1. Understanding Digest and Advanced Digest Authentication in IIS 6.0
Chris Adams
Web Platform Supportability Lead
Microsoft Corporation

2. Agenda Introduction to Authentication Defining Digest Authentication
Digest vs. Advanced Digest
Digging deeply into Digest Auth
Digging deeply into Advanced Digest
Summary

3. Introduction to Authentication
What is authentication?
What is authorization?
Authentication vs. Authorization
401.1 versus 401.3

4. Introduction to Authentication
How authentication works in Microsoft® Internet Information Services (IIS)
Request enters server core
Server core forwards to
anonymous provider. IIS builds
path (w3svc/1/root) and verifies
if anonymous is enabled.
Yes: Provide path and Anonymous
users token to authorization
manager
No: IIS passes the path to each
provider to determine if
path has that provider enabled.
Each provider that is enabled returns to
Server core the appropriate header.
Anonymous
Basic
Kerberos
Server
Core
NTLM
Digest
Passport

5. Introduction to Authentication
How authentication works in IIS
Server
Core
WWW-Authenticate
Digest
Digest Adv. Digest

6. Defining Digest Authentication
Digest Authentication is an industry standard per Requests for Comments (RFC) 2617
For IIS administrators and developers, Digest is available on these platforms:
Microsoft® Windows® 2000 and IIS 5.0
Microsoft® Windows Server™ 2003 and IIS 6.0
Why interest in Digest?
Password is protected, not sent on wire in “clear text”
Digest is optimized for Windows® domains

7. Digest vs. Advanced Digest
Digest, available on Windows 2000 Server and Windows Server 2003, requires the following:
Relies on worker process to run as Local System
Uses the IIS Sub-Authenticator (iissuba.dll)
In Windows Server 2003, UseDigestSSP must be set to “false”
Requires Microsoft® Windows® Active Directory®
User’s password must be stored with Reversible Encryption enabled
Calculates hash on the fly and transmit over the wire

8. Digest vs. Advanced Digest (2)
Not available on Windows 2000
Implemented in core authentication provider in LSASS (not relying on IIS Sub-Authenticator)
Hash is stored as property of user in Windows Server 2003 Active Directory
Is default Digest Authentication on clean installs of Windows Server 2003
Metabase property UseDigestSSP must be set to “true”

9. Digest vs. Advanced Digest (3)
How it clients are authenticated using Digest
Key
200 OK Status
401.1 Login Failed
with a
WWW Authenticate
header
IIS Sends Hash to Domain Controllers
Active Directory
401.2 with WWW-Authenticate: Digest:Realm
User Hash
(Username, Password, Realm)
IIS

10. Digest vs. Advanced Digest (4)
How it clients are authenticated using Digest
Key
200 OK Status
401.1 Login Failed
with a
WWW Authenticate
header
IIS Sends Hash to Domain Controllers
Active Directory
Hash pre-computed and stored in Active Directory
401.2 with WWW-Authenticate: Digest:Realm
User Hash
(Username, Password, Realm)
IIS

11. Digging Deeply Into Digest
Digest Authentication has unique characteristics that provide customers with challenges
Local System: Non-issue on Windows 2000 because it uses iissuba.dll and it runs in Inetinfo
Reversible Encryption: Users password must be stored with less security in Active Directory

12. Digging Deeply Into Digest
How is IIS Sub-Authenticator enabled?
Open a Command-Prompt, type:
rundll32 systemroot\system32\iissuba.dll,RegisterIISSUBA
(Case Sensitive)
Ensure Local System
Default for Windows 2000
Running as Local System is a Bad Security Practice
Windows Server 2003

13. Demonstration One
Enabling Digest Authentication in Windows Server 2003
The goal is to demonstrate how administrators and developers can successfully enable Digest

14. Digging Into Advanced Digest
Advanced Digest is ONLY available in Windows Server 2003 and IIS 6.0
Advanced Digest is implemented in LSASS where all other authentication types are performed
Advanced Digest is compliant with the Digest RFC
There is no UI for Advanced Digest it’s enabled using a command-line
Property = UseDigestSSP

15. Digging Into Advanced Digest (2)
Advanced Digest relies on a pre-computed MD5 hash stored in Active Directory
Stored in the same place as Kerberos hashes
MD5 hash is stored as multiple entries:
- Ex:
Domain\User – Ex: contoso\user
(UPN) –
Ex:
Is this property secure in Active Directory?
Yes, no user including Domain Admins have access to where the hash is stored
Only Local Security Authority (LSA) has access to this hash information
It is stored on the DC and never is sent off the DC

16. Digging Into Advanced Digest (3)
Limitations of Advanced Digest to date
Microsoft® Internet Explorer 6.0 SP1 does not handle advanced digest requests properly
For each request per connection, Internet Explorer prompts the user for credentials
This is being fixed in Windows Server 2003 Service Pack 1
:06: GET /iisstart.htm - 80 WS03EE\Administrator
:06: GET /pagerror.gif - 80 WS03EE\Administrator
Same Connection – Prompt for each Get

17. Demonstration Two
Enabling Advanced Digest Authentication in Windows Server 2003
The goal is to demonstrate how administrators and developers can successfully enable Advanced Digest

18. Session Summary Digest follows the RFC standard 2617
Windows 2000 offers Digest authentication only
Windows Server 2003 offers Digest and Advanced Digest authentication
Clients receive in WWW-Authenticate header “Digest” and Realm for both Digest and Advanced Digest
Digest requires the IIS Sub-Authenticator
Advanced digest stores all information in Active Directory for each user and is implemented in LSASS

19. References and Resources
IIS 6.0 Help:
Digest:
Adv. Digest:
KB Articles:
IIS 6.0 Resource Kit
IIS Forum:
IIS Answers:
IIS Frequently Asked Questions (FAQ):
IIS Resources:
