca.com When ERwin DM r8 is running, links to technical support resources are available through the Help menu item on the ERwin r8 toolbar.

35. technical information CA ERwin Data Modeler r8: Installing the Application Text-only option Silent installs and command-line options CA ERwin Data Modeler r8 installation is a “Basic MSI” installation package. It uses the standard Microsoft installer (msiexec.exe). It can be invoked from a command line. It will recognize all standard MSI command line arguments. CA ERwin Data Modeler r8 installation package can be installed silently using the standard MSI command-line parameters. For further details please refer to the Microsoft MSI documentation and the ERwin Data Modeler Implementation Guide.

36. thank you
