1. Look-ahead Linear Regression Trees (LLRT)
David Vogel, A.I. Insight
Ognian Asparouhov, A.I. Insight
Tobias Scheffer, Max Planck Institute for Computer Science

2. What is a Linear Regression Tree?
All Data
Regression Tree
All Data
LRT

3. Optimizing a Regression Tree
Optimizing a Model Tree

4. Simulated Example #1

5. Simulated Example #2 X1=0 X1=1 Regression CART split on X2
LLRT split on X1
True Model
Training
1.338
0.440
0.104
0.103
Validation
1.491
0.490
0.101

6. LLRT Idea
Brute Force: Try every possible split on each splitting variable
For each possible split, try every possible model in right and left partitions to achieve maximum accuracy
Use massive amounts of optimization to make this possible

7. Related Citations 1992, RETIS (Karalic) optimizes the overall RSS
RETIS optimization cited as “intractable” or “non-scalable” as recent as 2005 (Machine Learning)

8. Optimizations in LLRT
Quick calculations for evaluating multiple leaf models from common sufficient statistics
Matrix Solutions: G.E. versus SVD
Forward Stepwise model selection shortcuts
Limit possible splits per variable

9. Optimizing Regression Analysis
where
and
RSS

10. S-fold validation to avoid over-fitting

11. Stopping Rule
Proposed split fails to improve result with two different samplings

12. M5 Run-time
M5 Run time 10 20 30 40 50 60
20000
40000
60000
80000
100000
# Records
# Minutes for Training

15. Reviewer Criticisms Limitation of 10-20 possible split points
Experimental results do not include comparisons to many model tree algorithms
LLRT is slower than other model tree algorithms
