1. Smart PSS Associate Certified Class Dahua Security Certification
Overseas Business Center
本文旨在让对IPC不了解的客户做到，从原理，连接，操作，优势，方案等等全方位了解我们公司的IPC产品

2. Smart PSS Smart PSS Introduction Basic Function Introduction
Function and Operation
Specification
Smart PSS Extended

3. Smart PSS Introduction
What is Smart PSS？
Multiple Screen Supported
Analog
DVR
IP Camera
Switch
HDCVI
Smart PSS
IP Camera
NVR
Video Wall

4. Why Smart PSS? Smart PSS Smart PSS Introduction Various Devices
Supported
Stable
Easy of Use
Advanced Feature
Why Smart PSS?

5. Main Features Smart PSS Introduction Preview Audio E-Map PC-NVR
Playback
Alarm
Main Features
Video Wall
Device
Tour Task

6. Smart PSS Introduction
Menu
Basic Information
Basic
Extension
Settings

7. Smart PSS Smart PSS Introduction Basic Function Introduction
Function and Operation
Specification
Smart PSS Extended

8. Before Monitor – Easy to Add Device
Basic Function Introduction
Before Monitor – Easy to Add Device
Auto find & add devices in local network
Manual add device by:
IP address
DDNS domain
Import & Export devices to share devices on multiple clients
Connection status ……

9. Add Devices
Click icon in the settings pane, system goes to the device manager interface. Click refresh, the device that in the same ip segment with your pc will pop up, double click the device or click the box of the devices you want then click add to add devices
4.1 Before you import devices from P2P server, you need to register the P2P server website and sign up an account
4. Import from P2P server: click the button import, goes to the import interface, click From put in your user name and password of your account to import the devices you managed in P2P server.
2. Click Manual Add button, then input the corresponding information like device name、ip/domain name、user name and password and then click Add button.
3. Import from local disk: click the button import, goes to the import interface, then click button browse to choose the .xml file path, then click the file to add devices
4.2 login your account, and manage the devices that P2P function is enabled

10. Various Window Splits Basic Function Introduction
Up to 64*4 channels (for windows version)
Up to 36 channels (for MAC version)
Custom window mode to fit various monitor scene
Fish-eye overview
Fish-eye 360°
Corridor mode …
Full screen mode

11. Support to Group Device And Save Frequently Used Scene
Basic Function Introduction
Support to Group Device And Save Frequently Used Scene
Two modes to manage device and camera
Device mode – group devices to find what you want easily.
View mode - save frequently used scene as “view” and one-click to view them next time

12. Various Monitor & Control Function
Basic Function Introduction
Various Monitor & Control Function
Support real-time playback
Snapshot; Manual record;
Audio; Bidirectional talk
Digital-PTZ supported
Various fish-eye view mode
Stream type: main or extra stream
Image adjust: brightness…
Quick link to playback and camera setup

13. Playback –Record from Remote Device or Local PC
Basic Function Introduction
Playback –Record from Remote Device or Local PC
Search record & snapshot from:
Remote device
PC-NVR
Local snapshot & record
Two mode supported:
Time bar mode – search by time
Event mode – search by event
Support to export record:
Cut down and export
Export event

14. Smart PSS Smart PSS Introduction Basic Function Introduction
Function and Operation
Specification
Smart PSS Extended

15. Tour &Task
2. Click button to add task interface, then input task name, stay time. Click at the bottom of the interface to select window amount, and drag channel(s) on the right pane to the windows on the left pane
3. Click button to save current setup, and click to save current task setup and add more tasks at the same time
1. Click icon in the Settings pane, you can go to monitor tour interface
4. Click Preview button to go to the preview interface. Click at the bottom of the interface to enable the scheme

16. Account
3. If you want to login Smart PSS without username and password you can go to the GENERAL – Basic , enable the box
1. you can add/remove user and modify user name here
2. Input user name, password, and select a group from the dropdown list. Select corresponding rights and then click OK button

17. Alarm
3. Select the alarm type from the dropdown list and select a channel you want to set alarm scheme on the left pane; you can add it to the list on the right pane
1. Click the icon in the Settings pane,
you can go to alarm configuration interface
2. Click button, system goes to alarm sources setup interface, Here you can input a scheme name and some reference information
7. Click OK button, you can view the scheme information on the alarm setup interface
5. Click Period button on the left pane or click next button, you can go to the following interface
4. Click Alarm Link on the left pane or click next button, you can go to the following interface. Check the trigger channel and alarm output channel
6. Click after a date to set alarm activation period. There are six periods in one day

18. Alarm Log
3. Click the button , you can go to interface of alarm log, click the BACKUP button , you can backup the alarm log list.
3.1 What’s more, if you click the button under operation, you can output the alarm video
5. According the save path, open the log excel
1. Click LOG button
2. Choose the period and alarm type
4. Choose the log save path

19. Alarm Audio
Loop play
Fixed
1. Go to the interface GENERAL-Alarm prompt, choose the audios for different alarm types. And you can also choose audio play once or loop play
3. If you want to close the alarm audio, you can choose the link channels and choose the alarm process fixed then click ok button
2. When alarm happens, the link channels pop up the view, and alarm audio loop plays

20. E-map – Set and View Your Cameras on Map
5. If there are some hot zones that there have many cameras, you can set a detailed map for them, click the button , you will see a function bar , click add area.
3. Drag channel(s) on the right pane to the e-map on the left pane
1. Click Add map button
4. Buttons at the left top of the interface can zoom in, zoom out or move e-map. Double click a camera on the e-map, you can view video
2. Select e-map picture. You can input some reference information if necessary
6. Double click the icon , you can go to the hot zone map

21. PC-NVR – Use PC as NVR and Saving Cost
3. Click disk manager button on the left pane, select saved disk and then click
1. Click icon in the Settings pane, you can go the PC-NVR interface, then click add button
4. Set period information and type, set the corresponding time and then click OK button
2. Select a device and then check the record channels, click Save button

22. Smart PSS Smart PSS Introduction Basic Function Introduction
Function and Operation
Specification
Smart PSS Extended

23. Specification of Smart PSS
Max. Devices to Manager
256
Max. Channels to Manager
2000
Max. Groups to Manager
Max. accounts to Manager
128
Max. Windows of Live Preview Per Screen
64 for windows, 36 for MAC
Max. Screens of Live Preview
4 for windows, 1 for MAC
Max. Channels of Playback 36
Max. Tasks of Download 10
Max. Duration of Manual Record
30 min
Max. Channels of Free PC-NVR 16
Note: Client’s capacity is closely related to device’s ability and network.

24. Smart PSS Smart PSS Introduction Basic Function Introduction
Function and Operation
Specification
Smart PSS Extended

25. Several clients view the same camera with Smart PSS
Stream3
StreamN
Stream2
Stream1
Stream1
Client
Client

26. Stream Media Technology
DSS
Stream Media Technology
Several clients view the same camera with DSS
Client
Stream copy
Client
Stream1
Stream1
Stream1
Stream1
Stream1
Client
Smart Pss don’t support stream media and Audio/video data transfer, so it only support few customers to connect to the same DVR. But DSS can solve this problem.
Client

27. Specification of DSS Max. Devices to Manager 500
Max. Channels to Manager
2000
Max. Disks to Manager
16 (each up to 4T)
Max. accounts to Manager
10000
Max. online users to Manager
1000
Max. windows of Live Preview 36
Max. Channels of Playback
Max. IPSAN to Manager
5 (each up to 24pcs*4TB)
Max. Duration of Manual Record
30min
Max. E-map displays per screen
200-channels
Max. channels alarm per second procession
