1 Electrical Stimulation Currents
Therapeutic Modalities Chapter 5

2 Electricity is an element of PT
Electricity is an element of PT. May be most frightening and least understood. Understanding the basic principles will later aid you in establishing treatment protocols.

3 Electromagnetic Radiations
Other Forms Of Radiation Other Than Visible Light May Be Produced When An Electrical Force Is Applied

4 Infrared Spectrum Red Orange Yellow Green Blue Violet Ultraviolet

5 Electromagnetic Radiations
In Addition, Other Forms Of Radiation Beyond Infrared And Ultraviolet Regions May Be Produced When An Electrical Force Is Applied These Radiations Have Different Wavelengths And Frequencies Than Those In The Visible Light Spectrum

6 Collectively The Various Types Of Radiation Form The Electromagnetic Spectrum

7 Electromagnetic Spectrum Electrical Stimulating Currents
Longest Wavelength Lowest Frequency Electrical Stimulating Currents Commercial Radio and Television Shortwave Diathermy Microwave Diathermy Infrared { LASER Visible Light Ultraviolet Shortest Wavelength Highest Frequency Ionizing Radiation

8 Wavelength And Frequency
Wavelength-Distance Between Peak Of One Wave and Peak of the Next Wave Frequency-Number Of Wave Oscillations Or Vibrations Per Second (Hz, CPS, PPS) Velocity=Wavelngth X Frequency

9 Electromagnetic Radiations Share Similar Physical Characteristics
Produced When Sufficient Electrical Or Chemical Forces Are Applied To Any Material Travel Readily Through Space At An Equal Velocity (300,000,000 meters/sec) Direction Of Travel Is Always In A Straight Line

10 Electromagnetic Radiations Share Similar Physical Characteristics
When Contacting Biological Tissues May Be…

11 Electromagnetic Radiations Share Similar Physical Characteristics
When Contacting Biological Tissues May Be… Reflected

12 Electromagnetic Radiations Share Similar Physical Characteristics
When Contacting Biological Tissues May Be… Reflected Transmitted

13 Electromagnetic Radiations Share Similar Physical Characteristics
When Contacting Biological Tissues May Be… Reflected Transmitted Refracted

14 Electromagnetic Radiations Share Similar Physical Characteristics
When Contacting Biological Tissues May Be… Reflected Transmitted Refracted Absorbed

15 Laws Governing The Effects of Electromagnetic Radiations
Arndt-Schultz Principle No Changes Or Reactions Can Occur In The Tissues Unless The Amount Of Energy Absorbed Is Sufficient To Stimulate The Absorbing Tissues

16 Laws Governing The Effects of Electromagnetic Radiations
Law Of Grotthus-Draper If The Energy Is Not Absorbed It Must Be Transmitted To The Deeper Tissues The Greater The Amount Absorbed The Less Transmitted and Thus The Less Penetration

17 Laws Governing The Effects of Electromagnetic Radiations
Cosine Law The Smaller The Angle Between The Propagating Radiation And The Right Angle, The Less Radiation Reflected And The Greater The Absorption Source Source

18 Laws Governing The Effects of Electromagnetic Radiations
Inverse Square Law The Intensity Of The Radiation Striking A Surface Varies Inversely With The Square Of The Distance From The Source Source 1 Inch 2 Inch

19 Electromagnetic Modalities
The Majority of Therapeutic Modalities Used By Athletic Trainers Emit A Type Of Energy With Wavelengths And Frequencies That Can Be Classified As Electromagnetic Radiations

20 Electromagnetic Modalities Include...
Electrical Stimulating Currents Shortwave And Microwave Diathermy Infrared Modalities Thermotherapy Cryotherapy Ultraviolet Radiation Therapy Low-Power Lasers Magnet Therapy

21

22 General Therapeutic Uses of Electricity
Controlling acute and chronic pain Edema reduction Muscle spasm reduction Reducing joint contractures Minimizing disuse/ atrophy Facilitating tissue healing Strengthening muscle Facilitating fracture healing

23 Contraindications of Electrotherapy
Cardiac disability Pacemakers Pregnancy Menstruation (over abdomen, lumbar or pelvic region) Cancerous lesions Site of infection Exposed metal implants Nerve Sensitivity

24 Terms of electricity Electrical current: the flow of energy between two points Needs A driving force (voltage) some material which will conduct the electricity Amper: unit of measurement, the amount of current (amp) Conductors: Materials and tissues which allow free flow of energy

25 Fundamentals of Electricity
Electricity is the force created by an imbalance in the number of electrons at two points Negative pole: an area of high electron concentration (Cathode) Positive pole: an area of low electron concentration (Anode)

26 Charge An imbalance in energy. The charge of a solution has significance when attempting to “drive” medicinal drugs topically via iontophoresis and in attempting to artificially fire a denervated muscle

27 Charge: Factors to understand
Coulomb’s Law: Like charges repel, unlike charges attract Like charges repel allow the drug to be “driven” Reduce edema/blood

28 Charge: Factors Membranes rest at a “resting potential” which is an electrical balance of charges. This balance must be disrupted to achieve muscle firing Muscle depolarization is difficult to achieve with physical therapy modalities Nerve depolarization occurs very easily with PT modalities

29 Terms of electricity Insulators: materials and tissues which deter the passage of energy Semiconductors: both insulators and conductors. These materials will conduct better in one direction than the other Rate: How fast the energy travels. This depends on two factors: the voltage (the driving force) and the resistance.

30 Terms of electricity Voltage: electromotive force or potential difference between the two poles Voltage: an electromotive force, a driving force. Two modality classification are: Hi Volt: greater than V Lo Volt: less than V

31 Terms of electricity Resistance: the opposition to flow of current. Factors affecting resistance: Material composition Length (greater length yields greater resistance) Temperature (increased temperature, increase resistance)

32 Clinical application of Electricity: minimizing the resistance
Reduce the skin-electrode resistance Minimize air-electrode interface Keep electrode clean of oils, etc. Clean the skin of oils, etc. Use the shortest pathway for energy flow Use the largest electrode that will selectively stimulate the target tissues If resistance increases, more voltage will be needed to get the same current flow

33 Clinical application of Electricity: Temperature
Relationship An increase in temperature increases resistance to current flow Applicability Preheating the tx area may increase the comfort of the tx but also increases resistance and need for higher output intensities

34 Clinical Application of Electricity: Length of Circuit
Relationship: Greater the cross-sectional area of a path the less resistance to current flow Application: Nerves having a larger diameter are depolarized before nerves having smaller diameters

35 Clinical Application of Electricity: Material of Circuit
Not all of the body’s tissues conduct electrical current the same Excitable Tissues Nerves Muscle fibers blood cells cell membranes Non-excitable tissues Bone Cartilage Tendons Ligaments Current prefers to travel along excitable tissues

36 Stimulation Parameter:
Amplitude: the intensity of the current, the magnitude of the charge. The amplitude is associated with the depth of penetration. The deeper the penetration the more muscle fiber recruitment possible remember the all or none response and the Arndt-Schultz Principle

37 Simulation Parameter Pulse duration: the length of time the electrical flow is “on” ( on vs off time) also known as the pulse width. It is the time of 1 cycle to take place (will be both phases in a biphasic current) phase duration important factor in determining which tissue stimulated: if too short there will be no action potential

38 Stimulation Parameter:
Pulse rise time: the time to peak intensity of the pulse (ramp) rapid rising pulses cause nerve depolarization Slow rise: the nerve accommodates to stimulus and a action potential is not elicited Good for muscle reeducation with assisted contraction - ramping (shock of current is reduced)

39 Stimulation Parameters
Pulse Frequency: (PPS=Hertz) How many pulses occur in a unit of time Do not assume the lower the frequency the longer the pulse duration Low Frequency: 1K Hz and below (MENS .1-1K Hz), muscle stim units) Medium frequency: 1K ot 100K Hz (Interferential, Russian stim LVGS) High Frequency: above 100K Hz (TENS, HVGS, diathermies)

40 Stimulation Parameter:
Current types: alternating or Direct Current (AC or DC) AC indicates that the energy travels in a positive and negative direction. The wave form which occurs will be replicated on both sides of the isoelectric line DC indicated that the energy travels only in the positive or on in the negative direction DC AC

41 Stimulation Parameter:
Waveforms; the path of the energy. May be smooth (sine) spiked, square,, continuous etc. Method to direct current Peaked - sharper Sign - smoother

42 Stimulation Parameter:
Duty cycles: on-off time. May also be called inter-pulse interval which is the time between pulses. The more rest of “off” time, the less muscle fatigue will occur 1:1 Raito fatigues muscle rapidly 1:5 ratio less fatigue 1:7 no fatigue (passive muscle exercise)

43 Stimulation Parameter:
Average current (also called Root Mean Square) the “average” intensity Factors effecting the average current: pulse amplitude pulse duration waveform (DC has more net charge over time thus causing a thermal effect. AC has a zero net charge (ZNC). The DC may have long term adverse physiological effects)

44 Stimulation Parameter:
Current Density The amount of charge per unit area. This is usually relative to the size of the electrode. Density will be greater with a small electrode, but also the small electrode offers more resistance.

45 Capacitance: The ability of tissue (or other material) to store electricity. For a given current intensity and pulse duration The higher the capacitance the longer before a response. Body tissues have different capacitance. From least to most: Nerve (will fire first, if healthy) Muscle fiber Muscle tissue

46 Capacitance: Increase intensity (with decrease pulse duration) is needed to stimulate tissues with a higher capacitance. Muscle membrane has 10x the capacitance of nerve

47 Factors effecting the clinical application of electricity
Factors effecting the clinical application of electricity Rise Time: the time to peak intensity The onset of stimulation must be rapid enough that tissue accommodation is prevented The lower the capacitance the less the charge can be stored If a stimulus is applied too slowly, it is dispersed

48 Factors effecting the clinical application of electricity
An increase in the diameter of a nerve decreased it’s capacitance and it will respond more quickly. Thus, large nerves will respond more quickly than small nerves. Denervated muscles will require a long rise time to allow accommodation of sensory nerves. Best source for denervated muscle stimulation is continuous current DC

49 Factors effecting the clinical application of electricity:
Ramp: A group of waveforms may be ramped (surge function) which is an increase of intensity over time. The rise time is of the specific waveform and is intrinsic to the machine.

50 Law of DuBois Reymond: The amplitude of the individual stimulus must be high enough so that depolarization of the membrane will occur. The rate of change of voltage must be sufficiently rapid so that accommodation does not occur The duration of the individual stimulus must be long enough so that the time course of the latent period (capacitance), action potential, and recovery can take place

51 Muscle Contractions & Frequency
Are described according to the pulse width 1 pps = twitch 10 pps = summation 25-30 pps = tetanus (most fibers will reach tetany by 50 pps) Frequency selection: 100Hz - pain relief 50-60 Hz = muscle contraction 1-50 Hz = increased circulation The higher the frequency (Hz) the more quickly the muscle will fatigue

52 Frequency selection: 100Hz - pain relief 50-60 Hz = muscle contraction
1-50 Hz = increased circulation The higher the frequency (Hz) the more quickly the muscle will fatigue

53 Electrodes used in clinical application of current:
Electrodes used in clinical application of current: At least two electrodes are required to complete the circuit The body becomes the conductor Monophasic application requires one negative electrode and one positive electrode The strongest stimulation is where the current exists the body Electrodes placed close together will give a superficial stimulation and be of high density

54 Electrodes used in clinical application of current:
Electrodes spaced far apart will penetrate more deeply with less current density Generally the larger the electrode the less density. If a large “dispersive” pad is creating muscle contractions there may be areas of high current concentration and other areas relatively inactive, thus functionally reducing the total size of the electrode A multitude of placement techniques may be used to create the clinical and physiological effects you desire

55 General E-Stim Parameters

56 E-Stim for Pain Control: typical Settings

57 High Volt Pulsed Stimulation

58 CURRENT CONCEPTS EVIDENCE BASED
ES increased 20% verses control (no activity) demonstrating that ES “can alter the blood flow in muscle being stimulated” Currier et all 1996 Currier et al 1988: Similar study but 15% Bettany et al 1990: Edema formation in frogs decreased with HVPC 10 minutes after the trauma

59 CURRENT CONCEPTS EVIDENCE BASED
Walker et al 1988: HVS at a pulse rate of 30 Hz and intensities to evoke 10% - 20% MVC did not increase blood flow to the popliteal artery. The exercise group demonstrated 30% increase Von Schroeder et al 1991: Femoral venous flow shown to increase greatest with passive SLR elevation, then CPM, active ankle dorsiflexion, manual calf compression and passive dorsiflexion

60 HVPS The application of monophasic current with a known polarity
typically a twin-peaked waveform duration of msec Wide variety of uses: muscle reeducation (requires 150V) nerve stimulation (requires 150V) edema reduction pain control

61 Clinical Application:
Physiological response can be excitatory and non-excitatory Excitatory Peripheral nerve stimulation for pain modulation (sensory, motor and pain fibers) Promote circulation: inhibits sympathetic nervous system activity, muscle pumping and endogenous vasodilatation Non-Excitatory (cellular level) Protein synthesis Mobilization of blood proteins Bacteriocyte affects (by increased CT micro-circulation there is a reabsorption of the interstitial fluids) Setting the ES with no twitch has purpose

62 General Background Early in history HVS was called EGS (electrical galvanic stimulation), then HVGS, then HVPS Current qualifications to be considered HVS Must have twin peak monophasic current Must have 100 or 150 volts (up to 500 V)

63 HVPS Precautions Contraindications Indications
Stimulation may cause unwanted tension on muscle fibers Muscle fatigue if insufficient duty cycle Improper electrodes can burn or irritate Intense stim may result in muscle spasm or soreness Contraindications Cardiac disability Pacemakers Pregnancy Menstruation Cancerous lesion Infection Metal implants Nerve sensitivity Indications past slide

64 Treatment Duration General - 15-30 minutes repeated as often as needed
Pain reduction - sensory 30 minutes with 30 minute rest between tx

65 Current Parameters greater than 100-150 V usually provides up to 500 V
high peak, low average current strength duration curve = short pulse duration required higher intensity for a response high peak intensities (watts) allow a deeper penetration with less superficial stimulation

66 Current Parameters Pulse Rate: Modulations Pulse Charge
ranges from pps varies according to the desire clinical application Current Pulse Charge related to an excess or deficiency of negatively charged particles associated with the beneficial or harmful responses (thermal, chemical, physical) Modulations intrapulse spacing duty cycle: reciprocal mode usually 1:1 ratio ramped or surged cycles Clinical Considerations: always reset intensity after use (safety) electrode arrangements may be mono or bipolar units usually have a hand held probe for local (point) stimulation most units have an intensity balance control

67 Application Techniques
Monopolar: 2 unequal sized electrodes. Smaller is generally over the treatment site and the large serves as a dispersive pad, usually located proximal to the treatment area Bipolar: two electrodes of equal size, both are over or near the treatment site Water immersion - used for irregularly shaped areas Probes: one hand-held active lead advantages: can locate and treat small triggers disadvantages: one on one treatment requires full attention of the trainer

68 Electrodes Material carbon impregnated silicone electrodes are recommended but will develop hot spots with repeated use you want conductive durable and flexible material tin with overlying sponge has a decreased conformity and reduced conductivity

69 Electrodes Size based on size of target area
current density is important. The smaller the electrode size the greater the density

70 Neuromuscular Stimulation
Roles: re-educate a muscle how to contract after immobilization (does not produce strength augmentation but retards atrophy)

71 Pain Control Roles: Control acute or chronic pain both sensory (gate control pps)) and motor level (opiate release - through voltage)

72 Pain Control - Opiate Release Setting

73 Evidence Based Clinical Studies on HVPC and pain modulation is misleading – pain associated with muscle spasm is decreased secondary to muscle fatigue/exhaustion (Belanger, 2003) Studies on muscle strengthening have indicated no effect (Alon 1985, Mohr et al, 1985; Wong 1986)

74 Control and Reduction of Edema
Roles: Sensory level used to limit acute edema Motor-level stimulation used to reduce subacute or chronic inflammation

75 Motor-Level Edema Reduction
Cell Metabolism: increased and may increase blood flow Wound Healing: May increase collagnase levels and inhibit bacteria in infected wounds (for this effect 20 min - polarity followed by 40 min + polarity recommended)

76 Russian Current Continuous sine-wave modulation of 2,5000 pps and burst-modulated for fixed periods of 10 msec resulting in a frequency of 50 bursts per second. Thought to depolarize both sensory and motor concomitantly (knots 1977). Thus simulating muscle training. No North American has been able to duplicate Knots’ claims

77 T.E.N.S.

78 General Concepts: An Approach to pain control
Trancutaneous Electrical Nerve Stimulation: Any stimulation in which a current is applied across the skin to stimulate nerves 1965 Gate Control Theory created a great popularity of TENS TENS has 50-80% efficacy rate TENS stimulates afferent sensory fibers to elicit production of neurohumneral substances such as endorphins, enkephalins and serotonin (i.e. gate theory)

79 TENS Indications Precautions Control Chronic Pain
Management post-surgical pain Reduction of post-traumatic & acute pain Precautions Can mask underlying pain Burns or skin irritation prolonged use may result in muscle spasm/soreness caffeine intake may reduce effectiveness Narcotics decrease effectiveness Research is variable regarding the benefits of TENS Therapy (see Table 2-2; Belanger, 2001)

80 TENS may be: high voltage interferential acuscope
low voltage AC stimulator classical portable TENS unit

81 Biophysical Effects Primary use is to control pain through Gate Control Theory (between 0-100% can be placebo effect (Thorsteinsson et al., 1978, Wall,1994) Opiate pain relief through stimulation of naloxone (antagonist to endogenous opiates) May produce muscle contractions Various methods High TENS (Activate A-delta fibers) Low TENS (release of -endorphins from pituitary) Brief-Intense TENS (noxious stimulation to active C fibers)

82 Techniques of TENS application:
Conventional or High Frequency Short Duration , high frequency and low to comfortable current amplitude Only modulation that uses the Gate Control Theory (opiate all others) Acupuncture or Low Frequency Long pulse duration, Low frequency and low to comfortable current amplitude Brief Intense Long pulse duration, high frequency, comfortable to tolerable amplitude Burst Mode Burst not individual pulses, modulated current amplitude Modulated Random electronic modulation of pulse duration, frequency and current amplitude

83 Protocol for Various Methods of TENS

84 Conventional Tens/High Frequency TENS
Paresthesia is created without motor response A Beta filers are stimulated to SG enkephlin interneuron (pure gate theory) Creates the fastest relief of all techniques Applied 30 minutes to 24 hours relief is short lives (45 sec 1/2 life) May stop the pain-spasms cycle

85 Application of High TENS
Pulse rate: high Hz (generally 80), constant Pulse width: narrow, less than 300 mSec generally 60 microSec Intensity: comfortable to tolerance

86 Set up: 2 to 4 electrodes, often will be placed on post-op. Readjust parameters after response has been established. Turn on the intensity to a strong stimulation. Increase the pulse width and ask if the stimulation is getting wider (if deeper=good, if stronger...use shorter width)

87 Low Frequency/Acupuncture-like TENS:
Level III pain relief, A delta fibers get Beta endorphins Longer lasting pain relief but slower to start Application pulse rate low 1-5ppx (below 10) Pulse width: microSec Intensity: strong you want rhythmical contractions within the patient’s tolerance

88 Burst Mode TENS Carrier frequency is at a certain rate with a built in duty cycle Similar to low frequency TENS Carrier frequency of Hz packaged in bursts of about 7 bursts per second Pulses within burst can vary Burst frequency is 1-5 bursts per second Strong contraction at lower frequencies Combines efficacy of low rate TENS with the comfort of conventional TENS

89 Burst Mode TENS - Application
Pulse width: high microSec Pulse rate: pps modulated to 1-5 burst/sec Intensity: strong but comfortable treatment length: minutes

90 Brief, Intense TENS: hyper-stimulation analgesia
Stimulates C fibers for level II pain control (PAG etc.) Similar to high frequency TENS Highest rate (100 Hz), 200 mSec pulse width intensity to a very strong but tolerable level Treatment time is only 15 minutes, if no relief then treat again after 2-3 minutes Mono or biphasic current give a “bee sting” sensation Utilize motor, trigger or acupuncture points.

91 Brief Intense TENS - Application
Pulse width: as high as possible Pulse rate: depends on the type of stimulator Intensity: as high as tolerated Duration: 15 minutes with conventional TENS unit. Locus stimulator is advocated for this treatment type, treatment time is 30 seconds per point.

92 Locus point stimulator
Locus (point) stimulators treatment occurs once per day generally 8 points per session Auricular points are often utilized Treat distal to proximal Allow three treatment trails before efficacy is determined Use first then try other modalities

93 Modulated Stimulation:
Keeps tissues reactive so no accommodation occurs Simultaneous modulation of amplitude and pulse width As amplitude is decreased, pulse width is automatically increased to deliver more consistent energy per pulse Rate can also be modulated

94 Electrode Placement: May be over the painful sites, dermatomes, myotomes, trigger points, acupuncture points or spinal nerve roots. May be crossed or uncrossed (horizontal or vertical

95 Contraindications: Demand pacemakers over carotid sinuses Pregnancy
Cerebral vascular disorders (stroke patients) Over the chest if patient has any cardiac condition

96 Interferential Current - IFC

97 Interferential Current
History: In 1950 Nemec used interference of electrical currents to achieve therapeutic benefits. Further research and refinements have led to the current IFC available today Two AC are generated on separate channels (one channel produces a constant high frequency sine wave ( Hz) and the other a variable sine wave The channels combine/interface to produce a frequency of Hz (medium frequency) Evidence Based: Although IFC has been used for 40 years, only a few clinical studies have been published regarding use (DeDomenico, 1981,1987; Savage, 1984; Nikolova, 1987).

98 Effects of IFC treatment:
Primary Physiological Effect: Capacity of IFC to depolarize Sensory and motor nerve fibers Main Therapeutic Effects Sensory nerve fibers - Pain reduction - receive a lower amplitude stimulation than the area of tissue affected by the vector, thus IFC is said to be more comfortable than equal amplitudes delivered by conventional means Blood flow/edema management Muscle fatigue - muscle spasm - is reduced when using IFC versus HVS due to the asynchronous firing of the motor units being stimulated

99 Positive effects of IFC include:
reduction of pain and muscle discomfort following joint or muscle trauma these effects can be obtained with the of IFC and without associated muscle fatigue which may predispose the athlete to further injury.

100 Evidence Based Research
Low frequency This has been claimed as the key to IFC (Savage, 1984, Nikolova, 1987) Palmer, 1999: IFC unlikely to produce physiological and therapeutic effects different from those achieved by TENS Alon, 1999 states that IFC simply provides a more expensive, different, least effective and somewhat redundant approach to achieving the same effects as other electrical stimulation parameters/waveforms Pain sensation: Although the physiological changes are not different with IFC, Pain perception is decreased with IFC (Palmer, 1999)

101 Evidence Based Literature:
IFC does not lower skin impedance (Alon, 1999; Gerleman et al, 1999) Any pulsed biphasic current, regardless of waveform, having a medium frequency are capable of a deeper stimulating effect (Alon, 1999; Hayes, 2000; Kloth, 1991;) Snyder-Mackler, et al 1989) Increased Circulation is an anecdotal claim and has not been recreated in studies (Bersglien et al, 1988; Indergand et al.k 1995; Johnson, 1999; Nusswbaum et al., 1990: Olson et al., 1999) Analgesic Effect: Similar not superior to other stimulations (TENS) (DeDomenico, 1982, 1987; Nikolova, 1987; Savage, 1984) Stephenson et al., 1995: Superior to a control group with ice/pain Cramp et al., 2000: Failed to demonstrate any effective pain relief with IFC

102 Principles of wave interference - Combined Effects
Constructive, Destructive, & Continuous Constructive interference: when two sinusoidal waves that are exactly in phase or one, two, three or more wavelengths our of phase, the waves supplement each other in constructive interference = +

103 Principles of wave interference - Combined Effects
Destructive interference: when the two waves are different by 1/2 a wavelength (of any multiple) the result is cancellation of both waves = +

104 Principles of wave interference - Combined Effects
Continuous Interference Two waves slightly out of phase collide and form a single wave with progressively increasing and decreasing amplitude = +

105 Amplitude-Modulated Beats:
Rate at which the resultant waveform (from continuous interference) changes When sine waves from two similar sources have different frequencies are out of phase and blend (heterodyne) to produce the interference beating effect

106 IFC Duration of tx 15-20 minutes Precautions Contraindications
Burst mode typically applied 3x a week in 30 minute bouts Precautions same as all electrical currents Contraindications Pain of central origin Pain of unknown origin Indications Acute pain Chronic pain Muscle spasm

107 IFC Techniques of treatment:
Almost exclusively IFC is delivered using the four-pad or quad-polar technique. Various electrode positioning techniques are employed: Electrodes (Nemectrody: vacuum electrodes): four independent pads allow specific placement of pads to achieve desired effect an understanding of the current interference is essential four electrodes in one applicator allows IFC treatment to very small surface areas. The field vector is pre-determined by the equipment

108 Quad-polar Technique Pads placed at 45º angles from center of tx area
Can reduce inaccuracy of appropriate tissues by selecting rotation or scan Channel B Channel B Channel A SCAN Channel A

109 Bipolar Electrode Placement
The mix of two channels occurs in generator instead of tissues Biopolar does not penetrate tissues as deeply, but is more accurate When effects are targeted for one muscle or muscle group only one channel is used

110 Two-circuit IFC: At other points along the time axes the wave amplitude will be zero because the positive phase from one circuit cancels the negative phase from the second circuit (destructive interference) The rhythmical rise and fall of the amplitude results in a beat frequency and is equal to the number of times each second that the current amplitude increases to its maximum value and then decreases to its minimum value

111 Special Modulations of IFC:
Constant beat frequencies (model): the difference between the frequencies of the two circuits is constant and the result is a constant beat frequency. That is, if the difference in frequency between the two circuits is 40 pps, the beat frequency will be constant at 40 bps.

112 Special Modulations of IFC:
Variable beat mode: the frequency between the two circuits varies within preselected ranges. The time taken to vary the beat frequency through any programmed range is usually fixed by the device at about 15 sec. IFC machines often allow the clinician to choose from a variety of beat frequency programs.

113 Pain Control Similar to TENS - beat frequency 100Hz
Low beat frequencies when combined with motor level intensities (2-10Hz) initiate the release of opiates 30 Hz frequencies affects the widest range of receptors

114 Neuromuscular Stimulation
Beat frequency of approximately 15 HZ is used to reduce edema General Parameters

115 IFC Technique of treatment:
Electrode placement: The resultant vector should be visualized in placing the electrodes for a treatment . The target tissue should be identified and the vector positioned to hit that area. Typically at 45º angles is most effective. Segregation of the pin tips is essential in the proper electrode positioning for IFC. The electrodes may be of the same size or two different sizes (causing a shift in the intersecting vector). Treatment through a joint has also been advocated without adequate research to establish efficacy of the treatment technique.

116 Bone Stimulating Current:
Bone Stimulating Current:Bone Stimulating Current:IFC has been used (Laabs et al) studied the healing of a surgically induced fracture in the forelegs of sheep. Their study indicated an acceleration of healing in the sheep treated with IFC as compared to the control group

117 Bone Stimulating Current:
This study validated an earlier study by Gittler and Kleditzsch which showed similar results in callus formation in rabbits. Several other studies have shown an increase in the healing rate of fractures but the exact mechanism by which the healing occurs is not understood.

118 Bone Stimulating Current:
Some speculation is that an increased blood flow to the injured area is produced which allowed natural healing processes to occur more rapidly. In one study (mandible fractures ) the IFC caused very mild muscle contraction of the jaw and this muscle activity was thought to have been a potential accelerator of the healing.

119 MENS or LIDC (low-intensity direct current)

120 MENS No universally accepted definition or protocol & has yet to be substantiated This form of modality is at the sub-sensory or very low sensory level current less than 1000A (approx 1/1000 amp of TENS) Theorized that this is the current of injury (Becker et al 1967, Becker & Seldon, 1987)

121 Biophysical Effects Theory:
Currents below 500A increases the level of ATP (high Amp decreases ATP levels) Increase in ATP encourages amino acid transport and increased protein synthesis MENS reestablishes the body’s natural electrical balance allowing metabolic energy for healing without shocking the system (other types of e-stim) Studies conducted indicate no difference from control group for wound healing

122 MENS Indications Acute & Chronic Pain Acute & Chronic Inflammation
Duration 30 min to 2 hours up to 4x a day Research suggests high degree of variability on tx protocols Precautions Dehydrated patients on Scar tissue (too much impedance) Contraindications Pain of unknown origin Osteomyelitis Inconclusive Data: DOMS as an indication (Allen et al 1999, Weber et al 1994) Indications Acute & Chronic Pain Acute & Chronic Inflammation Edema reduction sprains & Strains Contusion TMJ dysfunction Neuropathies Superficial wound healing Carpal Tunnel Syndrome

123 Electrode Placement Electrodes should be placed in a like that transects the target tissues Remember that electrical current travels in path of least resistance, thus it is not always a straight line. Either the + or – electrode can be placed on the injured tissue (Research is inconclusive: Lampe 1998, Sussmen et al 1999) Suggest alternating + and - electrode TARGET

124 Application Techniques
Standard electrical stimulation pads generator may have bells & Whistles since MENS is sub-sensory Probe

125 Bone Stimulating Current:
MENS Has been advocated in the healing of bone, using implanted electrodes and delivering a DC current with the negative pole at the fracture site. Further use of MENS has allowed increased rate of fracture healing using surface electrodes in a non-invasive technique. Theories on the physiology behind the healing focus on the electrical charge present in the normal tissue as compared to the electrical charge found with the injured tissue. MENS is said to allow an induction of an electrical charge to return to he tissues to a better “healing” environment Research on bone stimulating current is inconclusive.

126 Microcurrent Electrical Stimulation
Tissue & Bone Healing

127 Electrical Stimulation
Physiological effect of electrical currents on nonexcitable tissue for tissue repair in its various forms: (a) improvement of vascular status, (b) edema control, (c) wound healing, (d) osteogenesis

128 Current of Injury (Theory)
Wounds are initially positive with respect to surrounding tissue This positive polarity triggers the onset of repair processes Maintaining this positive polarity would potentiate healing “Anode over the wound” was suggested by most of the previous studies Anode (+) Cathode (-)

129 Electrical Stimulation for Tissue Repair
Wound healing is also impeded by infection Electrical stimulation using the negative lead of a DC generator has been shown in culture and in vivo either to be bacteriostatic or to retard the growth of common gram+ and gram- microorganisms

130 Electrical Stimulation for Tissue Repair
There is no evidence for the effectiveness of sub-sensory-level stimulation for the healing of open wound

131 Electrical Stimulation for Bone Healing
The “current of injury” theory for bone: a relative negativity of the injured tissue with respect to the uninjured.

132 Electrical Stimulation for Bone Healing
The three best-studied and most commonly used techniques are (a) Cathodal placement in the fracture site and anodal placement on the skin at some distance. (b) Implantation of the entire system (c) The use of pulsed electromagnetic fields (PEMFs)

133 Electrical Stimulation for Bone Healing
PEMFs is the use of inductive coils to the skin or cast to deliver an asymmetrical, biphasic pulse at a frequency of about 15 pps. Semiinvasive DC, totally invasive DC, and PEMF were the only FDA-approved (and physician administered) osteogenic means.

134 Electrical Stimulation for Bone Healing
60 Hz sinusoidal AC, pulsed current, and interference modulations of higher-frequency alternating currents are also being used.

135 Electrical Stimulation
Treatment Strategies

136 HVPS: Neuromuscular Stimulation
Output Intensity Strong, intense, comfortable contractions. Pulse frequency If duty cycle cannot be adjusted: Low for individual muscle contractions (<15 pps). Adjustable duty cycle: Moderate for tonic contractions (>50 pps). Duty Cycle Initial treatments should begin with a low (e.g, 20%) duty cycle and be increased as the muscle responds. Electrode placement Bipolar: Proximal and distal to the muscle (or muscle group) to be stimulated. This method offers the most direct method of stimulating specific areas. Monopolar: Over motor points or muscle belly. Place the cathode over motor points Bipolar electrode arrangement

137 HVPS: Sensory-level Pain Control
Output Intensity Sensory level Pulse frequency 60 to 100 pps Phase duration <100 µsec* Mode Continuous Electrode arrangement Monopolar or bipolar Polarity Acute: Positive Chronic: Negative Electrode placement Directly over or surrounding the painful site * Not adjustable on most HVPS units.

138 HVPS: Motor-level Pain Control
Output Intensity Motor level Pulse rate 2–4 pps Phase duration 150–250 µsec Mode Continuous Electrode arrangement Monopolar or bipolar Polarity Acute: positive Chronic: Negative Electrode placement Directly over the painful site, distal to the spinal nerve root origin, trigger points, or acupuncture points

139 HVPS: Brief-Intense Pain Control Protocol
Output Intensity Noxious Pulse rate >120 pps Phase duration 300 to 1000 µsec Mode Probe 15 to 60 sec at each site Electrode arrangement Monopolar (probe) Polarity Acute: Positive Chronic: Negative Probe placement Gridding technique, stimulating hypersensitive areas working from distal to proximal

140 HVPS: Sensory-level Edema Control
Intensity: Sensory level Pulse duration: Maximum possible duration Pulse frequency: 120 pps. Polarity: Negative electrodes over injured tissues Mode: Continuous Electrode placement: The immersion method should be used when possible, or the active electrodes should be grouped over and around the target tissues. Treatment duration Four 30-minute treatments, followed by 60-minute rest periods or Four 30-minute treatments, each followed by 30-minute rest periods. Comments Start treatment as soon as possible after the trauma. The body part should be wrapped and elevated between sessions. This treatment regimen should not performed if gross swelling is present. Anode (+) Cathode (-)

141 HVPS: Edema Reduction Intensity: Strong, yet comfortable muscle contraction Avoid contraindicated joint motio Pulse frequency: Low Polarity: Positive or negative. Mode: Alternating. Electrode placement Bipolar: Proximal and distal ends of the muscle group proximal to the edematous area. Monopolar: Active electrodes follow the course of the venous return system. Comment: Ice may be applied to the injured area, but this could impede venous return by increasing the viscosity of fluids in the area

142 IFS: Sensory-level Pain Control
Carrier Frequency: Based on patient comfort Burst Frequency: 80 to 150 Hz Sweep: Fast Electrode Arrangement: Quadripolar Electrode Placement: Around the periphery of the target area Output Intensity: Strong sensory level Treatment Duration: 20 to 30 minutes

143 Premodulated Neuromuscular Stimulation
Carrier Frequency: 2500 Hz Burst Frequency: 30 to 60 bps Burst Duty Cycle: 10 percent Cycle Duration: 400 µsec On/off Duty Cycle: 10:50 sec Ramp: 2 sec Electrode Placement: Bipolar: Proximal and distal ends of the muscle Output Intensity: Strong muscle contraction. Discomfort may be experienced Treatment Duration: 10 cycles or until fatigue occurs


Download ppt "Electrical Stimulation Currents"

Similar presentations


Ads by Google
