1. Intermediate  configurations at the IP for commissioning and optimization Sha BAI IHEP/LAL Philip BAMBADE LAL

2. Increased  IP parameters may be useful to reduce the beam sensitivity to the energy spread and magnet displacement during early commissioning and approach an optimal value gradually Decreasing them can also be considered for the final optimisation Based on : Marie Thorey, LAL/RT- 07-05

3. Matching method Use MAD8 matching module Fit quadrupoles QM12, QM13, QM14, QM15, QM16 to get : -wanted  functions -α x,α y =0 -D x =0 Fit sextupoles SD0, SF1, SD4, SF5, SF6 to cancel T122, T126, T166, T342, T346

4. LAL/RT- 07-05

5. Variable beam size at the interaction point LAL/RT- 07-05

6. Intermediate parameters ( cross-check )

7. Tracking for reduced beam sizes : e.g.  y = 2.0 ×10 -5 m Only first quadrupoles used, not the entire line

8. Variable beam size at the interaction point (Gaussian fit to core)

9. Relative IP beam size increase for 1 micron displacements of the magnets moved one at a time  reduced tolerances with increased  y LAL/RT- 07-05

10. IP position change for 1 micron displacements of the magnets moved one at a time  transfer matrix unchanged with increased  y (but effects relative to size are reduced) LAL/RT- 07-05

11. Beam size at focal point is a function of choice of FD effective focal length (L*) and injected beam matching  L* adjusted by FD strength (orthogonal combinations for x and y waist positions in z)  injected beam adjusted by QM12,13,14,15,16 During commissioning, Honda monitor and wire scanner at displaced IP, respectively at -54cm and +39cm, with resolutions of 300-1000 nm. Variable  x,y at longitudinally displaced IP

12. Procedure to control  y at displaced IP 1) For close to nominal values at IP+39cm, use QM12~16 to obtain:  x =2×  x nominal =0.008m  y =4×  y nominal =0.0004m at the nominal IP 2) use QD,QF to fit  x =  y =0 at IP+39cm, step by step... 3) use SD0,4 & SF1,5,6 to zero T 122,T 126,T 166,T 342,T 346 KLQM12FF = 3.347954E-01 KLQM13FF = 9.109371E-01 KLQM14FF =-1.126109E+00 KLQM15FF =-3.172467E-01 KLQM16FF = 6.492773E-01 KLQD0FF = -1.117399E+00 KLQF1FF = 7.030127E-01 Configuration [m -2 ]

13. Close to nominal beam size at IP+39cm Linear optics  x =0.004m,  y =0.00016m  σ y = 43nm Tracking: σ y = 46nm

14. Use similar procedure for close to nominal values at IP-54cm KLQM12 = 3.438185E-01 KLQM13 = 8.779989E-01 KLQM14 = -1.182823E+00 KLQM15 =4.439885E-02 KLQM16 =-1.750061E-01 KLQD0FF=-2.204962E+00 KLQF1FF = 8.173861E-01 Configuration [m -2 ]

15. Close to nominal beam size at IP-54cm Tracking: σ y = 38nm Linear optics  x =0.005m,  y =0.00011m  σ y = 37nm

16. 1) a. Use QM12~16 to obtain:  x =0.004m  y =10×  y nominal =0.001m b. Use SD0,4 & SF1,5,6 to zero T122,T126, T166, T342,T346 KLQM12 = 4.374117E-01 KLQM13 = 8.278653E-01 KLQM14 =-1.06454E+00 KLQM15 = 3.285206E-01 KLQM16 =-6.317261E-01 Increase  y at IP-54cm Configuration [m -2 ]

17. Tracking: σ y = 112nm Close to 10×  y nominal at IP-54cm Linear optics  x =0.004m,  y =0.001m  σ y = 108nm

18. 2) a. Use QM12~16 to obtain:  x =0.004m  y =20×  y nominal =0.002m b. Use SD0,4 & SF1,5,6 to zero T122,T126, T166, T342,T346 KLQM12FF = 4.658464E-01 KLQM13FF = 8.260043E-01 KLQM14FF =-1.139217E+00 KLQM15FF = 4.000200E-01 KLQM16FF =-6.980810E-01 Configuration [m -2 ]

19. Tracking: σ y =155nm Close to 20×  y nominal at IP-54cm Linear optics  x =0.004m,  y =0.002m  σ y = 153nm

20.  functions  y =10×  y nominal =0.001m  y =20×  y nominal =0.002m

21. Conclusions and prospects With increased  y, tolerance reduced; while decreasing  y, get the minimum 23nm beam size at nominal IP.  y can also be adjusted at the displaced IP, where additional instruments will be used with larger resolutions for commissioning. This will be explored further including tolerances. Linear combinations of QD,QF will be prepared for orthogonal waist scanning at the different focal point locations.
