1. The Practice of Statistics, 5th Edition Starnes, Tabor, Yates, Moore Bedford Freeman Worth Publishers CHAPTER 1 Exploring Data 1.0 Introduction Data Analysis: Making Sense of Data Homework: Page 6 # 3,4,7 & 8 Page 21-23 # 12,13,14, 17, 19, 20

2. Learning Objectives After this section, you should be able to: The Practice of Statistics, 5 th Edition2 IDENTIFY the individuals and variables in a set of data CLASSIFY variables as categorical or quantitative Data Analysis: Making Sense of Data

3. The Practice of Statistics, 5 th Edition3 Data Analysis Statistics is the science of data. Data Analysis is the process of organizing, displaying, summarizing, and asking questions about data. Individuals objects described by a set of data Variable any characteristic of an individual Individuals objects described by a set of data Variable any characteristic of an individual Categorical Variable places an individual into one of several groups or categories. Categorical Variable places an individual into one of several groups or categories. Quantitative Variable takes numerical values for which it makes sense to find an average. Quantitative Variable takes numerical values for which it makes sense to find an average.

4. The Practice of Statistics, 5 th Edition4 A variable generally takes on many different values. We are interested in how often a variable takes on each value. Distribution tells us what values a variable takes and how often it takes those values. Distribution tells us what values a variable takes and how often it takes those values. Variable of Interest: MPG Variable of Interest: MPG Dotplot of MPG Distribution Data Analysis

5. The Practice of Statistics, 5 th Edition5 Examine each variable by itself. Then study relationships among the variables. Examine each variable by itself. Then study relationships among the variables. Start with a graph or graphs Start with a graph or graphs How to Explore Data Add numerical summaries

6. The Practice of Statistics, 5 th Edition6 Population Sample Collect data from a representative Sample... Perform Data Analysis, keeping probability in mind… Make an Inference about the Population. From Data Analysis to Inference

7. Section Summary In this section, we learned that… The Practice of Statistics, 5 th Edition7 A dataset contains information on individuals. For each individual, data give values for one or more variables. Variables can be categorical or quantitative. The distribution of a variable describes what values it takes and how often it takes them. Inference is the process of making a conclusion about a population based on a sample set of data. Data Analysis: Making Sense of Data

8. The Practice of Statistics, 5th Edition Starnes, Tabor, Yates, Moore Bedford Freeman Worth Publishers CHAPTER 1 Exploring Data 1.1 Analyzing Categorical Data

9. Learning Objectives After this section, you should be able to: The Practice of Statistics, 5 th Edition9 DISPLAY categorical data with a bar graph IDENTIFY what makes some graphs of categorical data deceptive CALCULATE and DISPLAY the marginal distribution of a categorical variable from a two-way table CALCULATE and DISPLAY the conditional distribution of a categorical variable for a particular value of the other categorical variable in a two-way table DESCRIBE the association between two categorical variables Analyzing Categorical Data

10. The Practice of Statistics, 5 th Edition10 Categorical Variables Categorical variables place individuals into one of several groups or categories. Frequency Table FormatCount of Stations Adult Contemporary1556 Adult Standards1196 Contemporary Hit569 Country2066 News/Talk2179 Oldies1060 Religious2014 Rock869 Spanish Language750 Other Formats1579 Total13838 Relative Frequency Table FormatPercent of Stations Adult Contemporary11.2 Adult Standards8.6 Contemporary Hit4.1 Country14.9 News/Talk15.7 Oldies7.7 Religious14.6 Rock6.3 Spanish Language5.4 Other Formats11.4 Total99.9 Count Percent Variable Values

11. The Practice of Statistics, 5 th Edition11 Frequency tables can be difficult to read. Sometimes is is easier to analyze a distribution by displaying it with a bar graph or pie chart. Displaying Categorical Data Frequency Table FormatCount of Stations Adult Contemporary1556 Adult Standards1196 Contemporary Hit569 Country2066 News/Talk2179 Oldies1060 Religious2014 Rock869 Spanish Language750 Other Formats1579 Total13838 Relative Frequency Table FormatPercent of Stations Adult Contemporary11.2 Adult Standards8.6 Contemporary Hit4.1 Country14.9 News/Talk15.7 Oldies7.7 Religious14.6 Rock6.3 Spanish Language5.4 Other Formats11.4 Total99.9

12. The Practice of Statistics, 5 th Edition12 Graphs: Good and Bad Bar graphs compare several quantities by comparing the heights of bars that represent those quantities. Our eyes, however, react to the area of the bars as well as to their height. When you draw a bar graph, make the bars equally wide. It is tempting to replace the bars with pictures for greater eye appeal. Don’t do it! There are two important lessons to keep in mind: (1)beware the pictograph, and (2)watch those scales. There are two important lessons to keep in mind: (1)beware the pictograph, and (2)watch those scales.

13. The Practice of Statistics, 5 th Edition13 Two-Way Tables and Marginal Distributions When a dataset involves two categorical variables, we begin by examining the counts or percents in various categories for one of the variables. A two-way table describes two categorical variables, organizing counts according to a row variable and a column variable. What are the variables described by this two-way table? How many young adults were surveyed?

14. The Practice of Statistics, 5 th Edition14 Two-Way Tables and Marginal Distributions The marginal distribution of one of the categorical variables in a two- way table of counts is the distribution of values of that variable among all individuals described by the table. Note: Percents are often more informative than counts, especially when comparing groups of different sizes. How to examine a marginal distribution: 1)Use the data in the table to calculate the marginal distribution (in percents) of the row or column totals. 2)Make a graph to display the marginal distribution. How to examine a marginal distribution: 1)Use the data in the table to calculate the marginal distribution (in percents) of the row or column totals. 2)Make a graph to display the marginal distribution.

15. The Practice of Statistics, 5 th Edition15 Two-Way Tables and Marginal Distributions ResponsePercent Almost no chance 194/4826 = 4.0% Some chance712/4826 = 14.8% A 50-50 chance1416/4826 = 29.3% A good chance1421/4826 = 29.4% Almost certain1083/4826 = 22.4% Examine the marginal distribution of chance of getting rich.

16. The Practice of Statistics, 5 th Edition16 Relationships Between Categorical Variables A conditional distribution of a variable describes the values of that variable among individuals who have a specific value of another variable. How to examine or compare conditional distributions: 1) Select the row(s) or column(s) of interest. 2) Use the data in the table to calculate the conditional distribution (in percents) of the row(s) or column(s). 3) Make a graph to display the conditional distribution. Use a side-by-side bar graph or segmented bar graph to compare distributions. How to examine or compare conditional distributions: 1) Select the row(s) or column(s) of interest. 2) Use the data in the table to calculate the conditional distribution (in percents) of the row(s) or column(s). 3) Make a graph to display the conditional distribution. Use a side-by-side bar graph or segmented bar graph to compare distributions.

17. The Practice of Statistics, 5 th Edition17 Relationships Between Categorical Variables ResponseMale Almost no chance 98/2459 = 4.0% Some chance 286/2459 = 11.6% A 50-50 chance 720/2459 = 29.3% A good chance 758/2459 = 30.8% Almost certain 597/2459 = 24.3% Calculate the conditional distribution of opinion among males. Examine the relationship between gender and opinion. Female 96/2367 = 4.1% 426/2367 = 18.0% 696/2367 = 29.4% 663/2367 = 28.0% 486/2367 = 20.5%

18. The Practice of Statistics, 5 th Edition18 Relationships Between Categorical Variables Caution! Even a strong association between two categorical variables can be influenced by other variables lurking in the background. Caution! Even a strong association between two categorical variables can be influenced by other variables lurking in the background. Can we say there is an association between gender and opinion in the population of young adults? Making this determination requires formal inference, which will have to wait a few chapters.

19. Section Summary In this section, we learned that… The Practice of Statistics, 5 th Edition19 DISPLAY categorical data with a bar graph IDENTIFY what makes some graphs of categorical data deceptive CALCULATE and DISPLAY the marginal distribution of a categorical variable from a two-way table CALCULATE and DISPLAY the conditional distribution of a categorical variable for a particular value of the other categorical variable in a two-way table DESCRIBE the association between two categorical variables Data Analysis: Making Sense of Data

20. Section Summary In this section, we learned that… The Practice of Statistics, 5 th Edition20
