1. Formation of a Corrie

2. Small hollow on the north facing side of a hillside
Water enters cracks in the rock. when temperatures fall below zero the water freezes and expands putting huge amounts of pressure on the surrounding rock. When temperatures rise again the water melts releasing the pressure. This process is known as freeze-thaw. This weakens the surrounding rocks.

3. Snow begins to collect in the hollow, and soon turns to ice in the falling temperatures. As snow continues to fall, the ice overflows out of the hollow to form a glacier

4. Direction of Ice Movement
The glacier freezes onto the surrounding rocks, that have been weakened by freeze-thaw. As the glacier moves downhill due to gravity, it tears away these rocks. This process is known as Plucking
GLACIER

5. Huge amounts of rock are torn away from the hillside, leaving a huge hollow.

6. Rocks embedded within the glacier scrape against the rock surface, acting like sandpaper, smoothening the surface. This process is known as abrasion.

7. Original profile, before glaciation
After glaciation, a huge hollow in the hillside, called a corrie
After glaciation, a small mound of moraine is left, forming a lip

8. Often meltwater remains in the corrie, known as a tarn or corrie loch

10. Formation of a U-Shaped Valley

11. Before glaciation, U-Shaped valleys are V-Shaped river valleys.
Water enters cracks in the rock. When temperatures fall below zero the water freezes and expands putting huge amounts of pressure on the surrounding rock. When temperatures rise again the water melts releasing the pressure. This process is known as freeze-thaw. This weakens the surrounding rocks.

12. Snow and ice begin to move through the valley floor as a glacier.

13. The glacier freezes onto the surrounding rocks, that have been weakened by freeze-thaw. As the glacier moves downhill due to gravity, it tears away these rocks. This process is known as Plucking

14. Huge amounts of rock are torn away from the valley sides and base, leaving very steep sides and a flat base.

15. Rocks embedded within the glacier scrape against the rock surface, acting like sandpaper, smoothening the surface. This process is known as abrasion.

16. Original profile, before glaciation
After glaciation, a U-Shaped valley has been formed, with steep side walls and a flat base.

18. Name 3 similarities between the formation of a Corrie and the formation of a U-Shaped Valley
Freeze – Thaw Action
Plucking
Abrasion

19. Before Glaciation
During Glaciation
After Glaciation

21. Annotated diagrams may be used.
Task 1:
Using the information that you have just heard and your
notes, answer the following question;
Select one feature of glacial erosion
and explain the processes involved in the
formation of this feature.
Annotated diagrams may be used.
4 marks
