2. Review Atomic Number (Z) – number of protons
Mass Number (A) – sum of protons and neutrons
Copyright © Cengage Learning. All rights reserved

3. 4 Forces in Nature Force Equation notes Gravity F = G m1 m2/r2
Works at an infinite distance. Weakest of all forces.
Electromagnetic
F = K q1 q2/r2
Works for short distances, Holds the atom together.
Strong Nuclear force
E =mc2 (mass defect)
This is the glue that holds the nucleus together.
Weak nuclear force
The force responsible for radioactivity. Pulls the nucleus apart.

4. No nucleus beyond lead is stable indefinitely.
Stable nuclei
When the strong force is greater than the weak force the nucleus is stable.
No nucleus beyond lead is stable indefinitely.
Iron has the most stable nuclei.
Most atoms have examples of stable and unstable nuclei

5. The Zone of Stability
Copyright © Cengage Learning. All rights reserved

6. Unstable nuclei become stable by changing the make up of their nucleus
When the weak force is greater than the strong force the nucleus is unstable.
Unstable nuclei become stable by changing the make up of their nucleus
This process is known as radioactive decay.

7. Radioactive Stability
Nuclides with 84 or more protons are unstable.
Light nuclides are stable when Z equals A – Z (neutron/proton ratio is 1).
For heavier elements the neutron/proton ratio required for stability is greater than 1 and increases with Z.
Copyright © Cengage Learning. All rights reserved

8. Radioactive Stability
Certain combinations of protons and neutrons seem to confer special stability.
Even numbers of protons and neutrons are more often stable than those with odd numbers.
Copyright © Cengage Learning. All rights reserved

9. Radioactive Stability
Certain specific numbers of protons or neutrons produce especially stable nuclides.
2, 8, 20, 28, 50, 82, and 126
Copyright © Cengage Learning. All rights reserved

10. Types of Radioactive Decay
Alpha production (α):
Beta production (β):
Copyright © Cengage Learning. All rights reserved

11. Types of Radioactive Decay
Gamma ray production (γ):
Positron production:
Copyright © Cengage Learning. All rights reserved

12. Types of Radioactive Decay
Electron capture:
Inner-orbital electron
Copyright © Cengage Learning. All rights reserved

13. Decay Series (Series of Alpha and Beta Decays)
Copyright © Cengage Learning. All rights reserved

14. Which of the following produces a particle? electron capture positron
CONCEPT CHECK!
Which of the following produces a particle?
electron capture
positron
alpha particle
beta particle
The correct answer is d. Go through the rest of the equations to identify these types of equations as well.
Copyright © Cengage Learning. All rights reserved

15. Rate of Decay
Rate = kN
The rate of decay is proportional to the number of nuclides. This represents a first-order process.
Copyright © Cengage Learning. All rights reserved

16. Half-Life
Time required for the number of nuclides to reach half the original value.
Copyright © Cengage Learning. All rights reserved

17. Nuclear Particles To play movie you must be in Slide Show Mode
PC Users: Please wait for content to load, then click to play
Mac Users: CLICK HERE
Copyright © Cengage Learning. All rights reserved

18. Half-Life of Nuclear Decay
To play movie you must be in Slide Show Mode
PC Users: Please wait for content to load, then click to play
Mac Users: CLICK HERE
Copyright © Cengage Learning. All rights reserved

19. EXERCISE!
A first order reaction is 35% complete at the end of 55 minutes. What is the value of k?
k = 7.8 × 10-3 min-1
k = 7.8 x 10-3 min-1. If students use [A] = 35 in the integrated rate law (instead of 65), they will get k = 1.9 x 10-2 min-1.
Note: Use the red box animation to assist in explaining how to solve the problem.

20. Nuclear Transformation
The change of one element into another.
Copyright © Cengage Learning. All rights reserved

21. A Schematic Diagram of a Cyclotron

22. A Schematic Diagram of a Linear Accelerator
Copyright © Cengage Learning. All rights reserved

23. Measuring Radioactivity Levels
Geiger counter
Scintillation counter
Copyright © Cengage Learning. All rights reserved

24. Geiger Counter To play movie you must be in Slide Show Mode
PC Users: Please wait for content to load, then click to play
Mac Users: CLICK HERE
Copyright © Cengage Learning. All rights reserved

25. Carbon–14 Dating Used to date wood and cloth artifacts.
Based on carbon–14 to carbon–12 ratio.
Copyright © Cengage Learning. All rights reserved

26. Radiotracers
Radioactive nuclides that are introduced into organisms in food or drugs and whose pathways can be traced by monitoring their radioactivity.
Copyright © Cengage Learning. All rights reserved

27. Radiotracers
Copyright © Cengage Learning. All rights reserved

28. Energy and Mass
When a system gains or loses energy it also gains or loses a quantity of mass.
E = mc2
Δm = mass defect
ΔE = change in energy
If ΔE is negative (exothermic), mass is lost from the system.
Copyright © Cengage Learning. All rights reserved

29. Mass Defect (Δm) Calculating the mass defect for :
Since atomic masses include the masses of the electrons, we must account for the electron mass.
nucleus is “synthesized” from 2 protons and two neutrons.

30. Binding Energy
The energy required to decompose the nucleus into its components.
Iron-56 is the most stable nucleus and has a binding energy of 8.79 MeV.
Copyright © Cengage Learning. All rights reserved

31. Binding Energy per Nucleon vs. Mass Number
Copyright © Cengage Learning. All rights reserved

32. Nuclear Fission and Fusion
Fusion – Combining two light nuclei to form a heavier, more stable nucleus.
Fission – Splitting a heavy nucleus into two nuclei with smaller mass numbers.
Bombardment+ Parent Daughters + neutrons
Copyright © Cengage Learning. All rights reserved

33. Nuclear Fission To play movie you must be in Slide Show Mode
PC Users: Please wait for content to load, then click to play
Mac Users: CLICK HERE
Copyright © Cengage Learning. All rights reserved

34. Criterion for a self sustaining reaction:
The target nuclei must produce at least one neutrons upon splitting.
The must be sufficient mass of target nuclei for the reaction to continue.
The mass defect must be sufficient in order to produce high energy emissions.

35. Fission Processes
A self-sustaining fission process is called a chain reaction.
Copyright © Cengage Learning. All rights reserved

36. Schematic Diagram of a Nuclear Power Plant
Copyright © Cengage Learning. All rights reserved

37. Schematic Diagram of a Reactor Core
Copyright © Cengage Learning. All rights reserved

38. Fuel rods: Contains fissionable material
What does each part do?
Fuel rods: Contains fissionable material
Control Rods: Conic neutron “catchers” made of boron or cadmium
Heat exchanger: Web of pipes containing superheated fluid that boils the water
Reactor vessel: Contains reactor core
Containment fluid: Fluid that surrounds fissionable material also serves to control reaction
Turbine: Spins when steam passes through

39. Condenser: Returns steam to water.
More parts
Generator: Connected to turbine. Converts mechanical Energy to electrical
Condenser: Returns steam to water.
External water source: Provides water for condenser.
Cooling tower: Releases excess heat so water can be returned to ecosystem
Pumps: Move fluid around and create elevated pressure conditions

40. Nuclear Waste
Low Level
High level

41. Nuclear Energy?
Pros
Cons

42. Nuclear Fusion To play movie you must be in Slide Show Mode
PC Users: Please wait for content to load, then click to play
Mac Users: CLICK HERE
Copyright © Cengage Learning. All rights reserved

43. Biological Effects of Radiation
Depend on:
Energy of the radiation
Penetrating ability of the radiation
Ionizing ability of the radiation
Chemical properties of the radiation source
Copyright © Cengage Learning. All rights reserved

44. rem (roentgen equivalent for man)
The energy dose of the radiation and its effectiveness in causing biologic damage must be taken into account.
Number of rems = (number of rads) × RBE
rads = radiation absorbed dose
RBE = relative effectiveness of the radiation in causing biologic damage

45. Effects of Short-Term Exposures to Radiation
Copyright © Cengage Learning. All rights reserved
