1. All rights reserved, property and © CAD Computer GmbH & Co.KG 2009

2. All rights reserved, property and © CAD Computer GmbH & Co.KG 2009 Installation steps for license server PC: 1.Install Net-DONGLE on your license server PC on the parallel printer port. 2.Install hlsw32.exe 3.Install aksmon32.exe 4.Start “AKS Monitor” 5.Add module 10081 6.Ready to access by remote clients. MCPS acquisition PC can be used as license server too. Hardlock server setup

3. All rights reserved, property and © CAD Computer GmbH & Co.KG 2009 Local DONGLE Module Address Local IP address Hardlock AKS Monitor

4. All rights reserved, property and © CAD Computer GmbH & Co.KG 2009 Button valid only for clients! Enables network search for dynamic client license key. Hardlock server must be installed on a computer which is accessible across the network. License server needs a special net DONGLE!! Enables MSERV client feature. These option is available for client and acquisition PC’s. Important: at least 1 acqui-sition PC with /MSERV option must be available. Only for demo purposes! Enables ERES mode in case of Master key or demo. (in demo mode only TESTDRV is supported) The environment variable HLS_IPADDR optimize the search via the TCP/IP protocol. SET HLS_IPADDR=xxx.xxx.xxx.xxx, MCPS Client settings

5. All rights reserved, property and © CAD Computer GmbH & Co.KG 2009 Connect to: PC_S1 at IP 192.168.2.10 PC_S2 at IP 192.168.2.20 Both notations are possible History buffer for online clients The number of data scans are downloaded from server at the time the online project is selected. MCPS Client settings

6. All rights reserved, property and © CAD Computer GmbH & Co.KG 2009 MCPS Client DA-server Example PC_S1 works as server and licence server MCPS Client DA-server Example PC_S1 works as server and licence server MCPS DA-server 1 + Licence server Options: /ONL X /Driver x /MSERV Local key + Hardlock-server key hostname: PC_S1 192.168.2.10 MCPS Client 1..x Options: if required /MATH x /SCRIPT … hostname: PC_C1 192.168.2.30 Search for network DONGLE is activated? Shared MCPS data files. Set directory “read only” for clients offline data access.

7. All rights reserved, property and © CAD Computer GmbH & Co.KG 2009 MCPS Client DA-server Example 2 server PC’s MCPS Client DA-server Example 2 server PC’s MCPS DA-server 1 Options: /Driver x /MSERV Local key hostname: PC_S1 192.168.2.10 MCPS DA-server 2 Options: /Driver x /MSERV Local key hostname: PC_S2 192.168.2.20 Works as normal acquisition PC and as client for PC_S2 Works as normal acquisition PC and as client for PC_S1

8. All rights reserved, property and © CAD Computer GmbH & Co.KG 2009 Open the MCPS remote project in the menu Project, Open from DA sever Select the remote computer and then choose the project. Several remote computers and projects are possible. Computer name Project name Client: Open remote online projects Client: Open remote online projects

9. All rights reserved, property and © CAD Computer GmbH & Co.KG 2009 Set default directory to MCPS data file location for easier access Open the MCPS remote history project in the menu Project, Open Choose the project and display data as trend or text. Client: Open remote historical projects Client: Open remote historical projects
