1. LENOVO – CERTIFIKOVANÁ HW PLATFORMA PRE SAP HANA
Miklos Farkas
9/25/2015
2015 Lenovo Internal. All rights reserved.

2. Lenovo Integrated Value Proposition
Lenovo provides Infrastructure components Technology services for SAP HANA
Continued use of IBM GPFS - key differentiator for Lenovo SAP HANA solutions
X6 Rack systems accommodate multiple generations of technology in the same server
On-going technology roadmap to drive leadership solution for SAP HANA
On-premise, TDI, Cloud
Continued leadership
Largest certified SAP HANA clusters (up to 112 TB main memory)
Showcase of 100 TB SAP HANA cluster at SAPPHIRE 2012
Investment protection (add new X6 Nodes to existing ex5 clusters)
Large system memory support – 64GB DIMMs and technology innovations beyond
Choice of X6 rack or Flex System blade form factor
Consistent, integrated support coordinated with SAP
2015 LENOVO. All rights reserved.

3. Building Blocks for SAP HANA “Appliance”
To support single node configurations and scale out clusters
2 to 8 E7-8880v2 processors (E7-8890v2 for improved performance or E7-4880v2 and E7-4890v2 only if the customer agrees to never upgrade to 8s)
128 GB – 6 (12) TB GB Main memory DDR3
Sufficient persistent internal storage according to SAP‘s KPIs 10k SAS HDD, Flash Cache, RAID5
Network 4 x 10 GbitE, 4 x 1 GbitE
GPFS
Systems Director (Agent)
VMware ESX 5.5 (optional)
Novell SLES for SAP Applications or RedHat
SAP HANA Software Stack
x3850 X6 HW
x3950 X6 SW
2015 LENOVO. All rights reserved.

4. X6 Servers: High End Innovation
100+ Benchmarks Across EXA Generations
Post-Launch, Winning Benchmarks for X6 Portfolio # 1
$1B
x3950 X6
Invested in
Enterprise X-Architecture
x3850 X6
1st joint development partner
IDEA 2014 Industrial Design Competition finalist1
1st
eXFlash memory- channel storage
Market leader
World’s largest system
Modular design for multiple generations of processors
2014 LENOVO INTERNAL. All rights reserved.

5. The Modular Design Concept: X6 Adapts to Business Needs
Each compute book includes one processor and 24 DIMMs
Storage Book
4 Compute Books
Each x3850 X6 contains 4 Compute books
Deliver up to 6TB of memory or 12.8TB of eXFlash memory-channel storage
The Storage book delivers up to 6.4TB of eXFlash 1.8” SSD or 12.8TB of SAS 2.5”.
Ability to host 2 storage controllers for maximum bandwidth
Ability to swap out Compute books as memory or processor generations change
2015 LENOVO. All rights reserved.

6. The modular “book” design also provides clients front and rear access to modular components
Primary I/O Book
Up to 2 types of IO Books, Half-Length and Full-Length
Each IO Book delivers an additional 3 PCIe slots
Hosts the IMM, PCIe slots, and the dedicated Mezz-LOM solution
This is the rear-view of the x3850 X6, once again sporting the modular rack design. The modular book design that is being featured here is around the IO books. The top left shows the rear of the x3850 X6, and starting from right to left, we have the Primary IO Book. This IO book hosts the integrated management module or IMM, PCIe slots, and the new dedicated Mezz-LOM slot. This book is standard in every server.
Let’s briefly talk about the the Mezz-LOM slot in the primary IO book as it is the new common networking form factor for several System x rack servers. Instead of designing a lan-on-motherboard or LOM down on the board, the LOM is placed on several mezzanine cards. These cards will support flavors of 1GbE copper and 10GbE fiber or copper. The x3850 X6 supports a dedicated slot for these Mezz-LOM cards. At launch, the x3850 X6 will support a quad port 1GbE copper card, a dual port 10GbE copper card, and a dual port 10GbE SFP+ fiber card. These cards host several key vendors such as Intel, Broadcom, and Emulex – giving clients maximum choice and flexibility.
To the left of the Primary IO book are optional IO books. Each optional IO book delivers an additional 3 PCIe slots – allowing the x3850 X6 to deliver up to 9 PCIe slots in the rear of the server. Optional IO books come in two flavors, a half-length IO book that supports 3 half-length, full-height PCIe cards, and a full-length IO book that supports 3 full-length, full-height PCIe cards. The full-length IO book support specialty Graphics or accelerator cards that may require 300W power. This is a big advancement for the x3850 because as it can support up to two of these power hungry graphics cards it can be a powerful offering for VDI and graphics intensive applications.
Clients can choose to install one or both or none of these optional IO books, and can clients select between having 6 half-lenfth, or 6 full-length or a mix of half-length and full-length slots through these optional IO books – to create that perfect fit for purpose configuration – maximizing flexibility while lowering the acquisition cost.
As you can see now, all of the components in the x3850 X6 are modular, and can be accessed from either the front or rear of the server – never a need to pull the actual chassis out of the server. Maximum agility to meet the client’s needs, maximum agility to grow, and maximum agility to deliver a lower cost of ownership.
Create the fit-for-purpose solution, whether clients need to support typical HBAs or specialty GPGPU cards
Mezz-LOM solution gives clients the ability to select the networking technology that fits their requirements 6

7. X3850/3950 X6 Compute Books
X6 Haswell will offer the choice of DDR3 or DDR4 Compute Books. Each Compute Book contains the Intel processor and 24 DDR3 or DDR4 DIMM slots. All Compute Books in the server must be the same type -- DDR3 or DDR4. (Within chassis, all books need to be same processor type and same memory type.)
12x DDR3 or DDR4 DIMM slots on right side of the Compute Book
12x DDR3 or DDR4 DIMM slots on left side of the Compute Book
Intel Xeon E v3 or E v3 processor
Note: DDR3 DIMMs can not be put into DDR4 compute books or visa versa.
2014 LENOVO. All rights reserved.

8. Lenovo Solution for SAP HANA with X6 (for BW, Datamart and SoH) 2 processors
Size
Building Block
x3850 X6
Part Number (Sys x - config)
Based on AC3
AC32S128S
AC32S256S
AC32S512S
Intel CPU *)
2x E7-8880v2
RAM
128 GB 16x 8GB
256 GB 16x 16GB or
32 x 8GB
512 GB
32x 16GB
Storage
2x 400 GB SSD
6x1.2TB HDD
Storage Ctrl
1x M5210
Data / Log Storage Summary
3.6 TB RAID5
Ethernet
4x 10GbE 4x 1GbE
Upgrade Options without replacing the Memory
128  256
256  512
2S  4s
2s  4s
No T-Shirt sizes
xConfig:
Alternate processor types:
E7-8890v2 for improved performance
E7-4880v2 only if customer agrees not to plan an upgrade to 8S ever
E7-4890v2 only if customer agrees not to plan an upgrade to 8S ever
*) Processor type alternatives: E7-8890v2 for improved performance E7-4880v2 and E7-4890v2 only if the customer agrees to never upgrade to 8s
Certification
2015 LENOVO. All rights reserved.

9. Lenovo Solution for SAP HANA with X6 (for BW, Datamart and SoH)
Size
Building Block
x3850 X6
x3950 X6
Part Number (Sys x - config)
Based on 3837-AC3
AC34S256S
AC34S512S
Based on AC3
AC34S1024S
Based on AC4
AC48S1024S
AC48S2048S
Intel CPU
4x E7-8880v2
8x E7-8880v2
RAM
256 GB 32 x 8GB
512 GB 32x 16GB or 64 x 8GB
1 TB 64x 16GB or 32 x 32GB
1 TB 64x 16GB
2 TB
128x 16GB
Storage
2x 400GB SSD 6x 1.2 TB HDD
2x 400GB SSD
6x 1.2 TB HDD
4x 400 GB SSD
15x 1.2 TB HDD
12x1.2TB HDD
4x400GB SSD
Storage Ctrl
1x M5210
1x M5120
2x M5210
Data / Log Storage Summary
3.6 TB RAID5
13.2 TB RAID5
9.6TB RAID5
data/log
Ethernet
4x 10GbE
4x 1GbE
4 x 10GbE
4 x 1GbE
4x 1GigE
Upgrade Options without replacing the Memory
256  512
512  1 TB
1 TB  2 TB
1 TB  1.5 TB
xConfig:
Alternate processor types:
E7-8890v2 for improved performance
E7-4880v2 only if customer agrees not to plan an upgrade to 8S ever
E7-4890v2 only if customer agrees not to plan an upgrade to 8S ever
All 4s systems upgradeable to 8 socket.
2015 LENOVO. All rights reserved.

10. Lenovo Solution for SAP HANA with X6 (for BW and Datamart)
Size
Building Block
x3850 X6
Part Number (Sys x - config)
Based on AC3
AC32S256C
AC32S512C
AC34S512C
AC34S1024C
Based on 3837-AC4
AC48S1024C
AC48S2048C
Intel CPU *)
2x E7-8880v2
4x E7-8880v2
8x E7-8880v2
RAM
256 GB 16x 16GB or
32 x 8GB
512 GB
32x 16 GB
32x 16GB or 64 x 8 GB
1 TB
32x 32GB or 64 x 16 GB
64x 16GB or 128 x 8 GB
2 TB
64x 32GB or 128 x 16 GB
Storage
2x 400 GB SSD
6x1.2TB HDD
4x 400 GB SSD
15x1.2TB HDD
4x 400 GB ZSD
12x1.2TB HDD
4x400GB SSD
21x1.2TB HDD
6x400GB SSD
Storage Ctrl
1x M5210
1x M5120
2x M5210
Data / Log Storage Summary
3.6 TB RAID5
13.2 TB RAID5
9.6 TB RAID5
19.2 TB RAID5
Ethernet
4x 10GbE
4x 1GbE
Upgrade Options without replacing the Memory
256  512
2S  4s
2s  4s
512  1 TB
1 TB  2 TB
2 TB  6 TB
Scale out
Up to 4 nodes
Up to 56 nodes
xConfig:
Alternate processor types:
E7-8890v2 for improved performance
E7-4880v2 only if customer agrees not to plan an upgrade to 8S ever
E7-4890v2 only if customer agrees not to plan an upgrade to 8S ever
2015 LENOVO. All rights reserved.

11. Lenovo Solution for SAP HANA only for Suite on HANA with X6
Size
Building Block
x3850 X6
x3950 X6
Part Number (Sys x - config)
Based on 3837-AC3
AC34S2048S
Based on 3837-AC4
AC48S4096S
AC48S6144S
Intel CPU
4x E7-8880v2
8x E7-8880v2
8 socket
RAM
2 TB 32 x 64GB or 64x 32GB
4 TB (128 x 32 GB)
6 TB (192 x 32 GB)
12 TB * (192 x 64 GB)
Storage
4x 400GB SSD 15x 1.2TB HDD
21x1.2TB HDD
6x400GB SSD
30x1.2TB HDD
tbd
Storage Ctrl
1 x M5210
1 x M5120
2x M5210
1x M5120
Data / Log Storage Summary
13.2 TB RAID5
19.2TB RAID5
data/log
28.8TB RAID5
Ethernet
4x 10GbE 4x 1GbE
4x 10GbE
4x 1GigE
Upgrade Options without replacing the Memory
2 TB  4 TB
4 TB  6 TB
SAP Business Suite on HANA:
Scale up recommended
xConfig:
Scale out certifications pending
* Not approved by SAP for SAP HANA, but technically feasible
2015 LENOVO. All rights reserved.

12. … SAP HANA Scalability Simple Seamless Scalable
No SAN required because of IBM’s General Parallel File System
Expand database by adding nodes with GPFS
One part number ordering for each node (stand-alone or scale-out)
Seamless
Highly Available through IBM GPFS (HA)
Intelligent Cluster integrated packaging and assembly
Installation and managed services
Scalable
Scale out to 56 nodes and larger using IBM GPFS
Certified by SAP …
Scale up
each node
or continue
to scale out
Scale out
Optimizes system availability
Speeds installation and deployment
Reduces implementation risk
Speeds installation
Ensures skills transfer
Simplifies on-going maintenance
Supports very large database requirements
Scale out
Scale up
Never lose your initial investment with Scale Up / Scale Out options !
2015 LENOVO. All rights reserved.

13. SAP HANA Cluster with IBM GPFS FPO
FPO - File Placement Optimizer
Locality
Write Affinity
Metablocks
Pipelined replication
Distributed recovery
node
client
Eth/IB
Eth/IB
Unlimited, simple, reliable scaling
Lenovo is the only SAP partner to offer linear scaling of our solution. This is based on the IBM General Parallel File System™ (GPFS™) software (high-performance, seamless expansion, data reliability between nodes without human involvement).
IBM GPFS was designed as a parallel file system, and has been widely employed in supercomputing for more than a decade. It has shown near-linear scalability in extremely large configurations – systems with 1,000+ nodes are common, and the largest exceed 5,000 nodes. Data volumes often run to hundreds of terabytes, and petabyte-scale systems have been deployed.
In terms of scalability, all vendors offer SAP-certified 16-node scale-out configurations – although there is little production experience with these – and Cisco claims that 48-node
configurations may be “certified on request.” However, Lenovo Solution servers and GPFS formed the basis of the three highest-performing HANA systems demonstrated to date.
nsd server
FibreChannel
2015 LENOVO. All rights reserved.

14. Investment Protection
Compatibility with existing clusters
Scale out with up to 50% of nodes in cluster based on new X6 systems
Up to 50% of the nodes in the cluster based on X6 systems
Once more than 50% of the nodes are based on X6 systems, then cluster must migrate to 100% X6 systems
Older eX5 systems redeployed to other environments
1TB eX5
node
1TB eX5
node
1TB eX5
node
1TB eX5
node
1TB eX5
node
5TB Total Memory
Ethernet
Ethernet
Beware, the amount of memory and sockets needs to be the same in mixed environments
More HANA memory capacity
1TB eX5
node
1TB eX5
node
1TB eX5
node
1TB eX5
node
1TB eX5
node
1TB X6
node
1TB X6
node
1TB X6
node
1TB X6
node
Ethernet
9TB Total Memory
Ethernet
2015 LENOVO. All rights reserved.

15. Flex System X6 Solution for SAP HANA
Key Features
Customer Benefits
Flex System x880 X6
HANA certification enables support for new SAP HANA TDI opportunities where customers or MSPs need to using existing storage Integrated management with enterprise class RAS
Leadership Performance & Scalability to 8 sockets
Consolidate SAP application landscapes
Workload Optimized for SAP HANA
Manage large data volumes cost effectively
Realize accelerated analytics with SAP HANA
Enhance data reliability and system availability
IBM GPFS with Integrated GPFS Storage Server (GSS)
Seamless scalability
Virtual storage management
Business Warehouse on HANA and data marts
Single node
128GB up to 2TB
Scale out 4 node cluster
2 socket up to 512GB per node
4 socket up to 1TB per node
4 nodes provides 3 worker nodes and 1 standby node for High Availability solutions or 4 worker nodes for capacity
Business Suite on HANA
Single node – Up to 8 socket, 6TB
HANA TDI
Flex System x880 X6 integrated with SAP HANA Certified Storage
BW on HANA, Data Marts, Business Suite on HANA
2015 LENOVO. All rights reserved.

16. SAP HANA on Flex – Solution Overview
2015 LENOVO. All rights reserved.

17. x880 Workload Optimized Solution for SAP HANA
2015 LENOVO. All rights reserved.

18. Tailored Datacenter Integration (TDI) for SAP HANA
(aka: „Bring your own storage or network components“)
2015 LENOVO. All rights reserved.

19. Integrated Solution vs. TDI
Appliance Delivery Model
SAP HANA TDI Approach
Hardware Selection
Little flexibility only
Customer can choose between different appliances
No possibility to replace certain components by HW already used in customers DC
Save IT budget and existing investments
reuse preferred storage
reuse preferred network components
Implementation Effort
Low for customer
Preconfigured HW plus preinstalled SW
Only HW is delivered
Installation to be done by customer (incl OS)
Extensive docu (guides, SAP notes) available
Safeguarding / Solution Validation
Done together by SAP and HW Partner
SAP HANA Going-Live check offered by SAP AGS
Self-managed infrastructure tests possible - SAP HANA HW Configuration Check Tool
Support
Fully provided by SAP
Individual support agreement(s) with HW partner(s) required
OS Service Contract
Appliance vendor is reseller of OS provider’s service contract
Customer to care for getting the OS provider’s service contract (standard with Lenovo HANA TDI)
2015 LENOVO. All rights reserved.

20. Lenovo Solution for SAP HANA™ appliance
Applications
Data Center Ready
Improved reliability by helping reduce single points of failure
Reduced risk, maintainance and administration
Persistence in internal disks
Integrated Backup / Restore
High Availability
Monitoring
Disaster Recovery Solutions
Security and Auditing
Technology Services provide a safe project start in the datacenter
SAP HANA®
GPFS
FPO functionality OS
SUSE Linux Enterprise Server 11 or Red Hat 6.5
Priority Support for SAP applications
SUSE
Red Hat
Server HW
eX5 / x6
2015 LENOVO. All rights reserved.

21. Business Continuity Options
High Availability (local within one datacenter):
Scale out with stand-by node in a cluster (IBM GPFS functionality)
SAP HANA System Replication (but no automatic failover)
Stretched HA (e.g. campus setup for single node systems):
1+1+ quorum node (IBM GPFS functionality)
Disaster Recovery (between two datacenters):
Storage Replication (IBM GPFS functionality)
SAP HANA System Replication
2015 LENOVO. All rights reserved.

22. SAP HANA Appliance - Single Node
x3850 X6 node
SAP HANA® DB
DB partition 1
- SAP HANA® DB
- Index server
- Statistic server
- SAP HANA® studio
Shared file system - GPFS
3.6 TB
9.6 TB
First replica
data + log
2015 LENOVO. All rights reserved.

23. SAP HANA Appliance - Scale out
node01
node02
node03
SAP HANA DB
Validated by SAP
Only Lenovo Solution has 56 x 2 TB systems certified for scale out.
Larger cluster sizes can be validated on request.
DB partition 1
DB partition 2
DB partition 3
- SAP HANA DB
Worker node
- SAP HANA DB
Worker node
- SAP HANA DB
Worker node
- Index server
- Statistic server
- SAP HANA studio
- Index server
- Statistic server
- Index server
- Statistic server
Shared file system - GPFS
local storage
local storage
local storage
First replica
data01 + log01
data02 +log02
data03 + log03
Lenovo Solution configurations are delivered with GPFS shared file system for seamless growth
2015 LENOVO. All rights reserved.

24. SAP HANA Appliance – Scale Out with High Availability
node01
node02
node03
node04
SAP HANA DB
DB partition 1
DB partition 2
DB partition 3
- SAP HANA DB
Worker node
- SAP HANA DB
Worker node
- SAP HANA DB
Worker node
- SAP HANA DB
Standby node
- Index server
- Statistic server
- SAP HANA studio
- Index server
- Statistic server
- Index server
- Statistic server
- Index server
- Statistic server
Shared file system - GPFS
local storage
local storage
local storage
local storage
First replica
data01 + log01
data02 + log02
data03 + log03
Second replica
2015 LENOVO. All rights reserved.

25. SAP HANA Appliance – Scale Out with High Availability
node01
node02
node03
node04
SAP HANA DB
DB partition 1
DB partition 2
DB partition 3
- SAP HANA DB
Worker node
- SAP HANA DB
Worker node
- SAP HANA DB
Defunct node
- SAP HANA DB
Worker node
- Index server
- Statistic server
- SAP HANA studio
- Index server
- Statistic server
- Index server
- Statistic server
- Index server
- Statistic server
Shared file system - GPFS
local storage
local storage
local storage
local storage
First replica
data01 + log01
data02 + log02
data03 + log03
Second replica
2015 LENOVO. All rights reserved.

26. SAP HANA Appliance – Scale Out with High Availability
node01
node02
node03
node04
SAP HANA DB
DB partition 1
DB partition 2
DB partition 3
- SAP HANA DB
Worker node
- SAP HANA DB
Worker node
- SAP HANA DB
Standby node
- SAP HANA DB
Worker node
- Index server
- Statistic server
- SAP HANA studio
- Index server
- Statistic server
- Index server
- Statistic server
- Index server
- Statistic server
Shared file system - GPFS
local storage
local storage
local storage
local storage
First replica
data01 + log01
data02 + log02
data03 + log03
Second replica
2015 LENOVO. All rights reserved.

27. 1+1 / 1 HA and DR SAP HANA System Replication OS OS OS
node1
node2
SAP HANA
System Replication
node3
Shared File System A
File system B
HDD
HDD
HDD
1+1 / 1 HA and DR
first
replica
replica
first
Data
Data
second
replica
Data
System
Descriptor
File
System
Descriptor
File
FS Desc
FS Desc
FS Desc
meta data
meta data
Meta
data
Meta
data
Meta
data
LG1
LG1
LG1
FG1
FG2
FG1
sda1
sda2
sda1
sda2
sda1
sda2 OS OS OS
M5120
Extra file system
for non-prod
...
GPFS Cluster A
HA using GPFS Storage Replication with DR using SAP HANA System Replication and storage expansion for additional non-production instance
GPFS Cluster B
2015 LENOVO. All rights reserved.

28. Global industrial company, Belgium
IBM SAP HANA on new x3850 X6 Platform
STG Lab Services Team:
Thomas Heinsch, David Rajendra
What did we do?
SAP-HANA installation/configuration service
Preparation sessions with customer to plan system setup, network setup and installation.
SAP HANA HW configuration validation and BIOS, firmware, RAID configuration.
Installation of Operating System (SLES 11 SP3 for SAP with HANA extensions).
Configure network switches and OS network settings and verify operation for seamless integration into customer network.
GPFS installation/configuration/verification.
Install HANA DB in the DR Cluster.
Skill transfer, training and documentation.
Results
Successful installation of this complex IBM SAP HANA environment
Successful ‘in-time’ installation (5 days) of the IBM SAP HANA appliance despite Networking and HW errors/corrections
Customer team was very satisfied with the level of expertise and consultant capabilities
Overview of project
A Global industrial group of companies headquartered in Stockholm, Sweden. The Group employs more than 40,000 people. The company manufactures products at about 100 production sites in more than 20 countries.
Subsidiary companies develop and manufacture industrial tools worldwide.
STG Lab Services delivered a first of a kind implementation of a full redundant IBM SAP HANA Desaster Recovery (DR) appliance based on the new x3850 X6 Platform. The Disaster Recovery appliance was spread over two data centres for high availability in case of disaster in Brussels, Belgium.
The service also covered training and consulting for the installed IBM SAP HANA appliance to enable the customer on operational aspects.

29. Lenovo – EMEA Enterprise Solution Services
Food company - France
Lenovo Services Team:
Frank Kuchenbecker
Overview of project
What did we do?
SAP-HANA installation/configuration service
Sessions with customer to plan system setup, network setup and installation.
SAP HANA HW configuration validation.
BIOS, firmware, RAID configuration and verification.
Install OS (SLES 11 SP3 for SAP).
GPFS installation/configuration/verification
Install HANA IMDB as HA cluster, ready for replication
Skill transfer and post install documentation.
Healthcheck for several other IBM HANA appliances, installed by a BP
Results
Successful installation of SAP-HANA appliances.
Customer team was very satisfied with the level of expertise and consultant capabilities and plans further activities with our Lab Services team for upcoming expansions of their HANA landscape.
A France based, worldwide operating food company. Their businesses are flour mills and french bakery products served in over 50 countries.
STG Lab Services delivered an on-site installation and configuration of two AC32S512S IBM SAP HANA appliances in a High Availability setup for the company as future productive core part of a new SAP landscape of overall 6 appliances.
These are distributed over two locations and will be replicated for increased availability.
The service ensures the complex configuration between OS, GPFS and SAP HANA. This Lab Service installation service allows an effective use and support of the IBM SAP HANA appliances.
2015 LENOVO. All rights reserved.

30. Lenovo – EMEA Enterprise Solution Services
Brewing and beverage company
SAP HANA, Germany
Lenovo Services Team:
Thomas Heinsch
Overview of project
What did we do?
SAP-HANA installation/configuration service
Extensive sessions with customer to plan system setup, network setup and installation in a productive live environment.
BIOS, firmware, RAID and OS configuration and verification.
Configure network switches and OS network settings and verify operation for seamless integration into customer network.
GPFS installation/configuration/verification.
Expand HANA Data Base with 2 new nodes and verified successful implementation with additional fail over tests.
Skill transfer and post install documentation.
Results
Successful installation of SAP-HANA appliance in the customer’s data centre environment
Customer team was very satisfied with the level of expertise and consultant capabilities and plans further activities with our Lab Services team.
A multinational brewing and beverage company headquartered in London, United Kingdom. It is the world's second-largest brewer. It has operations in 75 countries across Africa, Asia, Australia, Europe, North America and South America and sells around 21 billion liters of lager per year.
STG Lab Services provided further expansion of a business critical IBM SAP HANA production system. The Scale-Out cluster was expanded to increase HANA Database capacity in customer data center in Frankfurt/Main.
This service ensures the complex configuration between OS, Network, GPFS and SAP HANA Platform edition is properly installed and configured for effective use and support of the IBM SAP HANA appliance.
2014 LENOVO. All rights reserved.

31. Thomas Heinsch, Frank Kuchenbecker, David Rajendra
Multinational document management corporation – IBM SAP HANA - UK
STG Lab Services Team:
Thomas Heinsch, Frank Kuchenbecker, David Rajendra
What did we do?
SAP-HANA installation/configuration service
Extensive sessions with customer to plan system setup, network setup and installation in two data centres.
Design, plan and implementation of a GPFS based Disaster Tolerance setup and supporting migration from an existing customer environment.
Replacement of a failed node in an existing Disaster Tolerance setup.
BIOS, firmware, RAID and OS and network configuration and verification for seamless integration into customer network and existing HANA environment.
Skill transfer and post install documentation.
Results
Successful installation of SAP-HANA appliance in the customer’s data centre environment
Customer team was very satisfied with the level of expertise and consultant.
Overview of project
An American multinational document management corporation that produces and sells a range of color and black-and-white printers, multifunction systems, photocopiers, digital production printing presses, and related consulting services and supplies. This company also offers managed IT services and runs own data centres.
STG Lab Services delivered consulting and technical assistance for the implementation of a Disaster Tolerant IBM SAP HANA Appliance. Th company is running the Disaster Tolerant environment in two data centres near Telford as a managed service in the UK.
The service ensured the complex Disaster Recovery configuration between Operating System, GPFS, Network switches and SAP HANA application spanned over two data centres.

32. Reference Customers Link Link Link Link Link Link Link Link Link Link
Fragrance Company owns several European fashion brands
Link
Link
Link
Major Electric Utility Provider
Link
Link
Link
Major Retailer
Link
2015 LENOVO. All rights reserved.

33. More Information
Lenovo Solution for SAP HANA Documentation: Quickstartguide, Implementationguide and Operationsguide
2015 LENOVO. All rights reserved.

34. Numerous #1 Benchmark results since X6 roll-out
#1 TPC-E* – as of Feb 16, 20141
#1 SPECvirt_sc2013** – as of Feb 20, 20142
#1 SAP® Applications Sales & Distribution 2-Tier 4-S*** – as of Feb 18, 20143
non-clustered TPC-H* – as of Apr 15, 20144
#1 SPECvirt_sc2013** – as of May 20145
#1 SAP Applications Sales & Distribution 2-Tier 8-S – as of June 16, 20146
#1 SPECvirt_sc2013** – as of Nov 20147
#1 TPC-E – as of Nov 25, 20148
7 Winning Performance Measures in STAC-M3 -- as of Jan 20159
#1 SAP BW-EML – as of Mar 16,
1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11 Detailed information about all of these benchmarks and their respective company trademarks can be found in the Backup section of this presentation.
non-clustered TPC-H* – as of Apr 6,
2015 LENOVO. All rights reserved.

35. Continued innovation: 7 new world records as of 5/5/15
SAP HANA BW-EML Scale Billion records 4-processor world record12
GB 4-processor world record13
SPECvirt_sc2013** 4-processor world record14
SAP SD 2-Tier*** (Windows) 4-processor world record15
TPC-E* 4-processor world record16
ANSYS FLUENT x86 4-processor world record for single x86 server on the fluidized_bed_2m compared to a baseline as tested by Intel 17
SAP HANA BW-EML Scale Billion records 4-processor world record18
12, 13, 14, 15, 16, 17, 18 Detailed information about all of these benchmarks and their respective company trademarks can be found in the backup section of this presentation.
All results listed on this page are as of May
2015 LENOVO. All rights reserved.
