1. Once upon a time Not so very long ago An intro to hex

2. The problem is, that even though binary is perfect for computers.. Binary is really hard for people to read For example: 11001011000101111101101101011101 Here is the starting address of an instruction in memory that the computer needs to run a program 1 – Not easy to read – Not easy to copy – Not easy to work with 1 And this is only the 32 bit version, a 64 bit address would, obviously, be twice as long

3. Somebody had the bright idea… Why not group the binary numbers into chunks to make them easier to read? 0100 0011 1011 0111 1011 1010 That’s better But there still must be a better way

4. If you use groups of 4 bits, how many unique combinations of 0’s and 1’s are there? 1000 1001 1010 1011 1100 1101 1110 1111 0000 0001 0010 0011 0100 0101 0110 0111 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Would it work to represent each unique combination with a unique symbol?

5. Supposedly…. IBM invented the term hexadecimal 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 = base 16 Since this system needed six extra symbols, why not just use the first six letters of the alphabet? The symbol for the value 10 in decimal is represented by the symbol A in hex. Both are represented in the computer as binary 1010. 0 1 2 3 4 5 6 7 8 9 A B C D E F = base 16 There is an interesting reason why IBM named it "hexadecimal". The prefix "hex" is Greek but "decimal" is Latin. Why didn't they go with an "all Latin" name? Well, then the name would then have been "sexadecimal" and IBM just couldn't accept a name like that.

6. What color is: 010000111011011110111010? http://rogercortesi.com/athleticlog_help/html_multi/colorchart.png Break it up 01004 00113 1011B 01117 1011B 1010A

7. It’s easy to convert back and forth Take binary numbers in chunks of 4 Write down the corresponding hex number – 1000 0101 0010 1100 1111 – 8 5 2 C F Write hex numbers in binary – 37ED – 0011 0111 1110 1101
