2 RDK Stand-Alone Development Environment The RDK standalone development environment provides an easy way for RDK licensees to get started with RDK development projects!
3 RDK Stand-Alone Development Environment Develop without a headendLow cost, simple designDesigned for a single developerCan be used for demos
4 Stand-Alone Application on Headed Gateway Web PageStand Alone Qt/Webkit Application (Web Browser)LighttpdIARM Bus/MgrService MgrRMFOther Generic/SoC RDK ComponentsLinux Kernel
5 Stand-Alone Application on Headed Gateway GraphicsVideoChannel ChangeDiagnosticsPerform trick-playsDVRThe standalone application is a simple HTML application framework that allows for the display of
6 IARM-Mgr and IARM-Bus for the IR Uses RDK SNMP diagonistics Stand-Alone modulesrmfAppRMF mediastreamerSchedulerRecorderIARM-Mgr and IARM-Bus for the IRUses RDK SNMP diagonisticsElements of RDK that rely on back-end server support at Comcast.Uses rmfApp and RMF mediastreamer for Live and recorded content playback.Uses a dummy scheduler and recorder component for recording initiation/deletion/listing.Uses IARM Mgr/Bus for the IRUses RDK SNMP framework for diagonistics
7 Live Tuning Stand Alone application Mediaframework (rmfApp) Lighttpd rmfApp Commandhtml get requestLighttpdcgi-bin scripthtml get responseRMF Media StreamerTuning requestSA App handles load, display, and state of the web pages.Lighttpd web server configured to listen on localhost:8082
8 Stand Alone application RecordingStand Alone applicationRecorderJSON CommandJSON responsehtml get requestLighttpdcgi-bin scripthtml get responseON Headed GatewaySA App handles load, display, and state of the web pages.Lighttpd web server configured to listen on localhost:8082
9 Stand Alone Connection Diagram LaptopIPNetworkRFNetworkLaptop Serial PortRF Splitter & MoCA FilterIPSwitchXG1Xi3RF VideoDHCPQAMStreamerServer
