1. The history is cornerstone of the present time as well as challenge to the future Application of ZKL Bearings

2. ► ► ◄ ◄ Concrete Mixers

3. ► ► ◄ ◄

4. Railway Industry

6. Cross-split cylindrical roller bearing in “Sandvik, a. s. Chomutov” -outer diameter = 431.8 mm -inner diameter = 260 mm -width = 170mm -dynamic load rating = 1,135 kN -static load rating = 1,937 kN -mass = 86.5 kg -outer diameter = 431.8 mm -inner diameter = 260 mm -width = 170mm -dynamic load rating = 1,135 kN -static load rating = 1,937 kN -mass = 86.5 kg ► ► ◄ ◄ Steel Industry

8. Cross-split spherical roller bearing in mine “Nástup Tušimice, a. s.” -outer diameter = 1,000 mm -inner diameter = 750 mm -width = 360 mm -mass = 724 kg -outer diameter = 1,000 mm -inner diameter = 750 mm -width = 360 mm -mass = 724 kg ► ► ◄ ◄ Cross-split spherical roller bearing PLC 512-39 in mine “OKD Darkov” Mining Industry

9. Bearings for heavy gearboxes: 23072W33M, 23068W33M ► ► ◄ ◄ Heavy Industry

10. Historically Heaviest Roller Bearing in ZKL Brno Production 232/750CFC2 For mounting of butterfly gate DN 5400 of CKD Blansko – pumped- storage hydro-electric power plant Dalesice Bore750 mm Outer diameter1360mm Width475 mm Mass3070 kg 232/750CFC2 For mounting of butterfly gate DN 5400 of CKD Blansko – pumped- storage hydro-electric power plant Dalesice Bore750 mm Outer diameter1360mm Width475 mm Mass3070 kg The entire process from designing manufacture and assistance in installation materialized within 5 months Designed for maximum load and service life of 25 years of operation Energy Industry

11. Windmills Double row spherical roller bearings of new design are particularly suitable for mounting of main rotors of wind turbines Capacity to accommodate combined loads of radial and axial forces as well as of tilting moments Designed for maximum reliability and minimum maintenance Double row spherical roller bearings of new design are particularly suitable for mounting of main rotors of wind turbines Capacity to accommodate combined loads of radial and axial forces as well as of tilting moments Designed for maximum reliability and minimum maintenance

12. Thank you for your attention!!
