1. JAVELIN

2. MAJOR COMPONENTS M98 FRONT M98A1 FRONT M98 REAR M98A1 REAR
COMMAND LAUNCH UNIT
(CLU)
M98
FRONT
M98A1
FRONT
M98
REAR
M98A1
REAR

3. MAJOR COMPONENTS
ROUND

4. CAPABILITIES & LIMITATIONS
LETHALITY
Dual Attack Mode (Top & Direct)
2000 Meter Maximum Effective Range
Tandem Shape Charged Warhead
Defeats Reactive Armor
Fire And Forget
Decreases Probability Of Gunner Error

5. CAPABILITIES & LIMITATIONS
MANEUVERABILITY
Man Portable
Total Weight Approx. = 49.5 lbs.
Shoulder Fired
Soft Launch
Can Be Fired From Inside Enclosures
Buildings Or Rooms Require 12’x15’x7’
Effective Frontal And Oblique Shots

6. CAPABILITIES & LIMITATIONS
SURVIVABILITY
Low Launch Signature Increases Gunner Survivability
All Gunner Engagement Tasks Accomplished Prior To Firing
Fire And Forget Allows Gunner To Displace Immediately
2000 Meter Stand Off Range
Passive Infrared System
Not Visible With Night Vision Devices

7. CAPABILITIES & LIMITATIONS
SURVIVABILITY (con’t)
CLU Offers Enhanced Surveillance And Observation
Can Detect Targets To 3000m
Cannot Identify Past 2000m
Low Back Blast Allows Firing From Beneath Overhead Cover And Inside Bunkers

8. CAPABILITIES & LIMITATIONS
FLEXIBILITY FOR COMMANDERS
Increased Medium A.T. Range
JAVELIN Compliments TOW
Allows Mutual Support And Greater Overlapping Fields Of Fire
Fills Void Past DRAGON’s 1000m
Allows Tow To Concentrate Fires At Maximum Range (3750 Meters Tow 2b)

9. JAVELIN vs. DRAGON JAVELIN DRAGON
SYSTEM TYPE FIRE & FORGET WIRE GUIDED
CARRY WEIGHT 49.5 lbs approx lbs approx.
CLU lbs day & night lbs day
integrated 36 lbs night
ROUND lbs lbs
CREW 2 MAN TEAM 2 MAN TEAM
RELOAD TIME LESS THAN 20 sec. TIME OF FLIGHT +20 sec.

10. JAVELIN vs. DRAGON JAVELIN DRAGON
COMPONENTS CLU, ROUND DAY SIGHT, THERMAL SIGHT, COOLANT BOTTLES, BATTERIES, ROUND
MISSLE MODE TOP / DIRECT DIRECT
GUIDANCE SYS. THERMAL SEEKER WIRE GUIDED
TIME OF FLIGHT 2000m  14.5 sec 1000m  10 sec
SIGHT 4x DAY 6x DAY
MAGNIFICATION 4x / 9x NIGHT 4x NIGHT

11. TRAINING EQUIPMENT Basic Skills Trainer (BST)
Indoor Trainer (Practice & Qual.)
Multiple Targets
React To Malfunctions

12. TRAINING EQUIPMENT Missile Simulation Round (MSR)
Replicates Size, Weight And Balance Of Actual Round
Maintain JAVELIN (Inspection)
Prepare / Restore JAVELIN
Demonstrate Proper Carry Techniques

13. TRAINING EQUIPMENT Field Tactical Trainer (FTT) Outdoor Trainer
Force On Force (FOF) Trainer
Integrated MILES Capability

14. PROPOSED
SUSTAINMENT TRAINING
IAW FM 23-37

15. AMUNITION TRAINING STRATEGY

16. LESSONS LEARNED

17. LESSONS LEARNED

18. LESSONS LEARNED

19. LESSONS LEARNED

20. LESSONS LEARNED

21. LESSONS LEARNED

23. POINTS TO PONDER Train As We Fight Develop Engagement Areas
Utilize Weapon System To Its Full Potential
Doctrine Is Constantly Evolving, Be Creative
