1 Fractures and dislocations of the wrist Dr Ihab Rassem Lecturer of radiology Ain Shams University Cairo, Egypt

2 Radiographic views Dorsovolar (PA) Dorsovolar (PA) Lateral Lateral Dorsovolar with ulnar deviation (scaphoid) Dorsovolar with ulnar deviation (scaphoid) Supinated oblique (pisiform, pisotriquetral joint) Supinated oblique (pisiform, pisotriquetral joint) Pronated oblique (triquetral) Pronated oblique (triquetral) Carpal tunnel (hook of hamate, pisiform, volar trapezium) Carpal tunnel (hook of hamate, pisiform, volar trapezium)

3

4

5 Dorsovolar with ulnar deviation

6 Supinated oblique

7 Pronated oblique view

8 Carpal Tunnel view

9 Carpal bones fractures

10 Scaphoid fracture Most common carpal bone to be fractured Most common carpal bone to be fractured Age Age Fall on outstretched arm Fall on outstretched arm Classification Classification Distal pole and tubercle 5-10% Distal pole and tubercle 5-10% Proximal pole 15-20% (nonunion & AVN) Proximal pole 15-20% (nonunion & AVN) Waist 70-80% Waist 70-80%

11

12 Scaphoid fracture

13

14 PA PA with ulnar deviation

15 Nonunited scaphoid fracture

16 Scaphoid fracture seen in MRI

17 AVN of scaphoid

18 Fracture of triquetral Usually a subtle fracture Usually a subtle fracture Best seen in the lateral or pronated oblique view. Best seen in the lateral or pronated oblique view.

19

20

21

22

23 Hamate fractures Usually arise due to direct blow to the volar aspect of the wrist Usually arise due to direct blow to the volar aspect of the wrist Two types Two types Fracture of the hook (hamulus) of hamate: Fracture of the hook (hamulus) of hamate: Fracture of the body of hamate Fracture of the body of hamate Hook of hamate is seen in dorsovolar view as a cortical ring. Absence, indistinctness, or sclerosis of this ring suggests hamulus fracture (eye sign) Hook of hamate is seen in dorsovolar view as a cortical ring. Absence, indistinctness, or sclerosis of this ring suggests hamulus fracture (eye sign) Carpal tunnel view is also helpful may may be difficult due to pain Carpal tunnel view is also helpful may may be difficult due to pain

24

25

26

27 Fracture of pisiform bone Rare Rare Results from fall on the outstretched hand or use of the hand as a hammer to strike an object Results from fall on the outstretched hand or use of the hand as a hammer to strike an object May be isolated or co-exist with other bone fractures May be isolated or co-exist with other bone fractures Best seen in supinated oblique or carpal tunnel view Best seen in supinated oblique or carpal tunnel view

28

29 Fractrue of the capitate Results from fall on outstretched hands or form direct blow Results from fall on outstretched hands or form direct blow Usually associated with other carpal bone injuries particularly scaphoid fracture and perilunate dislocation Usually associated with other carpal bone injuries particularly scaphoid fracture and perilunate dislocation Waist (neck) of capitate is the most common site Waist (neck) of capitate is the most common site

30 PA view Tomogram

31

32 Fracture of the lunate bone Usually result from fall on the dorsiflexed wrist or ecessive push on the heal of the hand Usually result from fall on the dorsiflexed wrist or ecessive push on the heal of the hand Often associated with perilunate dislocation. Often associated with perilunate dislocation. More commonly occur as a pathologic fracture in the setting of Kienböck disease More commonly occur as a pathologic fracture in the setting of Kienböck disease

33 Kienböck Disease Avascular necrosis of the lunate bone, Avascular necrosis of the lunate bone, May be related to repeated trauma May be related to repeated trauma May be related to negative ulnar variance May be related to negative ulnar variance Classification Classification Stage I: radiograph normal, transverse linear fracture on tomography Stage I: radiograph normal, transverse linear fracture on tomography Stage II: increased density with some flattening on the radial side Stage II: increased density with some flattening on the radial side Stage III: marked decrease in height of lunate with proximal migration of capitate Stage III: marked decrease in height of lunate with proximal migration of capitate Stage IV:radiocarpal joint osteoarthritis Stage IV:radiocarpal joint osteoarthritis

34

35 Stage I

36 Stage II

37 Stage III

38 Stage IV

39 Fracture of the trapezium Most commonly loading injury in the setting oa adducted thumb where the first metacarpal is driven into trapezium Most commonly loading injury in the setting oa adducted thumb where the first metacarpal is driven into trapezium Associated with fracture of the 1 st metacarpal base and subluxation or dislocation of 1 st carpometacarpal joint Associated with fracture of the 1 st metacarpal base and subluxation or dislocation of 1 st carpometacarpal joint

40

41 Fracture trapezoid Rare fracture. Rare fracture. Associated with dislocation of the 2 nd metacarpal bone Associated with dislocation of the 2 nd metacarpal bone

42

43 Carpal bones dislocations

44 Normal anatomical relations Lateral view with wrist in neutral position: radius, lunate, capitate, 3 rd metacarpal should be in the same line. Lateral view with wrist in neutral position: radius, lunate, capitate, 3 rd metacarpal should be in the same line.

45

46 Normal anatomical relations Dorsovolar view with wrist in neutral postion: 3 smooth unbroken arcs should be seen (Gilula arcs) Dorsovolar view with wrist in neutral postion: 3 smooth unbroken arcs should be seen (Gilula arcs) Arc I: proximal articular surfaces of the scaphoid,lunate,& triquetrum Arc I: proximal articular surfaces of the scaphoid,lunate,& triquetrum Arc II: distal concavities of scaphoid, lunate, & triquetrum Arc II: distal concavities of scaphoid, lunate, & triquetrum Arc III: proximal convexities of capitate & hamate Arc III: proximal convexities of capitate & hamate

47

48 Vulnerable zones theory Dislocations around the lunate can occur in two patterns. Dislocations around the lunate can occur in two patterns. Lesser arc injury pattern: consist of pure ligamentous injuries leading to dislocations Lesser arc injury pattern: consist of pure ligamentous injuries leading to dislocations Greater arc injury pattern: consist of dislocation in addition to fracture of one or more of the bones around the lunate (scaphoid, trapezium, capitate, hamate, triquetrum). Greater arc injury pattern: consist of dislocation in addition to fracture of one or more of the bones around the lunate (scaphoid, trapezium, capitate, hamate, triquetrum). In cases of greater arc injury you mention the prefix trans- followed by the name of the fractured bone then the dislocation e.g. trans- scaphoid perilunate dislocation In cases of greater arc injury you mention the prefix trans- followed by the name of the fractured bone then the dislocation e.g. trans- scaphoid perilunate dislocation

49 Greater arc =blue lesser arc = red

50 Dislocations around the lunate Occur in sequential stages according to the severity of trauma Occur in sequential stages according to the severity of trauma Stage I: Scapholunate dissociation; rotatory subluxation of scaphoid Stage I: Scapholunate dissociation; rotatory subluxation of scaphoid Stage II: perilunate dislocation Stage II: perilunate dislocation Stage III: midcarpal dislocation Stage III: midcarpal dislocation Stage IV: lunate dislocation Stage IV: lunate dislocation

51 Dislocations around the lunate

52 Scapholunate dissociation Results from injury of the scapholunate ligament Results from injury of the scapholunate ligament Radiographicaly diagnosed by Terry Thomas sign due to widening of the space between the scaphoid and lunate more than 2 mm Radiographicaly diagnosed by Terry Thomas sign due to widening of the space between the scaphoid and lunate more than 2 mm

53 Terry Thomas sign

54 Rotatory subluxation of scaphoid Related condition to scapholunate dissocaition where there is in addition rotation of the scaphoid along its long axis Related condition to scapholunate dissocaition where there is in addition rotation of the scaphoid along its long axis Radiographically diagnosed by signet ring sign: volar tilt of the scaphoid makes it appear foreshortened with its tuberosity seen end on giving a cortical ring. Radiographically diagnosed by signet ring sign: volar tilt of the scaphoid makes it appear foreshortened with its tuberosity seen end on giving a cortical ring. Radiographs in dorsovolar view should be in the neutral position or with ulnar tilt for this sign to be reliable one Radiographs in dorsovolar view should be in the neutral position or with ulnar tilt for this sign to be reliable one

55 Neutral position signet ring sign Radial tilt Normal scaphoid

56

57 Perilunate dislocation On lateral view: On lateral view: Dorsal or volar dislocation of the capitate. Dorsal or volar dislocation of the capitate. Lunate remains in articulation with the radius although there may be some degree of tilt Lunate remains in articulation with the radius although there may be some degree of tilt On dorsovolar view On dorsovolar view Crowdening of the proximal and distal carpal rows Crowdening of the proximal and distal carpal rows Break in arcs II and III at the site of the capitate Break in arcs II and III at the site of the capitate

58

59 Lunate dislocation On lateral view On lateral view Axis of lunate is titled away from the articular surface of radius (spilled tea cup sign) Axis of lunate is titled away from the articular surface of radius (spilled tea cup sign) Capitate remains in normal alignment with radius and 3 rd metacarpal Capitate remains in normal alignment with radius and 3 rd metacarpal On dorsovolar view On dorsovolar view Disruption of arc II while arc III remains intact Disruption of arc II while arc III remains intact

60

61

62 DISI

63 VISI

64 Thank you
