1. ASIC Design Flow – An Overview Ing. Pullini Antonio antonio.pullini@epfl.ch

2. Outline Introduction to ASIC Design Flow Standard Cells Design Details of Design Flow Timing Validation Post Layout Validation

3. A Typical ASIC Design Flow Ideally, one-shot linear flow In practice, iterations needed to fix issues – Validation failures – Bad quality of results – No timing closure Design Space Exploration RTL Coding Logic Synthesis PlacementRouting

4. Basics of a ASIC Design Flow Layout Placed and routed network of gates Layout Placed and routed network of gates

5. Standard Cell Design Standard-cell libraries are a fixed set of well-characterized logic blocks Basic logic functions that are used several times on the same integrated circuit It will have leaf cells ranging from simple gates to latches and flip-flops. These can then be used to build arithmetic blocks like adders and multipliers. ASIC designers commonly employ the use of standard cell libraries due to their robustness and flexibility resulting in quick turnaround times All cells have the same height (with adjacent power and ground)‏ Cells tiled into rows

6. Standard Cell Designs - Libraries Library of precharacterized cells – Delay/Power vs. Rise Time and Output Capacitance – Physical Dimension and Pin Position

7. Timing Delay of cell depends on Rise Time and Output Load

8. Capacitive Loads Load depends on Input Capacitance and Interconnect Capacitance

9. Standard Cell Designs – The Cells

10. Standard Cell Designs – The Rows VDD GND

11. Basic High Level Design Flow

12. RTL Simulation Behavioral simulation no delays for processing No performance parameters only functionality is verified Hardware description Not every construct in VHDL or Verilog can be implemented in hardware. This simulation will not show this.

13. Testbenches

14. Synthesis - Requirements Constraints to drive the synthesis process – Clock Period – IN/OUT delays – Max Area/Power Technology library – Timing view – Power consumption – Area Occupation RTL Gate Level Netlist Synthesis Tech Lib Constraints

15. Synthesis – Analyze design Check the syntax of the HDL files – Checks if the file is compliant with one of the supported HDL files (Verilog/VHDL)‏ Check the synthesizability of the design – Reports if some of the non-synthesizable construct have been used Identify the connectivity of the block – All the ports and their directions are identified

16. Synthesize - Elaborate Identifies all the components inferred in the RTL Map the inferred components to a Generic Library (GTECH)‏ Applies the required optimizzation on the RTL (ex. Clock Gating)‏

17. Synthesis – Elaborate – an example module simpleadder(ina,inb,out,clk); input [3:0] ina; input [3:0] inb; output [4:0] out; reg [4:0] out; input clk; reg [3:0] internal_a; reg [3:0] internal_b; reg [4:0] internal_res; always @(posedge clk)‏ begin internal_a <= ina; internal_b <= inb; out <= internal_res; end always @(internal_a or internal_b)‏ begin internal_res <= internal_a + internal_b; end endmodule

18. Synthesis – Linking And Opcond Setup Set the Operating Condition at which the synthesis will take place (process voltage and temperature P.V.T.)‏ Select the target library Links the design to other pre-characterized blocks or hard macros

19. Synthesis – Tech Mapping and Optimization The GTECH components are mapped onto the technology library Logic is minimized Implementation of basic building blocks (e.g. adders) are chosen considering the area/power/timing budget

20. Synthesis – Map & Opt an example Internal_a Out internal_b

21. Timing Design and Delay Test Timing simulation: Critical paths are identified by static (vector-less) timing analysis tools like Primetime (Synopsys). Timing or circuit-level simulation using designer- generated functional vectors verifies the design. Layout optimization: Critical path data are used in placement and routing. Delay parameter extraction, timing simulation and layout are repeated for iterative improvement. Testing: Some form of at-speed test is necessary. Critical paths and all gate transition delays are tested.

22. Static Timing Analysis Finds maximum and minimum delays between all clocked flip-flops. Combinational circuit Flip-flops

23. STA example 0000 0000 0000 0000 A1A1 B3B3 E1E1 F1F1 G2G2 H3H3 J1J1 C1C1 D2D2

24. 0000 0000 0000 0000 A1A1 B3B3 E1E1 F1F1 G2G2 H3H3 J1J1 C1C1 D2D2 8 5 2 1 10 7 4 3 1

25. STA example 0000 0000 0000 0000 A1A1 B3B3 E1E1 F1F1 G2G2 H3H3 J1J1 C1C1 D2D2 8 5 2 1 10 7 4 3 1

26. STA example 0000 0000 0000 0000 A1A1 B3B3 E1E1 F1F1 G2G2 H3H3 J1J1 C1C1 D2D2 4,8 2,2 1,1 4,10 4,7 2,4 3,3 1,1 3,5

27. Floorplanning Inputs: – Blocks with well-defined shapes and area – Blocks with approximated area and no particular shape – Netlist specifying block connections Outputs: – Locations for all blocks Objectives – Minimize area – Reduce wirelength – Maximize routability – Determine shapes of flexible blocks Constraints – Shape of each block – Area of each block – Pin locations for each block – Aspect ratio

28. Placement The process of arranging circuit components on a layout surface Inputs: Set of fixed modules, netlist Output: Best position for each module based on various cost functions Cost functions include wirelength, wire routability, performance, I/O pads

29. Placement Good placement – No congestion – Shorter wires – Fewer metal levels – Smaller delay – Lower power dissipation Bad placement –Congestion –Longer wires –More metal levels –Higher delay –Higher power dissipation

30. Power Planning

31. Clock Distribution Standard digital systems rely on the clock signal being present everywhere on the chip at the same time: skew Clock signal has to be connected to all flip- flops: high fan out Specialized tools insert multi level buffers (to drive the load) and balance the timing by ensuring the same wirelength for all connection

32. Clock Distribution

33. CTS example

39. Routing Connect the various standard cells using wires Input: – Cell locations, netlist Output: – Geometric layout of each net connecting various standard cells Two-step process – Global routing – Detailed routing Objective – 100% connectivity of a system – Minimize area – Minimize wirelength Constraints – Number of routing layers – Design rules – Timing (delay)‏ – Crosstalk – Process variations

40. Routing Global vs. Detailed

41. Extraction Once the physical design is complete, everything about the interconnection network is known. It is possible to extract parasitic capacitance for the interconnection – Wire capacitance – Wire to wire capacitance – Wire - via resistance The extracted information can be used to extract timing information. It can be stored in special files (SDF, SPEF) and can be used by circuit simulators.

42. Optimization Parasitics may influence timing severely. It is possible to make local optimizations to combat additional capacitance: – Buffers are added to long connections – Driver strength of the standard cells is adjusted – Incremental change of placement – Critical paths are resynthesized

43. Design Rule Check Every physical layer has limits that are determined by the production flow. These include: – Minimum spacing – Minimum width – Minimum coverage – Minimum area

44. Layout Versus Schematic The physical layout contains only geometric information The devices (transistors) and interconnections are extracted.This is the extracted netlist The extracted netlist is compared to the initial netlist that we started with. Shorts between layers can be detected in this stage. Very important step, this step tells us that the chip is good to go.
